2005 NISSAN X-TRAIL display

TROUBLE DIAGNOSIS
BRC-45
[ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC

Symptom 4: ABS Does Not WorkEFS004HM
CAUTION:
ABS does not operate when speed is 10 km/h or lower.
1. CHECK ABS WARNING LAMP DISPLAY
Make sure that the warning lamp turns off approximately 1 second after the key switch is turned on or when
driving.
OK or NG
OK >> GO TO 3. Check wheel sensor and sensor rotor in BRC-43, "Symptom 1: ABS Works Frequently"
.
NG >> Perform self-diagnosis. Refer to BRC-28, "
SELF-DIAGNOSIS" .
Symptom 5: Pedal Vibration and ABS Operation NoiseEFS004HN
CAUTION:
Under the following conditions, ABS is activated and vibration is felt when brake pedal is lightly
depressed (just place a foot on it). However, this is normal.

When shifting gears

When driving on slippery road

During cornering at high speed

When passing over bumps or grooves (Approx. 50 mm or more)

When pulling away just after starting engine (Approx. 10 km/h or more)
1. SYMPTOM CHECK 1
Check if pedal vibration or operation sounds occur when the engine is started.
OK or NG
OK >> GO TO 2.
NG >> Perform self-diagnosis. Refer to BRC-28, "
SELF-DIAGNOSIS" .
2. SYMPTOM CHECK 2
Check symptoms when electrical component (headlamps, etc.) Switches are operated.
Do symptoms occur?
YES >> Check if there is a radio, antenna, antenna lead wire, or wiring close to the control unit. If there is,
move it farther away.
NG >> GO TO 3. Check wheel sensor and sensor rotor in BRC-43, "
Symptom 1: ABS Works Frequently"
.

TROUBLE DIAGNOSIS
BRC-77
[ESP/TCS/ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC

Control Unit Input/Output Signal StandardEFS005W2
REFERENCE VALUE FROM CONSULT-II
CAUTION:
The displayed item is the data calculated by the control unit, so it may indicate a normal value even if
an output circuit (harness) is open or shorted.
Data monitor item ContentsData monitor
(Reference) Check items
for malfunction
ConditionReference value in
normal operation
FR RH SENSOR
FR LH SENSOR
RR RH SENSOR
RR LH SENSORWheel speed Vehicle stopped 0 [km/h]
Wheel sensor circuit
During driving (Note 1)Almost in accor-
dance with the
speedometer dis-
play (within ±10%)
ACCEL POS SIGOpen/close condition
of throttle valve (linked
with accelerator pedal)Accelerator pedal not
depressed (ignition switch is
ON)0%Control unit communica-
tion circuit between the
ESP/TCS/ABS control
unit and ECM Accelerator pedal depressed
(ignition switch is ON)0 – 100%
ENG RPMWith the engine run-
ningWith the engine stopped 0rpm
Engine speed signal cir-
cuit
Engine runningAlmost in accor-
dance with
tachometer display
STR ANGLE SIGSteering wheel angle
detected by steering
angle sensorStraight-ahead condition Approx. 0 °
Steering angle sensor
and circuit
Steering – 720 to 720°
YAW RATE SENYaw rate detected by
yaw rate sensorVehicle stopped Approx. 0 d/s
Yaw rate sensor and cir-
cuit
During driving – 70 to 70d/s
SIDE G-SENSORTransverse accelera-
tion detected by side G
sensorVehicle stopped
Approx. 0 m/s
2
Side G sensor and circuit
During driving
– 24.3 to 24.1m/s2
PRESS SENSORBrake fluid pressure
detected by pressure
sensorWith the ignition switch
turned ON and brake pedal
released.Approx. 0 bar
Pressure sensor and cir-
cuit
With the ignition switch
turned ON and brake pedal
depressed.– 40 to 300bar
BATTERY VOLTBattery voltage sup-
plied to the ESP/TCS/
ABS control unitIgnition switch ON 10 – 16VESP/TCS/ABS control
unit power supply circuit
and ground circuit
MOTOR RELAYMotor relay
ON/OFF conditionABS not activated. OFF
Motor relay and circuit
ABS activated. ON
ACTUATOR RLYActuator relay
ON/OFF conditionIgnition ON and Vehicle
stopped.OFF
Actuator relay and circuit
Engine running and Vehicle
stopped.ON
STOP LAMP SWOperating status of
brake pedalDepress brake pedal. ON
Stop lamp switch circuit
Release the brake pedal. OFF
PARK BRAKE SW Parking brake statusParking brake activated ON
Parking brake switch cir-
cuit
Parking brake not activated OFF

TROUBLE DIAGNOSIS
BRC-81
[ESP/TCS/ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC

SELF-DIAGNOSIS
Description

If an malfunction is detected in the system, ABS warning lamp, ESP OFF indicator lamp and SLIP indica-
tor lamp on the combination meter turn on. In this case, perform self-diagnosis as follows:

While CONSULT-II is used, ABS warning lamp, ESP OFF indicator lamp, SLIP indicator lamp may be
turned on in a case of no malfunctioning.
Operation Procedure
1. Turn ignition switch OFF.
2. Connect CONSULT-II and CONSULT-II CONVERTER to data link connector.
CAUTION:
If CONSULT-II is used with no connection of CONSULT-II CONVERTER, malfunctions might be
detected in self-diagnosis depending on control unit which carry out CAN communication.
3. Turn ignition switch ON.
4. Start engine and drive at 30 km/h (19 MPH) or more for approximately 1 minute.
5. After stopping vehicle, with the engine running, touch “START (NISSAN BASED VHCL)”, “ABS”, “SELF-
DIAG RESULTS” in order on the CONSULT-II screen.
CAUTION:
If “START (NISSAN BASED VHCL)” is touched immediately after starting engine or turning on the
ignition switch, “ABS” might not be displayed in the System Selection screen. In this case, repeat
the operation from step 1. If it cannot be shown after several attempts, ESP/TCS/ABS control unit
may have malfunctioned.
6. The self-diagnostic results are displayed. (If necessary, the self-diagnostic results can be printed out by
touching “PRINT”.)

When “NO FAILURE” is displayed, check ABS warning lamp, ESP OFF indicator lamp and SLIP indica-
tor lamp.
7. Perform the appropriate inspection from the display item list, and repair or replace the malfunctioning
component.
8. Drive the vehicle at 30 km/h (19 MPH) or more for approximately 1 minute.
CAUTION:

In a case that a wheel sensor is malfunctioning, ABS warning lamp, ESP OFF indicator lamp,
SLIP indicator lamp will turn on. If vehicle is not driven at approximately 30 km/h (19 MPH) or
more for at least approximately 1 minute after repair of the wheel sensor system, ABS warning
lamp, ESP OFF indicator lamp and SLIP indicator lamp may not turn off even if everything is
normal. Check again to make sure that there is no malfunction on other parts.
9. Turn ignition switch OFF to prepare for erasing the memory.
10. Start engine and touch “START (NISSAN BASED VHCL)”, “ABS”, “SELF-DIAG RESULTS”, “ERASE
MEMORY” in order on the CONSULT-II screen to erase the diagnostic memory.
If “ABS” is not indicated, go to GI-35, "
CONSULT-II Data Link Connector (DLC) Circuit" .
CAUTION:
If the diagnostic memory is not erased, re-perform the operation from step 5.
11. For the final inspection, drive at 30 km/h (19 MPH) or more for approximately 1 minute and confirm that
ABS warning lamp, ESP OFF indicator lamp and SLIP indicator lamp are OFF.

BRC-82
[ESP/TCS/ABS]
TROUBLE DIAGNOSIS

Display Item List
Self-Diagnostic item Malfunction detecting condition Check route
FR LH SENSOR – 1 Circuit of front LH wheel sensor is open.
Wheel sensor and cir-
cuit. Refer to BRC-91
RR RH SENSOR – 1 Circuit of rear RH wheel sensor is open.
FR RH SENSOR – 1 Circuit of front RH wheel sensor is open.
RR LH SENSOR – 1 Circuit of rear LH wheel sensor is open.
FR LH SENSOR – 2 Front LH wheel sensor is shorted or input signal is malfunction.
RR RH SENSOR – 2 Rear RH wheel sensor is shorted or input signal is malfunction.
FR RH SENSOR – 2 Front RH wheel sensor is shorted or input signal is malfunction.
RR LH SENSOR – 2 Rear LH wheel sensor is shorted or input signal is malfunction.
MAIN RELAYDuring the actuator relay operating with OFF, when the actuator
relay turns ON. Or when the control line for the relay is shorted to
the ground.Actuator relay and cir-
cuit. Refer to BRC-103
During the actuator relay operating with ON, when the actuator
relay turns OFF, or when the control line for the relay is open.
STOP LAMP SW Stop lamp switch circuit is open.Stop lamp switch and cir-
cuit. Refer to BRC-105
PRESS SEN CIRCUIT Pressure sensor signal line is open or shorted, or pressure sen-
sor is malfunction.Pressure sensor and cir-
cuit. Refer to BRC-93
ST ANGLE SEN CIRCUIT Neutral position of steering angle sensor is dislocated, or the
steering angle sensor is malfunction.Steering angle sensor
and circuit. Refer to
BRC-95
YAW RATE SENOR Yaw rate sensor is malfunction, or the yaw rate sensor signal line
is open or shorted.Yaw rate/side G sensor
and circuit. Refer to
BRC-97
FR LH IN ABS SOLCircuit of front LH wheel inlet solenoid valve is open or shorted,
or the control line is open or shorted to the power supply or the
ground.
Solenoid valve and cir-
cuit. Refer to BRC-98
FR LH OUT ABS SOLCircuit of front LH wheel outlet solenoid valve is open or shorted,
or the control line is open or shorted to the power supply or the
ground.
RR RH IN ABS SOLCircuit of rear RH wheel inlet solenoid valve is open or shorted,
or the control line is open or shorted to the power supply or the
ground.
RR RH OUT ABS SOLCircuit of rear RH wheel outlet solenoid valve is open or shorted,
or the control line is open or shorted to the power supply or the
ground.
FR RH IN ABS SOLCircuit of front RH wheel inlet solenoid valve is open or shorted,
or the control line is open or shorted to the power supply or the
ground.
FR RH OUT ABS SOLCircuit of front RH wheel outlet solenoid valve is open or shorted,
or the control line is open or shorted to the power supply or the
ground.
RR LH IN ABS SOLCircuit of rear LH wheel inlet solenoid valve is open or shorted, or
the control line is open or shorted to the power supply or the
ground.
RR LH OUT ABS SOLCircuit of rear LH wheel outlet solenoid valve is open or shorted,
or the control line is open or shorted to the power supply or the
ground.

BRC-84
[ESP/TCS/ABS]
TROUBLE DIAGNOSIS

Operation Procedure
1. After turning OFF ignition switch, connect CONSULT-II and CONVERTER to data link connector.
CAUTION:
If CONSULT-II is used with no connection of CONSULT-II CONVERTER, malfunctions might be
detected in self-diagnosis depending on control unit which carry out CAN communication.
2. Turn ignition switch ON.
3. Touch “START (NISSAN BASED VHCL)”, “ABS”, “DATA MONITOR” in order on the CONSULT-II screen.
If “ABS” is not indicated, go to GI-35, "
CONSULT-II Data Link Connector (DLC) Circuit" .
CAUTION:
When “START (NISSAN BASED VHCL)” is touched immediately after starting engine or turning on
ignition switch, “ABS” might not be displayed in the system selection screen. In this case, repeat
the operation from step 1.
4. Return to the Monitor Item Selection screen, and touch “ECU INPUT SIGNALS”, “MAIN SIGNALS” or
“SELECTION FROM MENU”. Refer to the following information.
5. When “START” is touched, the data monitor screen is displayed.
Display Item List
Data Monitor Item (Unit)Data Monitor item selection
Remarks
ECU INPUT
SIGNALSMAIN
SIGNALSSELECTION
FROM MENU
GEAR (A/T MODEL)×××The gear position determined
from A/T PNP switch signal is dis-
played.l
SLCT LVR POSI (A/T MODEL)×××Shift position determined from the
A/T PNP switch signal is dis-
played.
FR RH SENSOR [km/h]×××Wheel speed calculated by front
RH wheel sensor signal is dis-
played.
FR LH SENSOR [km/h]×××Wheel speed calculated by front
LH wheel sensor signal is dis-
played.
RR RH SENSOR [km/h]×××Wheel speed calculated by rear
RH wheel sensor signal is dis-
played.
RR LH SENSOR [km/h]×××Wheel speed calculated by rear
LH wheel sensor signal is dis-
played.
ACCEL POS SIG
(%)×––Throttle valve open/close status
judged by the CAN communica-
tion signal is displayed.
ENGINE RPM
(rpm)×–×Engine speed judged by the CAN
communication signal is dis-
played.
CAN COM START
(ON/OFF)––×Communication status of CAN
communication is displayed.
STR ANGLE SIG
(°)×–×Steering wheel angle detected by
the steering angle sensor is dis-
played.
YAW RATE SEN
(d/s)××–Yaw rate detected by the yaw rate
sensor is displayed.
SIDE G-SENSOR
(m/s
2 )×–×Transverse acceleration detected
by the side G sensor is displayed.
PRESS SENSOR
(bar )×–×Brake fluid pressure detected by
the pressure sensor is displayed.

TROUBLE DIAGNOSIS
BRC-85
[ESP/TCS/ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC

BATTERY VOLT
(V )×××Voltage supplied to ESP/TCS/
ABS control unit is displayed.
MOTOR RELAY
(ON/OFF )–××Motor relay signal (ON/OFF) sta-
tus is displayed.
ACTUATOR RLY
(ON/OFF )–××Actuator relay signal (ON/OFF)
status is displayed.
STOP LAMP SW
(ON/OFF)×××Stop lamp switch (ON/OFF) status
is displayed.
PARK BRAKE SW
(ON/OFF)×–×Parking brake switch (ON/OFF)
status is displayed.
OFF SW
(ON/OFF)×××ESP OFF switch (ON/OFF) sta-
tus is displayed.
ABS WARN LAMP
(ON/OFF)–××ABS warning lamp (ON/OFF) sta-
tus is displayed.
OFF LAMP
(ON/OFF)–××ESP OFF indicator lamp (ON/
OFF) status is displayed.
SLIP LAMP
(ON/OFF)–××SLIP indicator lamp (ON/OFF)
status is displayed.
FR LH IN SOL
(ON/OFF)–××Front LH wheel inlet solenoid
valve (ON/OFF) status is dis-
played.
FR LH OUT SOL
(ON/OFF)–××Front LH wheel outlet solenoid
valve (ON/OFF) status is dis-
played.
RR RH IN SOL
(ON/OFF)–××Rear RH wheel inlet solenoid
valve (ON/OFF) status is dis-
played.
RR RH OUT SOL
(ON/OFF)–××Rear RH wheel outlet solenoid
valve (ON/OFF) status is dis-
played.
FR RH IN SOL
(ON/OFF)–××Front RH wheel inlet solenoid
valve (ON/OFF) status is dis-
played.
FR RH OUT SOL
(ON/OFF)–××Front RH wheel outlet solenoid
valve (ON/OFF) status is dis-
played.
RR LH IN SOL
(ON/OFF)–××Rear LH wheel inlet solenoid
valve (ON/OFF) status is dis-
played.
RR LH OUT SOL
(ON/OFF)–××Rear LH wheel outlet solenoid
valve (ON/OFF) status is dis-
played.
M/R OUTPUT
(ON/OFF)––×Motor relay activation signal (ON/
OFF) status is displayed.
FLUID LEV SW
(ON/OFF)×–×Brake fluid level warning switch
(ON/OFF) status is displayed.
SNOW MODE SW
(ON/OFF)––דOFF” is displayed.
BST OPER SIG
(ON/OFF)––דOFF” is displayed.
M MODE SIG
(ON/OFF)––דOFF” is displayed. Data Monitor Item (Unit)Data Monitor item selection
Remarks
ECU INPUT
SIGNALSMAIN
SIGNALSSELECTION
FROM MENU

BRC-86
[ESP/TCS/ABS]
TROUBLE DIAGNOSIS

×: Applicable
–: Not applicable
ACTIVE TEST
CAUTION:

Do not perform active test while driving.

Make sure to completely bleed air from the brake system.

Active test cannot be performed when EBD, ABS, TCS or ESP operation is malfunction.

ABS and brake warning lamps turn on during the active test.
Operation Procedure
1. Connect CONSULT-II and CONVERTER to data link connector and start engine.
CAUTION:
If CONSULT-II is used with no connection of CONSULT-II CONVERTER, malfunctions might be
detected in self-diagnosis depending on control unit which carry out CAN communication.
2. Touch “START (NISSAN BASED VHCL) ” on the display screen.
3. Touch “ABS”.
If “ABS” is not indicated, go to GI-35, "
CONSULT-II Data Link Connector (DLC) Circuit" .
4. Touch “ACTIVE TEST”.
5. The test item selection screen is displayed.
6. Touch necessary test item.
7. With the “MAIN SIGNALS” display shown in reverse, touch “START”.
8. The “ACTIVE TEST” screen will be displayed, so perform the following test.
NOTE:

When the active test is performed while depressing pedal, the pedal depression amount will change,
but this is normal.

Approximately 10 seconds after the operation is begun, “TEST STOP” will be displayed.

To perform a retest after “TEST STOP” is displayed, touch “BACK” and perform the test from the step 6.
Test Item
Solenoid valve
OD OFF SW
(ON/OFF)––דOFF” is displayed.
EBD SIGNAL
(ON/OFF)––×EBD operation (ON/OFF) status is
displayed.
ABS SIGNAL
(ON/OFF)––×ABS operation (ON/OFF) status is
displayed.
TCS SIGNAL
(ON/OFF)––×TCS operation (ON/OFF) status is
displayed.
VDC SIGNAL
(ON/OFF)––×ESP operation (ON/OFF) status is
displayed. Data Monitor Item (Unit)Data Monitor item selection
Remarks
ECU INPUT
SIGNALSMAIN
SIGNALSSELECTION
FROM MENU
SFIA1172E

TROUBLE DIAGNOSIS
BRC-87
[ESP/TCS/ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC

CAUTION:
The example shown is for front right wheel. The procedure for the other wheels is the same as given
below.

When performing an active test of the ABS function, select the main item for each test item. In addition,
when performing an active test of the ESP/TCS function, select the item menu for each test item.

For ABS solenoid valve, touch “UP”, “KEEP”, “DOWN” on the display screen.
For ABS solenoid valve (ACT), touch “UP”, “ACT UP”, “ACT
KEEP” and confirm that solenoid valves (IN, OUT, USV, HSV)
operate as shown in the table below.
*: ON for 1 to 2 seconds after the touch, and then OFF
ABS Motor
Touch “ON”, “OFF” on the display screen and make sure ABS motor
relay is operating as shown in the table below.
SFIA0591E
OperationABS solenoid valve ABS solenoid valve (ACT)
UP KEEP DOWN UP ACT UP ACT KEEP
FR RH IN SOL OFF ON ON OFF OFF OFF
FR RH OUT SOL OFF OFF ON* OFF OFF OFF
USV [FR - RL] OFF OFF OFF OFF ON ON
HSV [FR - RL] OFF OFF OFF OFF ON* OFF
Operation ON OFF
MOTOR RELAY ON OFF
ACTUATOR RELAY ON ON
SFIA0593E
