2004 NISSAN PATROL Electronic Repair Manual

Wiring Diagram Ð H/LAMP Ð
TEL973M
HEADLAMP/WAGON AND HARDTOP MODELS Ð Xenon Type Ð
EL-4042

TEL974M
HEADLAMP/WAGON AND HARDTOP MODELS Ð Xenon Type Ð
Wiring Diagram Ð H/LAMP Ð (Cont'd)EL-4043

Wiring Diagram Ð H/AIM Ð/Except for the
Middle East
TEL975M
HEADLAMP/WAGON AND HARDTOP MODELS Ð Headlamp Aiming Control Ð
EL-4044

TEL976M
HEADLAMP/WAGON AND HARDTOP MODELS Ð Headlamp Aiming Control Ð
Wiring Diagram Ð H/AIM Ð/Except for the
Middle East (Cont'd)EL-4045

TEL977M
HEADLAMP/WAGON AND HARDTOP MODELS Ð Headlamp Aiming Control Ð
Wiring Diagram Ð H/AIM Ð/Except for the
Middle East (Cont'd)EL-4046

Wiring Diagram Ð DTRL Ð
TEL978M
HEADLAMP/WAGON AND HARDTOP MODELS Ð Daytime Light System Ð
EL-4047

TEL656M
HEADLAMP/WAGON AND HARDTOP MODELS Ð Daytime Light System Ð
Wiring Diagram Ð DTRL Ð (Cont'd)EL-4048

Wiring Diagram Ð TAIL/L Ð/Type A
Rear combination lamps are not located on rear bumper.
TEL979M
PARKING, LICENSE AND TAIL LAMPS/WAGON AND HARDTOP MODELS
EL-4049
