2004 NISSAN PATROL Electronic Repair Manual

TEL905M
WARNING LAMPS/WAGON AND HARDTOP MODELS
Wiring Diagram Ð WARN Ð (Cont'd)EL-4106

TEL906M
WARNING LAMPS/WAGON AND HARDTOP MODELS
Wiring Diagram Ð WARN Ð (Cont'd)EL-4107

TEL025N
WARNING LAMPS/WAGON AND HARDTOP MODELS
Wiring Diagram Ð WARN Ð (Cont'd)EL-4108

TEL908M
WARNING LAMPS/WAGON AND HARDTOP MODELS
Wiring Diagram Ð WARN Ð (Cont'd)EL-4109

TEL909M
WARNING LAMPS/WAGON AND HARDTOP MODELS
Wiring Diagram Ð WARN Ð (Cont'd)EL-4110

LHD MODELS
TEL910M
WARNING LAMPS/WAGON AND HARDTOP MODELS
Wiring Diagram Ð WARN Ð (Cont'd)EL-4111

RHD MODELS
TEL026N
WARNING LAMPS/WAGON AND HARDTOP MODELS
Wiring Diagram Ð WARN Ð (Cont'd)EL-4112

Wiring Diagram Ð CHIME Ð/Except for Europe
and with Theft Warning System Models
TEL027N
WARNING CHIME/WAGON AND HARDTOP MODELS
EL-4113
