2000 TOYOTA CAMRY relay

* The titles given inside the components are the names of the terminals (terminal codes) and are not treated as being
abbreviations.
ABBREVIATIONS D
ABBREVIATIONS
The following abbreviations are used in this manual.
ABS = Anti±Lock Brake System
A/C = Air Conditioning
ACIS = Acoustic Control Induction System
A/T = Automatic Transaxle
COMB. = Combination
ECU = Electronic Control Unit
EGR = Exhaust Gas Recirculation
ESA = Electronic Spark Advance
EVAP = Evaporative Emission
FL = Fusible Link
J/B = Junction Block
LH = Left±Hand
M/T = Manual Transaxle
O/D = Overdrive
R/B = Relay Block
RH = Right±Hand
SFI = Sequential Multiport Fuel Injection
SRS = Supplemental Restraint System
SW = Switch
TEMP. = Temperature
VSV = Vacuum Switching Valve
w/ = With
w/o = Without

E
RELAY
Basically, an electrically operated
switch which may be normally
closed (1) or open (2).
Current flow through a small coil
creates a magnetic field which either
opens or closes an attached switch.
1. NORMALLY
CLOSED
2. NORMALLY
OPEN
SWITCH, MANUAL
Opens and closes
iitth b
SPEAKER
An electromechanical device which
creates sound waves from current
flow.
RELAY, DOUBLE THROW
A relay which passes current
through one set of contacts or the
other.
circuits, thereby
stopping (1) or
allowing (2) current
flow.1. NORMALLY
OPEN
2. NORMALLY
CLOSED
RESISTOR
An electrical component with a fixed
resistance, placed in a circuit to
reduce voltage to a specific value.SWITCH, DOUBLE THROW
A switch which continuously passes
current through one set of contacts
or the other.
RESISTOR, TAPPED
A resistor which supplies two or
more different non adjustable
resistance values.SWITCH, IGNITION
A key operated switch with several
positions which allows various
circuits, particularly the primary
ignition circuit, to become
operational.
RESISTOR, VARIABLE or RHEOSTAT
A controllable resistor with a variable
rate of resistance.
Also called a potentiometer or
rheostat.
SENSOR (Thermistor)
A resistor which varies its resistance
with temperature.SWITCH, WIPER PARK
Automatically returns wipers to the
stop position when the wiper switch
is turned off.
(Reed Switch Type)
SENSOR, SPEED
Uses magnetic impulses to open
and close a switch to create a signal
for activation of other components.TRANSISTOR
A solidstate device typically used as
an electronic relay; stops or passes
current depending on the voltage
applied at ºbaseº.
SHORT PIN
Used to provide an unbroken
connection within a junction block.WIRES
Wires are always drawn as
straight lines on wiring
diagrams.
Crossed wires (1) without a
black dot at the junction are
tj i d
(1) NOT
CONNECTED
SOLENOID
An electromagnetic coil which forms
a magnetic field when current flows,
to move a plunger, etc.
j
not joined;
crossed wires (2) with a
black dot or octagonal ( )
mark at the junction are
spliced (joined)
connections.
(2) SPLICED

F RELAY LOCATIONS
[Engine Compartment]
[Body]

F RELAY LOCATIONS
: Instrument Panel J/BLower Finish Panel (See Page 19)

F RELAY LOCATIONS
: Engine Room J/B No.2Engine Compartment Left (See Page 18)

F RELAY LOCATIONS
1: Engine Room R/B No.1Engine Compartment Left (See Page 18)
(Inside Engine Room J/B No.2)
2: Engine Room R/B No.2Near the Battery (See Page 18)

G ELECTRICAL WIRING ROUTING
Position of Parts in Instrument Panel
A 12 A/C Amplifier
A 13 A/C Evaporator Temp. Sensor
A 14 A/C SW
A 15 ABS and Traction ECU
A 16 ABS and Traction ECU
A 17 ABS and Traction ECU
A 18 ABS ECU
A 19 ABS ECU
A 20 Air Vent Mode Control Servo Motor
A 22 Airbag Squib (Front Passenger Airbag Assembly)
A 23 Airbag Squib (Steering Wheel Pad)
A 24 Ashtray Illumination
A 33 A/C Blower Motor Linear Controller
A 34 A/C Control Assembly
A 35 A/C Control Assembly
A 36 A/C Room Temp. Sensor
A 37 A/C Solar Sensor
A 38 Air Inlet Control Servo Motor
A 39 Air Mix Control Servo Motor
A 40 Automatic Light Control Sensor
B 3 Blower Motor
B 4 Blower Resistor
B 5 Blower SW
B 8 Blower Resistor (Low Speed)
C 4 Cigarette Lighter
C 5 Cigarette Lighter Illumination
C 6 Clock
C 7 Clutch Start SW
C 8 Combination Meter
C 9 Combination Meter
C 10 Combination MeterC 11 Combination SW
C 12 Combination SW
C 13 Combination SW
C 14 Cruise Control Clutch SW
C 15 Cruise Control ECU
C 17 Center Airbag Sensor Assembly
C 18 Center Airbag Sensor Assembly
C 19 Center Airbag Sensor Assembly
D 4 Data Link Connector 2
D 5 Data Link Connector 3
D 6 Daytime Running Light Relay (Main)
D 7 Diode (Courtesy)
D 10 Diode (Dome)
D 11 Diode (Idle±Up)
E 7 Engine Control Module
E 8 Engine Control Module
E 9 Engine Control Module
E 10 Engine Control Module
E 11 Engine Control Module
G 3 Glove Box Light and SW
H 7 Hazard SW
H 8 Heated Oxygen Sensor (Bank 1 Sensor 2)
H 9 Heater Control SW
I 15 Ignition Key Cylinder Light
I 16 Ignition SW
I 17 Integration Relay
I 18 Integration Relay

G ELECTRICAL WIRING ROUTING
Position of Parts in Body
A 25 ABS Speed Sensor Rear LH
A 26 ABS Speed Sensor Rear RH
A 27 Auto Antenna Motor and Relay
B 6 Buckle SW LH
C 16 Condenser
D 12 Door Courtesy SW Front LH
D 13 Door Courtesy SW Front RH
D 14 Door Courtesy SW Rear LH
D 15 Door Courtesy SW Rear RH
D 16 Door Key Lock and Unlock SW Front LH
D 17 Door Key Lock and Unlock SW Front RH
D 18 Door Lock Control SW RH
D 19 Door Lock Motor and Door Unlock Detection SW Front LH
D 20 Door Lock Motor and Door Unlock Detection SW Front RH
D 21 Door Lock Motor and Door Unlock Detection SW Rear LH
D 22 Door Lock Motor and Door Unlock Detection SW Rear RHF 10 Front Door Speaker LH
F 11 Front Door Speaker RH
F 12 Front Tweeter (Speaker) LH
F 13 Front Tweeter (Speaker) RH
F 14 Fuel Pump and Sender
H 10 High Mounted Stop Light
I 19 Interior Light
J 38 Junction Connector
J 39 Junction Connector
J 40 Junction Connector
L 1 License Plate Light LH
L 2 License Plate Light RH
L 3 Light Failure Sensor
L 4 Luggage Compartment Key Unlock SW
L 5 Luggage Compartment Light
L 6 Luggage Compartment Light SW
