1999 TOYOTA CAMRY Engine idle speed

SS0AD±03
SS±6
± SERVICE SPECIFICATIONSENGINE MECHANICAL (5S±FE)
169 Author: Date:
ENGINE MECHANICAL (5S±FE)
SERVICE DATA
Compression
pressureat 250 rpm STD
Minimum
Difference of pressure between each cylinder1,226 kPa (12.5 kgf/cm2, 178 psi) or more
981 kPa (10.0 kgf/cm2, 142 psi)
98 kPa (1.0 kgf/cm2, 14 psi) or less
Valve
clearanceat cold Intake
Exhaust
Adjusting shim (for repair part) Mark 2.500
Mark 2.550
Mark 2.600
Mark 2.650
Mark 2.700
Mark 2.750
Mark 2.800
Mark 2.850
Mark 2.900
Mark 2.950
Mark 3.000
Mark 3.050
Mark 3.100
Mark 3.150
Mark 3.200
Mark 3.250
Mark 3.3000.19 ± 0.29 mm (0.007 ± 0.011 in.)
0.28 ± 0.38 mm (0.011 ± 0.015 in.)
2.500 mm (0.0984 in.)
2.550 mm (0.1004 in.)
2.600 mm (0.1024 in.)
2.650 mm (0.1043 in.)
2.700 mm (0.1063 in.)
2.750 mm (0.1083 in.)
2.800 mm (0.1102 in.)
2.850 mm (0.1122 in.)
2.900 mm (0.1142 in.)
2.950 mm (0.1161 in.)
3.000 mm (0.1181 in.)
3.050 mm (0.1201 in.)
3.100 mm (0.1220 in.)
3.150 mm (0.1240 in.)
3.200 mm (0.1260 in.)
3.250 mm (0.1280 in.)
3.300 mm (0.1299 in.)
Ignition timingw/ Terminals TE1 and E1 connected of DLC18 ± 12° BTDC @ idle
Idle speed±700 ± 50 rpm
Idler pulley
tension springFree length
Installed load at 50.5 mm (1.988 in.)42.0 mm (1.654 in.)
32 ± 37 N (3.25 ± 3.75 kgf, 7.2 ± 8.3 lbf)
Cylinder headWarpage
Cylinder block side Maximum
Manifold sideMaximum
Valve seat
Refacing angle
Contacting angle
Contacting width
0.05 mm (0.0020 in.)
0.08 mm (0.0031 in.)
30°, 45°, 75°
45°
1.0 ± 1.4 mm (0.039 ± 0.055 in.)
Valve guide
bushingInside diameter
Outside diameter (for repair part) STD
O/S 0.056.010 ± 6.030 mm (0.2366 ± 0.2374 in.)
11.048 ± 11.059 mm (0.4331 ± 0.4342 in.)
11.050 ± 11.077 mm (0.4350 ± 0.4361 in.)
ValveValve overall length STD Intake
Exhaust
Minimum Intake
Exhaust
Vale face angle
Stem diameterIntake
Eh t
97.40 ± 97.80 mm (3.8346 ± 3.8504 in.)
98.25 ± 98.65 mm (3.8681 ± 3.8839 in.)
97.1 mm (3.823 in.)
98.0 mm (3.858 in.)
44.5°
5.970 ± 5.985 mm (0.2350 ± 0.2356 in.)
5 965 5 980 (0 2348 0 2354 i )Exhaust
Stem oil clearance STD Intake
Exhaust
Maximum Intake
Exhaust
Margin thickness STD
Minimum5.965 ± 5.980 mm (0.2348 ± 0.2354 in.)
0.025 ± 0.060 mm (0.0010 ± 0.0024 in.)
0.030 ± 0.065 mm (0.0012 ± 0.0026 in.)
0.08 mm (0.0031 in.)
0.10 mm (0.0039 in.)
0.8 ± 1.2 mm (0.031 ± 0.047 in.)
0.5 mm (0.020 in.)
Valve springDeviation Maximum
Free length
Installed tension at 34.7 mm (1.366 in.)2.0 mm (0.079 in.)
40.95 ± 42.80 mm (1.6122 ± 1.6850 in.)
164 ± 189 N (16.7 ± 19.3 kgf, 36.8 ± 42.5 lbf)

SS076±02
± SERVICE SPECIFICATIONSENGINE MECHANICAL (1MZ±FE)
SS±11
174 Author: Date:
ENGINE MECHANICAL (1MZ±FE)
SERVICE DATA
Compression
pressureat 250 rpm STD
Minimum
Difference of pressure between each cylinder1,500 kPa (15.3 kgf/cm2, 218 psi)
1,000 kPa (10.2 kgf/cm2, 145 psi)
100 kPa (1.0 kgf/cm2, 15 psi) or less
Valve
clearanceat cold Intake
Exhaust
Adjusting shim for repair part Mark 2.500
Mark 2.550
Mark 2.600
Mark 2.650
Mark 2.700
Mark 2.750
Mark 2.800
Mark 2.850
Mark 2.900
Mark 2.950
Mark 3.000
Mark 3.050
Mark 3.100
Mark 3.150
Mark 3.200
Mark 3.250
Mark 3.3000.15 ± 0.25 mm (0.006 ± 0.010 in.)
0.25 ± 0.35 mm (0.010 ± 0.014 in.)
2.500 mm (0.0984 in.)
2.550 mm (0.1004 in.)
2.600 mm (0.1024 in.)
2.650 mm (0.1043 in.)
2.700 mm (0.1063 in.)
2.750 mm (0.1083 in.)
2.800 mm (0.1102 in.)
2.850 mm (0.1122 in.)
2.900 mm (0.1142 in.)
2.950 mm (0.1161 in.)
3.000 mm (0.1181 in.)
3.050 mm (0.1201 in.)
3.100 mm (0.1220 in.)
3.150 mm (0.1240 in.)
3.200 mm (0.1260 in.)
3.250 mm (0.1280 in.)
3.300 mm (0.1299 in.)
Ignition timingw/ Terminals TE1 and E1 connected of DLC18 ± 12° BTDC @ idle
Idle speed±700 ± 50 rpm
Timing belt
tensionerProtrusion from housing side10.0 ± 10.8 mm (0.394 ± 0.425 in.)
Cylinder headWarpage Maximum
Valve seat
Refacing angle
Contacting angle
Contacting width
Valve guide bushing bore diameter STD
O/S 0.05
12 pointed head cylinder head bolt diameter
at tension portion STD
Minimum0.10 mm (0.039 in.)
30°, 45°, 75°
45°
1.0 ± 1.4 mm (0.039 ± 0.055 in.)
10.295 ± 10.313 mm (0.4053 ± 0.4080 in.)
10.345 ± 10.363 mm (0.4073 ± 0.4080 in.)
8.95 ± 9.05 mm (0.3524 ± 0.3563 in.)
8.75 mm (0.3445 in.)
Valve guide
bushingInside diameter
Outside diameter for repair part STD
O/S 0.055.510 ± 5.530 mm (0.2169 ± 0.2177 in.)
10.333 ± 10.344 mm (0.4068 ± 0.4072 in.)
10.383 ± 10.394 mm (0.4088 ± 0.4092 in.)
ValveValve overall length STD Intake
Exhaust
Minimum Intake
Exhaust
Valve face angle
Stem diameterIntake
Exhaust
Stem oil clearance STD Intake
Exhaust
Maximum Intake
Exhaust
Margin thickness STD
Maximum95.45 mm (3.5779 in.)
95.40 mm (3.7559 in.)
94.95 mm (3.7382 in.)
94.90 mm (3.7362 in.)
44.5°
5.470 ± 5.485 mm (0.2154 ± 0.2159 in.)
5.465 ± 5.480 mm (0.2152 ± 0.2157 in.)
0.025 ± 0.060 mm (0.0010 ± 0.0024 in.)
0.030 ± 0.065 mm (0.0012 ± 0.0026 in.)
0.08 mm (0.0031 in.)
0.10 mm (0.0039 in.)
1.0 mm (0.039 in.)
0.5 mm (0.020 in.)

SS076±02
± SERVICE SPECIFICATIONSENGINE MECHANICAL (1MZ±FE)
SS±11
174 Author: Date:
ENGINE MECHANICAL (1MZ±FE)
SERVICE DATA
Compression
pressureat 250 rpm STD
Minimum
Difference of pressure between each cylinder1,500 kPa (15.3 kgf/cm2, 218 psi)
1,000 kPa (10.2 kgf/cm2, 145 psi)
100 kPa (1.0 kgf/cm2, 15 psi) or less
Valve
clearanceat cold Intake
Exhaust
Adjusting shim for repair part Mark 2.500
Mark 2.550
Mark 2.600
Mark 2.650
Mark 2.700
Mark 2.750
Mark 2.800
Mark 2.850
Mark 2.900
Mark 2.950
Mark 3.000
Mark 3.050
Mark 3.100
Mark 3.150
Mark 3.200
Mark 3.250
Mark 3.3000.15 ± 0.25 mm (0.006 ± 0.010 in.)
0.25 ± 0.35 mm (0.010 ± 0.014 in.)
2.500 mm (0.0984 in.)
2.550 mm (0.1004 in.)
2.600 mm (0.1024 in.)
2.650 mm (0.1043 in.)
2.700 mm (0.1063 in.)
2.750 mm (0.1083 in.)
2.800 mm (0.1102 in.)
2.850 mm (0.1122 in.)
2.900 mm (0.1142 in.)
2.950 mm (0.1161 in.)
3.000 mm (0.1181 in.)
3.050 mm (0.1201 in.)
3.100 mm (0.1220 in.)
3.150 mm (0.1240 in.)
3.200 mm (0.1260 in.)
3.250 mm (0.1280 in.)
3.300 mm (0.1299 in.)
Ignition timingw/ Terminals TE1 and E1 connected of DLC18 ± 12° BTDC @ idle
Idle speed±700 ± 50 rpm
Timing belt
tensionerProtrusion from housing side10.0 ± 10.8 mm (0.394 ± 0.425 in.)
Cylinder headWarpage Maximum
Valve seat
Refacing angle
Contacting angle
Contacting width
Valve guide bushing bore diameter STD
O/S 0.05
12 pointed head cylinder head bolt diameter
at tension portion STD
Minimum0.10 mm (0.039 in.)
30°, 45°, 75°
45°
1.0 ± 1.4 mm (0.039 ± 0.055 in.)
10.295 ± 10.313 mm (0.4053 ± 0.4080 in.)
10.345 ± 10.363 mm (0.4073 ± 0.4080 in.)
8.95 ± 9.05 mm (0.3524 ± 0.3563 in.)
8.75 mm (0.3445 in.)
Valve guide
bushingInside diameter
Outside diameter for repair part STD
O/S 0.055.510 ± 5.530 mm (0.2169 ± 0.2177 in.)
10.333 ± 10.344 mm (0.4068 ± 0.4072 in.)
10.383 ± 10.394 mm (0.4088 ± 0.4092 in.)
ValveValve overall length STD Intake
Exhaust
Minimum Intake
Exhaust
Valve face angle
Stem diameterIntake
Exhaust
Stem oil clearance STD Intake
Exhaust
Maximum Intake
Exhaust
Margin thickness STD
Maximum95.45 mm (3.5779 in.)
95.40 mm (3.7559 in.)
94.95 mm (3.7382 in.)
94.90 mm (3.7362 in.)
44.5°
5.470 ± 5.485 mm (0.2154 ± 0.2159 in.)
5.465 ± 5.480 mm (0.2152 ± 0.2157 in.)
0.025 ± 0.060 mm (0.0010 ± 0.0024 in.)
0.030 ± 0.065 mm (0.0012 ± 0.0026 in.)
0.08 mm (0.0031 in.)
0.10 mm (0.0039 in.)
1.0 mm (0.039 in.)
0.5 mm (0.020 in.)

SS0AS±01
SS±54
± SERVICE SPECIFICATIONSAUTOMATIC TRANSAXLE (A140E)
217 Author: Date:
AUTOMATIC TRANSAXLE (A140E)
SERVICE DATA
Line pressure (Wheel locked)
Engine idling
D position
R position
at stall (Throttle valve fully opened)
D position
R position
363 ± 422 kPa (3.7 ± 4.3 kgf/cm2, 53 ± 61 psi)
618 ± 794 kPa (6.3 ± 8.1 kgf/cm2, 90 ± 115 psi)
735 ± 862 kPa (7.5 ± 8.8 kgf/cm
2, 107 ± 125 psi)
1,373 ± 1,608 kPa (14.0 ± 16.4 kgf/cm2, 199 ± 233 psi)
Engine stall revolution D and R positions2,450 ± 150 rpm
Time lag N " D position
N " R positionLess than 1.2 seconds
Less than 1.5 seconds
Engine idle speed A/C OFF and N range750 ± 50 rpm
Throttle cable adjustment
(Throttle valve fully opened)Between boot end face and inner cable stopper
0 ± 1 mm (0 ± 0.04 in.)
Drive plate runoutMax.
Torque converter runout Max.
Torque converter installation distance0.20 mm (0.0079 in.)
0.30 mm (0.0118 in.)
More than 13.0 mm (0.512 in.)
Differential oil seal drive in depth LH side
RH side2.7 ± 0.5 mm (0.106 ± 0.020 in.)
0 ± 0.5 mm (0 ± 0.020 in.)
Shift point
D position
(Throttle valve fully opened) 1 " 2
2 " 3
3 " O/D
O/D " 3
3 " 2
2 " 1
(Throttle valve fully closed) O/D " 3
3 " O/D
2 position
(Throttle valve fully opened) 1 " 2
3 " 2
2 " 1
L position
(Throttle valve fully opened) 2 "1
*1: The maximum vehicle speed for manual shift down when shifting down
from D to 2.
*2: The maximum vehicle speed for manual shift down when shifting down
from 2 to L.
58 ± 63 km/h (36 ± 39 mph)
109 ± 117 km/h (68 ± 73 mph)
145 ± 151 km/h (90 ± 94 mph)
138 ± 146 km/h (86 ± 91 mph)
100 ± 108 km/h (62 ± 67 mph)
51 ± 56 km/h (32 ± 35 mph)
38 ± 43 km/h (24 ± 27 mph)
18 ± 22 km/h (11 ± 14 mph)
58 ± 63 km/h (36 ± 39 mph)
106 ± 114 km/h (66 ± 71 mph)
51 ± 56 km/h (32 ± 35 mph)
47 ± 51 km/h (29 ± 32 mph)
Lock±up point (Throttle valve fully opened)
D position
3rd Gear (O/D main switch OFF)
Lock±up ON
Lock±up OFF
O/D gear
Lock±up ON
Lock±up OFF
67 ± 72 km/h (42 ± 45 mph)
64 ± 69 km/h (40 ± 43 mph)
67 ± 72 km/h (42 ± 45 mph)
64 ± 69 km/h (40 ± 43 mph)

SS0BL±01
SS±56
± SERVICE SPECIFICATIONSAUTOMATIC TRANSAXLE (A541E)
219 Author: Date:
AUTOMATIC TRANSAXLE (A541E)
SERVICE DATA
Line pressure (wheel locked)Engine idling
D position
R position
at stall (Throttle valve fully opened)
D position
R position
401 ± 461 kPa (4.1 ± 4.7 kgf/cm2, 58 ± 66 psi)
804 ± 882 kPa (8.2 ± 9.0 kgf/cm2, 117 ± 128 psi)
1,138 ± 1,236 kPa (11.6 ± 12.6 kgf/cm
2, 165 ± 179 psi)
1,716 ± 1,854 kPa (17.5 ± 18.9 kgf/cm2, 249 ± 269 psi)
Engine stall revolution2,600 ± 150 rpm
Time lag N " D position
N " R positionLess than 1.2 seconds
Less than 1.5 seconds
Engine idle speed (A/C OFF)
N position
700 ± 50 rpm
Throttle cable adjustment (Throttle valve fully opened)Between boot and face and inner cable stopper
0 ± 1 mm (0 ± 0.04 in.)
Drive plate runoutMax.
Torque converter clutch runout Max.
Torque converter clutch installation distance0.3 mm (0.0118 in.)
0.20 mm (0.0079 in.)
More than 13.7 mm (0.539 in.)
Lock±up point (Throttle valve opening 5%)
3rd gear (O/D main switch OFF) Lock±up ON
Lock±up OFF
O/D gear Lock±up ON
Lock±up OFF
60 ± 65 km/h (37 ± 40 mph)
53 ± 58 km/h (33 ± 36 mph)
60 ± 64 km/h (37 ± 40 mph)
53 ± 58 km/h (33 ± 36 mph)
Shift schedule
D position
(Throttle valve fully opened) 1 "2
2 "3
3 "O/D
O/D "3
3 "2
2 "1
(Throttle valve fully closed) 3 "O/D
O/D "3
2 position
(Throttle valve fully opened) 1 "2
3 "2
2 "1
L position
(Throttle valve fully opened) 3 "2
2 "1
60 ± 66 km/h (37 ± 41 mph)
112 ± 121 km/h (70 ± 75 mph)
174 ± 183 km/h (108 ± 114 mph)
167 ± 176 km/h (104 ± 109 mph)
104 ± 112 km/h (65 ± 70 mph)
50 ± 55 km/h (31 ± 34 mph)
35 ± 40 km/h (22 ± 25 mph)
20 ± 25 km/h (12 ± 16 mph)
60 ± 66 km/h (37 ± 41 mph)
122 ± 130 km/h (76 ± 81 mph)
50 ± 55 km/h (31 ± 34 mph)
106 ± 115 km/h (66 ± 71 mph)
54 ± 59 km/h (34 ± 37 mph)

SS06L±03
SS±64
± SERVICE SPECIFICATIONSSTEERING
227 Author: Date:
STEERING
SERVICE DATA
ON±VEHICLE INSPECTION
Steering wheel freeplayMaximum30 mm (1.18 in.)
5S±FE Engine :
Drive belt tension New belt95 ± 145 lbf
Drive belt tension Used belt60 ± 100 lbf
1MZ±FE Engine :
Drive belt tension New belt150 ± 185 lbf
Drive belt tension Used belt95 ± 135 lbf
Fluid level rise Maximum5 mm (0.20 in.)
Fluid pressure at idle speed with valve closed Minimum7,845 kPa (80 kgf/cm2, 1,138 psi)
Steering effort at idle speedMaximum5.9 N´m (60 kgf´cm, 52 in.´lbf)
PS VANE PUMP
5S±FE and 1MZ±FE Engines:
Vane pump rotating torqueMaximum0.3 N´m (2.8 kgf´cm, 2.4 in.´lbf)
Oil clearance between pump shaft and bushing STD0.03 ± 0.05 mm (0.0012 ± 0.0020 in.)
Oil clearance between pump shaft and bushingMaximum0.07 mm (0.0028 in.)
Vane plate heightMinimum8.6 mm (0.339 in.)
Vane plate thickness Minimum1.397 mm (0.0550 in.)
Vane plate lengthMinimum14.991 mm (0.5902 in.)
Clearance between the rotor groove and plateMaximum0.035 mm (0.0014 in.)
Vane plate length Pump rotor and cam ring mark
NONE14.999 ± 15.001 mm (0.59051 ± 0.59059 in.)
114.997 ± 14.999 mm (0.59043 ± 0.59051 in.)
214.995 ± 14.997 mm (0.59035 ± 0.59043 in.)
314.993 ± 14.995 mm (0.59027 ± 0.59035 in.)
414.991 ± 14.993 mm (0.59020 ± 0.59027 in.)
Spring free lengthMinimum32.3 mm (1.272 in.)
PS GEAR
Steering rack runout Maximum0.30 mm (0.0118 in.)
Total preload (Control valve rotating torque)0.8 ± 1.4 N´m (8 ± 14 kgf´cm, 6.9 ± 12.2 in.´lbf)

S05331
B01279
Plug
Disconnect
B01280
2.5 mm Hexagon Wrench
SF±30
± SFI (5S±FE)THROTTLE BODY
1463 Author: Date:
(b) Connect a TOYOTA hand±held tester or OBDII scan tool.
(1) Remove the fuse cover on the instrument panel.
(2) Connect a TOYOTA hand±held tester or OBDII
scan tool to the DLC3.
(3) Please refer to the TOYOTA hand±held tester or
OBDII scan tool operator's manual for further de-
tails.
(c) Check the idle speed.
Idle speed: 700 ± 50 rpm
(d) Check and adjust the throttle opener setting speed.
(1) Disconnect the vacuum hose from the throttle open-
er, and plug the hose end.
(2) Maintain the engine speed at 2,500 rpm.
(3) Release the throttle valve.
(4) Check that the throttle opener is set.
Throttle opener setting speed:
1,300 ± 1,500 rpm (w/ Cooling fan OFF)
(5) Using a 2.5 mm hexagon wrench, loosen the lock
nut and adjust the throttle opener setting speed by
turning the throttle opener adjusting screw. Tighten
the lock nut.
(6) Reconnect the vacuum hose to the throttle opener.
(e) Disconnect the TOYOTA hand±held tester or OBDII scan
tool.

SF0DS±03
A07370
SST
E1
TE1
B01281
Ohmmeter
ISCC+B
ISCO
± SFI (5S±FE)IDLE AIR CONTROL (IAC) VALVE
SF±35
1468 Author: Date:
IDLE AIR CONTROL (IAC) VALVE
ON±VEHICLE INSPECTION
1. INSPECT IAC VALVE OPERATION
(a) Initial conditions:

Engine at normal operating temperature

Idle speed set correctly

Transmission in neutral position
(b) Using SST, connect terminals TE1 and E1 of the DLC1.
SST 09843±18020
(c) After the engine speed is kept at 900 ± 1,300 rpm for 5 se-
conds, check that it returns to idle speed.
If the engine speed operation is not as specified, check the IAC
valve, wiring and ECM.
(d) Remove the SST from the DLC1.
SST 09843±18020
2. INSPECT IAC VALVE RESISTANCE
NOTICE:
ºColdº and ºHotº in these sentences express the tempera-
ture of the coils themselves. ºColdº is from ±10°C (14°F) to
50°C (122°F) and ºHotº is from 50°C (122°F) to 100°C
(212°F).
(a) Disconnect the IAC valve connector.
(b) Using an ohmmeter, measure the resistance between ter-
minal +B and other terminals (ISCC, ISCO).
Resistance:
Cold17.0 ± 24.5 W
Hot21.5 ± 28.5 W
If the resistance is not as specified, replace the IAC valve.
(c) Reconnect the IAC valve connector.
