168
[SS20820(ALL)05/96]
13-1/2 pica
art:0040402-A[SS20825(ALL)03/96]5.
Let the retractor wind up the slack from the lap/shoulder
belt. A clicking sound should be heard as the belt retracts,
indicating that the retractor is in automatic locking mode.
Tighten the tether strap to remove any slack.
[SS20835(ALL)05/96]6.
Before placing a child in the child restraint, use force to tilt
the child restraint from side to side and tug it forward to
make sure it is securely held in place.
[SS20837(ALL)05/96]7.
Check that the retractor is in automatic locking mode by
trying to pull more belt out of the retractor. If you cannot
pull any more belt webbing out of the retractor, the belt is in
automatic locking mode.
[SS20838(ALL)03/96]8.
Check to make sure the child restraint is properly secured
prior to each use. If the belt is not locked, repeat steps 4
through 7.
File:06vxssn.ex
Update:Thu Jun 6 10:54:22 1996

Seating and Safety Restraints
169
[SS20840(ALL)01/96]
17-1/2 pica
art:0040296-A%*
[SS20845(ALL)01/96]
Safety Belts for Children
[SS20850(ALL)01/96]
Children who are too large for child safety seats should always
wear safety belts. (See instructions with your child seat, or
contact its manufacturer, to determine maximum size of a child
that will fit safely in the safety seat.)
*
[SS20855(ALL)01/96]
RWARNING
If safety belts are not properly worn and adjusted as
described, the risk of serious injury to the child in a
collision will be much greater.
File:06vxssn.ex
Update:Thu Jun 6 10:54:22 1996

170
[SS20860(ALL)01/96]
RWARNING
If the shoulder belt portion of one of the lap/shoulder
belts can be positioned so that it does not cross or rest in
front of the child's face or neck, the child should wear
the lap/shoulder belt. Moving the child closer to the
center of the vehicle may help provide a good shoulder
belt fit.
*
[SS20865(ALL)01/96]
To improve the fit of lap and shoulder belts on children who
have outgrown child safety seats, Ford recommends use of a
belt-positioning booster seat that is labelled as conforming to all
Federal motor vehicle safety standards. Belt-positioning booster
seats raise the child and provide a shorter, firmer seating
cushion that encourages safer seating posture and better fit of
lap and shoulder belts on the child. A belt-positioning booster
should be used if the shoulder belt rests in front of the child's
face or neck, or if the lap belt does not fit snugly on both
thighs, or if the thighs are too short to let the child sit all the
way back on the seat cushion when the lower legs hang over
the edge of the seat cushion. You may wish to discuss the
specific needs of your child with your pediatrician.
*
[SS20870(ALL)01/96]
RWARNING
Do not use a belt-positioning booster with a lap-only
belt.
[SS20875(ALL)01/96]
RWARNING
The lap belt portion of combination lap/shoulder belts
should always be worn snugly and below the hips,
touching the child's thighs.
File:06vxssn.ex
Update:Thu Jun 6 10:54:22 1996

Seating and Safety Restraints
171
[SS20895(ALL)01/96]
Built-In Child Seats (If equipped)
[SS20900(ALL)01/96]
The optional second row bench seat includes two built-in child
seats. These child restraints are to be used only by children
who:
[SS20940(ALL)01/96]
n
are at least one year old
[SS20960(ALL)01/96]
AND
[SS20980(ALL)05/96]
n
weigh between 10 and 27 kilograms (22 and 60 pounds)
[SS21000(ALL)01/96]
AND
[SS21025(ALL)01/96]
n
whose shoulders are below the shoulder harness slots
[SS21030(ALL)01/96]
10-1/2 pica
art:0040318-A[SS21050(ALL)01/96]
Children not meeting these requirements should be restrained in
an approved aftermarket child safety seat. Follow the specific
manufacturer's instructions for weight and height restrictions.
[SS21075(ALL)01/96]
Children must be properly buckled before riding in the vehicle.
It is the law in every state and province. These child seats
conform to all Federal/Canadian motor vehicle safety standards.
File:06vxssn.ex
Update:Thu Jun 6 10:54:22 1996

172
[SS21090(ALL)01/96]
RWARNING
The second row seatback must be fully locked before
operating the child restraint system. Check the position
of the seatback release lever.
[SS21200(ALL)01/96]
17-1/2 pica
art:0040321-A
Second row bench built-in child seats
File:06vxssn.ex
Update:Thu Jun 6 10:54:22 1996

Seating and Safety Restraints
173
[SS21225(ALL)01/96]
Built-In Child Seat Retractors
[SS21250(ALL)01/96]
The retractor will switch from the emergency locking mode to
the automatic locking mode when the right shoulder belt is
pulled all the way out. The retractor will switch back to
emergency locking mode when the belts are unbuckled and the
shoulder belts retract completely.
[SS21275(ALL)01/96]
The automatic locking mode must be used to hold small
children in position, particularly sleeping children and those
who may try to squirm out of the belts. The emergency locking
mode is used while buckling the belts.
*
[SS21300(ALL)01/96]
Always adjust the lap and shoulder harness belts provided with
this child seat snugly around your child.
*
[SS21375(ALL)01/96]
RWARNING
Failure to follow all of the instructions on the use of this
child restraint system can result in your child striking the
vehicle's interior during a sudden stop or crash.
[SS21400(ALL)01/96]
How to Use the Built-In Child Seat
[SS21425(ALL)04/96]
Read the following procedures and all of the labels on the
built-in child seat before using the seat.
*
[SS21450(ALL)01/96]
RWARNING
Never use the Built-In Child Seat as a booster cushion
with the adult safety belts. A child using the adult belts
could slide forward and out from under the safety belts.
File:06vxssn.ex
Update:Thu Jun 6 10:54:22 1996

174
[SS21475(ALL)01/96]1.
Hold the tab from the lower outboard side of the child seat
and lower the cushion completely.
[SS21500(ALL)01/96]
13-1/2 pica
art:0040322-AFile:06vxssn.ex
Update:Thu Jun 6 10:54:22 1996

Seating and Safety Restraints
175
[SS21525(ALL)01/96]2.
If connected, unbuckle the two safety belt tongues. Also
detach the chest clip.
[SS21530(ALL)01/96]
17-1/2 pica
art:0040320-AFile:06vxssn.ex
