1997 Mercury Villager Owner's Manuals

Controls and Features
103
%*
[CF31200(ALL)01/96]
Liftgate
[CF31300(ALL)01/96]
Opening the Liftgate
[CF31400(ALL)01/96]
To unlock the liftgate with the key, insert the key into the lock
and turn it counterclockwise. To make the gate swing up to the
fully opened position, pull back and upward on the handle. The
liftgate will not unlock if the optional liftgate window is open.
[CF31500(ALL)01/96]
17-1/2 pica art:0040121-F
Opening the liftgate
[CF31600(ALL)01/96]
You can also unlock the liftgate using the optional power door
lock system, or the optional keyless entry system. However, it
cannot be opened until you release the latch by reaching under
the license plate light shield and lifting up on the handle.
File:05vxcfn.ex
Update:Thu May 30 09:49:09 1996

104
[CF31700(ALL)01/96]
Opening the Liftgate Window (If equipped)
[CF31800(ALL)01/96]
To open the liftgate window only, turn the key clockwise. The
window unlatches and the rear wiper falls out of the way. Do
not force the wiper down by hand Ð it moves when the key is
turned. To close, push downward until it latches.
[CF31900(ALL)01/96]
13-1/2 pica
art:0040098-A
The liftgate window in the open position
File:05vxcfn.ex
Update:Thu May 30 09:49:09 1996

Controls and Features
105
*
[CF32000(ALL)01/96]
RWARNING
Make sure that the liftgate door and/or window are
closed to prevent exhaust fumes from being drawn into
the vehicle. This will also prevent passengers and cargo
from falling out. If you must drive with the liftgate door
or window open, keep the vents open so outside air
comes into the vehicle.
[CF32100(ALL)01/96]
Closing the Liftgate
[CF32200(ALL)01/96]
To close the liftgate, reach up and pull the handle on the inner
trim panel downward.
[CF32300(ALL)01/96]
When you have pulled down the liftgate enough so that you
can reach the license plate light shield, push the shield down
and forward to close the liftgate. At this point, the liftgate is not
locked.
[CF32400(ALL)01/96]
The liftgate has an intermediate and a fully closed position.
Make sure the liftgate is fully closed before you drive your
vehicle.
File:05vxcfn.ex
Update:Thu May 30 09:49:09 1996

106
[CF32500(ALL)01/96]
24 pica art:0040099-D
Locking the liftgate using the lock lever
[CF32600(ALL)01/96]
You can lock the liftgate by pushing in the lock lever before
you begin to close the liftgate. You can also lock the liftgate by
closing the liftgate, inserting your key and turning it clockwise
until you hear the lock lever engage. If you turn it too far, the
optional liftgate window will open. The liftgate can also be
locked with the optional power door locks.
[CF32700(ALL)01/96]
The liftgate area is intended only for cargo, not passengers. It
cannot be opened from inside the vehicle.
File:05vxcfn.ex
Update:Thu May 30 09:49:09 1996

Controls and Features
107
[CF32800(ALL)01/96]
After the lock lever is depressed, the liftgate must be unlocked
with the power door lock button or the key.
[CF32900(ALL)01/96]
NOTE: The lock lever will be on the right side of the lock
cylinder if your vehicle is equipped with the standard
liftgate glass. The lock lever will be on the left side
of the lock cylinder if your vehicle is equipped with
the optional flip-up liftgate window.
%*
[CF33000(ALL)04/96]
Windows
%*
[CF33100(ALL)01/96]
Power Windows (If equipped)
[CF33200(ALL)01/96]
Each of the front doors has a power control that opens and
closes the window on that door. The driver's door has master
controls that operate both front door windows. You must place
the ignition in the ON position to use your power window
controls. The driver's power window controls include a lockout
button which prevents the operation of the passenger side
window from either the passenger or driver side controls.
[CF33300(ALL)01/96]
To open the window, press down on the switch; to close the
window, lift up on the switch.
*
[CF33400(ALL)01/96]
RWARNING
Do not let children play with the power windows.
File:05vxcfn.ex
Update:Thu May 30 09:49:09 1996

108
[CF33500(ALL)05/96]
13-1/2 pica art:0040101-F
Driver's side power window controls
[CF33600(ALL)01/96]
One-Touch-Down Power Window (Included with
optional power windows Ð driver side only)
[CF33700(ALL)01/96]
The one-touch-down power window feature allows you to
completely open the driver's window without holding down the
window switch. To open the window completely, press the
switch down for about one second, then release it. If the switch
is momentarily lifted while the window is going down, the
window will stop at that position.
[CF33800(ALL)01/96]
To close the window you must lift and hold the switch until the
window closes.
*
[CF33900(ALL)01/96]
Manual Flip-Open Quarter Windows
[CF34000(ALL)03/96]
To open the flip-open quarter windows in the second or third
row, pull the rear portion of the latch toward you. Swing the
latch forward and out, then lock it into the open position by
pushing rearward until you hear a click. To close the windows,
reverse the procedure.
File:05vxcfn.ex
Update:Thu May 30 09:49:09 1996

Controls and Features
109
[CF34100(ALL)01/96]
13-1/2 pica
art:0040102-A
Manual flip-open quarter window latch location
[CF34200(ALL)01/96]
NOTE: Optional third-row power windows must be opened
with the overhead console controls.
*
[CF34300(ALL)01/96]
Power Quarter Windows (If equipped)
[CF34400(ALL)01/96]
The power quarter windows operate with the ignition in the
ON position. The power-operated quarter windows in the third
seat position are controlled by the RIGHT VENT and LEFT
VENT switches on the overhead console. Press the indented side
of the switch to open the windows; press the raised side of the
switch to close the windows.
File:05vxcfn.ex
Update:Thu May 30 09:49:09 1996

110
[CF34500(ALL)01/96]
10-1/2 pica
art:0040123-B
Power quarter window switch
%*
[CF34600(ALL)03/96]
Mirrors
*
[CF34700(ALL)01/96]
RWARNING
Make sure you can see clearly through the rearview
mirror at all times. Do not block your vision. If you
cannot see through the mirror, it could result in a
collision, injuring yourself and others.
%*
[CF34800(ALL)01/96]
Side View Mirrors
*
[CF34900(ALL)01/96]
Close your door and adjust the driver's seat to the most
comfortable position before you adjust the side view mirrors.
[CF35000(ALL)05/96]
If you have manually adjusting side view mirrors, you can
adjust them in any direction by moving the mirror. The mirror
heads can be folded rearward to prevent damage when using an
automatic car wash.
*
[CF35100(ALL)01/96]
NOTE: Be careful. The convex side view mirror on the right
makes objects appear smaller and farther away than
they actually are. Use the inside rearview mirror (or
look behind you) to determine the actual size and
distance of objects that appear in the convex mirror.
File:05vxcfn.ex
