1997 FORD PROBE Owners Manual

118 [SS18800(ALL)01/96]4. Grasp the shoulder portion of the belt and
pull downward until all of the belt is
extracted and a click is heard. At this time,
the retractor is in the automatic locking
mode (child seat restraint mode).
[SS18900(ALL)01/96]
half page art:0032363-A
Setting the retractor to automatic locking mode
File:06prssp.ex
Update:Mon Jun 3 10:07:19 1996

119 [SS19000(ALL)01/96]
5. Allow the belt to retract. Pull up on the
shoulder webbing. A clicking sound will be
heard as the belt retracts. This indicates that
the retractor is in the automatic locking
mode. Push down on the child seat while
you pull up on the belt webbbing to remove
any slack in the belt.
[SS19100(ALL)01/96]
half page art:0032388-A
Removing slack from belt
File:06prssp.ex
Update:Mon Jun 3 10:07:19 1996

120 [SS19200(ALL)01/96]6. Before placing the child in the child seat or
infant carrier, forcibly tilt the seat from side
to side, and tug it forward to make sure that
the seat is securely held in place.
[SS19300(ALL)01/96]
half page art:0032364-A
Checking that the seat is secure
File:06prssp.ex
Update:Mon Jun 3 10:07:19 1996

121 [SS19400(ALL)01/96]
7. Double check that the retractor is in the
automatic locking mode. Try to pull more
belt out of the retractor. If you cannot, the
belt is in the automatic locking mode.
[SS19500(ALL)01/96]
half page art:0032387-B
Checking the retractor
[SS19600(ALL)01/96]
8. Check to make sure that the child seat or
infant carrier is properly secured prior to
each use. If the belt is not locked, repeat
steps 4 through 7.
[SS19700(ALL)01/96]
NOTE: To remove the retractor from automatic
lock mode, allow seat belt retract fully
to its stowed position and the retractor
will automatically switch back to the
vehicle sensitive locking mode for
normal adult usage.
File:06prssp.ex
Update:Mon Jun 3 10:07:19 1996

122
*
[SS19800(ALL)03/96]
RWARNING
Carefully follow all of the manufacturer's
instructions included with the safety seat
you put in your vehicle. If you do not
install and use the safety seat properly,
the child may be injured in a sudden stop
or collision.
%*
[SS20200(ALL)04/96]
Attaching Safety Seats With Tether Straps
*
[SS20300(ALL)04/96]
Some manufacturers make safety seats that
include a tether strap that goes over the back of
the vehicle seat and attaches to an anchoring
point. Other manufacturers offer the tether strap
as an accessory. Contact the manufacturer of
your child safety seat for information about
ordering a tether strap.
*
[SS20410(ALL)01/96]
Front Seats
*
[SS20420(ALL)01/96]
To install a tether from a child safety seat in the
front seat:
[SS20430(ALL)04/96]
1. Buckle the lap/shoulder belt (in the seat
directly behind the front passenger seat in
which the child safety seat will be installed).
*
[SS20440(ALL)01/96]
2. Pull all the stored belt out of the rear seat
retractor to switch the retractor to automatic
locking mode.
*
[SS20450(ALL)03/96]
3. Let the retractor wind up the slack from the
lap/shoulder belt. A clicking sound should
be heard as the belt retracts, indicating that
the retractor is in automatic locking mode.
*
[SS20460(ALL)01/96]
4. Install the child safety seat in the front seat.
Refer to the previous section onInstalling
Safety Seats. Hook the tether strap hook
around the webbing near the center of the
shoulder portion of the locked lap/shoulder
belt.
*
[SS20470(ALL)05/96]
5. Tighten the tether strap.
File:06prssp.ex
Update:Mon Jun 3 10:07:19 1996

123
*
[SS20500(ALL)08/95]
Rear Seats
[SS20600(ALL)01/96]
If you use a tethered safety seat on one of the
rear seats, install a tether anchor bracket to one
of the two 0.3 inch (8 mm) weld nuts on the
rear of the cargo area below the opening for the
liftgate.
*
[SS20700(ALL)01/96]
Tether Anchorage Hardware
[SS20800(ALL)01/96]
Tether anchor hardware kits can be obtained at
no charge from any Ford or Lincoln-Mercury
dealer.
*
[SS20900(ALL)01/96]
Be sure to follow the child safety seat
manufacturer's instructions.
*
[SS21000(ALL)01/96]
RWARNING
Tighten the anchor according to
specifications. Otherwise, the safety seat
may not be properly secured and the child
may be injured in a sudden stop or
collision.
[SS21100(ALL)01/96]
Installing the Anchor Bracket
[SS21200(ALL)01/96]
1. Open the liftgate and take out the luggage
compartment cover (if equipped).
[SS21300(ALL)01/96]
2. The anchorage nuts used to secure the tether
anchor are located in the rear body panel
behind the trim at the rear of the luggage
compartment. Remove the trim panel. The
backside of the panel is scored at the
locations of the anchorage nuts. Make a hole
the size of the scoring in the trim panel to
provide access to the anchor nut. The hole
should be made on the same side of the
vehicle as the child safety seat will be
located. Reinstall the trim panel.
File:06prssp.ex
Update:Mon Jun 3 10:07:19 1996

124 [SS21400(ALL)01/96]3. Install the hardware for anchoring the tether
following the instructions in the tether
anchorage hardware kit.
[SS21500(ALL)01/96]
4. Re-install luggage compartment cover.
[SS21600(ALL)01/96]
half page art:0030027-C
Installing the anchor bracket
File:06prssp.ex
Update:Mon Jun 3 10:07:19 1996

125
Starting
%*
[TO04100(ALL)01/96]
Fuel-Injected Engines
*
[TO04200(ALL)01/96]
When starting a fuel-injected engine,the most
important thing to remember is to avoid
pressing down on the accelerator before or
during starting. Only use the accelerator when
you have problems getting your vehicle started.
SeeStarting Your Enginein this chapter for
details about when to use the accelerator while
you start your vehicle.
*
[TO04500(ALL)01/96]
Starting Your Vehicle
%*
[TO05000(ALL)01/96]
Preparing to Start Your Vehicle
*
[TO05100(ALL)02/96]
RWARNING
Do not start your vehicle in a closed
garage or in other enclosed areas. Exhaust
fumes can be toxic. Always open the
garage door before you start the engine.
*
[TO05200(ALL)01/96]
Before you start your vehicle, do the following:
*
[TO05300(ALL)01/96]
1. Make sure all occupants in the vehicle
buckle their safety belts. SeeSafety Restraints
in the Index for more details.
*
[TO05400(ALL)01/96]
2. Make sure the headlamps and other
accessories are turned off when starting.
File:08prtop.ex
Update:Wed May 15 15:01:01 1996
