1997 FORD PROBE Owners Manual

46
%*
[AS37000(ALL)08/95]
Important Warranty and Service
Information
*
[AS37050(ALL)07/90]
q
Warranty
*
[AS37100(ALL)08/95]
Your sound system is warranted for three years
or 36,000 miles (60,000 kilometers), whichever
comes first. Consult your vehicle warranty
booklet for further information. Ask your dealer
for a copy of this limited warranty.
*
[AS37150(ALL)07/90]
q
Service
*
[AS37200(ALL)04/96]
At Ford, we stand behind our audio systems
with a comprehensive service and repair
program. If anything should go wrong with
your Ford audio system, return to your dealer
for service. There is a nationwide network of
qualified Ford authorized repair centers to assist
you.
File:04prasp.ex
Update:Mon Jun 3 10:03:33 1996

47
Controls and Features
*
[CF00300(ALL)03/96]
Your vehicle has a variety of features designed
for your comfort, convenience and safety. Read
this chapter to find out about standard and
optional features.
%*
[CF00400(ALL)01/96]
The main controls for the climate control system,
clock, and radio are on the instrument panel.
File:05prcfp.ex
Update:Tue Jun 11 11:03:33 1996

48 [CF00500(ALL)05/96]
full page art:0032028-HInstrument panel
File:05prcfp.ex
Update:Tue Jun 11 11:03:33 1996

49 %
*
[CF00600(ALL)03/96]
NOTE: Any cleaner or polish that increases the
gloss (shine) of the upper part of the
instrument panel should be avoided.
The dull finish in this area is to help
protect the driver from undesirable
windshield reflection.
%
*
[CF00700(ALL)01/96]
The Climate Control System
*
[CF01000(ALL)01/96]
Heating Only System (Without Air
Conditioning)
*
[CF01100(ALL)01/96]
Function selection
[CF01300(ALL)01/96]
The heater in your vehicle has three controls
used for air direction, temperature and fan
speed. The function selector control lets you
direct heated or unheated air through the
instrument panel registers, or down to the floor.
It also allows you to vent your vehicle with
outside air.
[CF01400(ALL)01/96]
one third page art:0032040-C
Heating only system control panel
[CF01800(ALL)01/96]
Turning the function selector control all the way
to the right (V) directs air to defroster vents
and the side window defoggers only.
[CF01900(ALL)01/96]
With the function selector control in the MIX
position, air is directed out the defrosters, side
defoggers and the floor heater outlets.
File:05prcfp.ex
Update:Tue Jun 11 11:03:33 1996

50 [CF02000(ALL)01/96]The FLOOR position directs air out the floor
outlets and the side window defoggers.
[CF02100(ALL)01/96]
Ventilate your vehicle with outside air by
choosing the VENT position.
[CF03000(ALL)01/96]
Temperature control
[CF03100(ALL)01/96]
The air temperature can be adjusted by moving
the marker on the temperature control to the red
area for warm air, or to the blue area for
unheated air. The air will become warmer or
cooler depending on how far the control is
turned.
[CF03400(ALL)01/96]
Fan speed control
[CF03500(ALL)01/96]
Fan speed can be controlled by turning the
control from LO to HI.
*
[CF03600(ALL)04/96]
Turning On the Heat
*
[CF03800(ALL)01/96]
To heat the inside of your vehicle:
[CF03850(ALL)01/96]
1. Turn the function selector control to FLOOR.
[CF03900(ALL)01/96]
When FLOOR is selected, air is directed
through the floor registers, and a little air is
also directed at the windshield and side
windows to help prevent fogging.
[CF03975(ALL)01/96]
2. Turn the temperature control all the way to
the right in the red area, or to the desired
temperature.
[CF04000(ALL)04/96]
3. Set the fan at the desired speed.
File:05prcfp.ex
Update:Tue Jun 11 11:03:33 1996

51 [CF04300(ALL)04/96]
Defrosting the Windshield and Side
Windows
[CF04500(ALL)01/96]
1. Turn the function selector control to the
defrost position.
[CF04550(ALL)01/96]
WhenVis selected, air is directed to the
windshield and side windows.
[CF04600(ALL)01/96]
2. Turn the temperature control to the desired
temperature.
[CF04650(ALL)04/96]
3. Set the fan at the desired speed.
[CF04700(ALL)04/96]
Heating and Defrosting at the Same Time
[CF05000(ALL)01/96]
1. Set the function selector control to MIX.
[CF05100(ALL)01/96]
2. Set the temperature and fan speed as
desired.
[CF05200(ALL)04/96]
Ventilating Your Vehicle With Outside Air
*
[CF05300(ALL)08/95]
On mild days, you may want to ventilate your
vehicle with outside air. To open the vents:
[CF05400(ALL)01/96]
1. Turn the function selector control to VENT.
[CF05500(ALL)01/96]
When VENT is selected, air is directed out of
the panel registers.
[CF05600(ALL)01/96]
2. Turn the temperature control to the desired
temperature.
[CF05700(ALL)04/96]
3. Set the
H(fan speed) as desired.
File:05prcfp.ex
Update:Tue Jun 11 11:03:33 1996

52
*
[CF05800(ALL)05/96]
Tips for controlling the temperature in your
vehicle
*
[CF05900(ALL)01/96]
q
To vary the temperature inside your vehicle,
move the temperature selector toward the red
area for warmer air and toward the blue area
for cooler air.
*
[CF06000(ALL)01/96]
q
If you drive with the fan off and the
windows closed, the windows may fog up.
To prevent fogging:
[CF06100(ALL)01/96]
1. Set the function selector control to VENT,
MIX, FLOOR or theVposition.
*
[CF06200(ALL)01/96]
2. Set the desired temperature.
*
[CF06300(ALL)04/96]
3. Set the
H(fan speed) to the desired
position.
*
[CF06400(ALL)01/96]
q
Do not put objects under the front seats that
will interfere with the flow of air to the back
seats.
*
[CF06500(ALL)01/96]
q
Remove any snow, ice, or leaves from the
area below the windshield on the outside of
your vehicle. They could block the air intake.
File:05prcfp.ex
Update:Tue Jun 11 11:03:33 1996

53
*
[CF06600(ALL)01/96]
Air Conditioning System (If equipped)
[CF06800(ALL)01/96]
Operate the air conditioning by using the climate
controls on the center of the instrument panel.
[CF06900(ALL)01/96]
one third page art:0032041-A
Air conditioning controls
*
[CF06950(ALL)01/96]
Sometimes you may notice slight engine surging
if you have the air conditioner on. This is
normal, as the system is designed to cycle the
compressor on and off to maintain desired
cooling. The reduced compressor operation
should benefit fuel economy.
*
[CF07000(ALL)01/96]
On some vehicles with air conditioning,
wide-open throttle acceleration will temporarily
cut off the air conditioning.
*
[CF07050(ALL)01/96]
Since the air conditioner removes a lot of
moisture from the air during operation, it is
normal for water to drip on the pavement under
the air conditioner drain after you have stopped
the vehicle.
[CF07150(ALL)01/96]
Action for heating and windshield defrosting are
identical for cars equipped with either the
Heating Only Systemor theHeating and Air
Conditioning System. For instructions about these
functions, see the previous section,Heating Only
System. For instructions about using the air
conditioning, see the following sections.
File:05prcfp.ex
Update:Tue Jun 11 11:03:33 1996
