1997 FORD PROBE Owners Manual

110
*
[SS12200(ALL)05/96]
Determining if System Is Operational
*
[SS12250(ALL)05/96]
The Air Bag Supplemental Restraint System uses
a readiness light and a tone to indicate the
condition of the system. The readiness light is in
the instrument cluster. When you turn the
ignition key to ON, this light will illuminate for
approximately six (6) seconds and then turn off.
This indicates that the system is operating
normally. NOTE: Routine maintenance of the air
bag system is not required.
%*
[SS12300(ALL)05/96]
A problem with the system is indicated by one
or more of the following:
*
[SS12350(ALL)05/96]
q
the readiness light will either flash or stay lit,
*
[SS12400(ALL)05/96]
q
the readiness light will not light immediately
after ignition is turned on,
%*
[SS12450(ALL)05/96]
q
a group of five beeps will be heard. The tone
pattern will repeat periodically until the
problem and light are repaired.
*
[SS12500(ALL)05/96]
If any of these things happen, even
intermittently, have the Air Bag Supplemental
Restraint System serviced at your Ford or
Lincoln-Mercury dealer immediately. Unless
serviced, the system may not function properly
in the event of a collision.
*
[SS12550(ALL)05/96]
Disposal of Air Bags and Air Bag
Equipped Vehicles
*
[SS12600(ALL)05/96]
For disposal of air bags or air bag equipped
vehicles, see your local Ford or Lincoln-Mercury
dealer. Air bags MUST BE disposed of by
qualified personnel.
File:06prssp.ex
Update:Mon Jun 3 10:07:19 1996

111
%*
[SS15900(ALL)01/96]
Safety Restraints for Children
*
[SS16000(ALL)01/96]
In the U.S. and Canada, you are required by law
to use safety restraints for children. If small
children ride in your vehicle Ð this generally
includes children who are four years old or
younger and who weigh 40 pounds (18 kg) or
less Ð you must put them in safety seats that
are made specially for children. Safety belts
alone do not provide maximum protection for
these children. Check your local and state laws
for specific requirements.
*
[SS16100(ALL)02/96]
RWARNING
Never let a passenger hold a child on his
or her lap while the vehicle is moving.
The passenger cannot protect the child
from injury in a collision.
*
[SS16200(ALL)01/96]
RWARNING
To prevent the risk of injury, make sure
children sit where they can be properly
restrained.
*
[SS16300(ALL)05/96]
RWARNING
It is extremely dangerous to ride in a
cargo area, inside or outside of a vehicle.
In a collision, people riding in these areas
are more likely to be seriously injured or
killed. Do not allow people to ride in any
area of your vehicle that is not equipped
with seats and safety belts. Be sure
everyone in your vehicle is in a seat and
using a safety belt properly.
File:06prssp.ex
Update:Mon Jun 3 10:07:19 1996

112
*
[SS16400(ALL)05/96]
When possible, put children in the rear seat of
your vehicle. Accident statistics suggest that
children are safer when properly restrained in
the rear seating positions than in the front
seating positions.
[SS16450(ALL)05/96]
RWARNING
Failure to follow all instructions on the
proper use of child seats or the vehicle
restraint systems can result in serious
injury or death in the event of a sudden
stop or collision.
*
[SS16500(ALL)03/96]
RWARNING
Carefully follow all of the manufacturer's
instructions included with the safety seat
you put in your vehicle. If you do not
install and use the safety seat properly,
the child may be injured in a sudden stop
or collision.
*
[SS16600(ALL)01/96]
RWARNING
Safety belts and seats can become hot in a
vehicle that has been closed up in sunny
weather; they could burn a small child.
Check seat covers and buckles before you
place a child anywhere near them.
*
[SS16700(ALL)03/96]
RWARNING
Do not leave children, unreliable adults,
or pets unattended in your vehicle.
File:06prssp.ex
Update:Mon Jun 3 10:07:19 1996

113 %
*
[SS16800(ALL)01/96]
Safety Seats for Children
[SS16900(ALL)01/96]
Use a safety belt that is recommended for the
size and weight of the child. Always follow the
safety seat manufacturer's instructions when
installing and using the safety seat.
*
[SS17000(ALL)01/96]
Ford recommends the use of a child safety seat
having a top tether strap. Install the child safety
seat in a seating position which is capable of
providing a tether anchorage. For more
information on top tether straps seeAttaching
Safety Seats With Tether Strapsin this chapter.
*
[SS17100(ALL)05/96]
When installing a child safety seat, be sure to
use the correct safety belt buckle for that seating
position, and make sure the tongue is securely
fastened in the buckle. For a shoulder/lap belt
combination with a sliding tongue, make sure
the retractor is in the automatic locking mode.
%*
[SS17300(ALL)05/96]
RWARNING
When using forward-facing child seats
move the passenger seat as far back from
the instrument panel as possible. Never
secure rear-facing child seats or infant
carriers in the front seat.
*
[SS17400(ALL)05/96]
The force of the rapidly inflating passenger air
bag could push the top of the rear-facing seat
against the vehicle seatback, armrests or console.
Rear-facing infant seats must always be secured
in the rear seat.
*
[SS17500(ALL)05/96]
All child restraint systems are designed to be
secured in vehicle seats by lap belts or by the
lap portion of a lap-shoulder belt.
File:06prssp.ex
Update:Mon Jun 3 10:07:19 1996

114
*
[SS17600(ALL)03/96]
RWARNING
If you do not properly secure the safety
seat, the child occupying the seat may be
injured during a collision or sudden stop.
An unsecured safety seat could also injure
other passengers.
*
[SS17700(ALL)03/96]
RWARNING
Carefully follow all of the manufacturer's
instructions included with the safety seat
you put in your vehicle. If you do not
install and use the safety seat properly,
the child may be injured in a sudden stop
or collision.
*
[SS17800(ALL)01/96]
Installing Child Safety Seats
*
[SS17900(ALL)02/96]
Your vehicle is equipped with a dual locking
mode retractor on the shoulder belt portion of
the front passenger seat and both rear seats. The
automatic locking modemust be usedwhen
installing a child seat or infant carrier in the
front passenger seat or rear seats.
*
[SS18000(ALL)05/96]
RWARNING
Rear-facing child seats or infant carriers
should never be placed in the front seats.
File:06prssp.ex
Update:Mon Jun 3 10:07:19 1996

115
*
[SS18100(ALL)01/96]
If you choose to install a child safety seat in the
front seat, move the seat as far back as possible.
[SS18200(ALL)01/96]
1. Position the child seat or infant carrier on
the passenger seat of the vehicle.
[SS18300(ALL)01/96]
2. Pull down on the shoulder belt, then grasp
the shoulder belt and lap belt together.
[SS18400(ALL)01/96]
half page art:0032385-B
Grasping lap and shoulder belt together
File:06prssp.ex
Update:Mon Jun 3 10:07:19 1996

116 [SS18500(ALL)01/96]3. While holding the shoulder and lap belt
portions together, route the tongue through
the child seat according to the child seat
manufacturer's instructions. Be sure the belt
webbing is not twisted.
[SS18600(ALL)03/96]
half page art:0032361-A
Routing safety belt through child seat or infant carrier
File:06prssp.ex
Update:Mon Jun 3 10:07:19 1996

117 [SS18700(ALL)01/96]
half page art:0032386-A
Buckling the belt
File:06prssp.ex
Update:Mon Jun 3 10:07:19 1996
