1997 FORD PROBE Owners Manual

13
*
[IS02700(ALL)03/96]
This light will also illuminate if the parking
brake does not release fully. If it does stay on
afterthe parking brake is fully released, it
means there may be a brake problem. Pull off
the road and stop carefully. You may notice that
the pedal is harder to push, the pedal may go
closer to the floor, or it may take longer to stop
the vehicle. Try the brakes again after you have
stopped.
*
[IS02800(ALL)03/96]
RWARNING
The BRAKE light indicates that the brakes
may not be working properly. Have the
brakes checked immediately.
%*
[IS02900(ALL)03/96]
Anti-Lock Brake System Warning Light
[IS03000(ALL)03/96]
When the ignition switch is turned to the ON
position, the anti-lock brake system warning
light will illuminate. When the engine is started,
the anti-lock brake system control unit will
determine if all components of the system are
operating correctly. The warning light could
remain on for two to four seconds.
[IS03100(ALL)01/96]
one inch art:0032359-C
The anti-lock brake system warning light
*
[IS03200(ALL)03/96]
RWARNING
If the anti-lock brake system warning
light remains on or comes on while
driving, have the braking system checked
by a qualified service technician as soon
as possible.
File:03prisp.ex
Update:Thu May 16 09:43:45 1996

14
*
[IS03300(ALL)03/96]
NOTE: If a fault occurs in the anti-lock
system, and the brake warning light is
not lit, the anti-lock system is disabled
but normal brake function remains
operational.
*
[IS03400(ALL)01/96]
NOTE: If your vehicle must be jump-started
because of a low battery, the Anti-Lock
Brake System warning light could
remain on. This is due to low battery
voltage and does not indicate a
malfunction in the system. Under these
circumstances, you should drive your
vehicle only after the battery has had
time to charge and the light has gone
out.
[IS03500(ALL)01/96]
The Low Fuel Light
[IS03600(ALL)03/96]
This light illuminates when fuel level in your
tank has reached approximately 2-3 gallons (7-10
liters).
[IS03700(ALL)01/96]
one inch art:0032048-A
Low fuel light
File:03prisp.ex
Update:Thu May 16 09:43:45 1996

15 %
*
[IS03800(ALL)05/96]
High Beam Light
*
[IS03900(ALL)03/96]
This light illuminates when the headlamps are
turned to high beam or when you flash the
lights.
*
[IS04000(ALL)01/96]
one inch art:0030174-A
High beam light
%*
[IS04100(ALL)03/96]
Check Engine Warning Light
*
[IS04200(ALL)03/96]
This light illuminates when the electronic engine
control system is not working properly. This is
the computer that controls the operating
conditions of the engine.
*
[IS04300(ALL)01/96]
one inch art:0030175-B
Check engine warning light
[IS04400(ALL)03/96]
This light illuminates briefly when you turn the
ignition to the ON position, but should turn off
when the engine starts. If the light does not
come on when you turn the ignition to the ON
position or if it comes on and stays on when
you are driving, have your vehicle serviced as
soon as possible. This indicates a possible
problem with one of the engine's emission
control systems.You do not need to have your
vehicle towed in.
File:03prisp.ex
Update:Thu May 16 09:43:45 1996

16
*
[IS04500(ALL)04/96]
If the light flashes briefly while you are driving,
it means that the condition is no longer present.
[IS04600(ALL)01/96]
O/D OFF Light (If equipped)
[IS04700(ALL)05/96]
This light tells you that the overdrive off (O/D
OFF) button on the shift selector has been
pushed. When the light is on, the transaxle will
not shift into overdrive. Depressing the button
on the shift selector again will return the vehicle
to ªoverdrive onº mode. The transaxle will be in
the ªoverdrive onº mode when the vehicle is
started even if the O/D OFF mode was selected
when the vehicle was last shut off. Refer to the
Drivingchapter for more information.
[IS04800(ALL)03/96]
If the light does not illuminate when the O/D
OFF button is pressed, or if the light flashes
when you are driving, have your vehicle
serviced at the first opportunity. If this condition
persists, damage could occur to the transaxle.
[IS04900(ALL)01/96]
one inch art:0032053-A
Overdrive OFF light
*
[IS05000(ALL)04/96]
Gauges
%*
[IS05100(ALL)05/96]
Fuel Gauge
*
[IS05200(ALL)01/96]
The fuel gauge displays approximately how
much fuel you have in the fuel tank.
*
[IS05300(ALL)01/96]
The ignition must be turned off while putting
fuel in the tank in order to get a correct fuel
gauge reading after the ignition is turned on.
File:03prisp.ex
Update:Thu May 16 09:43:45 1996

17
*
[IS05400(ALL)01/96]
The fuel gauge indicator may vary slightly while
the vehicle is in motion. This is the result of fuel
movement within the tank. You can get a more
accurate reading with the vehicle on smooth,
level ground.
[IS05500(ALL)01/96]
Charging System Gauge
[IS05600(ALL)01/96]
This gauge tells you your battery's voltage when
you turn your ignition key to ON. When you
start your engine, the pointer should move to
the NORMAL range if you are not operating
any electrical accessories. (If electrical accessories
are operating and the engine is not running, the
pointer may move into the red area).
[IS05700(ALL)01/96]
If the pointer moves into the red area when no
electrical accessories are operating, have the
vehicle's electrical system checked.
%*
[IS05800(ALL)04/96]
Engine Oil Pressure Gauge
[IS05900(ALL)01/96]
The gauge needle should stay in the NORMAL
range (indicating normal engine oil pressure). If
the needle drops below the NORMAL range into
the low range, there is a loss of oil pressure.
[IS06000(ALL)01/96]
If this happens:
*
[IS06100(ALL)04/96]
1. Pull off the road as soon as safely possible.
*
[IS06200(ALL)04/96]
2. Shut off the engine immediately or severe
engine damage could result.
[IS06300(ALL)01/96]
3. Check the oil level when the vehicle is on
level ground.
[IS06400(ALL)01/96]
4. Add only as much oil as the engine needs
before you drive the vehicle again. Do not
overfill the oil reservoir. For more
information, seeAdding engine oilin the
Index.
File:03prisp.ex
Update:Thu May 16 09:43:45 1996

18 %
*
[IS06500(ALL)03/96]
Engine Coolant Temperature Gauge
*
[IS06600(ALL)02/96]
This gauge indicates the temperature of the
engine coolant, not the coolant level. If the
coolant is not at its proper level or mixture, the
gauge indication will not be accurate.
[IS06650(ALL)04/96]
The pointer usually moves from C (cold) into
the NORMAL band as your vehicle warms up.
Under most driving conditions, the pointer
should stay in the NORMAL band. If you are
driving in heavy traffic or on an extended grade
in hot weather, the pointer may reach to the top
of the NORMAL band.
*
[IS06700(ALL)04/96]
If, under any circumstances, the pointer moves
above the NORMAL band, the engine is
overheating and continued operation may cause
engine damage.
*
[IS06800(ALL)03/96]
If your engine overheats:
*
[IS06900(ALL)03/96]
1. Pull off the road as soon as it is safely
possible.
*
[IS07000(ALL)04/96]
2. Shut off the engine immediately or severe
engine damage could result.
*
[IS07100(ALL)01/96]
3. Let the engine cool.
*
[IS07200(ALL)01/96]
4. Check the coolant level following the
instructions on checking and adding coolant
to your engine. (SeeEngine coolantin the
Index.) If you do not follow these
instructions, you or others could be injured.
*
[IS07250(ALL)01/96]
For instructions on checking and adding coolant
to your engine, seeEngine coolantin the Index. If
you do not follow these instructions, you or
others could be injured.
File:03prisp.ex
Update:Thu May 16 09:43:45 1996

19
*
[IS07300(ALL)04/96]
5. Refer toAdding Engine Coolantin the
Maintenance and Carechapter. Add as much
coolant as your engine needs. If the engine
continues to overheat, have the cooling
system serviced.
%*
[IS07500(ALL)03/96]
Speedometer
*
[IS07600(ALL)03/96]
The speedometer tells you how many miles
(kilometers) per hour your vehicle is moving.
%*
[IS07700(ALL)03/96]
Odometer
*
[IS07800(ALL)01/96]
The odometer tells you the total number of miles
(kilometers) your vehicle has been driven.
%*
[IS08000(ALL)01/96]
Trip Odometer
[IS08100(ALL)01/96]
Use the trip odometer to track your mileage.
Simply set the trip odometer to zero by pressing
the reset button.
%*
[IS09000(ALL)03/96]
Tachometer
[IS09100(ALL)01/96]
The tachometer indicates approximate engine
revolutions per minute, and is located on the
right-hand side of the instrument cluster. The
tachometer pointer may move slightly when the
key is placed in the ACC or ON position, with
the engine off. This pointer movement is normal,
and will not affect the accuracy of the
tachometer once the engine is running.
File:03prisp.ex
Update:Thu May 16 09:43:45 1996

21
Electronic Sound Systems
*
[AS00950(ALL)08/95]
full page art:0060648-B
Compact Disc Radio
