1997 FORD PROBE Owners Manual

70
WARNING
Alwayswar mup thewindshiel dwit hthe

71
WARNING
Neveradjus tth esteerin gwhee lwhe nthe
File:05prcfp.ex

72
%*
[CF21300(ALL)03/96]
Speed Control (If equipped)
[CF21600(ALL)01/96]
half page art:0032031-C
Speed control switches on the steering wheel
%*
[CF21610(ALL)05/96]
To Turn Speed Control Off
[CF21612(ALL)05/96]
Press OFF, or
[CF21614(ALL)05/96]
Turn off the vehicle ignition.
*
[CF21616(ALL)05/96]
Once speed control is switched off, the
previously programmed set speed will be erased.
*
[CF21620(ALL)05/96]
To Turn Speed Control On
[CF21640(ALL)05/96]
Press ON
*
[CF21740(ALL)05/96]
To Set a Speed
[CF21760(ALL)05/96]
Press SET ACC. For speed control to operate,
the speed control must be ON and the vehicle
speed must be greater than 30 mph (48 km/h).
*
[CF21780(ALL)05/96]
If you drive up or down a steep hill, your
vehicle speed may vary slower or faster than the
set speed. This is normal.
File:05prcfp.ex
Update:Tue Jun 11 11:03:33 1996

73
WARNING
To kee pyou rvehicl eunde rcontrol ,do

74
*
[CF22020(ALL)05/96]
To Disengage Speed Control
[CF22040(ALL)05/96]
Depress the brake pedal, or
[CF22060(ALL)05/96]
Depress the clutch pedal (if equipped).
*
[CF22080(ALL)05/96]
Disengaging the speed control will not erase the
previously programmed set speed.
*
[CF22100(ALL)05/96]
To Return to a Set Speed
[CF22120(ALL)05/96]
Press RSM. For RSM to operate, the vehicle
speed must be faster than 30 mph (48 km/h).
%
*
[CF25200(ALL)01/96]
Moon Roof (If equipped)
[CF25300(ALL)01/96]
The control switch for the sliding moon roof is
on the interior/map lamp control panel located
above the windshield and between the sun
visors. The ignition must be in the ON position
for the moon roof to be operational.
[CF25400(ALL)01/96]
To open the sliding moon roof to the vent
position, push the recessed part of the moon
roof switch until the back of the moon roof tilts
into the vent position. You must release the
switch after opening the vent before pressing it
again to slide the moon roof open. To close,
push the other side of the switch until the moon
roof sets back into place.
File:05prcfp.ex
Update:Tue Jun 11 11:03:33 1996

75 [CF25500(ALL)05/96]
half page art:0032055-C
Sliding moon roof control switch
[CF25600(ALL)01/96]
Press the switch until the moon roof is opened
to the desired position. When you release the
switch, the moon roof will stop sliding open. To
close the moon roof, press the other side of the
switch and hold it until the roof is closed to the
desired position.
File:05prcfp.ex
Update:Tue Jun 11 11:03:33 1996

76
%*
[CF26000(ALL)02/96]
Doors
[CF26200(ALL)01/96]
one third page art:0030073-C
The inside of the door
[CF26300(ALL)01/96]
If you close the door with the lock button
depressed, the door will remain locked.
%*
[CF26400(ALL)01/96]
Power Door Locks (If equipped)
[CF26500(ALL)01/96]
If your vehicle has power door locks, the
controls to lock the doors are below the inside
door handles on each door. When you close the
doors after you set the door locks, the doors
remain locked. If the power mechanism ever
fails, the manual door locks will override the
power controls.
[CF26600(ALL)01/96]
NOTE: Vehicles equipped with power locks
have a safety feature which allows you
to unlock one or both front doors from
either door key lock cylinder. To
unlock the driver's or passenger door
only, insert the key in the door lock
cylinder and turn to the left
(counterclockwise) to the first position.
To unlock the other door at the same
time, simply continue turning the key
to the left to the second position. Both
doors are locked by turning the key to
the right (clockwise).
File:05prcfp.ex
Update:Tue Jun 11 11:03:33 1996

77 [CF26700(ALL)01/96]
half page art:0030079-C
Power locks on the driver's door
%*
[CF27000(ALL)04/96]
Windows
%*
[CF27400(ALL)01/96]
Using the Power Windows (If equipped)
[CF27450(ALL)01/96]
Each door has a power control that opens and
closes the window on that door. The driver's
door has a master control panel that operates
both windows.
[CF27500(ALL)01/96]
To use your power windows, your ignition
switch must be placed in the ON position. Press
the recessed end of the power window switch to
lower a window, press the raised end of the
switch to raise a window.
% [CF27550(ALL)01/96]
NOTE: Your vehicle is equipped with a ªone
touch downº feature. This feature
allows the driver to fully open the
driver's window by firmly pressing the
switch and then releasing. The switch
will release when the window has
fully opened.
File:05prcfp.ex
Update:Tue Jun 11 11:03:33 1996
