1997 FORD PROBE mirror

56
*
[CF09300(ALL)01/96]
Rear Window Defroster (If equipped)
[CF09400(ALL)01/96]
quarter page art:0032068-D
Rear window defroster button
[CF09500(ALL)01/96]
The defroster for the rear window clears frost,
fog, or thin ice from both the inside and outside
of the rear window. The rear window defroster
button is located on the lower right of the
instrument panel below the climate control
panel. This button is also used to activate your
heated power mirrors (if equipped).
*
[CF09600(ALL)03/96]
To defrost the rear window:
[CF09700(ALL)03/96]
1. Clear any snow and/or ice from the rear
window.
*
[CF09800(ALL)03/96]
2. Get in your vehicle and start the engine.
[CF09900(ALL)01/96]
3. Press the rear defrost button. The indicator
light turns on.
[CF10000(ALL)01/96]
The defroster turns off automatically after 15 to
25 minutes. If the window is not clear, turn on
the defroster again. It will also automatically
shut off any time the engine is shut off.
%*
[CF10100(ALL)03/96]
NOTE: Never use sharp instruments or
window cleaners with abrasives to
clean the inside of your rear window.
If you do, you may damage the heating
elements that are bonded to the inside
of the rear window and cause damage
to the rear window defroster.
File:05prcfp.ex
Update:Tue Jun 11 11:03:33 1996

79 [CF28200(ALL)01/96]
Dual-Electric Remote Control Mirrors
(If equipped)
[CF28300(ALL)01/96]
Dual-electric remote control mirrors are
collapsible. The mirror heads can be folded
rearward to prevent damage when using an
automatic car wash.
*
[CF28400(ALL)01/96]
To adjust the side mirrors:
[CF28500(ALL)01/96]
1. Locate the control switch in the power
control panel on the driver's door.
[CF28600(ALL)01/96]
2. Select the right or left mirror by moving the
selector switch right or left.
[CF28700(ALL)01/96]
3. Push the control switch in the direction you
want to move the mirror.
[CF28800(ALL)01/96]
4. Return the selector switch to the middle OFF
position to keep the mirror in place.
[CF28900(ALL)01/96]
half page art:0030108-C
Dual-electric side mirror control switches
File:05prcfp.ex
Update:Tue Jun 11 11:03:33 1996

278 Index
Cleaning your vehicle (continued)
interior................ 233
interior lamps............. 233
plastic parts............. 231
polishing............... 230
rear windows.............. 56
rustproofing............. 231
safety belts.............. 234
tail lamps.............. 232
upholstery and interior trim...... 233
washing............... 230
waxing................ 230
wheels................ 232
windows................ 56
Clock................. 27,43
Clutch
fluid reservoir............ 193
operation while driving........ 147
recommended shift speeds....... 150
shifting the gears........... 148
Cold engine starting........... 127
Combination lap and shoulder belts . . 98, 100
Compact disc player (see Electronic
sound system)........... 22,28
Compact disc radio (see Electronic
sound system)............. 22
Console, description............ 80
Controls, mirrors............. 78
Convenience kit in cargo area...... 169
Coolant (see Engine coolant)
checking and adding......... 196
preparing for storage......... 236
temperature gauge........... 18
warnings............... 196
Cooling fan............... 184
Crankcase emission filter......... 237
Customer Assistance Center, Ford (U.S.) . . 247
Customer Assistance Centre,
Ford of Canada............ 252
File:prixp.ex
Update:Tue Jun 11 11:04:36 1996

Index 285
Lug nuts
standard............... 171
tightening sequence.......... 170
M
Maintenance schedule and record
(see separate Maintenance Schedule
and Record booklet).......... 3
Maintenance (see Servicing)....... 183
Maintenance (see servicing)....... 183
Manual transaxle
backing up (reverse)......... 149
clutch................ 147
shifting gears............. 148
shift speeds............. 150
Map pockets............... 80
Master cylinder, brakes......... 193
Mileage, calculating fuel economy.... 220
Mirrors
rearview................ 78
side view mirrors............ 78
Moon roof................ 74
Motorcraft parts............. 237
N
National Highway Traffic Safety
Administration............ 243
New vehicle break-in........... 6
O
Octane rating.............. 217
Odometer
description............... 19
trip odometer............. 19
Oil filter..............192, 237
Oil (see Engine oil)........... 190
File:prixp.ex
Update:Tue Jun 11 11:04:36 1996

286 Index
Oil viscosity.............. 190
On-board diagnostic (OBD II) system . . . 224
Order forms, service information...... 24
Overseas offices............. 254
P
Parking brake
operation............... 135
warning light.............. 12
Parts (see Motorcraft Parts)........ 237
PCV valve, specifications......... 237
Power door locks............. 76
Power features
door locks............... 76
mirrors................. 78
moon roof............... 74
windows................ 77
Power steering
dipstick............... 199
driving with power steering...... 137
fluid, checking and adding....... 199
servicing............... 137
Prop rod, hood............. 186
R
Radio (see Electronic sound systems).... 21
Rear window............... 77
washer reservoir........... 195
Regulations, National Highway Traffic
Safety Administration......... 243
Relays................. 165
Remote entry system
replacement/additional transmitters.... 88
replacing the batteries.......... 87
Reporting safety defects......... 243
File:prixp.ex
Update:Tue Jun 11 11:04:36 1996

288 Index
Seat belts (see Safety restraints)....... 98
Seats
child safety seats........... 113
cleaning upholstery.......... 233
folding rear seats............ 96
head restraints............. 89
rear seat access............. 96
split-folding rear seat.......... 96
Serial number (VIN)........... 252
Service concerns............. 246
Servicing your vehicle
precautions when servicing...... 184
servicing when you tow........ 179
Shift positions (see Gearshift).....138, 148
Shoulder and lap belts
(see Safety restraints)....... 98,100
Shoulder belts (see Safety restraints).... 100
Side mirrors............... 78
Sliding moon roof (see Moon roof)..... 74
Snow tires and chains.......... 214
Spare tire
changing the tire.........167, 170
conventional spare.......... 169
finding the spare........... 169
removing the spare tire........ 169
storing the flat tire........169, 171
temporary spare........... 168
Spark plugs, specifications........ 237
Speed control, turning off......... 72
Speedometer............... 19
Starting your vehicle
preparing to start your vehicle..... 125
starting a cold engine......... 127
starting after a collision........ 130
starting a warm engine........ 127
starting your vehicle if the battery
is disabled............. 174
Steering, power............. 137
Steering wheel, locking........... 61
Storage compartments........... 80
File:prixp.ex
Update:Tue Jun 11 11:04:36 1996
