1997 FORD PROBE steering

58
*
[CF10200(ALL)01/96]
Interior Lights
%*
[CF10300(ALL)01/96]
Lighting Up the Interior and Instrument
Panel
*
[CF10400(ALL)01/96]
With the parking lamps or headlamps on, the
brightness of the instrument panel lighting can
be adjusted.
*
[CF10500(ALL)01/96]
To brighten or dim the instrument panel
lighting, rotate the dimmer control thumbwheel
as desired.
[CF10600(ALL)01/96]
quarter page art:0030050-B
Dimmer control thumbwheel
[CF10700(ALL)01/96]
The dimmer control thumbwheel is located to
the left of the steering wheel on the instrument
panel.
[CF10800(ALL)01/96]
Dome Lamp
[CF10900(ALL)01/96]
The dome lamp illuminates whenever one of the
front doors is opened and turns off
automatically when the doors are closed. You
may turn the dome lamp on and off while the
doors are closed by using the ON/OFF switch
located on the interior/map lamp control panel.
File:05prcfp.ex
Update:Tue Jun 11 11:03:33 1996

61
*
[CF15100(ALL)01/96]
Ignition
%*
[CF15200(ALL)01/96]
Understanding the Positions of the Ignition
[CF15300(ALL)01/96]
one third page art:0032054-A
Ignition lock cylinder
*
[CF15400(ALL)01/96]
LOCK locks the steering wheel. It also locks the
gearshift lever in P (Park) (automatic transaxle).
*
[CF15500(ALL)01/96]
LOCK is the only position that allows you to
remove the key. The LOCK feature helps to
protect your vehicle from theft.
[CF15600(ALL)01/96]
To remove the key if you have a manual
transaxle, push the key in while turning it to the
LOCK position.
*
[CF15700(ALL)01/96]
If your key is stuck in the LOCK position and
will not turn, move your steering wheel left or
right until the key turns freely.
[CF15800(ALL)01/96]
ACC (Accessory) allows some of your vehicle's
electrical accessories to operate while the engine
is not running.
*
[CF15900(ALL)01/96]
ON allows you to test your vehicle's warning
lights (except the brake system warning light) to
make sure they work before you start the
engine. The key returns to the ON position once
the engine is started and remains in this position
while the engine runs.
File:05prcfp.ex
Update:Tue Jun 11 11:03:33 1996

62
*
[CF16000(ALL)01/96]
START cranks the engine. Release the key once
the engine starts so that you do not damage the
starter. The key should return to ON when you
release it. The START position also allows you
to test the brake warning light.
%
*
[CF16010(ALL)02/96]
The Turn Signal Lever
*
[CF16020(ALL)02/96]
You can use the turn signal lever on the left side
of the steering column to:
*
[CF16030(ALL)02/96]
q
operate the headlamps and parking lamps
*
[CF16040(ALL)02/96]
q
operate the turn signals and cornering lamps
*
[CF16050(ALL)03/96]
q
turn the high beams on/off
*
[CF16060(ALL)03/96]
q
flash the lamps
*
[CF16070(ALL)02/96]
Headlamps and Parking Lamps
*
[CF16080(ALL)02/96]
To turn the parking lamps or headlamps on,
twist the knob at the end of the turn signal
lever.
[CF16100(ALL)01/96]
FIRST STOP Ð Turning the knob to the first
stop (g) will turn on the the license plate
lamps, parking lamps, side marker lamps, tail
lamps and instrument panel lamps.
[CF16200(ALL)03/96]
SECOND STOP Ð Turning the knob to the
second stop (B) will turn on the headlamps,
license plate lamps, parking lamps, side marker
lamps, tail lamps, and instrument panel lamps.
[CF16300(ALL)01/96]
quarter page art:0032032-A
Headlamp control
File:05prcfp.ex
Update:Tue Jun 11 11:03:33 1996

68
%*
[CF19100(ALL)01/96]
Windshield Wipers and Washer
*
[CF19200(ALL)01/96]
To operate the windshield wipers and washers,
make sure your ignition key is turned to the ON
position.
[CF19300(ALL)01/96]
The windshield wipers have two speeds. To
operate the wipers, pull down the lever on the
right side of your steering column. The first
position is LO (Low) and the second position is
HI (High). To turn the wipers off, return the
lever to the uppermost position.
[CF19400(ALL)01/96]
quarter page art:0032071-C
Windshield wiper control
[CF19500(ALL)01/96]
ONE-TOUCH WIPER CONTROL (If equipped)
Ð For one wiping cycle, push the lever away
from you and release it with the lever in the
OFF or interval position. The ignition switch
must be in the ON position for this operation.
[CF19600(ALL)01/96]
quarter page art:0032058-B
One touch wiper control
File:05prcfp.ex
Update:Tue Jun 11 11:03:33 1996

72
%*
[CF21300(ALL)03/96]
Speed Control (If equipped)
[CF21600(ALL)01/96]
half page art:0032031-C
Speed control switches on the steering wheel
%*
[CF21610(ALL)05/96]
To Turn Speed Control Off
[CF21612(ALL)05/96]
Press OFF, or
[CF21614(ALL)05/96]
Turn off the vehicle ignition.
*
[CF21616(ALL)05/96]
Once speed control is switched off, the
previously programmed set speed will be erased.
*
[CF21620(ALL)05/96]
To Turn Speed Control On
[CF21640(ALL)05/96]
Press ON
*
[CF21740(ALL)05/96]
To Set a Speed
[CF21760(ALL)05/96]
Press SET ACC. For speed control to operate,
the speed control must be ON and the vehicle
speed must be greater than 30 mph (48 km/h).
*
[CF21780(ALL)05/96]
If you drive up or down a steep hill, your
vehicle speed may vary slower or faster than the
set speed. This is normal.
File:05prcfp.ex
Update:Tue Jun 11 11:03:33 1996

105
*
[SS11200(ALL)05/96]
RWARNING
All occupants of the vehicle, including the
driver, should always wear their safety
belts, failure to do so may increase the
risk of personal injury in the event of a
collision.
*
[SS11250(ALL)05/96]
RWARNING
Do not place objects or mount equipment
on or near the air bag covers that may
come into contact with an inflating air
bag. Failure to follow these instructions
may increase the risk of personal injury in
the event of a collision.
*
[SS11300(ALL)05/96]
RWARNING
Do not attempt to service, repair, or
modify the air bag Supplemental Restraint
System or its fuses. See your Ford or
Lincoln-Mercury dealer.
*
[SS11350(ALL)05/96]
RWARNING
If you are close to an inflating air bag, it
could seriously injure you. Position your
seat such that it is as far back from the
steering wheel as possible but still allows
you to properly control the vehicle.
File:06prssp.ex
Update:Mon Jun 3 10:07:19 1996

126
*
[TO05500(ALL)01/96]
3.If you have an automatic transaxle, make
sure that the gearshift is in P (Park) and the
parking brake is set before you turn the key.
*
[TO05600(ALL)01/96]
If you have a manual transaxle, make sure
that the parking brake is fully set, push the
clutch pedal to the floor, and put the
gearshift into Neutral before you turn the
key.(Remember, the starter will operate
only if the clutch pedal is pushed all the
way to the floor.)
%*
[TO05700(ALL)01/96]
Testing the Warning Lights
*
[TO05800(ALL)02/96]
Before you start your vehicle, you should test
the warning lights on the instrument panel to
make sure that they work. Refer to the
Instrumentationchapter.
%*
[TO06000(ALL)01/96]
Starting Your Engine
*
[TO06100(ALL)01/96]
To start your engine:
*
[TO06300(ALL)01/96]
1. Follow the steps underPreparing to Start
Your Vehicleat the beginning of this section.
*
[TO06320(ALL)01/96]
2. Keep your foot on the brake pedal and turn
the ignition key to the ON position.
*
[TO06330(ALL)01/96]
3. DO NOT depress the accelerator pedal when
starting your engine. DO NOT use the
accelerator while the vehicle is parked.
*
[TO06340(ALL)01/96]
4. Turn the key to the START position
(cranking) until the engine starts. Allow the
key to return to the ON position after the
engine has started.
*
[TO06400(ALL)05/96]
If you have difficulty in turning the key,
rotate the steering wheel slightly because it
may be binding.
File:08prtop.ex
Update:Wed May 15 15:01:01 1996

133
Driving
%*
[GF00300(ALL)05/96]
Brakes
%*
[GF00400(ALL)01/96]
Applying the Brakes
[GF00500(ALL)04/96]
Your vehicle may have four-wheel power
anti-lock disc brakes which adjust automatically
through everyday use.
[GF00600(ALL)04/96]
Some models have power front disc brakes and
rear drum brakes which automatically adjust as
the brake pads and linings wear down.
*
[GF00700(ALL)01/96]
If your vehicle does not have anti-lock brakes,
apply the brake pedal gradually. Use the
ªsqueezeº technique Ð push on the brake pedal
with a steadily increasing force. This allows the
wheels to continue to roll while you are slowing
down, which lets you steer properly.
*
[GF00800(ALL)01/96]
If your vehicle does not have anti-lock brakes,
extreme braking can make the wheels lock and
slide, causing you to lose control of the steering.
If the wheels lock, release the brake pedal and
repeat the ªsqueezeº technique.
*
[GF00900(ALL)01/96]
Do not drive with your foot resting on the brake
pedal; you will wear out the linings and increase
your vehicle's stopping distance. Brake rotor
damage may also eventually occur.
*
[GF00950(ALL)02/96]
NOTE: If you are driving down a long or
steep hill, shift to a lower gear and do
not apply your brakes continuously. If
you apply your brakes continuously,
they may overheat and become less
effective.
File:09prgfp.ex
Update:Fri Jan 3 09:33:04 1997
