1996 FORD WINDSTAR Owners Manual

Roadside Emergencies
263
% [RE02100(ALL)02/95]
To connect the jumper cables:
[RE02200(ALL)02/95]1.
Connect one end of the first jumper cable to the positive (+)
terminal of the dead battery. (You can connect either jumper
cable to the positive (+) terminal, as long as you use the
same cable for both positive terminals.) Most jumper cables
have a red cable and a black cable. The red cable is generally
used for the positive terminals and the black for the negative
ones.
*
[RE02300(ALL)04/95]2.
Connect the other end of the first cable to the positive (+)
terminal of the booster battery.
*
[RE02400(ALL)03/95]3.
Connect one end of the second cable to the negative (s)
terminal of the booster battery Ð NOT to the dead battery.
[RE02500(ALL)12/93]4.
Connect the other end of that cable to a good, unpainted
metallic surface in the engine compartment of the vehicle
that needs a jump-start. The following illustration shows
where you can find a metallic surface.
*
[RE02600(ALL)05/95]
RWARNING
Do not connect the end of the second cable to the
negative (-) terminal of the battery to be jumped. A spark
may cause an explosion of the gases that surround the
battery.
File:wnres.ex
Update:Tue Mar 19 08:18:21 1996

264
[RE02700(ALL)08/94]
24 pica art:0050022-B
Jumper Cable Placement (3.8L)
File:wnres.ex
Update:Tue Mar 19 08:18:21 1996

Roadside Emergencies
265
[RE02750(ALL)04/95]
24 pica art:0050259-B
Jumper Cable Placement (3.0L)
[RE02800(ALL)02/95]
After you connect the jumper cables to the batteries:
*
[RE02900(ALL)03/95]1.
Make sure that the jumper cables are not in the way of
moving engine parts, then start the vehicle that has the
booster battery. Run the engine at a moderate speed.
File:wnres.ex
Update:Tue Mar 19 08:18:21 1996

266
[RE03000(ALL)02/95]2.
Let the dead battery charge for a few minutes and then start
the vehicle that has the dead battery. If the starter does not
crank, check for good, solid jumper cable clamp attachments.
It may take a couple of tries before your vehicle starts. If
your vehicle does not start after several attempts, you may
have a different mechanical problem.
*
[RE03100(ALL)03/95]3.
When both vehicles are running, let them idle for a few
minutes to charge the dead battery.
% [RE03200(ALL)02/95]
Take the jumper cables off in the following order:
[RE03300(ALL)02/95]1.
Remove the negative (s) end of the jumper cable from the
metallic surface in the engine compartment of the vehicle
that needed a jump-start.
*
[RE03400(ALL)03/95]2.
Remove the other end of the negative (s) cable from the
booster battery.
*
[RE03500(ALL)03/95]3.
Remove the positive (+) cable from the booster battery.
*
[RE03600(ALL)03/95]4.
Remove the other end of the positive (+) cable from the
vehicle that needed a jump-start.
% [RE03700(ALL)02/95]
After your vehicle is started, let it idle for a while to let the
engine ªrelearnº its idle conditions and drive it around for a
little while with all electrical accessories turned off, to let the
battery recharge.You may need to use a battery charger to
fully recharge the battery.
File:wnres.ex
Update:Tue Mar 19 08:18:21 1996

Roadside Emergencies
267
%*
[RE03800(ALL)01/93]
Changing a Flat Tire
*
[RE03900(ALL)01/95]
If you get a flat tire while you are driving, do not apply the
brake heavily. Instead, gradually decrease the speed. Hold the
steering wheel firmly and slowly move to a safe place on the
side of the road. Park on a level spot, turn off the ignition, set
the parking brake, and turn on the hazard flashers.
% [RE04000(ALL)02/95]
Using the Spare Tire
*
[RE04100(ALL)03/94]
Your vehicle has a temporary spare tire (unless you ordered the
optional full-size spare tire). This spare tire is smaller than a
regular tire and is designed for emergency use only. Use it only
when you get a flat tire and replace it as soon as you can. This
spare tire is marked with the words TEMPORARY USE ONLY
so that you can easily identify it.
*
[RE04200(ALL)01/93]
RWARNING
If you use the temporary spare tire continuously or do
not follow these precautions, the tire could fail, causing
you to lose control of the vehicle, possibly injuring
yourself or others.
*
[RE04300(ALL)02/95]
When you drive with the temporary spare tire, DO NOT:
*
[RE04500(ALL)02/95]
n
exceed 50 mph (80 km/h) under any circumstances
*
[RE04600(ALL)01/93]
n
load your vehicle so that it is heavier than the maximum
vehicle load rating listed on the tire decal
*
[RE04700(ALL)01/93]
n
tow a trailer
*
[RE04800(ALL)01/93]
n
use tire chains
*
[RE04900(ALL)01/93]
n
try to repair the temporary spare tire or remove it from its
wheel
File:wnres.ex
Update:Tue Mar 19 08:18:21 1996

268
*
[RE05000(ALL)01/93]
n
use the wheel for any other type of vehicle
*
[RE05100(ALL)01/93]
n
drive through an automatic car wash. Because the temporary
spare tire is smaller than a conventional tire, it reduces the
ground clearance. Your vehicle may get caught in the rails
and it could be damaged.
[RE05200(ALL)02/95]
Finding the spare tire
[RE05300(ALL)11/93]
The spare tire is stored underneath your vehicle, directly below
the cargo area.
[RE05400(ALL)02/95]
Removing the spare tire
*
[RE05500(ALL)01/93]1.
Open the liftgate and find the plastic hex nut cover in the
carpeting of the cargo area. Lift the cover to expose the hex
nut.
[RE05600(ALL)08/94]
17-1/2 pica
art:0050024-B
The spare tire cover
File:wnres.ex
Update:Tue Mar 19 08:18:21 1996

Roadside Emergencies
269
*
[RE05700(ALL)01/93]2.
Find the tapered lug wrench in the tool kit located behind
the jack in the right cargo area side panel.
*
[RE05800(ALL)12/93]3.
Fit the hex-shaped end of the lug wrench over the hex nut
in the floor of the cargo area. Turn counterclockwise until
the cable extends far enough to lower the spare tire to the
ground.
*
[RE05900(ALL)09/93]
10-1/2 pica
art:0040172-B
The spare tire in the lowered position
*
[RE06000(ALL)01/93]4.
Continue to turn the hex nut counterclockwise until the
spare tire retainer can be seen for removal.
*
[RE06100(ALL)01/93]5.
Remove the retainer from the center of the wheel. It may be
necessary to lift one end of the tire to disengage the retainer.
File:wnres.ex
Update:Tue Mar 19 08:18:21 1996

270
*
[RE06200(ALL)09/93]
10-1/2 pica
art:0040173-B
Removing the spare tire retainer
%*
[RE06800(ALL)03/95]
Changing the Tire
*
[RE06900(ALL)05/94]
You should only raise your vehicle with a jack properly placed
at the front or rear jacking points.
*
[RE07000(ALL)12/93]1.
Make sure that your vehicle will not move or roll. Put the
gearshift lever in P (Park). Set the parking brake and block
the wheel Ð in both directions Ðthat is diagonally opposite
the tire that you are changing.
*
[RE07100(ALL)01/93]
RWARNING
When one of the front wheels is off the ground, the
transaxle alone will not prevent the vehicle from moving
or slipping off the jack, even if the vehicle is in P (Park).
*
[RE07200(ALL)01/93]
RWARNING
To prevent the vehicle from moving when you change a
tire, be sure the parking brake is set, then block (in both
directions) the wheel that is diagonally opposite (other
side and end of the vehicle) to the tire being changed.
