1996 FORD WINDSTAR horn

134
*
[SC04320(ALL)11/93]
OVERDRIVE OFF Lamp
[SC04330(ALL)06/94]
This lamp indicates the operating range of the transaxle. This
lamp will illuminate when the Overdrive On/Off button is
depressed.
[SC04340(ALL)03/94]
6 pica art:0050187-C
OVERDRIVE OFF lamp location
[SC04350(ALL)05/95]
With the transaxle range selector in the Overdrivejrange, the
OVERDRIVE OFF lamp will not be illuminated. The transaxle
will be allowed to upshift and downshift from 1st through 4th
gears. When the Overdrive on/off button is depressed, the
OVERDRIVE OFF lamp will illuminate. The transaxle will now
only upshift and downshift from 1st through 3rd gears. The
vehicle will always return to the overdrive operation mode
when the ignition is turned off and back on.
[SC04360(ALL)06/94]
If the lamp does not come on when the Overdrive ON/OFF
button is depressed or if the lamp flashes when you are driving,
have your vehicle serviced at the first opportunity. If this
condition persists, damage could occur to the transaxle.
%*
[SC04400(ALL)01/95]
Horn
[SC04410(ALL)09/93]
To sound the horn, press the center of the steering wheel. Check
the horn regularly to make sure it operates properly.
File:wnscs.ex
Update:Tue Mar 19 08:22:27 1996

Steering Column Controls
135
[SC04415(ALL)09/93]
13-1/2 pica
art:0050017-A
The horn pad
%*
[SC04610(ALL)04/95]
Hazard Flasher Switch
*
[SC04620(ALL)04/95]
The hazard flasher is used to alert other drivers to hazardous
situations.
*
[SC04630(ALL)09/93]
The hazard flasher switch operates the same lamps as the turn
signal lever. When the hazard flasher is activated, all of these
lamps will flash on and off. The turn signal indicators cannot be
used when the hazard lamps are flashing. Operation of the
hazard flashers does not affect operation of the brakelamps.
*
[SC04640(ALL)12/93]
The flashers work even with the key out of the ignition. The
flashers will work for up to two hours when the battery is fully
charged and in good condition. They will not drain the battery
excessively. If the flashers run for longer than two hours or if
your battery is not fully charged, your battery may be drained
to the point where the vehicle will not start.
[SC04650(ALL)09/93]
The hazard flasher switch is located on top of the steering
column.
File:wnscs.ex
Update:Tue Mar 19 08:22:27 1996

152
[FV09323(ALL)11/93]
10-1/2 pica
art:0050158-B
The remote entry transmitter
% [FV09325(ALL)03/94]
Unlocking the doors
*
[FV09327(ALL)02/95]
To unlock the driver's door, press the UNLOCK button.
*
[FV09329(ALL)02/95]
To unlock the other doors, press the UNLOCK button a second
time within five seconds of unlocking the driver's door.
*
[FV09331(ALL)02/95]
Locking the doors
*
[FV09333(ALL)02/95]
To lock all the doors, press the LOCK button.
[FV09336(ALL)06/94]
If you would like a signal that the doors have been locked,
press the LOCK button again within five seconds. The doors
will lock again and the horn will beep.
%*
[FV09351(ALL)02/95]
Activating the remote personal alarm
[FV09361(ALL)05/95]
If you wish to activate the remote personal alarm, press the
PANIC button. This will honk the horn and flash the tail lamps
for approximately two minutes and forty-five seconds. You can
turn it OFF by pressing the PANIC button again on the same
transmitter or by turning the ignition key to the RUN position.
If the alarm does not turn off, move the transmitter closer to the
vehicle and press the button again.
File:wnfvs.ex
Update:Tue Mar 19 08:21:54 1996

156
% [FV09630(ALL)05/95]
Anti-Theft System (if equipped)
*
[FV09635(ALL)05/95]
When armed, this system helps protect your vehicle against
break-ins or theft.
%*
[FV09640(ALL)05/95]
When an unauthorized entry occurs, the system triggers and
will:
*
[FV09645(ALL)05/95]
n
flash the headlamps, parking lamps, and alarm indicator
lamp
*
[FV09650(ALL)05/95]
n
honk the horn
*
[FV09655(ALL)05/95]
n
disable the starting circuit to prevent the vehicle from being
started
%*
[FV09660(ALL)05/95]
Arming the system
*
[FV09665(ALL)05/95]1.
Remove the key from the ignition. The hood must be closed
to arm the system.
*
[FV09670(ALL)05/95]2.
Open any door. The alarm indicator light will start flashing
to remind you to arm the system.
*
[FV09675(ALL)05/95]3.
Lock the doors by using the power door lock switch. The
alarm indicator light will now glow steadily.
[FV09680(ALL)05/95]4.
Close all doors. The alarm indicator light will then remain
on steadily for 30 seconds and then go out. When the light
goes out, the system is armed.
*
[FV09685(ALL)05/95]
NOTE: Be sure to close all doors completely. If not, the alarm
indicator light will remain on. Remember, your
anti-theft system is armed only after the alarm
indicator light remains on steadily for approximately
30 seconds after the last door is closed, and then goes
out.
*
[FV09690(ALL)05/95]
You can also arm the anti-theft system with the factory installed
remote entry system or the keyless entry system by following
this sequence:
File:wnfvs.ex
Update:Tue Mar 19 08:21:54 1996

158
[FV09831(ALL)03/94]
NOTE: The flashing lights and honking horn will shut off
automatically approximately two minutes and 45
seconds after the system is triggered. It will trigger
again if another intrusion occurs. However, the starter
circuit remains disabled until the system is disarmed.
%*
[FV09901(ALL)01/93]
Liftgate
*
[FV09905(ALL)01/89]
Liftgate opening procedure
[FV09910(ALL)11/93]1.
To open the liftgate, insert the door key into the lock and
turn it clockwise. You can also unlock the latch (but not
release it) with the power door lock system.
*
[FV09915(ALL)01/89]2.
Reach under the license plate light shield and release the
liftgate latch by squeezing the paddle handle rearward.
[FV09920(ALL)06/94]3.
To make the gate swing up to the fully opened position, pull
back and upward on the latch paddle handle under or
behind the license plate shield.
[FV09930(ALL)12/93]
13-1/2 pica
art:0050108-B
Opening the liftgate
File:wnfvs.ex
Update:Tue Mar 19 08:21:54 1996

389
Index
GVWR (Gross Vehicle Weight Rating)
calculating..................... 253
definition...................... 251
H
Hazard flashers.................... 135
Headlamps
autolamp system.................. 123
checking alignment................. 352
cleaning...................... 125
daytime running lights................ 122
flashing...................... 130
high beam..................... 130
replacing bulbs................... 352
turning on and off................. 120
warning chime................... 122
Head restraints.................... 171
Heated mirrors.................... 190
Heating
manual heating and air conditioning system...... 106
rear seat controls.................. 116
High beams, indicator light.............. 75,90
Hitch......................... 255
Hood
latch location.................... 303
lubrication specifications............... 365
release lever.................... 303
Horn......................... 134
Hoses, checking.................... 323
I
Identification Number, Vehicle (VIN).......... 285
Idle, relearning.................... 266
Ignition
positions of the ignition................ 55
removing the key................... 56
Indicator lamp module................. 102
File:wnixs.ex
Update:Tue Mar 19 08:12:49 1996

394
Safety restraints (continued)
warning light and chime................ 83
Safety seats for children
and air bags................... 20,39
attaching with tether straps.............. 50
built-in child seat................... 27
in front seat..................... 39
in rear outboard................... 39
in rear seat...................... 39
tether anchorage hardware............... 50
Seats
child safety seats................... 39
cleaning upholstery................. 184
seat/bed conversion................. 173
Servicing your vehicle, precautions when servicing.... 301
Shoulder and lap belts (see Safety restraints)........ 9
Snow tires and chains................. 333
Special driving conditions............... 245
Speed control
canceling a set speed................ 141
resetting...................... 140
resuming a set speed................ 141
Speedometer.................... 79,95
Starting your vehicle, preparing to start your vehicle.... 57
Steering wheel
horn........................ 134
speed controls................... 137
tilting....................... 136
Storage compartments, map pockets........... 185
Storing your vehicle.................. 366
Supplemental air bag readiness light......... 74,85
Supplemental Restraint System (SRS)........... 19
T
Tachometer....................... 97
Tail lamps, cleaning.................. 125
Tether anchor installation (see Child restraints)....... 50
File:wnixs.ex
Update:Tue Mar 19 08:12:49 1996
