1996 FORD WINDSTAR washer fluid

76
% [LG06620(ALL)10/93]
Low Windshield Washer Fluid Level Warning
(Optional Chime with Light)
[LG06640(ALL)11/93]
This light indicates that the level of your washer fluid is low,
and you have to add more fluid. This light comes on briefly
after you turn your ignition key from the START to the ON
position. If the washer fluid is low, a one second chime will
sound and the light will remain on for 60 seconds. If the washer
fluid is not low, the light should turn off a few seconds after
the engine has started. The light and chime also come on if the
washer fluid is low when you use your windshield washers.
[LG06660(ALL)03/94]
The washer fluid is only checked when the engine is started or
the windshield washers are in operation. The light will not
come on if the fluid level becomes low while you are driving
unless you turn on the windshield washers.
[LG06680(ALL)12/93]
6 pica art:0050062-B
The low windshield washer indicator light
% [LG06685(ALL)03/94]
Low Fuel Indicator Light
[LG06690(ALL)04/95]
This light comes on when your fuel gauge indicates
approximately 1/16 of a tank. The ignition must be turned to
ON in order for this light to come on.
[LG06695(ALL)11/93]
6 pica art:0050189-A
The low fuel indicator light
File:wnlgs.ex
Update:Tue Mar 19 08:25:03 1996

Warning Lights and Gauges
91
% [LG11255(ALL)03/94]
Low Windshield Washer Fluid Level Warning Light
[LG11257(ALL)11/93]
This light indicates that the level of your washer fluid is low,
and you have to add more fluid. This light comes on briefly
after you turn your ignition key from the START to the ON
position. If the washer fluid is low, a one second chime will
sound and the light will remain on for 60 seconds. If the washer
fluid is not low, the light should turn off a few seconds after
the engine has started. The light and chime also come on if the
washer fluid is low when you use your windshield washers.
[LG11258(ALL)03/94]
The washer fluid is only checked when the engine is started or
the windshield washers are in operation. The light will not
come on if the fluid level becomes low while you are driving
unless you turn on the windshield washers.
[LG11260(ALL)12/93]
6 pica art:0050062-B
The low windshield washer indicator light
*
[LG11265(ALL)06/95]
Speed Control Indicator
[LG11270(ALL)05/95]
A SPEED CONTROL light is displayed in the optional electronic
instrument cluster when the speed control system is engaged.
The display will turn off when the brake pedal is pressed or if
speed control is shut off.
*
[LG11275(ALL)05/95]
This display does not indicate any problems with the speed
control, but is simply a convenient way of knowing when it is
active.
File:wnlgs.ex
Update:Tue Mar 19 08:25:03 1996

132
[SC03530(ALL)12/93]
The Speed Dependent feature comes disabled from the factory,
but can be activated at any time by using the following
procedure.
[SC03560(ALL)12/93]1.
Make sure the two front doors are securely closed.
[SC03570(ALL)04/95]2.
Insert the key into the ignition and turn first to the ON
position (the gauges on the instrument panel willnot
illuminate) and then back to the OFF position. Remove the
key and within 30 seconds:
[SC03575(ALL)12/93]3.
Press and hold the washer button on the end of the turn
signal lever.
[SC03580(ALL)04/95]4.
Within two seconds, put the key back in the ignition and
turn to the ON position.
[SC03585(ALL)06/94]5.
Hold the washer button down until a long (two second) tone
is heard. Release the button while the tone is active.
[SC03591(ALL)12/93]6.
After the long tone, a confirmation sequence will be heard.
One beep indicates the feature is inactive. Two beeps
indicates the feature is active.
[SC03595(ALL)12/93]
Repeat this procedure any time you want to cancel or reactivate
the Speed Dependent feature.
*
[SC03600(ALL)04/95]
Windshield Washer
[SC03700(ALL)08/94]
To clean the windshield, push in the washer button on the end
of the turn signal lever. For a constant spray, push and hold the
button. If the windshield wipers are off, one momentary push
results in one wipe and a longer push in three wipes and
activation of washer fluid. If the windshield wipers are in
interval mode a quick tap results in two wipe cycles and a
longer tap in three wipes and washer fluid activation.
*
[SC03800(ALL)01/93]
Do not try to clean the windshield when the washer fluid
container is empty and never activate the washers for more than
fifteen seconds continuously. This could damage the washer
pump system.
File:wnscs.ex
Update:Tue Mar 19 08:22:27 1996

Steering Column Controls
133
*
[SC03900(ALL)01/93]
RWARNING
In freezing weather, the washer solution may freeze on
the windshield and obscure your vision. Always warm
up the windshield with the defroster before you use the
washer fluid. If you cannot see through the windshield
clearly, it can increase the risk of being involved in a
collision.
*
[SC04000(ALL)04/95]
For information about refilling the washer fluid or replacing
your windshield wiper blades, seeWindshield washer fluid and
Wipersin the Index.
%*
[SC04100(ALL)01/93]
Gearshift Lever
[SC04200(ALL)06/94]
The gearshift lever on your vehicle is mounted on the steering
column. On the end of the gearshift lever is the Overdrive
On/Off button and the OVERDRIVE OFF lamp. For additional
information about the gearshift lever and the Overdrive On/Off
button, see theDriving Your Vehiclechapter.
[SC04300(ALL)09/93]
13-1/2 pica
art:0050016-A
The gearshift lever
File:wnscs.ex
Update:Tue Mar 19 08:22:27 1996

Servicing Your Windstar
319
*
[SV18300(ALL)05/95]
RWARNING
Continuous contact with USED motor oil has caused
cancer in laboratory mice.
*
[SV18320(ALL)05/95]
Protect your skin by washing with soap and water.
%*
[SV18400(ALL)03/95]
Engine Coolant
%*
[SV18500(ALL)02/95]
Checking the engine coolant
[SV18600(ALL)11/93]
Your vehicle's engine coolant protects the engine from
overheating in the summer and from freezing in the winter.
Check the level of the engine coolant at least once a month, but
preferably each time you stop for fuel. Simply check the coolant
reservoir, located in the engine compartment. The coolant
should stay slightly above the ªFULL COLDº mark.
*
[SV18700(ALL)01/95]
Adding engine coolant
*
[SV18900(ALL)05/95]
RWARNING
Do not put engine coolant in the container for the
windshield washer fluid.
*
[SV18920(ALL)05/95]
If sprayed to clean the glass, engine coolant or antifreeze could
make it difficult to see through the windshield.
File:wnsvs.ex
Update:Tue Mar 19 08:16:43 1996

Servicing Your Windstar
325
*
[SV21555(ALL)02/95]
RWARNING
The gases around the battery can explode if exposed to
flames, sparks, or lit cigarettes. An explosion could result
in injury or vehicle damage.
%*
[SV21560(ALL)05/95]
RWARNING
Batteries contain sulfuric acid which burns skin, eyes,
and clothing.
*
[SV21562(ALL)05/95]
If the acid touches someone's skin, eyes, or clothing,
immediately flush the area with water for at least 15 minutes. If
someone swallows the acid, have him or her drink lots of milk
or water first, then Milk of Magnesia, a beaten egg, or vegetable
oil. Call a doctor immediately.
%*
[SV21570(ALL)05/95]
RWARNING
Applying too much pressure on the ends when lifting a
battery could cause acid to spill. Lift the battery with a
carrier or with your hands on the opposite corners.
%*
[SV21580(ALL)03/95]
Windshield Washer Fluid and Wipers
%*
[SV21600(ALL)03/95]
Washer Fluid
[SV21700(ALL)02/95]
Check the level of the windshield washer fluid every time you
stop for fuel. The reservoir for washer fluid is located on the
front, passenger side of the engine compartment. This reservoir
contains the fluid for both the windshield and liftgate washers.
*
[SV21900(ALL)05/95]
RWARNING
Do not put windshield washer fluid in the container for
the engine coolant.
File:wnsvs.ex
Update:Tue Mar 19 08:16:43 1996

326
[SV22000(ALL)12/93]
13-1/2 pica
art:0050050-B
Windshield washer fill location
%*
[SV22100(ALL)01/95]
Use specially formulated windshield washer fluid rather than
plain water, because specially formulated washer fluids contain
additives that dissolve road grime. For safety reasons, washer
fluids containing an appropriate antifreeze such as methanol
should be used in freezing weather (temperatures below32ÊF
[0ÊC]). State or local regulations on Volatile Organic Compounds
(VOC's) may restrict use of the most common antifreeze,
methanol. Washer fluids containing non-methanol antifreeze
agents should be used only if they provide cold weather
protection without damaging the vehicle's paint finish, wiper
blades, and windshield washer system.
[SV22200(ALL)04/95]
RWARNING
Washer solution contains methanol which is poisonous.
[SV22250(ALL)04/95]
When adding windshield washer solution, be sure to observe all
warnings indicated on the washer solution container.
File:wnsvs.ex
Update:Tue Mar 19 08:16:43 1996

391
Index
Lamps (continued)
illuminated mirrors................. 191
interior lamps.................... 125
map lamps..................... 127
trailer....................... 256
Lane change indicator (see Turn signal)......... 129
Lap belts........................ 17
Liftgate........................ 158
Lights, warning and indicator
airbag...................... 74,85
anti-lock brakes (ABS)............... 69,88
anti-theft...................... 104
brake...................... 68,84
charging system.................. 72,85
check engine................... 70,86
door ajar..................... 74,90
hazard warning light................. 93
high beam.................... 75,90
low fuel....................... 76
low washer fluid................. 76,91
oil pressure.................... 73,89
safety belt.................... 69,83
speed control...................91,142
theft system.................... 104
traction control system................ 102
turn signal indicator................ 75,92
Load limits, trailer towing............... 254
Lubricant specifications................. 365
Luggage rack..................... 193
Lug nuts
anti-theft...................... 273
tightening sequence................. 278
Lumbar support pad.................. 170
M
Maintenance (see servicing)............... 301
Map pockets..................... 185
