Safety Restraints
11
[SR03830(ALL)05/95]
Shoulder Belt Adjustment (Driver and Right Front
Passenger)
[SR03840(ALL)05/95]
You can adjust the shoulder belt height to one of five (5)
positions. To adjust, pinch the release button and slide it up or
down until the belt rests on your shoulder near your neck.
Release the button and make sure the adjuster is firmly seated
in one of the five (5) positions.
[SR03850(ALL)05/95]
10-1/2 pica
art:0050166-A
The shoulder belt height adjuster
[SR03860(ALL)11/93]
Combination Lap and Shoulder Belt Ð Second Row
Bench Seat
[SR03901(ALL)11/93]
There is a unique safety restraint system for the outside seating
position of the second row bench seat. It is very important that
you read and understand this section before anyone rides in the
outside seating position (near the sliding door) of the
two-passenger bench seat.
[SR03910(ALL)05/95]
In addition to safety belt anchorages in the floor and roof
structures, the second row bench seat has a detachable safety
belt anchor mounted to the right window side of the seat. The
safety belt should always remain attached to this anchor except
when removing this seat.
[SR03915(ALL)12/93]
The second row passenger side outboard seating position uses a
hook above the sliding door to stow the shoulder safety belt when
entering or exiting the vehicle or when it is not being used.
File:wnsrs.ex
Update:Tue Mar 19 08:27:08 1996

Features
163
[FV11800(ALL)09/93]
10-1/2 pica
art:0050034-A
The power quarter window switches
%*
[FV13000(ALL)01/95]
Seats
*
[FV13100(ALL)01/95]
Adjusting the Seats
[FV13150(ALL)03/94]
Adjusting the front seats manually
*
[FV13200(ALL)04/95]
To move the front seats forward or backward:
[FV13300(ALL)09/93]1.
Find the adjustment bar at the lower cushion of the front
seat.
[FV13400(ALL)10/93]2.
Pull the bar up to unlatch the seat.
*
[FV13500(ALL)04/95]3.
Move the seat to the desired position.
[FV13600(ALL)10/93]4.
Release the bar to latch the seat in its new position. Make
sure the seat locks securely in place.
*
[FV13900(ALL)05/95]
RWARNING
Never adjust the driver's seat or seatback when the
vehicle is moving.
File:wnfvs.ex
Update:Tue Mar 19 08:21:54 1996

Features
167
[FV14125(ALL)02/96]
7-1/2 pica art:0050292-A[FV14130(ALL)02/96]2.
Continue pushing to return the seatback to its previously
locked position.
[FV14135(ALL)02/96]
NOTE: When returning the seatback to its original position,
you may experience a slight hesitation. If so, stop
pushing the seatback momentarily, then resume. The
seatback will only return to its original position after
the seat is safely latched.
[FV14140(ALL)02/96]
Your Windstar tip slide seat has been equipped with a lock-out
safety feature which prevents the seatback from returning to its
original position until the seat pedestal latches in the tracks. If
the seat has not latched check under the seat and in the rear
tracks for possible obstructions.
[FV14145(ALL)02/96]
RWARNING
DO NOT DRIVE THE VEHICLE WITH THE TIP SLIDE
SEAT UNLATCHED.
[FV14150(ALL)02/96]
To move the seat forward or backward:
[FV14155(ALL)02/96]1.
Find the adjustment bar underneath the front part of the
seat.
[FV14160(ALL)02/96]2.
Lift the bar to unlatch the seat.
File:wnfvs.ex
Update:Tue Mar 19 08:21:54 1996

172
[FV14946(ALL)06/94]
7-1/2 pica art:0050172-A
Head restraint adjustment
[FV14951(ALL)06/94]
NOTE: On GL models, front bucket seats are designed with
integral headrests.
[FV14960(ALL)06/94]
E-Z access operation Ð passenger side optional
second row bucket seats
[FV14965(ALL)03/94]
To provide easy access to the rear of the vehicle, the passenger
side second row bucket seatback can be tilted forward.
*
[FV14970(ALL)11/93]
To tilt seat forward:
*
[FV14975(ALL)11/93]1.
Put the seatback in the upright position.
[FV14980(ALL)11/93]2.
Lift upward on the handle on the right (outboard) side of
the seat (also the recliner release handle).
*
[FV14985(ALL)11/93]3.
The seat can now be tilted forward.
*
[FV14990(ALL)11/93]
To latch the seat in its normal position, push seatback rearward
until it is latched in position.
[FV15020(ALL)11/93]
Adjustable Three Passenger Bench Seat (If equipped)
[FV15040(ALL)12/93]
Your vehicle's third row passenger bench seat may be adjustable
forward and backward. This adjustment allows for additional
cargo space with the seat adjusted to the full forward position
and extra leg room when adjusted rearward.
[FV15060(ALL)04/95]
Rotate the release handle upward to unlatch. The release handle
is located on the right side of the seat near the floor. Adjust to
the desired seat position and release the handle. Make certain
the seat is latched and secure.
File:wnfvs.ex
Update:Tue Mar 19 08:21:54 1996

228
*
[AS24300(ALL)04/95]
n
Increasing or decreasing treble response
*
[AS24425(ALL)05/95]
Push the ªAUDIOº button repeatedly until the display reads
ªTREB.º Push the right (+) side of the ªVOLUMEº button to
increase the treble (more ªhighsº), and push the left (-) side
to decrease treble (less ªhighsº).
*
[AS24500(ALL)08/89]
Speaker features and operation
*
[AS24600(ALL)04/95]
n
Adjusting speaker balance
*
[AS24725(ALL)05/95]
Balance control allows you to adjust the sound distribution
between the right and left speakers. Push the ªAUDIOº
button repeatedly until the display reads ªBAL.º Push the
right (+) side of the ªVOLUMEº button to shift the sound to
the right speakers, and push the left (-) side to shift the
sound to the left speakers.
*
[AS24800(ALL)04/95]
n
Adjusting speaker fader
*
[AS24925(ALL)05/95]
Fade control allows you to adjust the sound distribution
between the front and rear speakers. Push the ªAUDIOº
button repeatedly until the display reads ªFADE.º Push the
right (+) side of the ªVOLUMEº button to shift the sound to
the front speakers, and push the left (-) side to shift the
sound to the rear speakers.
[AS24950(ALL)11/93]
NOTE: Illuminated bars in the display show relative levels of
bass and treble and positions of speaker balance and
fader functions for five seconds after adjustments are
made, then revert to volume level set.
%*
[AS25000(ALL)02/95]
Using the Controls of Your Cassette Tape Player
*
[AS25500(ALL)02/95]
How to insert a tape
*
[AS25600(ALL)02/95]
Insert a cassette (with theopen edge to the right) firmly into
the tape door opening, making sure the cassette is completely in
and ªseated.º
