1996 FORD WINDSTAR ignition

Safety Restraints
25
*
[SR12920(ALL)05/95]
The air bag system uses a readiness light and a tone to indicate
the condition of the system. The readiness light is in the
instrument cluster. When you turn the ignition to the ON
position, this light will illuminate for approximately six (6)
seconds and then turn off. This indicates that the system is
operating normally.NOTE:Maintenance of the air bag system is
not required.
%*
[SR12930(ALL)05/95]
A problem with the system is indicated by one or more of the
following:
*
[SR12940(ALL)05/95]
n
the readiness light will either flash or stay lit,
*
[SR12950(ALL)05/95]
n
or it will not light immediately after ignition is turned on,
% [SR12960(ALL)05/95]
n
a group of five beeps will be heard. The tone pattern will
repeat periodically until the problem and light are repaired.
[SR12970(ALL)05/95]
If any of these things happen, even intermittently, have the air
bag system serviced at your Ford or Lincoln-Mercury dealer
immediately.
%*
[SR13000(ALL)03/95]
Disposal of supplemental air bag equipped vehicles
[SR13150(ALL)02/95]
For disposal of air bags or air bag equipped vehicles, see your
local Ford or Lincoln-Mercury dealer. Air bags MUST be
disposed of by qualified personnel.
*
[SR13700(ALL)05/95]
Safety Restraints for Children
*
[SR13800(ALL)02/95]
In the U.S. and Canada, you are required by law to use safety
restraints for children. If small children ride in your vehicle Ð
this generally includes children who are four years old or
younger and who weigh 40 pounds (18 kg) or less Ð you must
put them in safety seats that are made specially for children.
Safety belts alone do not provide maximum protection for these
children. Check your local and state laws for specific
requirements.
File:wnsrs.ex
Update:Tue Mar 19 08:27:08 1996

55
Starting Your Windstar
*
[ST02000(ALL)03/95]
Ignition
%*
[ST02100(ALL)01/95]
Understanding the Positions of the Ignition
*
[ST02300(ALL)09/93]
13-1/2 pica
art:0040047-C
The ignition positions
% [ST02401(ALL)02/94]
ACCESSORY allows you to operate some of your vehicle's
electrical accessories while the engine is not running. For
example, you can use ACCESSORY to turn on the radio or
windshield wipers without starting the engine.
*
[ST02501(ALL)01/93]
LOCK locks the steering wheel and the gearshift lever.
*
[ST02600(ALL)01/93]
OFF allows you to shut off the engine and all accessories
without locking the steering wheel, or the gearshift lever.
*
[ST02701(ALL)01/93]
ON allows you to test your vehicle's warning lights to make
sure they work before you start the engine. The key returns to
the ON position once the engine is started and remains in this
position while the engine runs.
*
[ST02801(ALL)01/93]
START cranks the engine. Release the key once the engine starts
so that you don't damage the starter. The key should return to
the ON position when you release it. The START position also
allows you to test the brake warning light.
File:wnsts.ex
Update:Tue Mar 19 08:25:19 1996

56
%*
[ST03100(ALL)02/95]
Removing the Key From the Ignition
*
[ST03200(ALL)01/93]
LOCK is the only position that allows you to remove the key
from the ignition. The LOCK feature helps to protect your
vehicle from theft, because it also locks the steering wheel and
the gearshift lever when the key is removed.
%*
[ST03300(ALL)01/93]
If your key is stuck in the LOCK position, and you are unable
to turn it, move your steering wheel left or right until the key
turns freely.
*
[ST03400(ALL)01/93]
To remove your key from the ignition:
*
[ST03500(ALL)05/95]1.
Put the gearshift lever in P (Park).
*
[ST03600(ALL)02/95]2.
Set the parking brake fully.
*
[ST03700(ALL)03/95]3.
Turn the ignition key to LOCK.
*
[ST03800(ALL)03/95]4.
Remove the key.
*
[ST03900(ALL)01/93]
RWARNING
When you leave your vehicle, place the gearshift lever in
Park (P). Set the parking brake fully, and shut off the
engine. Never park your vehicle in Neutral (N). If you do
not take these precautions, your vehicle may move
suddenly and injure someone.
*
[ST04100(ALL)01/93]
RWARNING
Do not leave children, unreliable adults, or pets alone in
your vehicle. They could accidentally injure themselves
or others through inadvertent operation of the vehicle.
Further, on hot, sunny days, temperatures in a closed
vehicle could quickly become high enough to cause
severe and possibly fatal injuries to people as well as
animals.
File:wnsts.ex
Update:Tue Mar 19 08:25:19 1996

58
[ST05400(ALL)02/95]
Starting the Engine
[ST05500(ALL)02/95]
To start the engine:
[ST05600(ALL)02/95]1.
Follow the steps underPreparing to Start Your Vehicleand
underTesting the Warning Lightsin this section.
*
[ST05700(ALL)01/93]2.
Keep your foot on the brake pedal and turn the ignition key
to ON.
[ST05800(ALL)02/95]3.
DO NOT depress the accelerator pedal when starting your
engine. DO NOT use the accelerator until after the engine is
running and you are ready to drive away.
[ST05900(ALL)02/95]4.
Turn the key to the START position until the engine starts.
(Release the key after the engine has started and it will
return to the ON position.)
[ST06000(ALL)02/95]
If you have difficulty in turning the key, rotate the steering
wheel slightly to relieve any binding.
%*
[ST06600(ALL)04/94]
For a cold engine:
*
[ST06700(ALL)04/95]
n
At temperatures10ÊF (-12ÊC) andbelow:If the engine does
not start infifteen (15) secondson the first try, turn the key
to OFF, wait approximately ten (10) seconds so you do not
flood the engine, then try again.
*
[ST06800(ALL)04/95]
n
At temperaturesabove10ÊF(-12ÊC):If the engine does not
start infive (5) secondson the first try, turn the key to OFF,
wait approximately ten (10) seconds so you do not flood the
engine, then try again.
*
[ST06900(ALL)04/94]
For a warm engine:
*
[ST07000(ALL)04/95]
n
Do not hold the key in the START position for more than
five (5) secondsat a time. If the engine does not start within
five (5) seconds on the first try, turn the key to the OFF
position. Wait a few seconds after the starter stops, then try
again.
File:wnsts.ex
Update:Tue Mar 19 08:25:19 1996

62
*
[ST10600(ALL)02/95]
If your engine cranks, but does not start after a collision:
*
[ST10700(ALL)02/95]1.
Turn the key in the ignition to the OFF position.
*
[ST10800(ALL)03/95]2.
Check under the vehicle for leaking fuel.
*
[ST10900(ALL)02/95]3.
If you do not see or smell fuel, push the fuel pump shut-off
reset button down. If the red button is already set, you may
have a different mechanical or electrical problem.
*
[ST11000(ALL)02/95]4.
Turn the ignition key to the ON position for a few seconds,
then turn it to the OFF position.
*
[ST11100(ALL)02/95]5.
Check under the vehicle again for leaking fuel. If you see or
smell fuel, do not start your vehicle again. If there is no fuel,
you can try to start your vehicle again.
*
[ST11200(ALL)02/95]6.
Check all vehicle warning lights before driving your vehicle.
%*
[ST11300(ALL)02/95]
Guarding Against Exhaust Fumes
[ST11400(ALL)02/95]
Carbon monoxide, although colorless and odorless, is present in
exhaust fumes.
*
[ST11500(ALL)02/95]
RWARNING
Never let your vehicle idle in an enclosed area, and do
not sit in a parked vehicle, (with the engine running) for
more than a short period of time. Exhaust fumes,
particularly carbon monoxide, might build up. These
fumes are harmful and could kill you.
*
[ST11600(ALL)02/95]
RWARNING
If you ever smell exhaust fumes of any kind inside your
vehicle, have your dealer inspect and fix your vehicle
immediately. Do not drive if you smell exhaust fumes.
These fumes are harmful and could kill you.
File:wnsts.ex
Update:Tue Mar 19 08:25:19 1996

68
%*
[LG00475(ALL)06/94]
The Mechanical Cluster
[LG00501(ALL)06/94]
The following warning lights and gauges are on the Mechanical
Cluster. All of these indicators alert you to the status of vehicle
systems or possible problems with your vehicle. Some of the
lights listed are optional. The following section explains each of
the indicators.
[LG00600(ALL)12/93]
Warning and Indicator Lights
%*
[LG00900(ALL)03/95]
Brake System Light
[LG01000(ALL)11/93]
The warning light for the brakes indicates two things Ð that
either the parking brake is on or not fully released, or that the
brake fluid level is low in the master cylinder reservoir. If the
fluid level is low, the brake system should be checked by a
qualified service technician.
[LG01100(ALL)11/93]
6 pica art:0050144-B
The brake system light
[LG01200(ALL)12/93]
The BRAKE light normally comes on when you turn the
ignition key to the ON or START position to verify that the
indicator bulb is working. If the light stays on or comes on
when the engine is running and after you have released the
parking brake fully, have the hydraulic brake system serviced.
*
[LG01300(ALL)05/95]
RWARNING
The BRAKE light indicates that the brakes may not be
working properly. Have the brakes checked immediately.
File:wnlgs.ex
Update:Tue Mar 19 08:25:03 1996

Warning Lights and Gauges
69
% [LG01400(ALL)02/95]
Anti-lock Brake System (ABS) Warning Light
*
[LG01500(ALL)12/93]
To check the anti-lock brake warning light, turn the ignition key
to the ON position. The ABS warning light should glow
momentarily.
*
[LG01600(ALL)10/93]
NOTE: If it does not glow at all or stays on for a long time,
have your vehicle's electrical system checked
immediately.
[LG01700(ALL)11/93]
6 pica art:0050147-B
The anti-lock brake warning light
*
[LG01800(ALL)05/95]
RWARNING
If the anti-lock brake system warning light remains on or
comes on while driving, have the braking system checked
by a qualified service technician as soon as possible.
[LG01820(ALL)06/95]
NOTE: If a fault occurs in the anti-lock system, and the brake
warning light is not lit, the anti-lock system is
disabled but normal brake function remains
operational.
% [LG01900(ALL)04/95]
Safety Belt Warning Light and Chime
*
[LG02000(ALL)03/95]
This warning light and chime remind you to fasten your safety
belt. The following conditions will take place:
[LG02010(ALL)02/95]
n
If the driver does not fasten the safety belt before the
ignition is turned to ON, the chime will sound for four (4) to
eight (8) seconds and the light will illuminate for one (1) to
two (2) minutes, or until the safety belt is fastened.
File:wnlgs.ex
Update:Tue Mar 19 08:25:03 1996

70
[LG02021(ALL)02/95]
n
If the driver fastens the safety belt before the ignition is
turned to ON, the chime will not sound and the light will
not illuminate.
[LG02050(ALL)02/95]
n
If the safety belt is buckled while the light is on and the
chime is sounding, both the light and the chime turn off.
[LG02100(ALL)11/93]
6 pica art:0050148-B
The safety belt warning light
%*
[LG02200(ALL)03/95]
Check Engine Warning Light
*
[LG02301(ALL)05/95]
The Powertrain On-Board Diagnostic II (OBD II) system consists
of the hardware and software necessary to monitor the
operation of the powertrain. The OBD II system is designed to
check the function of the vehicle's powertrain control system
during normal operation. If an emission problem is detected, the
Check Engine Warning Light (in the cluster) is turned on.
[LG02400(ALL)11/93]
6 pica art:0050065-B
The check engine warning light
*
[LG02410(ALL)05/95]
Modification or additions to the vehicle may cause incorrect
operation of the OBD II system. Additions such as burglar
alarms, cellular phones, and CB radios must be carefully
installed. Do not install these devices by tapping into or running
wires close to powertrain control system wires or components.
File:wnlgs.ex
Update:Tue Mar 19 08:25:03 1996
