Warning Lights and Gauges
85
%*
[LG10861(ALL)01/95]
Air Bag Readiness Light
[LG10871(ALL)11/93]
This light indicates that the Air Bag system is not functional
and needs to be serviced. The light illuminates for
approximately six seconds when the ignition is turned to the
ON position to verify that the indicator bulb is working. If the
light fails to illuminate, flashes continuously, or remains on,
have the air bag system serviced as soon as possible.
[LG10881(ALL)11/93]
6 pica art:0050153-B
The air bag readiness light
%*
[LG10901(ALL)01/95]
Charging System Light
[LG10911(ALL)11/93]
This light indicates that your battery is not being charged. The
light comes on briefly during the display self-test every time
you turn your ignition key to the ON position. The light will go
off when the key is turned to the START position. The light
should stay off when the self-test is done if the engine is
running and the alternator is charging.
*
[LG10913(ALL)01/95]
If the light stays on or comes on when the engine is running,
have the electrical system checked as soon as possible.
[LG10915(ALL)11/93]
6 pica art:0050149-B
The charging system light
File:wnlgs.ex
Update:Tue Mar 19 08:25:03 1996
Page 88 of 394
![FORD WINDSTAR 1996 1.G Owners Manual 86
%*
[LG10921(ALL)03/95]
Check Engine Warning Light
[LG10932(ALL)02/95]
The Powertrain On-Board Diagnostic II (OBD II) system consists
of the hardware and software necessary to monitor the
operation FORD WINDSTAR 1996 1.G Owners Manual 86
%*
[LG10921(ALL)03/95]
Check Engine Warning Light
[LG10932(ALL)02/95]
The Powertrain On-Board Diagnostic II (OBD II) system consists
of the hardware and software necessary to monitor the
operation](/manual-img/11/5410/w960_5410-87.png)
86
%*
[LG10921(ALL)03/95]
Check Engine Warning Light
[LG10932(ALL)02/95]
The Powertrain On-Board Diagnostic II (OBD II) system consists
of the hardware and software necessary to monitor the
operation of the powetrain. The OBD II system is designed to
check the function of the vehicle's powertrain control system
during normal operation. If an emission problem is detected, the
Check Engine Warning Light (in the cluster) is turned on.
[LG10941(ALL)11/93]
6 pica art:0050065-B
The check engine warning light
*
[LG10949(ALL)05/95]
Modification or additions to the vehicle may cause incorrect
operation of the OBD II system. Additions such as burglar
alarms, cellular phones, and CB radios must be carefully
installed. Do not install these devices by tapping into or running
wires close to powertrain control system wires or components.
[LG10955(ALL)02/95]
The light comes on briefly when you turn the ignition key to
ON, but it should turn off when the engine starts. If the light
does not come on when you turn the ignition to ON or if it
comes on and stays on when you are driving, have your vehicle
serviced as soon as possible. This indicates a possible problem
with one of the vehicle's emission control systems. You do not
need to have your vehicle towed in.
*
[LG10960(ALL)05/95]
If the light turns on and off at one (1) second intervals while
you are driving the vehicle, it means that the engine is
misfiring. If this condition persists, damage could occur to the
engine or catalytic convertor. Have your vehicle serviced at the
first opportunity. You do not need to have your vehicle towed
in.
File:wnlgs.ex
Update:Tue Mar 19 08:25:03 1996
Page 90 of 394
88
% [LG10971(ALL)02/95]
Anti-lock Brake System (ABS) Warning Light
*
[LG10975(ALL)12/93]
To check the anti-lock brake warning light, turn the ignition key
to the ON position. The ABS warning light should glow
momentarily.
*
[LG10981(ALL)10/93]
NOTE: If it does not glow at all or stays on for a long time,
have your vehicle's electrical system checked
immediately.
[LG10985(ALL)11/93]
6 pica art:0050147-B
The anti-lock brake warning light
*
[LG10991(ALL)05/95]
RWARNING
If the anti-lock brake system warning light remains on or
comes on while driving, have the braking system checked
by a qualified service technician as soon as possible.
[LG10995(ALL)06/95]
NOTE: If a fault occurs in the anti-lock system, and the brake
warning light is not lit, the anti-lock system is
disabled but normal brake function remains
operational.
File:wnlgs.ex
Update:Tue Mar 19 08:25:03 1996
Page 92 of 394
90
%*
[LG11111(ALL)01/93]
Door Ajar Warning Light
*
[LG11121(ALL)08/94]
If the ignition switch is in the ON position and any door or the
liftgate is not completely closed, the light will illuminate.
[LG11126(ALL)06/94]
If the light illuminates, safely stop the vehicle and check and
close all doors until the light turns off.
[LG11131(ALL)11/93]
6 pica art:0050151-B
The door ajar warning light
%*
[LG11231(ALL)01/95]
High Beam Light
[LG11241(ALL)10/93]
This light comes on when the headlamps are turned to high
beam or when the high beams are flashed. If your vehicle is
equipped with Daytime Running Lights (Canadian vehicles
only) and the headlamps are on when the high beams are
flashed, the high beam indicator will not light.
[LG11251(ALL)11/93]
6 pica art:0050154-B
The high beam indicator light
File:wnlgs.ex
Update:Tue Mar 19 08:25:03 1996
Page 93 of 394
![FORD WINDSTAR 1996 1.G Owners Manual Warning Lights and Gauges
91
% [LG11255(ALL)03/94]
Low Windshield Washer Fluid Level Warning Light
[LG11257(ALL)11/93]
This light indicates that the level of your washer fluid is low,
and you have to FORD WINDSTAR 1996 1.G Owners Manual Warning Lights and Gauges
91
% [LG11255(ALL)03/94]
Low Windshield Washer Fluid Level Warning Light
[LG11257(ALL)11/93]
This light indicates that the level of your washer fluid is low,
and you have to](/manual-img/11/5410/w960_5410-92.png)
Warning Lights and Gauges
91
% [LG11255(ALL)03/94]
Low Windshield Washer Fluid Level Warning Light
[LG11257(ALL)11/93]
This light indicates that the level of your washer fluid is low,
and you have to add more fluid. This light comes on briefly
after you turn your ignition key from the START to the ON
position. If the washer fluid is low, a one second chime will
sound and the light will remain on for 60 seconds. If the washer
fluid is not low, the light should turn off a few seconds after
the engine has started. The light and chime also come on if the
washer fluid is low when you use your windshield washers.
[LG11258(ALL)03/94]
The washer fluid is only checked when the engine is started or
the windshield washers are in operation. The light will not
come on if the fluid level becomes low while you are driving
unless you turn on the windshield washers.
[LG11260(ALL)12/93]
6 pica art:0050062-B
The low windshield washer indicator light
*
[LG11265(ALL)06/95]
Speed Control Indicator
[LG11270(ALL)05/95]
A SPEED CONTROL light is displayed in the optional electronic
instrument cluster when the speed control system is engaged.
The display will turn off when the brake pedal is pressed or if
speed control is shut off.
*
[LG11275(ALL)05/95]
This display does not indicate any problems with the speed
control, but is simply a convenient way of knowing when it is
active.
File:wnlgs.ex
Update:Tue Mar 19 08:25:03 1996
Page 95 of 394
![FORD WINDSTAR 1996 1.G Owners Manual Warning Lights and Gauges
93
% [LG11351(ALL)10/93]
Hazard Flasher Indicator Light
[LG11371(ALL)03/94]
This light flashes when you turn on the hazard flashers. If your
ignition is ON, the turn signal i FORD WINDSTAR 1996 1.G Owners Manual Warning Lights and Gauges
93
% [LG11351(ALL)10/93]
Hazard Flasher Indicator Light
[LG11371(ALL)03/94]
This light flashes when you turn on the hazard flashers. If your
ignition is ON, the turn signal i](/manual-img/11/5410/w960_5410-94.png)
Warning Lights and Gauges
93
% [LG11351(ALL)10/93]
Hazard Flasher Indicator Light
[LG11371(ALL)03/94]
This light flashes when you turn on the hazard flashers. If your
ignition is ON, the turn signal indicator lights in the electronic
cluster will flash in time with the hazard flashers.
[LG11385(ALL)08/94]
6 pica art:0050237-A[LG11400(ALL)10/93]
Electronic Gauges
%*
[LG11500(ALL)01/95]
Engine Coolant Temperature Gauge
[LG11550(ALL)06/94]
7-1/2 pica art:0050175-B
Engine coolant temperature gauge
[LG11600(ALL)02/94]
This gauge indicates the temperature of the engine's coolant, not
the coolant level. If the coolant is not at its proper level or
mixture, the gauge indication will not be accurate. The gauge is
identified by a thermometer symbol, an ªHº (hot), and a ªCº
(cold). The ªNORMº indicates the normal operating range. The
bars will move into the normal operating range as the engine
coolant warms up. It is acceptable for the bars to fluctuate
within the normal operating range under normal driving
conditions. Under certain driving conditions, such as heavy stop
and go traffic, or driving up hills in hot weather, the gauge may
File:wnlgs.ex
Update:Tue Mar 19 08:25:03 1996
Page 96 of 394
![FORD WINDSTAR 1996 1.G Owners Manual 94indicate at the top of the NORMAL band. This is also
acceptable.
[LG11700(ALL)04/95]
If, under any circumstances, the bars move above the NORMAL
band, the temperature symbol will flash and a chime w FORD WINDSTAR 1996 1.G Owners Manual 94indicate at the top of the NORMAL band. This is also
acceptable.
[LG11700(ALL)04/95]
If, under any circumstances, the bars move above the NORMAL
band, the temperature symbol will flash and a chime w](/manual-img/11/5410/w960_5410-95.png)
94indicate at the top of the NORMAL band. This is also
acceptable.
[LG11700(ALL)04/95]
If, under any circumstances, the bars move above the NORMAL
band, the temperature symbol will flash and a chime will sound
to alert the driver that the engine coolant is overheating and
continued operation may cause engine damage.
*
[LG11800(ALL)01/95]
If your engine coolant overheats:
*
[LG11900(ALL)03/95]1.
Pull off the road as soon as it is safely possible.
*
[LG12000(ALL)03/95]2.
Turn off the engine. If you do not stop the engine as soon as
safely possible, severe engine damage could result.
*
[LG12100(ALL)05/95]3.
Let the engine cool.DO NOT REMOVE COOLANT
SYSTEM FILL CAP UNTIL THE ENGINE IS COOL.
[LG12200(ALL)11/93]4.
Check the coolant level following the instructions on
checking and adding coolant to your engine in this Owner
Guide. Seeengine coolantin the index. If you do not follow
these instructions, you or others could be injured.
*
[LG12300(ALL)01/95]
If the coolant continues to overheat, have the coolant system
serviced.
[LG12400(ALL)06/94]
If the temperature gauge displays only the top two and bottom
two bars, the temperature indication system is indicating that it
requires servicing. Take the vehicle to a dealership for service as
soon as possible.
%*
[LG12600(ALL)01/95]
Fuel Gauge
[LG12700(ALL)03/94]
The fuel gauge displays approximately how much fuel you have
in the fuel tank. The number of bars illuminated in the display
indicates fuel level. Your ignition must be in the ON position to
read the fuel gauge. Read the fuel level at the top bar that is lit.
When only one bar on the gauge is lit, the fuel pump symbol
on the gauge will flash to warn you of a low fuel level
condition.
File:wnlgs.ex
Update:Tue Mar 19 08:25:03 1996
Page 97 of 394
![FORD WINDSTAR 1996 1.G Owners Manual Warning Lights and Gauges
95
[LG12800(ALL)10/93]
If the fuel gauge displays only the top two bars and bottom two
bars, or if the Distance to Empty function in the fuel computer
displays CO or CS, you FORD WINDSTAR 1996 1.G Owners Manual Warning Lights and Gauges
95
[LG12800(ALL)10/93]
If the fuel gauge displays only the top two bars and bottom two
bars, or if the Distance to Empty function in the fuel computer
displays CO or CS, you](/manual-img/11/5410/w960_5410-96.png)
Warning Lights and Gauges
95
[LG12800(ALL)10/93]
If the fuel gauge displays only the top two bars and bottom two
bars, or if the Distance to Empty function in the fuel computer
displays CO or CS, you must have the fuel indication system
serviced.
[LG12900(ALL)10/93]
Turn your ignition to OFF while fueling to obtain an accurate
fuel gauge indication. If you do not turn your ignition off, the
fuel gauge will not display the new fuel level immediately, but
will slowly increase to the correct value.
[LG13000(ALL)03/94]
7-1/2 pica art:0050156-B
The fuel gauge
%*
[LG13100(ALL)01/95]
Speedometer
[LG13200(ALL)08/94]
The electronic speedometer in the left center of the cluster has
two displays that indicate how fast your vehicle is moving in
miles or kilometers per hour. Press the fuel computer E/M
(English/Metric) button to switch between MPH and km/h. The
main digital speedometer indicates speed up to 120 MPH
(199 km/h). The secondary bar graph speedometer indicates
approximate speed up to 120 MPH in steps of 4 MPH
(180 km/h in steps of 6 km/h). The bar graph speedometer
shows your approximate speed relative to the full scale, and it
gives you a visual indication of how fast your speed is changing
when you accelerate or decelerate.
[LG13300(ALL)10/93]
Your vehicle may not actually be able to travel at the maximum
speeds indicated by the speedometer due to a speed limiter in
the Electronic Engine Control module. The purpose of the
limiter is to maintain vehicle speed below a specified limit to
ensure safe vehicle operation.
File:wnlgs.ex
Update:Tue Mar 19 08:25:03 1996
