1996 FORD WINDSTAR ignition

Features
155
[FV09540(ALL)05/95]
n
the ignition key is turned to the ON position
[FV09545(ALL)05/95]
n
the brake pedal is pressed
[FV09550(ALL)05/95]
n
you shift through R (Reverse)
[FV09555(ALL)05/95]
n
the brake pedal is released
[FV09560(ALL)05/95]
The Autolock feature will repeat when:
[FV09565(ALL)05/95]
n
a door is opened and then all doors and the liftgate are
closed
[FV09570(ALL)05/95]
n
the brake pedal is released
[FV09575(ALL)05/95]
On vehicles with Keyless Entry, you can deactivate the system
by using the buttons for the keyless entry system if you do not
want to use the Autolock feature.
[FV09580(ALL)05/95]
The doors may not lock automatically at the correct time if the
driver:
[FV09585(ALL)05/95]
n
shifts through gears without pressing the brake
[FV09590(ALL)05/95]
n
shifts through gears quickly after starting the vehicle
[FV09595(ALL)05/95]
n
releases their foot from the brake while someone has stepped
out of the vehicle for a moment
[FV09600(ALL)05/95]
To deactivate the Autolock system:
[FV09605(ALL)05/95]1.
Enter your permanent five-digit entry code (not the user
code you may have set).
[FV09610(ALL)05/95]2.
Within five seconds, press and hold 7/8.
[FV09615(ALL)05/95]3.
Within five more seconds, press and release 3/4.
[FV09620(ALL)05/95]4.
Release 7/8.
[FV09625(ALL)05/95]
To reactivate the Autolock system, simply repeat the instructions
for deactivating the system. By re-entering the code that
deactivates the Autolock, the keyless entry system reinstates the
Autolock feature.
File:wnfvs.ex
Update:Tue Mar 19 08:21:54 1996

156
% [FV09630(ALL)05/95]
Anti-Theft System (if equipped)
*
[FV09635(ALL)05/95]
When armed, this system helps protect your vehicle against
break-ins or theft.
%*
[FV09640(ALL)05/95]
When an unauthorized entry occurs, the system triggers and
will:
*
[FV09645(ALL)05/95]
n
flash the headlamps, parking lamps, and alarm indicator
lamp
*
[FV09650(ALL)05/95]
n
honk the horn
*
[FV09655(ALL)05/95]
n
disable the starting circuit to prevent the vehicle from being
started
%*
[FV09660(ALL)05/95]
Arming the system
*
[FV09665(ALL)05/95]1.
Remove the key from the ignition. The hood must be closed
to arm the system.
*
[FV09670(ALL)05/95]2.
Open any door. The alarm indicator light will start flashing
to remind you to arm the system.
*
[FV09675(ALL)05/95]3.
Lock the doors by using the power door lock switch. The
alarm indicator light will now glow steadily.
[FV09680(ALL)05/95]4.
Close all doors. The alarm indicator light will then remain
on steadily for 30 seconds and then go out. When the light
goes out, the system is armed.
*
[FV09685(ALL)05/95]
NOTE: Be sure to close all doors completely. If not, the alarm
indicator light will remain on. Remember, your
anti-theft system is armed only after the alarm
indicator light remains on steadily for approximately
30 seconds after the last door is closed, and then goes
out.
*
[FV09690(ALL)05/95]
You can also arm the anti-theft system with the factory installed
remote entry system or the keyless entry system by following
this sequence:
File:wnfvs.ex
Update:Tue Mar 19 08:21:54 1996

Features
157
*
[FV09695(ALL)05/95]1.
Remove the key from the ignition. The hood must be closed
to arm the system
*
[FV09700(ALL)05/95]2.
Close all of the doors.
[FV09705(ALL)05/95]3.
Press the remote entry transmitter LOCK button or use the
keyless entry system by pressing 7/8 and 9/0 at the same
time. The alarm indicator will come on for 30 seconds to
show the alarm is arming and then turn off to show that it
has armed.
[FV09710(ALL)05/95]
The anti-theft system is designed to work with the factory
installed remote keyless entry system. It may not work with
other remote entry systems.
%*
[FV09715(ALL)05/95]
Disarming an untriggered anti-theft system
[FV09720(ALL)05/95]
You can disarm the system by unlocking either front door or
the liftgate with your door key. Turn the key all the way to the
end of travel or the system will not disarm.
[FV09725(ALL)05/95]
You can also disarm the system by unlocking the driver's door
by using the UNLOCK button of the remote entry transmitter or
by using the five-digit unlock code on the keyless entry system
keypad.
*
[FV09731(ALL)04/95]
If the system is armed and you remain in your vehicle, simply
insert the key into the ignition and turn it to ON. This disarms
the system and allows you to open the door and exit without
triggering the system.
%*
[FV09791(ALL)05/95]
Disarming a triggered system
*
[FV09801(ALL)05/95]
The alarm can be disarmed by:
*
[FV09811(ALL)04/95]
n
unlocking any door with the key, or
*
[FV09821(ALL)05/95]
n
using the UNLOCK button of the remote entry transmitter
[FV09825(ALL)11/93]
n
using the five-digit unlock code on the keyless entry keypad
File:wnfvs.ex
Update:Tue Mar 19 08:21:54 1996

160
%*
[FV10050(ALL)02/95]
Windows
[FV10300(ALL)10/93]
Power Windows with Accessory Delay (If equipped)
[FV10400(ALL)11/93]
Both of the front doors have a power control that opens and
closes the window on that door. The driver's door has master
controls that operate both front door windows. You must
initially place the ignition switch in the ON or ACC position to
use your power window controls. The Accessory Delay function
also allows the power windows to be operated for up to 30
seconds after the ignition key is removed or taken out of the
ON or ACC position. Accessory Delay will be cancelled,
however, if either of the front doors are opened.
[FV10500(ALL)03/94]
To open a window, press the recessed area of the switch. To
close it, press the raised area of the switch.
*
[FV10600(ALL)05/95]
RWARNING
Do not let children play with the power windows. They
may seriously hurt themselves. Make sure occupants are
clear of the window(s) before closing.
[FV10700(ALL)11/93]
10-1/2 pica
art:0050030-B
The power window switches
File:wnfvs.ex
Update:Tue Mar 19 08:21:54 1996

Features
161
[FV10800(ALL)03/94]
One-Touch-Down Power Window (If equipped)
[FV10900(ALL)12/93]
The one-touch-down power window feature allows you to
completely open the driver's window without holding down the
window switch. To open the window completely, tap quickly on
the lower half of the switch and release it. If the top of the
button is pressed firmly while the window is going down, the
window will stop at that position.
*
[FV11000(ALL)07/93]
To open the window only partially, press the lower half of the
switch lightly and hold it until the window has opened to the
desired position and then release the switch.
*
[FV11100(ALL)01/93]
To close the window you must hold the upper half of the
button until the window closes.
[FV11120(ALL)03/94]
Cancelling and reactivating the one-touch-down feature
[FV11130(ALL)06/94]
The one-touch-down power window feature can be cancelled
and reactivated at any time using the following procedure:
[FV11140(ALL)12/93]1.
Make sure the two front doors are securely closed.
[FV11150(ALL)12/93]2.
Insert the key into the ignition and turn first to the ON
position and then back to the OFF position. Remove the key
and within 30 seconds:
[FV11160(ALL)12/93]3.
Press and hold the DOWN side of the driver's side window
rocker switch.
[FV11170(ALL)12/93]4.
Within two seconds, put the key in the ignition.
[FV11180(ALL)12/93]5.
Hold the switch down until a long (two second) tone is
heard. Release the switch while the tone is active.
[FV11190(ALL)12/93]6.
After the long tone, a confirmation sequence will be heard.
One beep indicates the feature is inactive. Two beeps
indicates the feature is active.
[FV11195(ALL)12/93]
Repeat this procedure any time you want to cancel or reactivate
the one-touch-down power window feature.
File:wnfvs.ex
Update:Tue Mar 19 08:21:54 1996

162
*
[FV11200(ALL)01/93]
Manual Flip-Open Quarter Windows
[FV11300(ALL)06/94]
To open the flip-open quarter windows in the third row,
squeeze the upper and lower pads and pull the rear portion of
the latch toward you. Swing the latch forward and out, then
lock it into the open position by pushing rearward until you
hear a click. To close the windows, squeeze the upper and
lower pads and pull the handle inward. Release pads and push
the handle inward until you hear a click.
[FV11400(ALL)10/93]
13-1/2 pica
art:0050083-A
Manual flip-open quarter window latch location
*
[FV11600(ALL)09/93]
Power Quarter Windows (If equipped)
[FV11701(ALL)03/94]
The power rear quarter vent windows operate with the ignition
in the ON or ACC positions. The vent windows are controlled
by the right and left switches located in the center of the
instrument panel, just to the right of the rear defogger. Press the
indented side of the switch to open the windows; press the
raised side of the switch to close the windows.
File:wnfvs.ex
Update:Tue Mar 19 08:21:54 1996

196
%*
[AS01175(ALL)04/95]
Compact Disc Radio
*
[AS01250(ALL)05/95]
The Compact Disc Radio combines the Electronic Stereo Radio
with the Ford Compact Disc Player.
*
[AS01300(ALL)04/95]
Using the Controls on Your New Radio/CD Player
*
[AS01400(ALL)04/92]
Most of the features of this unit work for both radio and CD
operation, depending on which mode the unit is in. Also, some
of the buttons control several different functions, so be sure to
read all of the operating instructions carefully.
*
[AS01500(ALL)04/95]
How to turn the radio on and off
*
[AS01600(ALL)04/95]
Press the ªPOWERº button to turn the radio on. Press it again
to turn it off.
*
[AS01625(ALL)04/95]
How to adjust the volume
*
[AS01650(ALL)05/95]
Press the (+/±) side of the ªVOLº button to increase/decrease
the volume. Bars illuminate in the display to show the relative
volume level.
*
[AS01675(ALL)04/95]
NOTE: If the volume level is set above a certain listening
level when the ignition switch is turned off, when the
ignition switch is turned back on, the volume will
come back to a ªnominalº listening level. However, if
the radio power is turned off (with the ªPOWERº
button), the volume will remain in the position it was
set at when radio power is switched back on.
*
[AS01700(ALL)04/95]
Selecting the AM or FM frequency band
*
[AS01800(ALL)04/95]
Push the ªAM/FMº button to select the desired frequency band.
When in the radio mode, pushing the button more than once
will alternate between AM, FM1 and FM2. These functions are
used with the station memory buttons described underHow to
tune radio stations.
File:wnass.ex
Update:Tue Mar 19 08:19:39 1996

Electronic Sound Systems
201
*
[AS05800(ALL)04/95]
When in the CD mode, push the ªCLOCKº button to change
the display from elapsed time mode to track number mode to
clock mode. If the CD track selection is changed when you are
in the clock or elapsed time mode, the new track number will
be displayed for approximately ten seconds and then revert
back to the previous mode.
*
[AS05900(ALL)04/95]
To set the clock, simultaneously press the ªCLOCKº button and
either the bottom (
b) half of the ªSEEKº button to set hours,
or the top (
a) half of the ªSEEKº button to set minutes.
*
[AS06000(ALL)05/94]
NOTE: The clock can be set with the radio and/or ignition on
or off.
%*
[AS07000(ALL)04/95]
Using the Controls on Your New Compact Disc Player
*
[AS07100(ALL)04/95]
Your new Ford Compact Disc Player is capable of playing 12
cmor8 cm discs, without an adapter! The Player operates when
the power is on and a disc is inserted (label side up). Handle
the disc by its edge only. (Be sure to read and follow all of the
care and cleaning instructions underHow To Take Care of and
Clean Your CD Player and Discs.
[AS07200(ALL)11/93]
NOTE: If after you insert a disc, the disc is ejected and
ªERRORº begins scrolling in the display, remove the
disc and reinsert it right side up (label side up).
*
[AS07300(ALL)04/95]
The digital display on your CD player will either show the
track (selection) number or the elapsed time. (The display mode
can be selected by pressing the ªCLOCKº button.) Indicators for
play (
a), stop (
X) and compression on (ªCº) are also in the
display. (These features are described later.)
*
[AS07400(ALL)04/95]
Once a disc is inserted, operation of the CD player will override
that of the radio.
[AS07500(ALL)11/93]
NOTE: The volume, bass, treble, balance and fader controls
on the radio are also used with the CD player. Refer
to earlier operating instructions on these controls.
File:wnass.ex
Update:Tue Mar 19 08:19:39 1996
