Anti-Theft Active Indicator Light
[LG18900(ALL)03/94]
This indicator is used in the optional Anti-Theft System. See
ªAnti-Theft Systemº in theFeatureschapter of this Owner
Guide.
[LG18950(ALL)11/93]
6 pica art:0050123-B
The anti-theft active indicator light
[LG19000(ALL)08/94]
Air Suspension Warning Light
[LG19050(ALL)08/94]
6 pica art:0050227-A
The air suspension warning light
[LG19100(ALL)08/94]
The warning light for the Air Suspension indicates one of two
things:
[LG19150(ALL)08/94]1.
The service switch (located in the jack storage area) is in the
ªoffº position.
[LG19200(ALL)08/94]2.
A system malfunction has occurred electronically disabling
Air Suspension function.
[LG19250(ALL)08/94]
NOTE: If the switch is returned to or in the ªONº position
and the light does not go out after recycling the
ignition switch OFF/ON, the Air Suspension should
be checked by a qualified service technician.
File:wnlgs.ex
Update:Tue Mar 19 08:25:03 1996

Driving Your Windstar
251
*
[DR15500(ALL)01/93]
Payload
*
[DR15600(ALL)07/93]
Maximum payload is the combined, maximum allowable weight
of cargo, occupants and optional equipment that the vehicle is
designed to carry. It is the Gross Vehicle Weight Rating minus
the base curb weight.
*
[DR15700(ALL)01/93]
Gross Vehicle Weight (GVW)
*
[DR15800(ALL)09/93]
The Gross Vehicle Weight (GVW) is the total weight of the
passengers, cargo and all equipment.
*
[DR15900(ALL)12/93]
It is important to remember that GVW is not a limit or a
specification, but actual weight. If an owner loads up the vehicle
and weighs it, that's the GVW at that moment. If the owner
adds on more of a load and weighs it again, that becomes the
GVW.
%*
[DR16000(ALL)03/91]
Gross Vehicle Weight Rating (GVWR)
[DR16100(ALL)06/94]
To avoid overloading your vehicle, never exceed the specified
Gross Vehicle Weight Rating for your vehicle. The GVWR is the
maximum allowable weight of the vehicle when fully loaded
including passengers, cargo and all equipment.
%*
[DR16200(ALL)01/93]
Gross Axle Weight Rating (GAWR)
*
[DR16300(ALL)01/93]
We have all seen a car or a truck that is loaded down in the
rear and riding high in the front. This is a dangerous condition
that usually means that the rear suspension components are
under severe strain and that vehicle handling is impaired. There
is more to carrying a load than just payload or GVWR.
[DR16400(ALL)12/93]
Your Safety Compliance Certification Label not only gives the
GVWR, it also gives the Gross Axle Weight Rating (GAWR)
which is the maximum weight allowed on the axle system.
File:wndrs.ex
Update:Tue Mar 19 08:18:48 1996

Roadside Emergencies
271
*
[RE07300(ALL)01/93]
RWARNING
If the vehicle slips off the jack, you or someone else
could be seriously injured.
*
[RE07350(ALL)05/95]
RWARNING
On vehicles equipped with Air Suspension, turn OFF the
Air Suspension switch prior to jacking, hoisting or
towing your vehicle.
[RE07400(ALL)10/93]2.
Get out the spare tire and jack. See previous section for
instructions on spare tire removal. The jack is located in the
rear storage compartment in the right door panel of the
cargo area. Remove wing bolt to unfasten jack.
[RE07500(ALL)06/94]
17-1/2 pica
art:0050043-C
Jack storage
