1996 FORD WINDSTAR turn signal

Warning Lights and Gauges
75
%*
[LG06100(ALL)04/95]
Turn Signal Indicator Lights
[LG06150(ALL)12/93]
See ªTurn Signalsº in theSteering Column Controlschapter of
this Owner Guide.
[LG06200(ALL)12/93]
6 pica art:0050190-A
The turn signal indicator lights
[LG06250(ALL)03/94]
If one or both of your turn signal indicators does not light up
or remains on continuously when you signal a turn, have the
turn signaling system serviced as soon as possible.
%*
[LG06400(ALL)01/95]
High Beam Light
[LG06500(ALL)10/93]
This light comes on when the headlamps are turned to high
beam or when the high beams are flashed. If your vehicle is
equipped with Daytime Running Lights (Canadian vehicles
only) and the headlamps are on when the high beams are
flashed, the high beam indicator will not light.
[LG06600(ALL)11/93]
6 pica art:0050154-B
The high beam indicator light
File:wnlgs.ex
Update:Tue Mar 19 08:25:03 1996

Warning Lights and Gauges
83
%*[LG9580(ALL)09/93]
Electronic Cluster (If Equipped)
[LG09600(ALL)03/94]
The Electronic Cluster works only when your ignition is in the
ON position. Each time you start your vehicle, the displays go
through a self-test by lighting up all segments for about one
second and then turning off all segments for about one second,
before displaying actual gauge readings. (The turn signal and
high beam indicators do not light during the self-test. The LOW
OIL light may remain on throughout the self-test and for several
seconds after normal readings are displayed.) This self-test
demonstrates that all of the display segments are working
properly.
[LG09620(ALL)03/94]
The electronic cluster has three major functions to provide you
with information about your vehicle's operating status:
[LG09650(ALL)10/93]
n
Warning and Indicator Lights
[LG09661(ALL)10/93]
n
Electronic Gauges
[LG09670(ALL)12/93]
n
The Fuel Computer
[LG10801(ALL)12/93]
Warning and Indicator Lights
%*
[LG10820(ALL)02/95]
Safety Belt Warning Light and Chime
*
[LG10823(ALL)03/95]
This warning light and chime remind you to fasten your safety
belt. The following conditions will take place:
[LG10826(ALL)02/95]
n
If the driver does not fasten the safety belt before the
ignition is turned to ON, the chime will sound for four (4) to
eight (8) seconds and the light will illuminate for one (1) to
two (2) minutes, or until the safety belt is fastened.
[LG10829(ALL)02/95]
n
If the driver fastens the safety belt before the ignition is
turned to ON, the chime will not sound and the light will
not illuminate.
[LG10832(ALL)02/95]
n
If the safety belt is buckled while the light is on and the
chime is sounding, both the light and the chime turn off.
File:wnlgs.ex
Update:Tue Mar 19 08:25:03 1996

92
[LG11285(ALL)12/93]
6 pica art:0050220-A
The speed control light
%*
[LG11301(ALL)04/95]
Turn Signal Indicator Lights
[LG11310(ALL)12/93]
See ªTurn Signalsº in theSteering Column Controlschapter of
this Owner Guide.
[LG11320(ALL)12/93]
6 pica art:0050190-A
The turn signal indicator lights
[LG11331(ALL)03/94]
If one or both of your turn signal indicators does not light up
or remains on continuously when you signal a turn, have the
turn signaling system serviced as soon as possible.
File:wnlgs.ex
Update:Tue Mar 19 08:25:03 1996

Warning Lights and Gauges
93
% [LG11351(ALL)10/93]
Hazard Flasher Indicator Light
[LG11371(ALL)03/94]
This light flashes when you turn on the hazard flashers. If your
ignition is ON, the turn signal indicator lights in the electronic
cluster will flash in time with the hazard flashers.
[LG11385(ALL)08/94]
6 pica art:0050237-A[LG11400(ALL)10/93]
Electronic Gauges
%*
[LG11500(ALL)01/95]
Engine Coolant Temperature Gauge
[LG11550(ALL)06/94]
7-1/2 pica art:0050175-B
Engine coolant temperature gauge
[LG11600(ALL)02/94]
This gauge indicates the temperature of the engine's coolant, not
the coolant level. If the coolant is not at its proper level or
mixture, the gauge indication will not be accurate. The gauge is
identified by a thermometer symbol, an ªHº (hot), and a ªCº
(cold). The ªNORMº indicates the normal operating range. The
bars will move into the normal operating range as the engine
coolant warms up. It is acceptable for the bars to fluctuate
within the normal operating range under normal driving
conditions. Under certain driving conditions, such as heavy stop
and go traffic, or driving up hills in hot weather, the gauge may
File:wnlgs.ex
Update:Tue Mar 19 08:25:03 1996

129
Steering Column Controls
*
[SC00900(ALL)01/95]
The controls on the steering column and wheel are designed to
give you easy access to the controls while you are driving.
*
[SC01000(ALL)01/93]
Turn Signal Lever
*
[SC01100(ALL)01/95]
You can use the turn signal lever on the left side of the steering
column to:
*
[SC01200(ALL)01/93]
n
operate the turn signals.
*
[SC01300(ALL)01/93]
n
turn the headlamps to high beam.
*
[SC01400(ALL)01/93]
n
flash the headlamps.
*
[SC01500(ALL)01/93]
n
turn the windshield wipers and washer on/off.
%*
[SC01600(ALL)01/95]
Turn Signals
[SC01700(ALL)02/95]
To turn on the right turn signal, push the turn signal lever up.
The right-side arrow on the instrument panel will flash.
[SC01800(ALL)02/95]
To turn on the left turn signal, pull the turn signal lever down.
The left-side arrow on the instrument panel will flash.
*
[SC01900(ALL)11/93]
7-1/2 pica art:0040085-D
The turn signal lever
[SC02000(ALL)02/95]
Usually, the turn signals turn off automatically after you turn
your vehicle. If the turn signal continues to flash after you have
made the turn, pull the lever back to the neutral position.
File:wnscs.ex
Update:Tue Mar 19 08:22:27 1996

130
[SC02100(ALL)02/95]
To indicate a lane change to the right, push the turn signal
lever up slightly (without latching) and hold it in position. To
indicate a lane change to the left, pull the turn signal lever
down slightly (without latching) and hold it in position. The
lever will return to the OFF position when you release it.
*
[SC02200(ALL)05/94]
If the turn indicator light in the instrument panel does not
illuminate or remains on (does not flash) when you signal a
turn, the turn signaling system is malfunctioning. Have this
condition corrected as soon as possible, and use the accepted
hand signals until the turn signal system is repaired.
%*
[SC02220(ALL)03/95]
High Beams
*
[SC02226(ALL)01/93]
To turn on the high beams, turn the headlamps on and push
the turn signal lever away from you until it latches. When the
high beams are on, the high beam indicator light on the
instrument panel is illuminated.
*
[SC02230(ALL)01/93]
To return to the low beam setting, pull the turn signal lever
toward you until it latches back into the neutral position. The
high beam indicator light turns off.
*
[SC02235(ALL)11/93]
7-1/2 pica art:0040086-D
High beam and flash-to-pass operation
%*
[SC02700(ALL)05/95]
Flashing the Lights
*
[SC02800(ALL)01/93]
To flash the headlamps, pull the turn signal lever toward you
for a moment and then release it. The high beam headlamps
will flash whether the headlamps are on or off.
File:wnscs.ex
Update:Tue Mar 19 08:22:27 1996

Steering Column Controls
131
%*
[SC03100(ALL)03/95]
Windshield Wipers and Washer
%*
[SC03200(ALL)03/95]
Variable Interval Wipers
[SC03300(ALL)11/93]
Your vehicle has wipers that operate at varying intervals. For
example, you can set the interval so they wipe less often in
light rain or more often in heavier rain. The wiper delays range
from about 1.5 to 20 seconds.
*
[SC03400(ALL)09/93]
10-1/2 pica art:0040087-E
Variable interval wiper control
*
[SC03500(ALL)01/93]
To set the interval wipers, rotate the knob at the end of the turn
signal lever to the most effective interval. The farther the knob
is from the OFF position, the faster the wipers move.
[SC03510(ALL)12/93]
Speed Dependent Wipers
[SC03520(ALL)01/95]
This feature compensates for the extra moisture that
accumulates on your windshield at higher speeds during rain.
At higher speeds, the Speed Dependent feature shortens the
delay between wipes when you use the variable interval wipers.
Delay will automatically adjust at speeds between 10 and
65 mph (16 and 105 km/h).
File:wnscs.ex
Update:Tue Mar 19 08:22:27 1996

132
[SC03530(ALL)12/93]
The Speed Dependent feature comes disabled from the factory,
but can be activated at any time by using the following
procedure.
[SC03560(ALL)12/93]1.
Make sure the two front doors are securely closed.
[SC03570(ALL)04/95]2.
Insert the key into the ignition and turn first to the ON
position (the gauges on the instrument panel willnot
illuminate) and then back to the OFF position. Remove the
key and within 30 seconds:
[SC03575(ALL)12/93]3.
Press and hold the washer button on the end of the turn
signal lever.
[SC03580(ALL)04/95]4.
Within two seconds, put the key back in the ignition and
turn to the ON position.
[SC03585(ALL)06/94]5.
Hold the washer button down until a long (two second) tone
is heard. Release the button while the tone is active.
[SC03591(ALL)12/93]6.
After the long tone, a confirmation sequence will be heard.
One beep indicates the feature is inactive. Two beeps
indicates the feature is active.
[SC03595(ALL)12/93]
Repeat this procedure any time you want to cancel or reactivate
the Speed Dependent feature.
*
[SC03600(ALL)04/95]
Windshield Washer
[SC03700(ALL)08/94]
To clean the windshield, push in the washer button on the end
of the turn signal lever. For a constant spray, push and hold the
button. If the windshield wipers are off, one momentary push
results in one wipe and a longer push in three wipes and
activation of washer fluid. If the windshield wipers are in
interval mode a quick tap results in two wipe cycles and a
longer tap in three wipes and washer fluid activation.
*
[SC03800(ALL)01/93]
Do not try to clean the windshield when the washer fluid
container is empty and never activate the washers for more than
fifteen seconds continuously. This could damage the washer
pump system.
File:wnscs.ex
