1996 FORD WINDSTAR engine

Introductory Information
5
*
[IN04800(ALL)12/93]
n
Wheel lug nuts must be retightened to proper torque
specifications at 500 miles/800 km of new vehicle operation.
Proper torque specifications are provided in this guide. Also
retighten to proper torque specification at 500 miles/800 km
after any wheel change or any other time the wheel lug nuts
have been loosened.
%*
[IN04900(ALL)01/95]
n
Use only the type of engine oil that Ford recommends.See
Engine oil recommendationsin the Index. Do not use special
ªbreak-inº oils.
*
[IN05000(ALL)04/95]
Your vehicle is equipped with an Electronic Powertrain Control
Module that limits engine and/or vehicle speeds with a cut-out
mode to promote durability.
%*
[IN05001(ALL)04/95]
Cleaning the Outside of Your Vehicle
%*
[IN05101(ALL)04/95]
Washing and Polishing Your Vehicle
*
[IN05201(ALL)04/95]
Wash the outside of your vehicle, including the underside, with
a mild detergent.
*
[IN05301(ALL)04/95]
DO NOT:
*
[IN05401(ALL)04/95]
n
Wash your vehicle with hot water
*
[IN05501(ALL)04/95]
n
Wash your vehicle while it sits in direct sunlight
*
[IN05600(ALL)04/95]
n
Wash your vehicle while the body is hot
*
[IN05700(ALL)05/95]
Pollen, bird droppings and tree sap can damage the paint,
especially in hot weather. Wash your vehicle as often as
necessary to keep it clean.
*
[IN05800(ALL)05/95]
Take similar precautions if your vehicle is exposed to chemical
industrial fallout.
File:wnins.ex
Update:Tue Mar 19 08:27:16 1996

55
Starting Your Windstar
*
[ST02000(ALL)03/95]
Ignition
%*
[ST02100(ALL)01/95]
Understanding the Positions of the Ignition
*
[ST02300(ALL)09/93]
13-1/2 pica
art:0040047-C
The ignition positions
% [ST02401(ALL)02/94]
ACCESSORY allows you to operate some of your vehicle's
electrical accessories while the engine is not running. For
example, you can use ACCESSORY to turn on the radio or
windshield wipers without starting the engine.
*
[ST02501(ALL)01/93]
LOCK locks the steering wheel and the gearshift lever.
*
[ST02600(ALL)01/93]
OFF allows you to shut off the engine and all accessories
without locking the steering wheel, or the gearshift lever.
*
[ST02701(ALL)01/93]
ON allows you to test your vehicle's warning lights to make
sure they work before you start the engine. The key returns to
the ON position once the engine is started and remains in this
position while the engine runs.
*
[ST02801(ALL)01/93]
START cranks the engine. Release the key once the engine starts
so that you don't damage the starter. The key should return to
the ON position when you release it. The START position also
allows you to test the brake warning light.
File:wnsts.ex
Update:Tue Mar 19 08:25:19 1996

56
%*
[ST03100(ALL)02/95]
Removing the Key From the Ignition
*
[ST03200(ALL)01/93]
LOCK is the only position that allows you to remove the key
from the ignition. The LOCK feature helps to protect your
vehicle from theft, because it also locks the steering wheel and
the gearshift lever when the key is removed.
%*
[ST03300(ALL)01/93]
If your key is stuck in the LOCK position, and you are unable
to turn it, move your steering wheel left or right until the key
turns freely.
*
[ST03400(ALL)01/93]
To remove your key from the ignition:
*
[ST03500(ALL)05/95]1.
Put the gearshift lever in P (Park).
*
[ST03600(ALL)02/95]2.
Set the parking brake fully.
*
[ST03700(ALL)03/95]3.
Turn the ignition key to LOCK.
*
[ST03800(ALL)03/95]4.
Remove the key.
*
[ST03900(ALL)01/93]
RWARNING
When you leave your vehicle, place the gearshift lever in
Park (P). Set the parking brake fully, and shut off the
engine. Never park your vehicle in Neutral (N). If you do
not take these precautions, your vehicle may move
suddenly and injure someone.
*
[ST04100(ALL)01/93]
RWARNING
Do not leave children, unreliable adults, or pets alone in
your vehicle. They could accidentally injure themselves
or others through inadvertent operation of the vehicle.
Further, on hot, sunny days, temperatures in a closed
vehicle could quickly become high enough to cause
severe and possibly fatal injuries to people as well as
animals.
File:wnsts.ex
Update:Tue Mar 19 08:25:19 1996

Starting Your Windstar
57
%*
[ST04200(ALL)03/95]
Fuel-Injected Engines
[ST04300(ALL)02/95]
Since your vehicle has a fuel-injected engine,the most
important thing to remember is to avoid pressing down on the
acceleratorwhile cranking the engine to start. Only use the
accelerator when you have problems getting your vehicle
started. SeeStarting a Cold EngineandStarting a Warm Engine
later in this chapter for details about when to use the
accelerator while you start your vehicle.
%*
[ST04400(ALL)05/94]
Preparing to Start Your Vehicle
[ST04500(ALL)02/95]
RWARNING
Do not start your vehicle in a closed garage or in other
enclosed areas. Exhaust fumes can be toxic. Always open
the garage door before you start the engine. See
Guarding Against Exhaust Fumes in this chapter for more
instructions.
*
[ST04600(ALL)01/93]
Before you start your vehicle, always:
*
[ST04700(ALL)01/93]1.
Make sure you and all your passengers buckle your safety
belts. SeeSafety beltsin the Index for more details.
*
[ST04800(ALL)03/95]2.
Make sure the headlamps and other accessories are turned
off when starting.
[ST04900(ALL)02/95]3.
Make sure that the gearshift lever is in Park (P) and the
parking brake is set before you turn the key.
[ST05100(ALL)02/95]
Before you start your vehicle, you should test the warning lights
on the instrument cluster to make sure that they work. Refer to
theWarning Lights and Gaugeschapter.
File:wnsts.ex
Update:Tue Mar 19 08:25:19 1996

58
[ST05400(ALL)02/95]
Starting the Engine
[ST05500(ALL)02/95]
To start the engine:
[ST05600(ALL)02/95]1.
Follow the steps underPreparing to Start Your Vehicleand
underTesting the Warning Lightsin this section.
*
[ST05700(ALL)01/93]2.
Keep your foot on the brake pedal and turn the ignition key
to ON.
[ST05800(ALL)02/95]3.
DO NOT depress the accelerator pedal when starting your
engine. DO NOT use the accelerator until after the engine is
running and you are ready to drive away.
[ST05900(ALL)02/95]4.
Turn the key to the START position until the engine starts.
(Release the key after the engine has started and it will
return to the ON position.)
[ST06000(ALL)02/95]
If you have difficulty in turning the key, rotate the steering
wheel slightly to relieve any binding.
%*
[ST06600(ALL)04/94]
For a cold engine:
*
[ST06700(ALL)04/95]
n
At temperatures10ÊF (-12ÊC) andbelow:If the engine does
not start infifteen (15) secondson the first try, turn the key
to OFF, wait approximately ten (10) seconds so you do not
flood the engine, then try again.
*
[ST06800(ALL)04/95]
n
At temperaturesabove10ÊF(-12ÊC):If the engine does not
start infive (5) secondson the first try, turn the key to OFF,
wait approximately ten (10) seconds so you do not flood the
engine, then try again.
*
[ST06900(ALL)04/94]
For a warm engine:
*
[ST07000(ALL)04/95]
n
Do not hold the key in the START position for more than
five (5) secondsat a time. If the engine does not start within
five (5) seconds on the first try, turn the key to the OFF
position. Wait a few seconds after the starter stops, then try
again.
File:wnsts.ex
Update:Tue Mar 19 08:25:19 1996

Starting Your Windstar
59
*
[ST07030(ALL)04/95]
Whenever you start your vehicle, release the key as soon as the
engine starts. Excessive cranking could damage the starter or
flood the engine.
*
[ST07060(ALL)02/95]
After you start the engine, let it idle for a few seconds.Keep
your foot on the brake pedaland release the parking brake.
Put the gearshift lever in gear, slowly release the brake pedal
and drive away in the normal manner.
*
[ST07090(ALL)02/95]
NOTE: Your vehicle has an interlock that prevents you from
shifting out of P (Park) unless your foot is on the
brake pedal.
*
[ST07200(ALL)03/95]
If the engine still does not start after two attempts:
*
[ST07300(ALL)03/95]1.
Turn the key to the OFF position and wait about two
minutes.
*
[ST07400(ALL)04/95]2.
Press the accelerator all the way to the floor and hold it.
[ST07500(ALL)02/95]3.
Turn the key to the START position.
[ST07600(ALL)02/95]4.
Release the key when the engine starts.
[ST07700(ALL)02/95]5.
Release the accelerator gradually as the engine speeds up.
Then drive away in the normal manner.
*
[ST07800(ALL)04/95]
If the engine still does not start, the fuel pump shut-off switch
may have been triggered. For directions on how to reset the
switch seeFuel Pump Shut-Off Switchlater in this chapter.
[ST07900(ALL)02/95]
A computer system controls the engine's idle rpm. When you
start your vehicle, the engine's idling rpm normally runs high.
These faster engine speeds will make your vehicle move slightly
faster than when the engine is at its normal warm engine idle
speed. It should, however, slow down when the vehicle warms
up. If it does not, have the idle rpm checked.
File:wnsts.ex
Update:Tue Mar 19 08:25:19 1996

60
*
[ST08100(ALL)05/95]
RWARNING
Do not park, idle, or drive your vehicle in dry grass or
other dry ground cover. The emission system heats up
the engine compartment and exhaust system, which can
start a fire.
%*
[ST08300(ALL)03/95]
Using the Engine Block Heater (If equipped)
(Standard in Canada)
[ST08400(ALL)03/94]
Using your engine block heater is strongly recommended if you
live in a region where temperatures consistently reachs20ÊF
(s29ÊC) orbelow during the winter months. An engine block
heater warms the engine coolant which improves starting,
warms up the engine faster, and allows the heater-defrost
system to respond more quickly.
*
[ST08600(ALL)05/95]
RWARNING
To prevent electrical shock, do not use your heater with
ungrounded electrical systems or two-pronged (cheater)
adapters.
*
[ST08700(ALL)01/93]
For best results, plug the heater in at least three hours before
you start your vehicle. Using the heater for longer than three
hours will not damage the engine, so you can leave it plugged
in all night to start your vehicle the following morning.
File:wnsts.ex
Update:Tue Mar 19 08:25:19 1996

Starting Your Windstar
61
%*
[ST09900(ALL)02/95]
What To Do If The Engine Does Not Start
%*
[ST10000(ALL)02/95]
Fuel Pump Shut-Off Switch
*
[ST10100(ALL)03/95]
If the engine cranks but does not start or does not start after a
collision, the fuel pump shut-off switch may have been
triggered. The shut-off switch is a device intended to stop the
fuel pump when your vehicle has been involved in a substantial
jolt.
*
[ST10200(ALL)03/95]
Once the shut-off switch is triggered, you must reset the switch
by hand before you can start your vehicle.
[ST10300(ALL)06/94]
The fuel pump shut-off switch reset button is located behind the
jack access cover under the jack in the cargo compartment.
[ST10400(ALL)02/94]
10-1/2 pica
art:0050046-A
Fuel pump shut-off switch reset button location
*
[ST10500(ALL)05/95]
RWARNING
If you see or smell fuel, do not reset the switch or try to
start your vehicle. Have all the passengers get out of the
vehicle and call the local fire department or a towing
service.
File:wnsts.ex
Update:Tue Mar 19 08:25:19 1996
