1996 FORD WINDSTAR parking brake

56
%*
[ST03100(ALL)02/95]
Removing the Key From the Ignition
*
[ST03200(ALL)01/93]
LOCK is the only position that allows you to remove the key
from the ignition. The LOCK feature helps to protect your
vehicle from theft, because it also locks the steering wheel and
the gearshift lever when the key is removed.
%*
[ST03300(ALL)01/93]
If your key is stuck in the LOCK position, and you are unable
to turn it, move your steering wheel left or right until the key
turns freely.
*
[ST03400(ALL)01/93]
To remove your key from the ignition:
*
[ST03500(ALL)05/95]1.
Put the gearshift lever in P (Park).
*
[ST03600(ALL)02/95]2.
Set the parking brake fully.
*
[ST03700(ALL)03/95]3.
Turn the ignition key to LOCK.
*
[ST03800(ALL)03/95]4.
Remove the key.
*
[ST03900(ALL)01/93]
RWARNING
When you leave your vehicle, place the gearshift lever in
Park (P). Set the parking brake fully, and shut off the
engine. Never park your vehicle in Neutral (N). If you do
not take these precautions, your vehicle may move
suddenly and injure someone.
*
[ST04100(ALL)01/93]
RWARNING
Do not leave children, unreliable adults, or pets alone in
your vehicle. They could accidentally injure themselves
or others through inadvertent operation of the vehicle.
Further, on hot, sunny days, temperatures in a closed
vehicle could quickly become high enough to cause
severe and possibly fatal injuries to people as well as
animals.
File:wnsts.ex
Update:Tue Mar 19 08:25:19 1996

Starting Your Windstar
57
%*
[ST04200(ALL)03/95]
Fuel-Injected Engines
[ST04300(ALL)02/95]
Since your vehicle has a fuel-injected engine,the most
important thing to remember is to avoid pressing down on the
acceleratorwhile cranking the engine to start. Only use the
accelerator when you have problems getting your vehicle
started. SeeStarting a Cold EngineandStarting a Warm Engine
later in this chapter for details about when to use the
accelerator while you start your vehicle.
%*
[ST04400(ALL)05/94]
Preparing to Start Your Vehicle
[ST04500(ALL)02/95]
RWARNING
Do not start your vehicle in a closed garage or in other
enclosed areas. Exhaust fumes can be toxic. Always open
the garage door before you start the engine. See
Guarding Against Exhaust Fumes in this chapter for more
instructions.
*
[ST04600(ALL)01/93]
Before you start your vehicle, always:
*
[ST04700(ALL)01/93]1.
Make sure you and all your passengers buckle your safety
belts. SeeSafety beltsin the Index for more details.
*
[ST04800(ALL)03/95]2.
Make sure the headlamps and other accessories are turned
off when starting.
[ST04900(ALL)02/95]3.
Make sure that the gearshift lever is in Park (P) and the
parking brake is set before you turn the key.
[ST05100(ALL)02/95]
Before you start your vehicle, you should test the warning lights
on the instrument cluster to make sure that they work. Refer to
theWarning Lights and Gaugeschapter.
File:wnsts.ex
Update:Tue Mar 19 08:25:19 1996

Starting Your Windstar
59
*
[ST07030(ALL)04/95]
Whenever you start your vehicle, release the key as soon as the
engine starts. Excessive cranking could damage the starter or
flood the engine.
*
[ST07060(ALL)02/95]
After you start the engine, let it idle for a few seconds.Keep
your foot on the brake pedaland release the parking brake.
Put the gearshift lever in gear, slowly release the brake pedal
and drive away in the normal manner.
*
[ST07090(ALL)02/95]
NOTE: Your vehicle has an interlock that prevents you from
shifting out of P (Park) unless your foot is on the
brake pedal.
*
[ST07200(ALL)03/95]
If the engine still does not start after two attempts:
*
[ST07300(ALL)03/95]1.
Turn the key to the OFF position and wait about two
minutes.
*
[ST07400(ALL)04/95]2.
Press the accelerator all the way to the floor and hold it.
[ST07500(ALL)02/95]3.
Turn the key to the START position.
[ST07600(ALL)02/95]4.
Release the key when the engine starts.
[ST07700(ALL)02/95]5.
Release the accelerator gradually as the engine speeds up.
Then drive away in the normal manner.
*
[ST07800(ALL)04/95]
If the engine still does not start, the fuel pump shut-off switch
may have been triggered. For directions on how to reset the
switch seeFuel Pump Shut-Off Switchlater in this chapter.
[ST07900(ALL)02/95]
A computer system controls the engine's idle rpm. When you
start your vehicle, the engine's idling rpm normally runs high.
These faster engine speeds will make your vehicle move slightly
faster than when the engine is at its normal warm engine idle
speed. It should, however, slow down when the vehicle warms
up. If it does not, have the idle rpm checked.
File:wnsts.ex
Update:Tue Mar 19 08:25:19 1996

68
%*
[LG00475(ALL)06/94]
The Mechanical Cluster
[LG00501(ALL)06/94]
The following warning lights and gauges are on the Mechanical
Cluster. All of these indicators alert you to the status of vehicle
systems or possible problems with your vehicle. Some of the
lights listed are optional. The following section explains each of
the indicators.
[LG00600(ALL)12/93]
Warning and Indicator Lights
%*
[LG00900(ALL)03/95]
Brake System Light
[LG01000(ALL)11/93]
The warning light for the brakes indicates two things Ð that
either the parking brake is on or not fully released, or that the
brake fluid level is low in the master cylinder reservoir. If the
fluid level is low, the brake system should be checked by a
qualified service technician.
[LG01100(ALL)11/93]
6 pica art:0050144-B
The brake system light
[LG01200(ALL)12/93]
The BRAKE light normally comes on when you turn the
ignition key to the ON or START position to verify that the
indicator bulb is working. If the light stays on or comes on
when the engine is running and after you have released the
parking brake fully, have the hydraulic brake system serviced.
*
[LG01300(ALL)05/95]
RWARNING
The BRAKE light indicates that the brakes may not be
working properly. Have the brakes checked immediately.
File:wnlgs.ex
Update:Tue Mar 19 08:25:03 1996

84
[LG10835(ALL)11/93]
6 pica art:0050148-B
The safety belt warning light
%*
[LG10845(ALL)03/95]
Brake System Light
[LG10848(ALL)11/93]
The warning light for the brakes indicates two things Ð that
either the parking brake is on or not fully released, or that the
brake fluid level is low in the master cylinder reservoir. If the
fluid level is low, the brake system should be checked by a
qualified service technician.
[LG10850(ALL)11/93]
6 pica art:0050144-B
The brake system light
[LG10855(ALL)12/93]
The BRAKE light normally comes on when you turn the
ignition key to the ON or START position to verify that the
indicator bulb is working. If the light stays on or comes on
when the engine is running and after you have released the
parking brake fully, have the hydraulic brake system serviced.
*
[LG10858(ALL)05/95]
RWARNING
The BRAKE light indicates that the brakes may not be
working properly. Have the brakes checked immediately.
File:wnlgs.ex
Update:Tue Mar 19 08:25:03 1996

122
*
[IP12541(ALL)02/93]
To maximize fog lamp bulb life it is recommended that the fog
lamp switch be turned off after each use prior to turning off the
headlamps.
*
[IP12544(ALL)10/94]
n
To turn the fog lamps on, push the switch. An indicator light
will glow when the lamps are on.
*
[IP12547(ALL)10/94]
n
To turn off, push the switch again.
%*
[IP12550(ALL)03/95]
ªHeadlamps Onº Alert Chime
[IP12601(ALL)03/94]
The ªheadlamps onº alert chime acts as an indicator that you
have left the headlamps or parking lights on. This continuous
chime will activate when the following conditions are present:
[IP12620(ALL)03/94]
n
The headlamp and/or parking lamps are on
[IP12640(ALL)03/94]
n
There is no key in the ignition
[IP12660(ALL)05/94]
n
The driver's door is ajar (open)
%*
[IP12700(ALL)01/93]
Daytime Running Light (DRL) System
(Canadian vehicles only)
*
[IP12800(ALL)03/95]
The Daytime Running Light (DRL) system is designed to turn
the high beam headlamps on, with a reduced light output and
without illuminating the high beam indicator lamp in the
instrument panel. The DRL system operates when all of the
following conditions are met:
*
[IP12900(ALL)01/93]
n
the vehicle is ªrunningº
*
[IP13000(ALL)01/93]
n
the vehicle has a fully released parking brake
*
[IP13100(ALL)01/93]
n
the headlamp system is in the OFF position
*
[IP13200(ALL)01/93]
NOTE: You may notice that the lights flicker when the engine
is turned on or off. This is a normal condition.
File:wnips.ex
Update:Tue Mar 19 08:23:17 1996

236
% [DR01600(ALL)09/93]
Brake-Shift Interlock Safety Feature
[DR01700(ALL)05/95]
Your vehicle has a special brake-shift interlock safety feature
which prevents you from shifting out of P (Park) without the
brake pedal depressed. To shift the transaxle out of the P (Park)
position, the ignition must be in the ON position and your foot
must be pressing on the brake pedal.
[DR01750(ALL)02/96]
When parking on a hill, set the parking brake before shifting
into and out of P (Park). If the parking brake is not set, a clunk
or bang may be heard when shifting out of P (Park). This noise
can be considered a normal characteristic.
*
[DR01800(ALL)04/95]
If the shift lever cannot be moved from the P (Park) position
with the brake pedal depressed:
*
[DR01900(ALL)01/93]1.
Shut the engine off and remove the ignition key.
*
[DR02000(ALL)01/93]2.
Apply the parking brake.
*
[DR02100(ALL)01/93]3.
Reinsert the ignition key and turn it clockwise to the first
position (OFF).
*
[DR02200(ALL)04/95]4.
Depress the brake pedal, move the gearshift lever to N
(Neutral) and start the engine.
*
[DR02280(ALL)05/95]
If you need to shift out of P (Park) by using the alternate
procedure described above, it is possible that a fuse has blown
and that your brakelamps may also not be functional. Please
refer to the chapter titledServicing Your Windstarin this Owner
Guide for instructions on checking and replacing fuses.
*
[DR02300(ALL)05/95]
RWARNING
DO NOT DRIVE YOUR VEHICLE UNTIL YOU VERIFY
THAT THE BRAKELAMPS ARE WORKING.
%*
[DR02500(ALL)06/92]
Backing Up
*
[DR02600(ALL)01/93]
Before shifting into or out of R (Reverse), you should always
come to a complete stop.
File:wndrs.ex
Update:Tue Mar 19 08:18:48 1996

Driving Your Windstar
237
%*
[DR02700(ALL)01/95]
Driving
*
[DR02800(ALL)01/93]
When to use N (Neutral)
*
[DR02900(ALL)01/93]
In N (Neutral), the wheels of the transaxle are not locked. Your
vehicle will roll freely, even on the slightest incline, unless the
parking brake or brakes are on.
[DR03000(ALL)05/95]
When to usejOverdrive
[DR03100(ALL)06/95]
Overdrive is the normal driving position. When the gearshift
lever is placed injOverdrive , and the Overdrive Off button
has not been pressed, the vehicle will automatically upshift to
second, third and fourth gears. The transaxle will shift into the
correct gear when the right speed is reached.
%*
[DR03200(ALL)02/94]
When to use D (Drive) - with the Overdrive Off button
activated
[DR03300(ALL)06/94]
You will notice that there is only one drive position on your
gearshift indicator (instead of Drive and Overdrive). However,
you will find a button and an indicator light located on the
gearshift lever. Push in the button on the end of the lever and
the OVERDRIVE OFF light on the end of the gearshift lever will
illuminate. With the OVERDRIVE OFF light illuminated, the
transaxle will operate in first, second and third gears and will
not shift into fourth gear. Operating in Drive (OVERDRIVE OFF
light illuminated) provides more engine braking than Overdrive
for descending hills or city driving.
[DR03400(ALL)09/93]
6 pica art:0050058-A
Overdrive button location
File:wndrs.ex
Update:Tue Mar 19 08:18:48 1996
