Driving Your Windstar
239
[DR04600(ALL)05/95]
The gearshift is securely latched in P (Park) if you can not
rotate it in a clockwise direction without pulling it toward you.
*
[DR04700(ALL)05/95]
RWARNING
Always set the parking brake fully and make sure that
the gearshift is securely latched in P (Park).
*
[DR04800(ALL)05/95]
RWARNING
Never leave your vehicle unattended while it is running.
*
[DR04900(ALL)05/95]
RWARNING
Never leave your vehicle unattended while it is running.
*
[DR05000(ALL)06/94]
Forced Downshifts
[DR05100(ALL)05/95]
To gain extra acceleration in
j(Overdrive) (when passing
another vehicle) push the accelerator to the floor. The transaxle
will automatically downshift to the appropriate gear (third,
second or first).
% [DR05200(ALL)04/95]
Traction Control (If equipped)
[DR05300(ALL)04/95]
Traction Control can help improve your traction on slippery
surfaces, but always operate your vehicle within reasonable
limits. Abrupt changes in acceleration, deceleration, turning, or
combinations of these maneuvers can cause your vehicle to
behave differently than anticipated, especially when road
conditions vary.
[DR05400(ALL)04/95]
To turn Traction Control off, press the button located in the
glove compartment while the vehicle is stopped.
[DR05500(ALL)05/95]
Traction Control can be turned back on by pressing the button
again while the vehicle is stopped or by restarting the engine.
File:wndrs.ex
Update:Tue Mar 19 08:18:48 1996

240
%*
[DR05700(ALL)01/95]
Steering Your Vehicle
*
[DR05800(ALL)01/93]
Your vehicle has power steering. Power steering uses energy
from the engine to help steer your vehicle.
*
[DR05900(ALL)01/93]
Never hold the steering wheel in the extreme right or left
position for more than five seconds if the engine is running.
This can damage the power steering pump.
%*
[DR06000(ALL)04/95]
If the amount of effort needed to steer your vehicle changes at a
constant vehicle speed, have the power steering system checked.
If the power steering system breaks down (or if the engine is
turned off), you can steer the vehicle manually but it takes more
effort.
*
[DR06100(ALL)01/93]
NOTE: After any severe impact such as striking large
potholes, sliding into curbs on icy roads, or a collision
involving the front end, have the front suspension
and steering checked for possible damage.
%*
[DR06200(ALL)03/95]
Brakes
*
[DR06300(ALL)01/93]
When the foot (service) brake pedal is depressed, the
high-mount brake lamp should illuminate.
*
[DR06400(ALL)01/93]
Front Disc Brakes
[DR06500(ALL)11/93]
The front disc brakes are self-adjusting. They only require
periodic inspection for pad wear.
[DR06525(ALL)04/95]
Rear Disc Brakes (If equipped)
[DR06550(ALL)04/95]
The rear disc brakes are self-adjusting. They only require
periodic inspection for pad wear.
[DR06575(ALL)04/95]
The rear disc parking brakes need to be adjusted manually.
*
[DR06600(ALL)10/94]
Rear Drum Brakes
*
[DR06700(ALL)01/93]
The rear drum brakes are self-adjusting. Automatic adjustment
occurs through normal use of the brakes.
File:wndrs.ex
Update:Tue Mar 19 08:18:48 1996

242
*
[DR07300(ALL)05/95]
RWARNING
If the anti-lock brake system warning light remains on or
comes on while driving, have the braking system checked
by a qualified service technician as soon as possible.
*
[DR07320(ALL)05/95]
NOTE: If a fault occurs in the anti-lock system, and the brake
warning light is not lit, the anti-lock system is
disabled but normal brake function remains
operational.
*
[DR07350(ALL)12/93]
Ford Motor Company has not found any negative effects of
mobile radio transmitting equipment installed on vehicles with
the ABS system providing that the radio is installed according
to the radio manufacturer's instructions. However, if you have
had a mobile radio transmitter installed and the check ABS light
comes on (at any time other than immediately after turning the
key to the ON position) have your mobile radio dealer inspect
the radio installation. Also, if the ABS system is activated other
than during maximum braking, have your mobile radio
installation checked.
%*
[DR07400(ALL)12/89]
If Brakes Do Not Grip Well or Pedal is ªLowº
*
[DR07500(ALL)01/93]
If the brake pedal seems ªlowº it may indicate the need for a
brake system inspection and/or service. Apply your parking
brake several times. If the condition has not improved, you
should have your brakes checked as soon as possible.
%*
[DR07600(ALL)01/93]
Occasional brake squeal during light to moderate stops does not
affect the function of the brake system and is normal. However,
if the squeal becomes very loud or if it becomes more frequent,
return the vehicle to your dealer for inspection.
File:wndrs.ex
Update:Tue Mar 19 08:18:48 1996

244
%*
[DR08400(ALL)03/95]
Using the Parking Brake
*
[DR08501(ALL)01/95]
The parking brake should be used whenever you park your
vehicle.
[DR08520(ALL)09/93]
The parking brake is a hand operated lever located on the floor
of your vehicle just to the right of the driver's seat.
[DR08530(ALL)09/93]
To set the parking brake while parking your vehicle, press the
brake pedal with your right foot and hold it while you fully
apply the parking brake lever.
[DR08540(ALL)03/94]
To release the parking brake, press the brake pedal with your
right foot, pull up the lever while depressing the release button
on the parking brake lever then lower the lever all the way to
the floor.
[DR08600(ALL)11/93]
13-1/2 pica
art:0050057-B
The parking brake
File:wndrs.ex
Update:Tue Mar 19 08:18:48 1996

Driving Your Windstar
245
*
[DR08700(ALL)01/93]
RWARNING
When parking, do not use the gearshift in place of the
parking brake. Always set the parking brake fully and
make sure that the gearshift is securely latched in Park
(P). Turn off the ignition whenever you leave your
vehicle. Never leave your vehicle unattended while it is
running. If you do not take these precautions, your
vehicle may move unexpectedly and injure someone.
*
[DR08900(ALL)01/93]
RWARNING
If the parking brake is fully released, but the Brake
System light remains on, have the brakes checked
immediately. They may not be working properly.
*
[DR09000(ALL)02/94]
The parking brake is not designed to stop a moving vehicle, but
you can use the parking brake to stop your vehicle in an
emergency if the service brakes fail. However, since the parking
brake does not stop your vehicle as quickly as the normal
brakes, the stopping distance will increase greatly.
%*
[DR09100(ALL)01/95]
Driving Under Special Conditions
%*
[DR09200(ALL)01/95]
Tips for Safe Driving
*
[DR09300(ALL)01/93]
As with any new vehicle, yours may drive and handle
differently from your previous vehicle. Use greater care until
you become accustomed to its features and driving
characteristics.
*
[DR09400(ALL)01/93]
Always operate your vehicle within reasonable limits. Abrupt
changes in acceleration, deceleration, turning, or combinations of
these maneuvers can cause a vehicle to behave differently than
anticipated, especially when road conditions vary.
File:wndrs.ex
Update:Tue Mar 19 08:18:48 1996

Driving Your Windstar
259
[DR21600(ALL)10/93]
When stopped in traffic for long periods of time in hot weather,
place the gearshift selector lever in P (Park) to increase the
engine idle speed. This aids in engine cooling and air
conditioner efficiency. If the engine overheats, turn the selector
knob to select the fresh air position to stop the air conditioner
compressor. Increase the engine speed for a short time.
*
[DR21700(ALL)01/93]
Vehicles with trailers should not be parked on a grade.
However, if you must park on a grade, place wheel chocks
under the trailer's wheels as follows:
[DR21800(ALL)11/93]1.
Apply the foot service brake pedal and hold.
*
[DR21900(ALL)11/93]2.
Have another person place the wheel chocks under the
trailer wheels.
[DR22000(ALL)11/93]3.
With the chocks in place, release the foot service brake
pedal, making sure the chocks are holding.
[DR22100(ALL)11/93]4.
Apply the parking brake by pressing the service brake pedal
down firmly with your right foot while applying the parking
brake lever with your right hand.
*
[DR22200(ALL)11/93]5.
Shift the gearshift lever into P (Park).
File:wndrs.ex
Update:Tue Mar 19 08:18:48 1996

260
[DR22300(ALL)11/93]
Complete the following steps to start your vehicle after it has
been parked on a grade:
[DR22400(ALL)11/93]1.
Apply the foot service brake pedal and hold.
*
[DR22500(ALL)11/93]2.
Start the engine.
*
[DR22600(ALL)11/93]3.
Shift the gearshift lever into gear and release the parking
brake.
[DR22700(ALL)11/93]4.
Release the foot service brake pedal and move the vehicle
uphill to free the wheel chocks.
[DR22800(ALL)11/93]5.
Apply the foot service brake pedal and hold while another
person retrieves the chocks.
File:wndrs.ex
Update:Tue Mar 19 08:18:48 1996

262
*
[RE01400(ALL)03/95]
To avoid damaging your vehicle or your battery, and to avoid
injury to yourself, follow these directions for preparing your
vehicle to jump-start and connecting the jumper cables in the
order they are given. If in doubt, call for road service.
[RE01500(ALL)02/95]
To prepare your vehicle for jump-starting:
[RE01600(ALL)02/95]1.
Use only a 12-volt battery to jump-start your vehicle. Your
vehicle has a 12-volt starting system, so you need to use a
12-volt jumper system. You can damage your starting motor,
ignition system, and other electrical parts if you connect
them to a 24-volt power supply (either two 12-volt batteries
in series or a 24-volt motor generator set).
*
[RE01700(ALL)03/95]2.
Do not disconnect the battery of the vehicle that needs a
jump-start. You could damage the vehicle's electrical system.
*
[RE01800(ALL)03/95]3.
Park the second vehicle close to the hood of your vehicle,
but make sure the vehicles do not touch each other. Set the
parking brake on both vehicles and stay clear of the engine
cooling fan.
*
[RE01900(ALL)03/95]4.
Check the battery terminals and remove any excessive
corrosion before you attach the jumper cables.
*
[RE02000(ALL)01/93]5.
Turn on the heater blower in both vehicles. Turn off all other
switches and lights in both vehicles to prevent possible
damage to either vehicle's electrical systems.
