1996 FORD WINDSTAR Owners Manual

Instrument Panel Controls
127
% [IP13630(ALL)06/94]
Turning on the map lamps (If equipped)
[IP13640(ALL)12/93]
Your vehicle may have a map lamp for the passenger and one
for the driver. The map lamps and switches are located on the
front dome lamp.
[IP13660(ALL)10/93]
The rear cargo lamp is located overhead near the rear seating
positions.
[IP13680(ALL)06/94]
Second Row Reading Lamp
[IP13690(ALL)06/94]
The second row reading lamp may be turned on by using the
rocker switch located on the lamp assembly or by using the
instrument panel dimmer switch.
[IP13700(ALL)06/94]
10-1/2 pica
art:0050233-A
Second row reading lamp
File:wnips.ex
Update:Tue Mar 19 08:23:17 1996

128
%*
[IP13730(ALL)04/95]
Cleaning the Interior Lamps
*
[IP13760(ALL)04/95]
Your interior dome lamps and map lamps are plastic and
should be cleaned with a mild detergent diluted in water. Rinse
them with clear water.
*
[IP18000(ALL)04/95]
Clock Controls on Electronic Radios
[IP18100(ALL)03/94]
The electronic radios have a built-in clock. For complete
operating instructions, refer to theElectronic Sound Systems
chapter of this Owner Guide.
%*
[IP18200(ALL)05/92]
Radio Antenna
*
[IP18300(ALL)07/93]
The fixed radio antenna is mounted on the front fender on the
passenger's side of the vehicle.
File:wnips.ex
Update:Tue Mar 19 08:23:17 1996

129
Steering Column Controls
*
[SC00900(ALL)01/95]
The controls on the steering column and wheel are designed to
give you easy access to the controls while you are driving.
*
[SC01000(ALL)01/93]
Turn Signal Lever
*
[SC01100(ALL)01/95]
You can use the turn signal lever on the left side of the steering
column to:
*
[SC01200(ALL)01/93]
n
operate the turn signals.
*
[SC01300(ALL)01/93]
n
turn the headlamps to high beam.
*
[SC01400(ALL)01/93]
n
flash the headlamps.
*
[SC01500(ALL)01/93]
n
turn the windshield wipers and washer on/off.
%*
[SC01600(ALL)01/95]
Turn Signals
[SC01700(ALL)02/95]
To turn on the right turn signal, push the turn signal lever up.
The right-side arrow on the instrument panel will flash.
[SC01800(ALL)02/95]
To turn on the left turn signal, pull the turn signal lever down.
The left-side arrow on the instrument panel will flash.
*
[SC01900(ALL)11/93]
7-1/2 pica art:0040085-D
The turn signal lever
[SC02000(ALL)02/95]
Usually, the turn signals turn off automatically after you turn
your vehicle. If the turn signal continues to flash after you have
made the turn, pull the lever back to the neutral position.
File:wnscs.ex
Update:Tue Mar 19 08:22:27 1996

130
[SC02100(ALL)02/95]
To indicate a lane change to the right, push the turn signal
lever up slightly (without latching) and hold it in position. To
indicate a lane change to the left, pull the turn signal lever
down slightly (without latching) and hold it in position. The
lever will return to the OFF position when you release it.
*
[SC02200(ALL)05/94]
If the turn indicator light in the instrument panel does not
illuminate or remains on (does not flash) when you signal a
turn, the turn signaling system is malfunctioning. Have this
condition corrected as soon as possible, and use the accepted
hand signals until the turn signal system is repaired.
%*
[SC02220(ALL)03/95]
High Beams
*
[SC02226(ALL)01/93]
To turn on the high beams, turn the headlamps on and push
the turn signal lever away from you until it latches. When the
high beams are on, the high beam indicator light on the
instrument panel is illuminated.
*
[SC02230(ALL)01/93]
To return to the low beam setting, pull the turn signal lever
toward you until it latches back into the neutral position. The
high beam indicator light turns off.
*
[SC02235(ALL)11/93]
7-1/2 pica art:0040086-D
High beam and flash-to-pass operation
%*
[SC02700(ALL)05/95]
Flashing the Lights
*
[SC02800(ALL)01/93]
To flash the headlamps, pull the turn signal lever toward you
for a moment and then release it. The high beam headlamps
will flash whether the headlamps are on or off.
File:wnscs.ex
Update:Tue Mar 19 08:22:27 1996

Steering Column Controls
131
%*
[SC03100(ALL)03/95]
Windshield Wipers and Washer
%*
[SC03200(ALL)03/95]
Variable Interval Wipers
[SC03300(ALL)11/93]
Your vehicle has wipers that operate at varying intervals. For
example, you can set the interval so they wipe less often in
light rain or more often in heavier rain. The wiper delays range
from about 1.5 to 20 seconds.
*
[SC03400(ALL)09/93]
10-1/2 pica art:0040087-E
Variable interval wiper control
*
[SC03500(ALL)01/93]
To set the interval wipers, rotate the knob at the end of the turn
signal lever to the most effective interval. The farther the knob
is from the OFF position, the faster the wipers move.
[SC03510(ALL)12/93]
Speed Dependent Wipers
[SC03520(ALL)01/95]
This feature compensates for the extra moisture that
accumulates on your windshield at higher speeds during rain.
At higher speeds, the Speed Dependent feature shortens the
delay between wipes when you use the variable interval wipers.
Delay will automatically adjust at speeds between 10 and
65 mph (16 and 105 km/h).
File:wnscs.ex
Update:Tue Mar 19 08:22:27 1996

132
[SC03530(ALL)12/93]
The Speed Dependent feature comes disabled from the factory,
but can be activated at any time by using the following
procedure.
[SC03560(ALL)12/93]1.
Make sure the two front doors are securely closed.
[SC03570(ALL)04/95]2.
Insert the key into the ignition and turn first to the ON
position (the gauges on the instrument panel willnot
illuminate) and then back to the OFF position. Remove the
key and within 30 seconds:
[SC03575(ALL)12/93]3.
Press and hold the washer button on the end of the turn
signal lever.
[SC03580(ALL)04/95]4.
Within two seconds, put the key back in the ignition and
turn to the ON position.
[SC03585(ALL)06/94]5.
Hold the washer button down until a long (two second) tone
is heard. Release the button while the tone is active.
[SC03591(ALL)12/93]6.
After the long tone, a confirmation sequence will be heard.
One beep indicates the feature is inactive. Two beeps
indicates the feature is active.
[SC03595(ALL)12/93]
Repeat this procedure any time you want to cancel or reactivate
the Speed Dependent feature.
*
[SC03600(ALL)04/95]
Windshield Washer
[SC03700(ALL)08/94]
To clean the windshield, push in the washer button on the end
of the turn signal lever. For a constant spray, push and hold the
button. If the windshield wipers are off, one momentary push
results in one wipe and a longer push in three wipes and
activation of washer fluid. If the windshield wipers are in
interval mode a quick tap results in two wipe cycles and a
longer tap in three wipes and washer fluid activation.
*
[SC03800(ALL)01/93]
Do not try to clean the windshield when the washer fluid
container is empty and never activate the washers for more than
fifteen seconds continuously. This could damage the washer
pump system.
File:wnscs.ex
Update:Tue Mar 19 08:22:27 1996

Steering Column Controls
133
*
[SC03900(ALL)01/93]
RWARNING
In freezing weather, the washer solution may freeze on
the windshield and obscure your vision. Always warm
up the windshield with the defroster before you use the
washer fluid. If you cannot see through the windshield
clearly, it can increase the risk of being involved in a
collision.
*
[SC04000(ALL)04/95]
For information about refilling the washer fluid or replacing
your windshield wiper blades, seeWindshield washer fluid and
Wipersin the Index.
%*
[SC04100(ALL)01/93]
Gearshift Lever
[SC04200(ALL)06/94]
The gearshift lever on your vehicle is mounted on the steering
column. On the end of the gearshift lever is the Overdrive
On/Off button and the OVERDRIVE OFF lamp. For additional
information about the gearshift lever and the Overdrive On/Off
button, see theDriving Your Vehiclechapter.
[SC04300(ALL)09/93]
13-1/2 pica
art:0050016-A
The gearshift lever
File:wnscs.ex
Update:Tue Mar 19 08:22:27 1996

134
*
[SC04320(ALL)11/93]
OVERDRIVE OFF Lamp
[SC04330(ALL)06/94]
This lamp indicates the operating range of the transaxle. This
lamp will illuminate when the Overdrive On/Off button is
depressed.
[SC04340(ALL)03/94]
6 pica art:0050187-C
OVERDRIVE OFF lamp location
[SC04350(ALL)05/95]
With the transaxle range selector in the Overdrivejrange, the
OVERDRIVE OFF lamp will not be illuminated. The transaxle
will be allowed to upshift and downshift from 1st through 4th
gears. When the Overdrive on/off button is depressed, the
OVERDRIVE OFF lamp will illuminate. The transaxle will now
only upshift and downshift from 1st through 3rd gears. The
vehicle will always return to the overdrive operation mode
when the ignition is turned off and back on.
[SC04360(ALL)06/94]
If the lamp does not come on when the Overdrive ON/OFF
button is depressed or if the lamp flashes when you are driving,
have your vehicle serviced at the first opportunity. If this
condition persists, damage could occur to the transaxle.
%*
[SC04400(ALL)01/95]
Horn
[SC04410(ALL)09/93]
To sound the horn, press the center of the steering wheel. Check
the horn regularly to make sure it operates properly.
File:wnscs.ex
Update:Tue Mar 19 08:22:27 1996
