33B-98ACTIVE-ELECTRONIC CONTROL SUSPENSION - Strut Assembly i
SERVICE POINTS OF REMOVALM33lBAE
8. REMOVAL OF FRONT HEIGHT SENSOR RODWhen removing the right strut assembly and knuckleunion, always first remove the lower arm and front height
sensor rod union. l1RoooP
-
,Reserve tank
Joint assembly
Adaptor E
1 -1210289
9. REMOVAL OF BRAKE HOSE AND TUBE CLAMP
Remove the brake hose and tube without prying them.
10. REMOVAL OF FRONT SPEED SENSOR CLAMP
Remove the front speed sensor clamp; be sure the front
speed sensor harness doesn’t stretch.
11. REMOVAL OF FRONT STRUT LOWER MOUNTING
BOLTS
After the strut and knuckle union have been removed, jack up the lower arm, then hold the knuckle with wire, etc. not
to pull on the brake hose and tube, the speed sensor wiring harness and the drive shaft.
INSPECTION
M33LCAC
CHECKING FOR STRUT ASSEMBLY AIR LEAKAGE
(1) Disconnect the flow-control solenoid valve’s air tube (connected to the high-pressure side of the reservoir tank)
shown in the illustration, and then take off the join
t
assembly.
NOTE
This air tube is connected, via the reservoir tank and the dryer, to the compressor assembly.
(2) Install the removed joint assembly to the special tool (adaptor set) and then connect to the disconnected air
tube.
TSB Revision

ACTIVE-ELECTRONIC CONTROL SUSPENSION - f:::,%tmb’y’ 33B-103
pF&O-rin

g
81210311
2. INSTALLATION OF O-RING/l. JOINT
Apply a coating of rubber grease to the O-ring, install it tothe joint, and then install to the piston rod.
LOWER ARM
REMOVAL AND INSTALLATION .
35-45 Nm
25-33
ft.lbs.
.-- ~~69-87 .ft.lbs.*
eLII-uu. . ..“a. 80-100
Nni*
1.
35-45 Nm 17
'
- /I MJJNA-A
58-72
ft.lbs.* 9
---. .- ..__.
SO-100 Nm12A0316
1058-72ft.lbs.
\ 17-26 Nm
12-18 ft.lbs.
lZA0230
Removal steps
4*1. Front height sensor rod+e I)+ 2. Stabilizer link mounting nut (Stabilizer
bar side)
+e I)* 3. Stabilizer link mounting nut (Lower armside)
4. Stabilizer link
4*5. Lower arm ball-joint and knuckle
coupling self-locking nut
6. Lower arm mounting nut 7. Lower arm mounting bolt
8. Clamp mounting self locking nut
9. Clamp mounting bolt (small)
10. Clamp mounting bolt (large)
11. Lower arm mounting clamp
12. Lower arm
13. Stopper14. Dust cover
15. Rod bushing
NOTE*: Indicates parts which should be temporarily tight-ened, and then fully tightened with the vehicle inthe unladen condition.
TSB RevisionI

339-l 04 ACTIVE-ELECTRONIC CONTROL SUSPENSION - Lower Arm
SERVICE POINTS OF REMOVAL
hl33NBAC
1. REMOVAL OF FRONT HEIGHT SENSOR ROD When removing the right strut assembly and knuckleunion, always first remove the lower arm’and
front height
sensor rod union.
yz--q--o .-L
T Front height sensor
lzAm66
12RO258
2./3. REMOVAL OF STABILIZER LINK MOUNTING NUT
Use wrench or similar tool to secure the ball stud part at
both ends of the stabilizer link, and then remove the nut.
5. REMOVAL OF LOWER ARM BALL JOINT Using the special tool, disconnect the lower arm ball joint
from the knuckle.
NOTE
(1) Always tie the cord of the special tool to the nearby
part.
(2) Loosen the nut but do not remove it.
INSPECTION
l Check the lower arm for bend or breakage. l Check the clamp for deterioration or damage.
l Check the bushing for wear and deterioration.
l Check the ball joint dust cover for cracks.
l Check all bolts for condition and straightness.
TSB Revision

33B-110 ACTIVE-ELECTRONIC CONTROL SUSPENSION - i=ttbborber
SHOCK ABSORBER ASSEMBLYhl33MA-A[EMOVAL
AND INSTALLATION
1989 models
40-50 Nm
29-36 ft.lbs.
Removal
l *
l *
8-10 Nm
steps
1.Air tube2.O-ring3.Bush4.Actuator connector5.Actuator6. Rear height sensor rod
6
17-26 Nm 9127 ft.lbs;.i
1990 modelsz??
4.8-7.2 Nm
4-5 ftlbs.
\
6 80-100
Nm*
58-72

ft.lbs.*
7. Shock at%orber
upper mounting nuts
8. Shock absorber lower mounting bolts
9. Shock absorber assemblyWA0331
NOTE *: Points marked with an asterisk should first
be tightened
provisionally, then tightened fully when the vehicle is
empty.
SERVICE POINTS OF REMOVALm33hlsN
9. REMOVAL OF SHOCK ABSORBER ASSEMBLY
(1) Jack up the torsional axle and arm assembly and keep it lifted up to some degree.
Caution
1.Always insert a wooden block between the jack receptacle and the axle beam and place the jack
at the centre of the axle beam.
2. Make sure that the jack does not contact the lateral rod.
TSB Revision

33B-114 ACTIVE-ELECTRONIC CONTROL SUSPENSION - ~:h%pension
REAR SUSPENSION ASSEMBLYM33GA-A
REMOVAL AND INSTALLATION
50-60 Nm
17-26 Nm 36-43 ftlbs.
12-19
ft.lbs. 2
,
9-14
‘Nm7-10 ftlbs.
Vehicles with A.B.S. 9-14 Nm
7-10 ft.lbs.
12A0366
Removal steps1. Parking brake cable
2. Brake tube and hose bracket
3. Rear disc brake
4. Brake disc
5. Hub cap
l + 6. Flange nut
7. Washer
8. Speed sensor
9. Rear axle assembly
10. Dust shield 200-260
Nm
12A0355
%I*Removal of Trunk Room Srde Tnm
Post-installation Operationl installation of Trunk Room SideTrim. (Refer to GROUP 52-Trims.)l Check the Brake Disc Runout, andAdjust.(Refer to GROUP
35-ServiceAdjustment. Procedures.)l Check the Rear Disc Brakes Drag-ging Torque, and Adjust.(Refer to GROUP
35-ServiceAdjustment Procedures.)achecking Parking Brake LeverStroke.(Refer to GROUP
36-ServiceAdjustment Procedures.)@Check the Rolling Diaphragm forDouble-folding.(Refer to P.33B-89.)
TSB Revision

ACTIVE-ELECTRONIC CONTROL SUSPENSION - ~~%f;pension 33B-115
Removal
8-10 Nm
loo-120 Nm*72-87 ftlbs.’
steps
l * 11.Air tube12.Joint13.O-ring14.Bush15.Actuator connector
40-50 Nm
29-36
fi*‘v’g
SO-100
Nm*
58-72 ft.lbs.*
I
18
12AO337
16.Actuator17.Rear heiaht sensor rod mounting bolt (1989 models)
::**+*
17-l.Rear height sensor rod mounting nut
(From 1990 models)18.Lateral rod mounting bolt (body side)
19.Shock absorber upper mounting nuts20.Trailling arm mounting bolts21. Rear suspension assembly
NOTE *: Points marked with an asterisk shoud first be tightened
provisionally, then tightened fully when the vehicle is
empty.
1989 models
-From 1990 models
17-26 Nm12-19 ftlbs. 17
12AoG37
SERVICE POINTS OF REMOVAL
M33GBBE
18. REMOVAL OF LATERAL ROD MOUNTING BOLT (BODY SIDE)
(1) Remove the lateral rod from the body.
(2) Secure and hold the lateral rod to the axle beam with wire, etc.
TSB Revision

ACTIVE-ELECTRONIC CONTROL SUSPENSION - ii%%;%% god 336417
12AOO88
LATERAL ROD
REMOVAL AND INS
TALLATION
i
80-100
Nm*
‘3J@a-

-
58-72 ft.lbs.*
6. INSTALLATION OF THE FLANGE NUT
After tightening the flange nut, align with the indentationin the spindle, and crimp.
MBJUA-A
6’ rrom IJJU mooers1989 models
9-14Nms 7v7-10 ft.lbs.12A0602
Removal steps
*I)111.Rear height sensor rod mounting bolt (1989 models)
Rear height sensor rod mounting nut (From 1990 models)
l
+ 2.Rear height sensor bracket mounting
bolt
3.Rear height sensor bracket B4.Rear heigh sensor bracket A
::Spacer Lateral rod mounting bolt (body side)
++ 7. Lateral rod mounting bolt (axle beamNOTEside)+: Points marked with an asterisk should first be tightenedLateral rod
provisionally, then tightened fully when the vehicle is9.Lateral rod bushingempw.
TSB Revisio
n
I

33B-118
ACTIVE-ELECTRONIC CONTROL SUSPENSION - Lateral Rod
1989 modelsSERVICE POINTS OF REMOVAL M22UB6A
1. REMOVAL OF REAR HEIGHT SENSOR ROD
NOTE
If anything other than the rear height sensor rod mounting
bolt are removed, the height sensor installation dimension
must be readjusted so remove other parts only when
absolutely necessary.
\
12A0600
From 1990 models
-f
--_
(-_ \
41
L-r12A0601
MB990947-01-4 12R0142
Lateral rod
mounting bolt
IIIAxle beam
12Ao322
Move the height sensor bracket so that the displa
y
dimensions assume the standard values, then secure the bracket in place with the height sensor bracket mounting
bolts.
Standard value (L):
315&l mm (12.4k.04 in.)
Bolt centre
;’Bracket left edge surface,
TSB Revision INSPECTION M22UCAA
l Check lateral rod for damage and deformation.
l Check each bushing for cracks, deterioration and wear.
LATERAL ROD BUSHING REPLACEMENT
WUEAA
(1) Drive out the lateral rod bushing using the special tools.
(2) Press in the bushing using the special tools so that the amount of projection is equal at the left and right.
SERVICE POINTS OF INSTALLATION M22UDAA
7. INSTALLATION OF LATERAL ROD MOUNTING BOLT (AXLE BEAM SIDE)
Install the lateral rod mounting bolt from the direction
shown in the illustration.
2. ADJUSTMENT OF REAR HEIGHT SENSOR BRACKET MOUNTING BOLT
