2022 TOYOTA MIRAI Owners Manual

3456-1. Using the air conditioning system and defogger
Owners Manual_USA_M62084_en
6
Interior features
7 Settings are complete with any of
the following.
• Operate the button and turn OFF the rear control panel.
• Press the power switch.
• Do not operate the power switch for approximately 10 seconds.
■Customization
Some functions can be customized.
(  P.508)
FunctionSettingsIndicator
Reaction
Time
Fast
A little fast
Normal
A little
slow
Slow
Operation
sounds
ON
OFF
WARNING
■To prevent overheating and
minor burn injuries
Observe the following precautions
when using the seat heaters.
●Do not cover the seat with a
blanket or cushion when using
the seat heater.
●Do not use seat heater more
than necessary.

3466-2. Using the interior lights
Owners Manual_USA_M62084_en
6-2.Using the interior lights
Door trim ornament lights (P.347) (if equipped)
Rear personal lights ( P.347)
Inside door handle lights ( P.347) (if equipped)
Front personal lights ( P.347)
Shift lever lights (if equipped)
Interior lights ( P.347)
Outer foot lights (if equipped)
Front footwell lights (if equipped)
Instrument panel ornament lights ( P.347) (if equipped)
Cup holder lights ( P.347)
Rear footwell lights (if equipped)
Door courtesy lights
Interior lights list
Location of the i nterior lights

3476-2. Using the interior lights
Owners Manual_USA_M62084_en
6
Interior features
■Turning the door position
on
Press the door-linked interior
light switch
The lights are turned on and off
according to whether the doors are
opened/closed.
■Turning the lights on/off
Touch the light
The rear personal lights turn on/off
along with the in terior lights.
■Turning the lights on/off
Touch the light
■Turning the lights on/off
Press the switch
The rear personal lights turn on/off
along with the interior lights.
Using the Toyota multi-operation
touch ( P.353), one of 8 colors
of following lights can be
selected. However, it cannot be
changed individually.
 Inside door handle lights
 Door trim ornament lights
 Cup holder lights
 Instrument panel ornament
lights
Operating the interior
lights
Operating the front per-
sonal lights
Operating the rear per-
sonal lights
Changing the illumina-
tion color (if equipped)

3486-2. Using the interior lights
Owners Manual_USA_M62084_en
1Select .
2 Select “Illumination Color”.
3 Select the desired color.
■Illuminated entry system
The lights automatically turn on/off
according to the power switch
mode, the presence of the elec-
tronic key, whether the doors are
locked/unlocked, and whether the
doors are open/closed.
■To prevent the 12-volt battery
from being discharged
If the interior lights remain on when
the power switch is turned off, the
lights will go off automatically after
20 minutes.
■When the interior lights or front
personal lights do not respond
as normal
●When water, dirt, etc., have
adhered to the lens surface
●When operated with a wet hand
●When wearing gloves, etc.
■The interior lights may turn on
automatically when
If any of the SRS airbags deploy
(inflate) or in the event of a strong
rear impact, the interior lights will
turn on automatically.
The interior lights will turn off auto-
matically after approximately 20min-
utes.
The interior lights can be turned off
manually. However, in order to help
prevent further collisions, it is rec-
ommended that they be left on until
safety can be ensured.
(The interior lights may not turn on
automatically depending on the
force of the impact and conditions of
the collision.)
■Customization
Some functions can be customized.
(  P.498)
NOTICE
■To prevent 12-volt battery dis-
charge
Do not leave the lights on longer
than necessary when the fuel cell
system is off.
■Removing light lenses
Never remove the lens for the
interior lights and front personal
lights. Otherwise, the lights will be
damaged. If a lens needs to be
removed, contact your Toyota
dealer.

3496-3. Using the storage features
Owners Manual_USA_M62084_en
6
Interior features
6-3.Using the storage features
Auxiliary boxes* (  P.351)
Cup holders ( P.350)
Console box ( P.351)
Glove box ( P.349)
*: If equipped
Pull up the lever to open.
List of storage features
Location of the storage features
WARNING
■Items that should not be left
in the storage spaces
Do not leave glasses, lighters or
spray cans in the storage spaces,
as this may cau se the following
when cabin temperature becomes
high:
●Glasses may be deformed by
heat or cracked if they come
into contact with other stored
items.
●Lighters or spray cans may
explode. If they come into con-
tact with other stored items, the
lighter may catch fire or the
spray can may release gas,
causing a fire hazard.
Glove box

3506-3. Using the storage features
Owners Manual_USA_M62084_en
1Unlock with the mechanical
key
2 Lock with the mechanical key
■Glove box light
The glove box light turns on when
the tail lights are on.
■Trunk opener main switch
The trunk opener main switch is
located in the glove box. ( P.129)
Front
Rear (vehicles without rear
seat heater)
Press in and release the button.
Rear (vehicles with rear seat
heater)
Press in and release the button.
WARNING
■Caution while driving
Keep the glove box closed. In the
event of sudden braking or sud-
den swerving, an accident may
occur due to an occupant being
struck by the open glove box or
the items stored inside.
Cup holders
WARNING
■Items unsuitable for the cup
holder
Do not place anyth ing other than
cups or beverage cans in the cup
holders.
Inappropriate items must not be
stored in the cup holders even if
the lid is closed.
Other items may be thrown out of
the holders in the event of an
accident or sudden braking and
cause injury. If possible, cover hot
drinks to pre vent burns.
■When not in use
Keep the cup holders closed.
Injuries may resul t in the event of
an accident or sudden braking.

3516-3. Using the storage features
Owners Manual_USA_M62084_en
6
Interior features
Press a button to open the con-
sole box.
Overhead (vehicles without
electronic sunshade)
Push in and release the auxiliary
box.
This box is useful for temporarily
storing the small items.
Rear seat (vehicles with rear
seat heater)
Pull the armrest down then push
the knob and lift the lid to open it.
Console box
WARNING
■Caution while driving
Keep the console box closed.
Injuries may result in the event of
an accident or sudden braking.
Auxiliary boxes
WARNING
■Caution while driving
Do not leave the auxiliary box
open while driving.
Items may fall out and cause
death or serious injury in case of
an accident or sudden stop.
■Items unsuitable for storing
(overhead)
Do not store items heavier than
0.4 lb. (0.2 kg).
Doing so may cause the auxiliary
box to open and the items inside
may fall out, resulting in an acci-
dent.

3526-3. Using the storage features
Owners Manual_USA_M62084_en
Side covers
Lift the side covers and remove
it.
Luggage mat
1 Pull the strap upwards and lift
up the luggage mat.
2 Lift the luggage mat until it
engages with the hook. The warning reflector can be
stowed underneath the luggage
mat.
Trunk features
Luggage mats
NOTICE
■To prevent damage to the
hook for the luggage mat
Do not hang a grocery bag or any
other object from the hook.
Warning reflector
