2021 ACURA NSX Owners Manual

71
Safe Driving
Safety Labels
Label Locations
These labels are in the locations shown. They warn you of potential hazards that can cause serious injury or death. Read these labels
carefully.
If a label comes off or becomes hard to read (except for the U. S. dashboard label which may be removed by the owner), contact a n
authorized Acura NSX dealer for a replacement.
Inverter Coolant
Filler Tank Cap Sun Visors
U.S. models Canadian models
Engine Coolant
Reserve Tank
Cap
High Voltage System Components
U.S. models Canadian models
Dashboard
U.S. models only
Air Conditioner System U.S. models Canadian models
21 ACURA NSX PMC-31T6N6400.book 71 ページ ２０２０年１０月８日　木曜日　午後３時７分

72
21 ACURA NSX PMC-31T6N6400.book 72 ページ ２０２０年１０月８日　木曜日　午後３時７分

73
Instrument Panel
This chapter describes the buttons, indicators, and gauges that are used while driving.
Indicators............................................ 74
Driver Information Interface Warning and Information Messages ...................... 87
Gauges and Displays .......................... 99
Gauges .............................................. 99
Driver Information Interface ............. 102
21 ACURA NSX PMC-31T6N6400.book 73 ページ ２０２０年１０月８日　木曜日　午後３時７分

74
Instrument Panel
Indicators
IndicatorNameOn/BlinkingExplanationMessage
Brake System
Indicator (Red)
•Comes on for a few seconds when
you set the power mode to ON,
then goes off.
• Comes on when the brake fluid
level is low.
• Comes on if there is a problem with
the brake system.•Comes on while driving - Check the
brake fluid level.
2 What to do when the indicator comes
on while driving P. 457
•Comes on along with the brake
system indicator (amber) - Immediately
stop in a safe place. Contact an authorized
Acura NSX dealer for repair. The brake
pedal becomes harder to operate. Depress
the pedal further than you normally do.
• Comes on along with the ABS
indicator - Have your vehicle checked by
an authorized Acura NSX dealer.
2 If the Brake System Indicator (Red)
Comes On P. 457
Low Oil Pressure
Indicator
•Comes on when you set the power
mode to ON, and goes off when
the power system starts.
• Comes on when the engine oil
pressure is low.
• Comes on if there is a problem with
the engine oil pressure system.•Comes on while driving - Immediately
stop in a safe place and set the power
mode to VEHICLE OFF, then contact an
authorized Acura NSX dealer.
U.S.
Canada
(Red)
21 ACURA NSX PMC-31T6N6400.book 74 ページ ２０２０年１０月８日　木曜日　午後３時７分

75
uuIndicators u
Continued
Instrument Panel
IndicatorNameOn/BlinkingExplanationMessage
Electric Parking
Brake Indicator
•Comes on when the parking brake
is applied, and goes off when it is
released.
• Comes on for about 15 seconds
then goes off when you pull the
electric parking brake switch with
the power mode in OFF.
• Comes on for about 15 seconds
then goes off when you set the
power mode to OFF with the
parking brake applied.• Blinks and the electric parking brake
system indicator comes on at the same
time - There is a problem with the electric
parking brake system. The parking brake
may not be set.
• Comes on when you press the
electric parking brake switch
without depressing the brake
pedal.• Depress the brake pedal to release the
parking brake.
2 Parking Brake P. 361
Electric Parking
Brake System
Indicator
•Comes on for a few seconds when
you set the power mode to ON,
then goes off.
• Comes on if there is a problem with
the electric parking brake system.• Comes on while driving - Avoid using
the parking brake and have your vehicle
checked by an auth orized Acura NSX
dealer immediately.
2 If the Electric Parking Brake System
Indicator Comes On P. 458
U.S.
Canada
21 ACURA NSX PMC-31T6N6400.book 75 ページ ２０２０年１０月８日　木曜日　午後３時７分

76
uuIndicators u
Instrument Panel
IndicatorNameOn/BlinkingExplanationMessage
Automatic Brake
Hold System
Indicator•Comes on when the automatic
brake hold system is on.
2 Automatic Brake Hold P. 364
Automatic Brake
Hold Indicator
•Comes on for a few seconds when
you set the power mode to ON,
then goes off.
• Comes on when the automatic
brake hold is activated.
2 Automatic Brake Hold P. 364—
U.S.
Canada
21 ACURA NSX PMC-31T6N6400.book 76 ページ ２０２０年１０月８日　木曜日　午後３時７分

77
uuIndicators u
Continued
Instrument Panel
IndicatorNameOn/BlinkingExplanationMessage
Brake System
Indicator
(Amber)
•Comes on for a few seconds when
you set the power mode to ON,
then goes off.
• Comes on if there is a problem with
a system related to braking other
than the conventional brake
system.
• Comes on if there is a problem with
the cooperative control with
regenerative braking, the electric
servo brake system, or the hill start
assist system.• Comes on while driving - Have your
vehicle checked by an authorized Acura
NSX dealer.
• Stays on constantly - Avoid high speeds
and sudden braking. Take the vehicle to
an authorized Acura NSX dealer
immediately.
• With this indicator on, your vehicle still has
normal braking ability.
U.S.
Canada
(Amber)
U.S.
Canada
21 ACURA NSX PMC-31T6N6400.book 77 ページ ２０２０年１０月８日　木曜日　午後３時７分

78
uuIndicators u
Instrument Panel
IndicatorNameOn/BlinkingExplanationMessage
POWER
SYSTEM
Indicator
• Comes on for a few seconds when
you set the power mode to ON,
then goes off.
• Comes on if there is a problem with
the electric vehicle system.• Comes on while driving - Have your
vehicle checked by an authorized Acura
NSX dealer immediately.
READY Indicator
•Comes on when the vehicle is ready
to drive.
2 Turning on the Power P. 325
Active Damper
System Indicator
•Comes on for a few seconds when
you change the power mode to
ON, then goes off.
• Comes on if there is a problem with
the Active Damper System. The
speed of the vehicle will be limited.• Stays on constantly - Have the vehicle
checked by an authorized Acura NSX
dealer. With this indicator on, your vehicle
has normal damping ability without the
active damper feature.
2 Integrated Dynamics System P. 340
Brake Wear
Indicator*
•Comes on for a few seconds when
you change the power mode to
ON, then goes off.
• Comes on if a worn brake pad is
detected.• Comes on while driving - The brake
pads may need to be replaced. Have your
vehicle inspected by an authorized Acura
NSX dealer.U.S.
Canada
U.S.
Canada
* Not available on all models
