CLIMATE CONTROL
* Option/accessory.199
Clean Zone*
The Clean Zone function monitors the condi-tions affecting good air quality in the passengercompartment and indicates whether they are ful-filled or not.
The indicator is shown in the center display'sClimate view.
The indicator is shown in the climate barwhen Climate view is not open.
If the conditions are not met, the text CleanZone will be shown in white. When all the condi-tions are met, the text will change to blue.
The following conditions must be met:
All doors and trunk lid are closed.
All side windows and panoramic roof* areclosed.
The Interior Air Quality System* is activated.
The blower is activated.
Air recirculation is deactivated.

NOTE
Clean Zone does not indicate that the airquality is good, but only that the conditions forgood air quality have been met.

Related information
Air quality (p. 198)
Clean Zone Interior Package* (p. 199)
Interior Air Quality System* (p. 200)
Passenger compartment air filter (p. 201)
Clean Zone Interior Package*
Clean Zone Interior Package (CZIP) is a seriesof modifications that filters even more allergy andasthma-inducing substances from the passengercompartment.
CZIP includes the following:
An enhanced function that starts the blowerwhen the vehicle is unlocked using theremote key. The blower will then fill the pas-senger compartment with fresh air. The func-tion starts when required and switches offautomatically after a period of time or whenone of the passenger compartment doors isopened. The amount of time the blower runsgradually decreases due to reduced need upuntil the vehicle is 4 years old.
The fully automatic Interior Air QualitySystem (IAQS).

Related information
Air quality (p. 198)
Clean Zone* (p. 199)
Interior Air Quality System* (p. 200)
Passenger compartment air filter (p. 201)

CLIMATE CONTROL
* Option/accessory.200
Interior Air Quality System*
Interior Air Quality System (IAQS) is a fully auto-matic air quality system that removes gases andparticles to reduce odors and contaminants inthe passenger compartment.
IAQS is part of the Clean Zone Interior Package(CZIP) and removes air contaminants such asparticles, hydrocarbons, nitric oxides and ground-level ozone.
If the system's air quality sensors detect contami-nants in the outside air, the air intake closes andair recirculation is activated.

NOTE
To ensure optimal air quality in the passengercompartment, the air quality sensor shouldalways be engaged.
Recirculation is limited in cold weather to pre-vent fogging.
In the event of fogging, use the defrosterfunctions for the windshield, side windowsand rear window.

Related information
Activating and deactivating the air qualitysensor* (p. 200)
Air quality (p. 198)
Clean Zone* (p. 199)
Clean Zone Interior Package* (p. 199)
Passenger compartment air filter (p. 201)
Activating and deactivating the air
quality sensor*
The air quality sensor is part of the fully automa-ted Interior Air Quality System (IAQS).
The air quality sensor can be switched on or off.
1.Tap Settings in the Top view in the centerdisplay.
2.Tap Climate.
3.Select Air Quality Sensor to activate/deac-tivate the air quality sensor.
Related information
Interior Air Quality System* (p. 200)

CLIMATE CONTROL
* Option/accessory.201
Passenger compartment air filter
All air entering the passenger compartmentthrough the climate control system intake is fil-tered.

Replacing the passenger compartment
filter
To maintain the high performance of the climatecontrol system, the filter must be replaced regu-larly. Follow Volvo's service schedule for recom-mended replacement intervals. When driving inareas with a lot of smog, dust, etc., the filter mayneed to be changed more frequently.

NOTE
There are two types of passenger compart-ment filters. Make sure that the correct filteris installed.

Related information
Air quality (p. 198)
Clean Zone* (p. 199)
Clean Zone Interior Package* (p. 199)
Interior Air Quality System* (p. 200)
Air distribution
The climate system distributes incoming airthrough a number of vents in the passengercompartment.
Automatic and manual air distribution
When the auto-climate feature is on, air distribu-tion is regulated automatically. Air distribution canalso be controlled manually.

Adjustable air vents
Certain air vents in the vehicle are adjustable,which means they can be opened/closed and thedirection of the air flow from the vent can beadjusted.
Location of adjustable air vents in the passenger com-partment.
Four vents on the dashboard and one oneach of the pillars between the front and reardoors.
Related information
Climate (p. 196)
Adjusting air distribution (p. 202)
Opening, closing and directing air vents(p. 202)
Air distribution options (p. 204)

CLIMATE CONTROL
202
Adjusting air distribution
Air distribution can be adjusted manually if nee-ded.
1. Tap the symbol in the center of the climatebar to open Climate view in the center dis-play.
Air distribution buttons in Climate view.
Air distribution - windshield defrost vents
Air distribution - dashboard and center con-sole air vents
Air distribution - floor air vents
2.Tap one or more air distribution buttons toopen/close the airflow for that vent.
>The air distribution changes and the but-tons will light up or go out.

Related information
Air distribution (p. 201)
Opening, closing and directing air vents(p. 202)
Air distribution options (p. 204)
Opening, closing and directing airvents
Some of the air vents in the passenger compart-ment can be individually opened, closed anddirected.
Misting can be eliminated by directing the outerair vents towards the door windows.
Direct the outer air vents into the passengercompartment to maintain a comfortable tempera-ture in warm weather.
Opening and closing the air vents
Air vents on the dashboard:
–Turn the knob in the center of the air vent toopen/close airflow from the vent.
When the mark on the knob is vertical, theairflow is strongest.
Air vents on the door pillars:
–Move the lever in the center of the air ventup/down to open/close the airflow from thevent.
The airflow is stopped when the lever is inthe lowest position. In other positions, the air-flow is constant.

Directing air flow
–Move the lever in the center of the air venthorizontally or vertically to direct the airflowfrom the vent.

CLIMATE CONTROL
203

Related information
Air distribution (p. 201)
Adjusting air distribution (p. 202)
Air distribution options (p. 204)

CLIMATE CONTROL
204
Air distribution options
Air distribution can be adjusted manually if nee-ded. The following options are available.
Air distributionPurpose
If all air distribution buttons are deselected in manual mode, the climate control system will revert to automatic mode.
Main airflow from defroster vents. Some airflow from other vents. Helps remove ice and condensation in cold and humid weather(blower speed should not be set too low).
Main airflow from dashboard vents. Some airflow from other vents. Provides effective cooling in warm weather.
Main airflow from floor vents. Some airflow from other vents. Provides heating or cooling in footwell areas.

CLIMATE CONTROL
}}
205
Air distributionPurpose
Main airflow from defroster and dashboard vents. Some airflowfrom other vents.Provides a comfortable climate in warm and dry weather.
Main airflow from defroster and floor vents. Some airflow fromother vents.Provides a comfortable climate and effective defogging in cold andhumid weather.
Main airflow from dashboard and floor vents. Some airflow fromother vents.Provides a comfortable climate in sunny, cool weather.
Main airflow from defroster, dashboard and floor vents.Provides balanced comfort in the passenger compartment.

||
CLIMATE CONTROL
206

Related information
Air distribution (p. 201)
Opening, closing and directing air vents(p. 202)
Adjusting air distribution (p. 202)
