HEADLAMP (LO) CIRCUITEXL-81
< DTC/CIRCUIT DIAGNOSIS >
C
DE
F
G H
I
J
K
M A
B
EXL
N
O P
Is the inspection result normal?
YES >> Replace daytime light relay 2.
NO >> Repair or replace the harness or connector.
8.CHECK IPDM E/R TO DAYTIME LIGHT RELAY 2 CIRCUIT FOR OPEN
1. Disconnect IPDM E/R connector E44.
2. Check continuity between the daytime running li ght relay 2 harness connector E38 and the IPDM E/R
connector E44.
Is the inspection result normal?
YES >> Replace IPDM E/R. Refer to PCS-30, "Removal and Installation".
NO >> Repair or replace the harness or connector.
9.CHECK FRONT COMBINATION LAMP (LO) GROUND CIRCUIT
Check continuity between the front combination lamp harness connector and ground.
Is the inspection result normal?
YES >> Replace malfunctioning lamp.
NO >> Repair or replace the harness or connec tor (without daytime running light system).
>> GO TO 10 (with daytime running light system).
10.CHECK FRONT COMBINATION LAMP LH TO DA YTIME RUNNING LIGHT RELAY 1 GROUND CIRCUIT
1. Disconnect daytime running light relay 1 connector E37.
2. Check continuity between the daytime running light relay 1 harness connector E37 and the front combina-
tion lamp LH harness connector E25.
Is the inspection result normal?
YES >> GO TO 11.
NO >> Repair or replace the harness or connector.
11 .CHECK DAYTIME RUNNING LIGHT RELAY 1 GROUND CIRCUIT
Check continuity between the daytime running light relay 1 harness connector E37 and ground.
Is the inspection result normal?
YES >> Replace daytime running light relay 1.
NO >> Repair or replace the harness or connector.
Connector Terminal —Continuity
E38 1Ground Yes
ConnectorTerminalConnector Terminal Continuity
E38 2
E44 14 Yes
5
Connector Terminal —Continuity
LH E25
2 Ground Yes
RH E26
Connector TerminalConnector Terminal Continuity
E37 3E25 2Yes
Connector Terminal —Continuity
E37 4Ground Yes
