2016 NISSAN NOTE re0f

TM-236
< REMOVAL AND INSTALLATION >[CVT: RE0F11A]
CONTROL CABLE
2. Install the socket (A) onto the shift selector assembly.
CAUTION:
• Insert the socket into the shift selector assembly, thenpush it firmly in place.
• Check that pulling on the so cket does not disconnect it.
Inspection and AdjustmentINFOID:0000000012431181
INSPECTION AFTER INSTALLATION
Check CVT position. Refer to TM-133, "Inspection".
ADJUSTMENT AFTER INSTALLATION
Adjust CVT position. Refer to TM-133, "Adjustment".
JSDIA1810ZZ
Revision: August 2015 2016 Versa Note

cardiagn.com

KEY INTERLOCK CABLETM-237
< REMOVAL AND INSTALLATION > [CVT: RE0F11A]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
KEY INTERLOCK CABLE
Exploded ViewINFOID:0000000012431182
Removal and InstallationINFOID:0000000012431183
REMOVAL
CAUTION:
Always apply the parking brake before pe rforming removal and installation.
1. Move the shift selector to the “N” position.
2. Remove the shift selector handle. Refer to TM-232, "
Disassembly and Assembly".
3. Remove the instrumental lower panel LH. Refer to IP-24, "
Removal and Installation".
4. Remove steering column covers. Refer to IP-17, "
Removal and Installation".
5. Remove the center console. Refer to IP-18, "
Removal and Installation".
6. Move the shift selector to the “P” position.
7. Press the pawls (B) of the key interlock cable slider (A) while sliding it in the direction of the casing cap (C), and separate the
adjusting holder (D) and slider.
8. Remove the key interlock cable from the shift selector assembly.
1. Shift selector assembly 2. Key interlock cable A: Steering lock unit
B: Lock plate C: Clip
ALDIA0262ZZ
(E) :Key interlock rod
JSDIA1797ZZ
Revision: August 2015 2016 Versa Note

cardiagn.com

TM-238
< REMOVAL AND INSTALLATION >[CVT: RE0F11A]
KEY INTERLOCK CABLE
9. Lift lock plate (A) in the direction of the arrow ( C) and remove
in the direction of the arrow ( D).
10. Remove the key interlock cable from the steering lock unit.
11. Disengage the clips and remove the key interlock cable from the vehicle.
INSTALLATION
Installation is in the reverse order of removal.
• Temporarily install the adjust holder (A) to the key interlock rod (B).
• Install the casing cap (C) to the cable bracket (D) on the shift
selector assembly.
CAUTION:
• Do not bend or twist key interlock cable excessively wheninstalling.
• After installing key interlock cable to cable bracket (D) on shift selector assembly, make sure casing caps (C) is firmly
secured in cable bracket (D) on shift selector assembly.
• If casing cap (C) is loose [less than 39.2 N (4.0 kg, 8.8 lb) removing force], replace key interlock cable.
• Slide the slider (A) toward the key interlock rod (D) while pressing the pull lock (B) down to securely connect the adjust holder (C)
with the key interlock rod (D).
CAUTION:
• Do not press tabs when holding slider (A).
• Do not apply any side to side force to key interlock rod (D)
when sliding slider (A).
InspectionINFOID:0000000012431184
INSPECTION AFTER INSTALLATION
• Check the CVT operation. If a malfunction is found, adjust the CVT position. Refer to TM-232, "Inspection".
• Make sure the key can be removed only when the shift selector is in the “P” position.
• Make sure the ignition switch will not turn to LOCK pos ition when the shift selector is not in the “P” position.
(1) :Key interlock cable
(B) :Steering lock unit
JSDIA1798ZZ
JSDIA1799ZZ
JSDIA1800ZZ
Revision: August 2015 2016 Versa Note

cardiagn.com

TCM
TM-239
< REMOVAL AND INSTALLATION > [CVT: RE0F11A]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
TCM
Exploded ViewINFOID:0000000012431185
Removal and InstallationINFOID:0000000012431186
CAUTION:
• When replacing TCM, note the “CVTF DETERIORATION DATE” value displayed on CONSULT “CON- FORM CVTF DETERIORATION” in MAINTENANCE BOOKLET, before starting the operation.
• When replacing TCM, perform "ADDITIONAL SERVICE WHEN REPLACING TCM". Refer to TM-125,
"Description".
• When replacing TCM and transaxle assembly simultaneously, replace transaxle assembly first and then replace TCM.
REMOVAL
1. Remove the battery. Refer to PG-70, "Removal and Installation (Battery)".
2. Disconnect the harness connector from the TCM.
3. Remove the TCM and bracket as an assembly.
4. Remove the TCM from the bracket (if necessary).
INSTALLATION
Installation is in the reverse order of removal.
AdjustmentINFOID:0000000012431187
ADJUSTMENT AFTER INSTALLATION
Perform "ADDITIONAL SERVICE WHEN REPLACING TCM". Refer to TM-125, "Description".
1. TCM2. Bracket3. Clip
Front
AWBIA1482ZZ
Revision: August 2015 2016 Versa Note

cardiagn.com

TM-240
< REMOVAL AND INSTALLATION >[CVT: RE0F11A]
AIR BREATHER HOSE
AIR BREATHER HOSE
Removal and InstallationINFOID:0000000012431188
REMOVAL
1. Remove air duct (inlet). Refer to
EM-26, "Exploded View".
2. Remove air breather hose from transaxle assembly.
INSTALLATION
Installation is in the reverse order of removal.
CAUTION:
• Check that air breather hose is not collapsed or bl ocked due to folding or bending when installed.
• Be sure to insert air breather hose (1) fully until it reaches the base of the transaxle tube (A).
JSDIA1978ZZ
Revision: August 2015 2016 Versa Note

cardiagn.com

G SENSORTM-241
< REMOVAL AND INSTALLATION > [CVT: RE0F11A]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
G SENSOR
Exploded ViewINFOID:0000000012431189
Removal and InstallationINFOID:0000000012431190
CAUTION:
• Do not drop or strike G sensor, because it may be damaged by impact.
• Do not use a power tool.
REMOVAL
1. Disconnect the battery negative terminal. Refer to PG-70, "Exploded View".
2. Remove center console assembly. Refer to IP-18, "
Removal and Installation".
3. Disconnect the harness connector from G sensor.
4. Remove G sensor.
INSTALLATION
Installation is in the reverse order of removal.
AdjustmentINFOID:0000000012431191
ADJUSTMENT AFTER INSTALLATION
Perform “G SENSOR CALIBRATION”. Refer to TM-130, "Description".
1. G sensor Front
JSDIA1922GB
Revision: August 2015 2016 Versa Note

cardiagn.com

TM-242
< REMOVAL AND INSTALLATION >[CVT: RE0F11A]
OIL PAN, CONTROL VALVE
OIL PAN, CONTROL VALVE
Exploded ViewINFOID:0000000012431192
Removal and InstallationINFOID:0000000012431193
REMOVAL
1. Disconnect battery negative terminal.
1. Transaxle assembly
2. O-ring 3. Control valve
4. Manual plate 5. Washer 6. O-ring
7. Strainer 8. Oil pan gasket9. Magnet
10. Oil pan 11. Drain plug gasket 12. Drain plug
13. Overflow tube : Apply petroleum jelly
: Always replace after every disassembly.
: Apply CVT fluid
: N·m (kg-m, ft-lb)
: N·m (kg-m, in-lb)
JSDIA6707GB
Revision: August 2015 2016 Versa Note

cardiagn.com

OIL PAN, CONTROL VALVETM-243
< REMOVAL AND INSTALLATION > [CVT: RE0F11A]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
2. Disconnect the CVT unit harness connector.
3. Remove the drain plug and overflow tube, and then drain the CVT fluid. CAUTION:
Use caution when looking into the drain hole as there is the risk of fluid entering the eye.
4. Remove the drain plug gasket from the drain plug.
5. Remove the oil pan mounting bolts ( ), and then remove the oil pan and oil pan gasket.
6. Remove the magnets from the oil pan.
7. Remove the strainer bolts , and then remove the strainer from the control valve.
8. Remove the nut and washer , and then remove manual plate .
CAUTION:
To remove nut, fix manual plat e with flat-blade screwdriver
(B).
9. Press the CVT unit harness connector into the transaxle case. CAUTION:
Never damage the CVT unit harness connector.
NOTE:
Clean around the CVT unit harness connector to prevent foreign
materials from entering into the transaxle case.
10. Remove the control valve bolts , and then remove the control valve from the transaxle case.
CAUTION:
• Never drop the control valve and manual valve.
:Vehicle front
JSDIA1874ZZ
JSDIA6594ZZ
JSDIA6595ZZ
JSDIA6598ZZ
Revision: August 2015 2016 Versa Note
