SHIFT POSITION INDICATOR CIRCUIT
SHIFT POSITION INDICATOR CIRCUIT
Component Parts Fu
nction InspectionINFOID:0000000012431167
1.CHECK SHIFT POSITION INDICATOR
1. Start the engine.
2. Shift selector lever.
3. Check that the selector lever position and the shift position indicator on the combination meter are identi-
cal.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Go to TM-220, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000012431168
1.CHECK TCM INPUT/OUTPUT SIGNAL
With CONSULT
1. Start the engine.
2. Select “Data Monitor” in “TRANSMISSION”.
3. Select “RANGE”.
4. Shift selector lever.
5. Check that selector lever position, “RANGE” on CONSULT screen, and shift position indicator display on
combination meter are identical.
Is the check result normal?
YES >> INSPECTION END
NO-1 (“RANGE” is changed but is not displayed on shift position indicator.>>Check “Self Diagnostic Result” in “TRANSMISSION”.
NO-2 (“RANGE” and shift position indicator are differ ent.)>>Check “Self Diagnostic Result” in “TRANSMIS-
SION”.
NO-3 (Specific“RANGE” is not displayed on shift position indicator.)>>Check “Self Diagnostic Result” in
“METER/M&A”.
Revision: August 2015 2016 Versa Note

cardiagn.com

SHIFT LOCK SYSTEMTM-221
< DTC/CIRCUIT DIAGNOSIS > [CVT: RE0F11A]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
SHIFT LOCK SYSTEM
Component Function CheckINFOID:0000000012431169
1.CHECK SHIFT LOCK OPERATIO N (BRAKE PEDAL RELEASED)
1. Ignition switch ON.
2. Attempt to shift selector lever to any position other than “P” position with brake pedal released.
Can the selector lever be shifted?
YES >> Go to TM-221, "Diagnosis Procedure".
NO >> GO TO 2.
2.CHECK SHIFT LOCK OPERATIO N (BRAKE PEDAL APPLIED)
Attempt to shift the selector lever to any pos ition other than “P” position with brake pedal applied.
Can the selector lever be shifted?
YES >> Inspection End.
NO >> Go to TM-221, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000012431170
1.CHECK STOP LAMP SWITCH
1. Ignition switch ON.
2. Check voltage between stop lamp switch connector E13 terminal 4 and ground.
Is the inspection result normal?
YES >> GO TO 2.
NO >> GO TO 3.
2.CHECK GROUND CIRCUIT
1. Ignition switch OFF.
2. Disconnect CVT shift selector connector.
3. Check continuity between CVT shift selector connector M38 terminal 6 and ground.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace ground circuit.
3.CHECK STOP LAMP SWITCH POWER CIRCUIT
Check voltage between stop lamp switch connector E13 terminal 3 and ground.
Is the inspection result normal?
YES >> Replace stop lamp switch.
NO >> Repair or replace power circuit.
Stop lamp switch Ground Brake pedal Voltage
Connector Terminal
E13 4Ground Applied
Battery voltage
Released 0V
CVT shift selector
GroundContinuity
Connector Terminal
M38 6Ground Yes
Stop lamp switch
GroundVoltage
Connector Terminal
E13 3GroundBattery voltage
Revision: August 2015 2016 Versa Note

cardiagn.com

TM-222
< DTC/CIRCUIT DIAGNOSIS >[CVT: RE0F11A]
SHIFT LOCK SYSTEM
4.CHECK CVT SHIFT SELECTOR POWER CIRCUIT
Check voltage between CVT shift selector connector M38 terminal 5 and ground.
Is the inspection result normal?
YES >> Replace CVT shift selector. Refer to TM-231, "Removal and Installation".
NO >> Repair or replace power circuit.
CVT shift selector GroundBrake pedal Voltage
Connector Terminal
M38 5Ground AppliedBattery voltage
Revision: August 2015 2016 Versa Note

cardiagn.com

CVT CONTROL SYSTEMTM-223
< SYMPTOM DIAGNOSIS > [CVT: RE0F11A]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
SYMPTOM DIAGNOSIS
CVT CONTROL SYSTEM
Symptom TableINFOID:0000000012431171
The diagnosis item number indicates the order of check. Start checking in the order from 1.
Symptom diagnosis chart 1-1
SymptomCheck under on board condition (repair
and part replacement) Replace the transaxle assembly.
Engine system
Incorrect adjustment of CVT fluid level
Line pressure is out of the standard value.
Control cable
Electric system
TCM
Overdrive control switch
Primary speed sensor (P0715)
Secondary speed sensor (P2765)
Output speed sensor (P0720)
Transmission position switch (P0705, P0706)
Secondary pressure sensor (P0846, P0847, P0848)
Primary pressure soleno
id valve (P17BA, P17BB)
Line pressure solenoid valve (P0746, P0962, P0963)
Lock-up solenoid valve
(P0740, P0743, P0744)
High clutch &reverse brake solenoid valve
(P1739, P173C, P17B7, P17B8)
Low brake solenoid valve
(P173A, P173B, P17B4, P17B5)
CVT fluid temperature sensor (P0711, P0712, P0713)
EC-120
TM-229TM-131TM-232TM-99TM-217TM-110
Driving is
not possi-
ble. The engine speed increases in
“D”, “L”, or “R” position, but the
vehicle cannot start.
11111 11 12 1 1 1 2
Engine stall occurs in “D”, “L”,
or “R” position and the vehicle
does not start. 11 11 1111 1 1 2
Acceleration at start is not suf-
ficient in “D”, “L”, or “R” posi-
tion. 1 2 1 1112211 2 1 1 1
The engine speed increases
suddenly in “D”, “L”, or “R” po-
sition during driving. 11
211 1 1
Engine brake is suddenly ap-
plied in “D” or “R” position dur-
ing driving. 11
11 11
Revision: August 2015 2016 Versa Note

cardiagn.com

TM-224
< SYMPTOM DIAGNOSIS >[CVT: RE0F11A]
CVT CONTROL SYSTEM
Shifting is
not possi-
ble. The engine races when the
auxiliary gearbox is shifted
from 1GR ⇔
2GR. 21
1 11
Engine braking is not effective
in “L” position. 111 11 1 21 1 1
Shifting does not occur with
OD OFF. 111111 11
Engine stall occurs immediate-
ly before stop at deceleration in
“D” or “L” position. 11
During driving in “D” position,
slippage occurs in lockup or
lockup is not possible. 1 1111211 1
1
Symptom
Check under on board condition (repair
and part replacement) Replace the transaxle assembly.
Engine system
Incorrect adjustment of CVT fluid level
Line pressure is out of the standard value.
Control cable
Electric system
TCM
Overdrive control switch
Primary speed sensor (P0715)
Secondary speed sensor (P2765)
Output speed sensor (P0720)
Transmission position switch (P0705, P0706)
Secondary pressure sensor (P0846, P0847, P0848)
Primary pressure solenoid valve (P17BA, P17BB)
Line pressure solenoid valve (P0746, P0962, P0963)
Lock-up solenoid valve
(P0740, P0743, P0744)
High clutch &reverse brake solenoid valve
(P1739, P173C, P17B7, P17B8)
Low brake solenoid valve
(P173A, P173B, P17B4, P17B5)
CVT fluid temperature sensor (P0711, P0712, P0713)
EC-120
TM-229TM-131TM-232TM-99TM-217TM-110
Revision: August 2015
2016 Versa Note

cardiagn.com

CVT CONTROL SYSTEMTM-225
< SYMPTOM DIAGNOSIS > [CVT: RE0F11A]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
Symptom diagnosis chart 1-2
Symptom Replace the transaxle assembly.
Oil pres-
sure con- trol Power transmission
Valve body, control valve
Oil pump
Torque converter
Pulley, steel belt
Low brake
High clutch
Reverse brake
Bearings
Counter gear
Planetary gear
Reduction gear
Final gear, differential gear
Parking mechanism
TM-259
Driving is
not possi- ble. The engine speed increases in
“D”, “L”, or “R” position, but the
vehicle cannot start.
11 11
(In “D” or “L”) 1
(In “R”) 1111
Engine stall occurs in “D”, “L”,
or “R” position and the vehicle
does not start. 1
111111
Acceleration at start is not suf-
ficient in “D”, “L”, or “R” posi-
tion. 111
(In “D” or “L”) 1
(In “R”)
The engine speed increases
suddenly in “D”, “L”, or “R” po-
sition during driving. 11 11
(In “D” or “L”) 1
(In “D” or “L”) 1
(In “R”)
Engine brake is suddenly ap-
plied in “D” or “R” position dur-
ing driving. 1
1
(In “D” or
“L”) 1
(In “D” or
“L”) 1
(In “R”)
Shifting is
not possi- ble. The engine races when the
auxiliary gearbox is shifted
from 1GR ⇔
2GR. 11 2 1 1
Engine braking is not effective
in “L” position. 1212 1 1
Shifting does not occur with
OD OFF.
Engine stall occurs immedi-
ately before stop at decelera-
tion in “D” or “L” position. 11
During driving in “D” position,
slippage occurs in lockup or
lockup is not possible. 11
Revision: August 2015
2016 Versa Note

cardiagn.com

TM-226
< SYMPTOM DIAGNOSIS >[CVT: RE0F11A]
CVT CONTROL SYSTEM
Symptom diagnosis chart 2-1
SymptomCheck under on board condition (repair
and part replacement) Replace the transaxle assembly.
Engine system
Incorrect adjustment of CVT fluid level
Line pressure is out of the standard value.
Control cable
Electric system
TCM
Overdrive control switch
Primary speed sensor (P0715)
Secondary speed sensor (P2765)
Output speed sensor (P0720)
Transmission position switch (P0705, P0706)
Secondary pressure sensor (P0846, P0847, P0848)
Primary pressure soleno
id valve (P17BA, P17BB)
Line pressure solenoid valve (P0746, P0962, P0963)
Lock-up solenoid valve
(P0740, P0743, P0744)
High clutch &reverse brake solenoid valve
(P1739, P173C, P17B7, P17B8)
Low brake solenoid valve
(P173A, P173B, P17B4, P17B5)
CVT fluid temperature sensor (P0711, P0712, P0713)
EC-120
TM-229TM-131TM-232TM-99TM-217TM-110
Shock vi-
bration
Noise Shock at start is large in “D”,
“L”, or “R” position.
12
11
Shock is large when the aux-
iliary gearbox is shifted from
1GR → 2GR. 212
22 11
Shock in lockup is large dur-
ing driving in “D ” or “L” posi-
tion. 11
Shock is large when the lever
is shifted from “N” → “D” and
“N” → “R” positions. 1 12111 11111
Shock is large when the lever
is shifted from “D” → “L” posi-
tion.
Vibration occurs in “D”, “L”, or
“R” position during driving. 1111 12 111
Noise occurs during driving. 1
Noise occurs in idling. 1 1
Other Starter operates in “D”, “L”, or
“R” position.
11
1
Starter does not operate in
“P” or “N” position. 11
1
Engine stall occurs in “D”, “L”,
or “R” position during stop. 111 1
Engine stall occurs in “P” or
“N” position during stop. 111 1
Parking lock does not oper-
ate in “P” position. 11
Parking lock cannot be can-
celled when the selector le-
ver is shifted from “P” position
to other position. 11
Revision: August 2015
2016 Versa Note

cardiagn.com

CVT CONTROL SYSTEMTM-227
< SYMPTOM DIAGNOSIS > [CVT: RE0F11A]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
Symptom diagnosis chart 2-2
Symptom Replace the transaxle assembly.
Oil pres-
sure con- trol Power transmission
Valve body, control valve
Oil pump
Torque converter
Pulley, steel belt
Low brake
High clutch
Reverse brake
Bearings
Counter gear
Planetary gear
Reduction gear
Final gear, differential gear
Parking mechanism
TM-259
Shock vi-
bration
Noise Shock at start is large in “D”,
“L”, or “R” position.
111
(In “D” or “L”) 1
(In “R”) 2222
Shock is large when the auxil-
iary gearbox is shifted from
1GR → 2GR. 11
1
Shock in lockup is large dur-
ing driving in “D” or “L” posi-
tion. 11
Shock is large when the lever
is shifted from “N” → “D” and
“N” → “R” positions. 11
(“N” →
“D”) 1
(“N” →
“D”)
Shock is large when the lever
is shifted from “D” → “L” posi-
tion. 11
1
Vibration occurs in “D”, “L”, or
“R” position during driving. 11111
(In “D” or “L”) 1
(In “D” or “L”) 1
(In “R”) 11111
Noise occurs during driving. 1 1 1 11111
Noise occurs in idling. 1 1 1 1 1 1
Other Starter operates in “D”, “L”, or
“R” position.
Starter does not operate in “P”
or “N” position.
Engine stall occurs
in “D”, “L”,
or “R” position during stop. 11
Engine stall occurs in “P” or
“N” position during stop.
Parking lock does not operate
in “P” position. 1
Parking lock cannot be can-
celled when the selector lever
is shifted from “P” position to
other position. 1
Revision: August 2015
2016 Versa Note

cardiagn.com
