2016 NISSAN NOTE re0f

TM-244
< REMOVAL AND INSTALLATION >[CVT: RE0F11A]
OIL PAN, CONTROL VALVE
• To remove bolt of the oil temperature sensor bracket and
the control valve, fix bracket with flat-blade screw-
driver.
11. Remove the O-ring to the CVT unit harness connector.
INSTALLATION
1. Install the O-ring to the CVT unit harness connector. CAUTION:
• Never reuse O-ring.
• Apply CVT fluid to the O-ring
• Never pinch the harness , between the control valve and
the CVT unit harness connector bracket .
• Never twist the harness.
• Never slack the harness.
2. Install the control valve, and than tighten control valve bolts to the specitoed torque.
CAUTION:
• Never pinch the harness be tween the control valve and
the transaxle case.
• Never drop the control valve and manual valve.
3. Install the manual plate and washer , and then tighten nut to the specitied torque.
CAUTION:
To tighten nut, fix manual plat e with flat-blade screwdriver.
JSDIA6596ZZ
JSDIA6599ZZ
JSDIA6598ZZ
JSDIA6597ZZ
Revision: August 2015 2016 Versa Note

cardiagn.com

OIL PAN, CONTROL VALVETM-245
< REMOVAL AND INSTALLATION > [CVT: RE0F11A]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
4. Install the strainer , and then tighten the strainer bolts to the specitied torque.
5. Install oil pan (with oil pan gasket) to transaxle case and tempo- rarily tighten oil pan bolts ( ).
CAUTION:
Never reuse oil pan gasket.
6. Tighten the oil pan bolts to specification in the order shown.
7. Tighten the overflow tube to the specitied torque. CAUTION:
If it is not tightened to the specified torque, the tube may be
damaged.
8. Connect the CVT unit harness connector.
9. Connect battery negative terminal.
10. Fill with CVT fluid from overflow tube to the specified level. Refer to TM-228, "
Replacement".
11. Install the drain plug and drain plug gasket to oil pan. CAUTION:
Never reuse drain plug gasket.
Inspection and AdjustmentINFOID:0000000012431194
INSPECTION AFTER REMOVAL
Check oil pan for foreign material.
• If a large amount of worn material is found, clutch plate may be worn.
• If iron powder is found, bearings, gears, or clutch plates may be worn.
• If aluminum powder is found, bushing may be worn, or ch ips or burrs of aluminum casting parts may enter.
Check points where wear is found in all cases.
ADJUSTMENT AFTER INSTALLATION
Erase the CVT fluid deterioration data.
INSPECTION AFTER INSTALLATION
• When replacing control valve, perform "ADDITION AL SERVICE WHEN REPLACING CONTROL VALVE OR
TRANSAXLE ASSEMBLY". Refer to TM-127, "
Work Procedure".
• Check the CVT fluid level, condition and leakage.
JSDIA6594ZZ
: Vehicle front
JSDIA1874ZZ
: Vehicle front
JSDIA1884ZZ
Revision: August 2015 2016 Versa Note

cardiagn.com

TM-246
< REMOVAL AND INSTALLATION >[CVT: RE0F11A]
PRIMARY SPEED SENSOR
PRIMARY SPEED SENSOR
Exploded ViewINFOID:0000000012431195
Removal and InstallationINFOID:0000000012431196
REMOVAL
1. Partially remove fender protector (LH). Refer to
TM-246, "Exploded View".
2. Disconnect the harness connector from primary speed sensor.
3. Remove the primary speed sensor.
4. Remove the O-ring from the primary speed sensor.
INSTALLATION
Installation is in the reverse order of removal.
CAUTION:
• Do not reuse O-ring.
• Apply Genuine NISSAN CVT Fluid NS-3 to the O-ring.
Inspection and AdjustmentINFOID:0000000012431197
INSPECTION AFTER INSTALLATION
Check for CVT fluid leakage. Refer to TM-228, "Inspection".
ADJUSTMENT AFTER INSTALLATION
Adjust the CVT fluid level. Refer to TM-229, "Adjustment".
1. Transaxle assembly 2. O-ring 3. Primary speed sensor
Front : Genuine NISSAN CVT Fluid NS-3
JSDIA1880GB
Revision: August 2015 2016 Versa Note

cardiagn.com

SECONDARY SPEED SENSORTM-247
< REMOVAL AND INSTALLATION > [CVT: RE0F11A]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
SECONDARY SPEED SENSOR
Exploded ViewINFOID:0000000012431198
Removal and InstallationINFOID:0000000012431199
REMOVAL
1. Remove battery tray. Refer to PG-71, "Removal and Installation (Battery Tray)".
2. Remove IPDM/ER. Refer to PCS-30, "
Removal and Installation".
3. Disconnect the harness connector from secondary speed sensor.
4. Remove the secondary speed sensor.
5. Remove the O-ring from the secondary speed sensor.
INSTALLATION
Installation is in the reverse order of removal.
CAUTION:
• Do not reuse O-ring.
• Apply Genuine NISSAN CVT Fluid NS-3 to the O-ring.
Inspection and AdjustmentINFOID:0000000012431200
INSPECTION AFTER INSTALLATION
Check for CVT fluid leakage. Refer to TM-228, "Inspection".
ADJUSTMENT AFTER INSTALLATION
Adjust the CVT fluid level. Refer to TM-229, "Adjustment".
1. Transaxle assembly 2. O-ring3. Secondary speed sensor
Front : Genuine NISSAN CVT Fluid NS-3
JSDIA1881GB
Revision: August 2015 2016 Versa Note

cardiagn.com

TM-248
< REMOVAL AND INSTALLATION >[CVT: RE0F11A]
OUTPUT SPEED SENSOR
OUTPUT SPEED SENSOR
Exploded ViewINFOID:0000000012431201
Removal and InstallationINFOID:0000000012431202
REMOVAL
1. Disconnect the harness connector from output speed sensor.
NOTE:
Lift up the vehicle and perform the work from rear of the transaxle assembly.
2. Remove the output speed sensor.
3. Remove the O-ring from the output speed sensor.
INSTALLATION
Installation is in the reverse order of removal.
CAUTION:
• Do not reuse O-ring.
• Apply Genuine NISSAN CVT Fluid NS-3 to the O-ring.
Inspection and AdjustmentINFOID:0000000012431203
INSPECTION AFTER INSTALLATION
Check for CVT fluid leakage. Refer to TM-228, "Inspection".
ADJUSTMENT AFTER INSTALLATION
Check the CVT fluid level. Refer to TM-229, "Adjustment".
1. Transaxle assembly 2. Output speed sensor 3. O-ring
Front Genuine NISSAN CVT Fluid NS-3
JSDIA1882GB
Revision: August 2015 2016 Versa Note

cardiagn.com

DIFFERENTIAL SIDE OIL SEALTM-249
< REMOVAL AND INSTALLATION > [CVT: RE0F11A]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
DIFFERENTIAL SIDE OIL SEAL
Exploded ViewINFOID:0000000012431204
Removal and InstallationINFOID:0000000012431205
NOTE:
When removing components such as hoses, tubes/lines, etc. , cap or plug openings to prevent fluid from spill-
ing.
REMOVAL
1. Remove the front drive shaft from the transaxle assembly. Refer to FAX-19, "Removal and Installation"
2. Remove the differential side oil seal using suitable tool.
CAUTION:
When removing the differential side oil seal, be careful not to scratch the oil seal mating surfaces
of the transaxle case and converter housing.
INSTALLATION
CAUTION:
When inserting the drive shaf t, be sure to use Tool.
1. Measure height (A) of seal lip. Calculate protrusion (C) of seal
lip according to measured height (A) of seal lip and reference
value (B) of side oil seal insertion.
CAUTION:
• Do not reuse differential side oil seal.
• Put a mark on the measurement area and measure height of seal lip at four points diagonally
using suitable tool.
NOTICE:
1. Transaxle assembly 2. Differential side oil seal (left side) 3. Differential side oil seal (right side)
Front Genuine NISSAN CVT Fluid NS-3
JSDIA1888ZZ
Tool number : KV38107900 ( — )
(1) : Differential side oil seal
(2) : Converter housing or transaxle case
Lip protrusion (C): C=A–B
Differential side oil seal insertion
reference value (B) : 1.8 mm (0.071 in)
JSDIA4816ZZ
Revision: August 2015
2016 Versa Note

cardiagn.com

TM-250
< REMOVAL AND INSTALLATION >[CVT: RE0F11A]
DIFFERENTIAL SIDE OIL SEAL
Since seal lips have a tolerance of
± 0.3 mm ( ± 0.012 in) at maximum due to manufacturing tolerances or
packing conditions, it is necessary to measure t he seal lip height beforehand to clarify the tolerance.
2. As an indicator of the parallelism and insertion depth, cut a masking tape (1) to specified width [add 1 mm (0.04 in) to the
value calculated from the tip of differential side oil seal lip] and
affix to the differential side oil seal.
3. Install the differential side oil seal using a suitable tool according to the guide of the masking tape (1).
CAUTION:
• If differential side oil seal is inserted deeper than the ref-erence value, use a new differe ntial side oil seal and per-
form the steps again.
• Apply ATF to the differential side oil seal lip and around
the oil seal.
NOTE:
A hub cap (Part No. 43234 1HA0A) can be used as substitute for drift. To use a hub cap, be sure to pre-
pare a new one specifically for patting seal.
4. Remove masking tape.
5. Adjust as instructed below to optimize the protrusion size and parallelism. CAUTION:
If differential side oil seal is inserted deeper th an the reference value, use a new differential side
oil seal and perform the steps again.
• Protrusion size (A) CAUTION:
Protrusion must fall within ± 0.5mm (0.020 in) of calculated
size.
• Parallelism at four diagonal points ( ) CAUTION:
The difference among four diagona l points must be within 0.3
mm (0.012 in).
NOTE:
If differential side oil seal is uneven while installing, tilt suitable tool.
6. Check that the protrusion size and parallelism are adequate.
Inspection and AdjustmentINFOID:0000000012431206
INSPECTION AFTER INSTALLATION
Check for CVT fluid leakage. Refer to TM-228, "Inspection".
ADJUSTMENT AFTER INSTALLATION
Adjust the CVT fluid level. Refer to TM-229, "Adjustment".
JSDIA4817ZZ
JSDIA4815ZZ
JSDIA4814ZZ
Revision: August 2015 2016 Versa Note

cardiagn.com

WATER HOSETM-251
< REMOVAL AND INSTALLATION > [CVT: RE0F11A]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
WATER HOSE
Exploded ViewINFOID:0000000012431207
Removal and InstallationINFOID:0000000012431208
REMOVAL
WARNING:
Do not remove the radiator cap when the engine is hot. Serious burns could occur from high-pressure
engine coolant escaping from the radiator. Wrap a thick cloth around the cap. Slowly push down and
turn it a quarter turn to allow built-up pressure to escape. Carefully remove the cap by pushing it down
and turning it all the way.
CAUTION:
Perform these steps after the engine cool ant temperature has cooled sufficiently.
NOTE:
When removing components such as hoses, tubes/lines, etc. , cap or plug openings to prevent fluid from spill-
ing.
1. Remove the hose clamp and pull out the water hose A.
2. Remove the hose clamp and pull out the water hose B.
3. Remove the hose clamp and pull out the water hose C.
4. Pull out the heater hose and remove the water bypass pipe.
5. Remove the heater thermostat assembly.
1. Hose clamp 2. Water hose A3. Clip
4. Bracket A 5. Bracket B6. CVT oil warner
7. Water hose B 8. Water bypass pipe9. Hose clamp
10. Water hose C 11. Water outlet
A. To heater core : Always replace after every disassembly.
: N·m (kg-m, in-lb)
JSDIA4111GB
