2016 NISSAN NOTE key

MAINSHAFT AND GEARTM-47
< UNIT DISASSEMBLY AND ASSEMBLY > [5MT: RS5F91R]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
MAINSHAFT AND GEAR
Exploded ViewINFOID:0000000012430972
DisassemblyINFOID:0000000012430973
CAUTION:
• Secure mainshaft in a vise usin g blocks of wood to prevent dama ge, and then remove gears and
snap rings.
1. Mainshaft front bearing 2. Mainshaft 3. 1st main gear
4. 1st inner baulk ring 5. 1st synchronizer cone 6. 1st outer baulk ring
7. 1st-2nd synchronizer hub 8. 1st-2nd coupling sleeve 9. Spring
10. Insert key 11. 2nd outer baulk ring 12. 2nd synchronizer cone
13. 2nd inner baulk ring 14. Snap ring 15. Thrust washer
16. 2nd main gear 17. 3rd main gear 18. 3rd baulk ring
19. 3rd-4th synchronizer hub 20. 3rd-4th coupling sleeve 21. 4th baulk ring
22. 4th main gear 23. Spacer 24. Mainshaft rear bearing
25. 5th main gear
: Apply gear oil.
: Replace the parts as a set.
JPDIC0531GB
Revision: August 2015 2016 Versa Note

cardiagn.com

MAINSHAFT AND GEARTM-49
< UNIT DISASSEMBLY AND ASSEMBLY > [5MT: RS5F91R]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
5. Remove 2nd main gear (1) and thrust washer (2).
6. Remove snap ring (1), and then remove 2nd inner baulk ring, 2nd synchronizer cone, and 2nd outer baulk ring.
7. Remove 1st-2nd coupling sleeve, insert keys, springs, and 1st- 2nd synchronizer hub.
8. Remove 1st outer baulk ring, 1st synchronizer cone, 1st inner baulk ring, and 1st main gear (2).
AssemblyINFOID:0000000012430974
Assembly is in the reverse order of disassembly.
CAUTION:
• Do not reuse snap ring.
• For installation of snap ring, set snap ring pliers and flat pliers
at both sides of snap ring. While expanding snap ring with
snap ring pliers, remove sn ap ring with flat pliers.
• Check that snap ring is secu rely installed to the groove.
• Apply gear oil to 1st outer ba ulk ring, 1st synchronizer cone,
1st inner baulk ring, 2nd oute r baulk ring, 2nd synchronizer
cone, 2nd inner baulk ring, and 3rd baulk ring.
• Replace 1st outer baulk ring, 1st synchronizer cone, and 1st inner baulk ring as a set.
• Replace 2nd outer baulk ring, 2nd synchronizer cone, and 2nd
inner baulk ring as a set.
• Be careful with the orientation of 1st-2nd synchronizer hub.
• Replace 1st-2nd synchronizer hub and 1st-2nd coupling sleeve as a set.
PCIB1562E
JPDIC0541ZZ
SCIA1755J
(A) : 1st main gear side
(B) : 2nd main gear side
PCIB1566E
Revision: August 2015 2016 Versa Note

cardiagn.com

TM-50
< UNIT DISASSEMBLY AND ASSEMBLY >[5MT: RS5F91R]
MAINSHAFT AND GEAR
• Be careful with the orientation of 1st-2nd coupling sleeve.
• Be careful with the orientatio
n of 3rd-4th synchronizer hub.
• Replace 3rd-4th synchronize r hub and 3rd-4th coupling
sleeve as a set.
• Be careful with the orientation of insert key (1) and spring (2).
InspectionINFOID:0000000012430975
INSPECTION AFTER DISASSEMBLY
Mainshaft and Gear
Check the following items and replace if necessary.
• Damage, peeling, uneven wear, and distortion of shaft.
• Excessive wear, damage, and peeling of gear.
Synchronizer
Check the following items and replace if necessary.
(A) : 2nd main gear side
(B) : 1st main gear side
PCIB1567E
(A) : 4th main gear side
(B) : 3rd main gear side
PCIB1565E
PCIB1564E
SCIA1762J
Revision: August 2015 2016 Versa Note

cardiagn.com

MAINSHAFT AND GEARTM-51
< UNIT DISASSEMBLY AND ASSEMBLY > [5MT: RS5F91R]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
• Contact surface breakage, damage, and unusual wear of coupling sleeve, synchronizer hub, insert key, and spring.
• Coupling sleeve and synchronizer hub move smoothly.
• Breakage, damage, and excessive wear of baulk ring cam surface
and insert contact surface.
Bearing
Check bearing for damage and rough rotation. Replace if necessary.
SCIA1753J
SCIA0608J
MTF0041D
Revision: August 2015 2016 Versa Note

cardiagn.com

STRUCTURE AND OPERATIONTM-75
< SYSTEM DESCRIPTION > [CVT: RE0F11A]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
SHIFT LOCK SYSTEM : System DescriptionINFOID:0000000012431016
The selector lever cannot be shifted from “P” position to any other position unless the ignition switch is in the
ON position and the brake pedal is depressed.
KEY LOCK SYSTEM
KEY LOCK SYSTEM : System DescriptionINFOID:0000000012431017
• The key lock mechanism also operates as a shift lock: With the ignition switch turned to ON, selector lever cannot be shifted from “P” position to any other position
unless brake pedal is depressed.
With the key removed, selector lever cannot be shifted from “P” position to any other position.
The key cannot be removed unless selector lever is placed in “P” position.
• The shift lock and key lock mechanisms are controlled by the ON-OFF operation of the shift lock solenoid and by the operation of the rotator and slider located inside key cylinder, respectively.
Revision: August 2015 2016 Versa Note

cardiagn.com

CVT SHIFT SELECTORTM-231
< REMOVAL AND INSTALLATION > [CVT: RE0F11A]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
REMOVAL AND INSTALLATION
CVT SHIFT SELECTOR
Exploded ViewINFOID:0000000012431175
Removal and InstallationINFOID:0000000012431176
CAUTION:
Always apply the parking brake before pe rforming removal and installation.
REMOVAL
1. Move the shift selector to the “N” position.
2. Remove the shift selector handle. Refer to TM-232, "
Disassembly and Assembly".
3. Remove the center console. Refer to IP-18, "
Removal and Installation".
4. Disconnect the harness connectors from shift selector.
5. Move the shift selector to the “P” position.
6. Remove the key interlock cable from the shift selector assembly. Refer to TM-237, "
Exploded View".
7. Remove the control cable from the shift selector assembly. Refer to TM-234, "
Exploded View".
8. Remove the shift selector assembly.
INSTALLATION
Installation is in the reverse order of removal.
1. Shift selector handle 2. Lock pin3. Shift selector handle cover
4. Position indication panel 5. Shift selector assembly
ALDIA0263GB
Revision: August 2015 2016 Versa Note

cardiagn.com

KEY INTERLOCK CABLETM-237
< REMOVAL AND INSTALLATION > [CVT: RE0F11A]
C
EF
G H
I
J
K L
M A
B
TM
N
O P
KEY INTERLOCK CABLE
Exploded ViewINFOID:0000000012431182
Removal and InstallationINFOID:0000000012431183
REMOVAL
CAUTION:
Always apply the parking brake before pe rforming removal and installation.
1. Move the shift selector to the “N” position.
2. Remove the shift selector handle. Refer to TM-232, "
Disassembly and Assembly".
3. Remove the instrumental lower panel LH. Refer to IP-24, "
Removal and Installation".
4. Remove steering column covers. Refer to IP-17, "
Removal and Installation".
5. Remove the center console. Refer to IP-18, "
Removal and Installation".
6. Move the shift selector to the “P” position.
7. Press the pawls (B) of the key interlock cable slider (A) while sliding it in the direction of the casing cap (C), and separate the
adjusting holder (D) and slider.
8. Remove the key interlock cable from the shift selector assembly.
1. Shift selector assembly 2. Key interlock cable A: Steering lock unit
B: Lock plate C: Clip
ALDIA0262ZZ
(E) :Key interlock rod
JSDIA1797ZZ
Revision: August 2015 2016 Versa Note

cardiagn.com

TM-238
< REMOVAL AND INSTALLATION >[CVT: RE0F11A]
KEY INTERLOCK CABLE
9. Lift lock plate (A) in the direction of the arrow ( C) and remove
in the direction of the arrow ( D).
10. Remove the key interlock cable from the steering lock unit.
11. Disengage the clips and remove the key interlock cable from the vehicle.
INSTALLATION
Installation is in the reverse order of removal.
• Temporarily install the adjust holder (A) to the key interlock rod (B).
• Install the casing cap (C) to the cable bracket (D) on the shift
selector assembly.
CAUTION:
• Do not bend or twist key interlock cable excessively wheninstalling.
• After installing key interlock cable to cable bracket (D) on shift selector assembly, make sure casing caps (C) is firmly
secured in cable bracket (D) on shift selector assembly.
• If casing cap (C) is loose [less than 39.2 N (4.0 kg, 8.8 lb) removing force], replace key interlock cable.
• Slide the slider (A) toward the key interlock rod (D) while pressing the pull lock (B) down to securely connect the adjust holder (C)
with the key interlock rod (D).
CAUTION:
• Do not press tabs when holding slider (A).
• Do not apply any side to side force to key interlock rod (D)
when sliding slider (A).
InspectionINFOID:0000000012431184
INSPECTION AFTER INSTALLATION
• Check the CVT operation. If a malfunction is found, adjust the CVT position. Refer to TM-232, "Inspection".
• Make sure the key can be removed only when the shift selector is in the “P” position.
• Make sure the ignition switch will not turn to LOCK pos ition when the shift selector is not in the “P” position.
(1) :Key interlock cable
(B) :Steering lock unit
JSDIA1798ZZ
JSDIA1799ZZ
JSDIA1800ZZ
