2015 LEXUS LS600H Owners Manual

3595-3. Using the air conditioning system and defogger
5
Interior features
LS600hL_U(OM50E41U)
Press the “MENU” button on the Remote Touch. ( P. 330)
Select on the “Menu” screen.
Select on the “Climate” screen.
Operates the windshield wiper
de-icer on/off.
Select on the option control
screen to turn on the windshield wiper
de-icer, then the indicator will be on.
The windshield wiper de-icer will
automatically turn off after approxi-
mately 15 minutes, then the indicator
will be off. Selecting on the
option control screen again also turns
the de-icer off.
■Operating conditions
The power switch must be in the ON mode.
Windshield wiper de-icer
: If equipped
This feature is used to prevent ice from building up on the windshield
and wiper blades.
1
2
3
4
CAUTION
■When the windshield wiper de-icer is on
Do not touch the glass at the lower part of the windshield or to the side of the front
pillars as the surfaces can become very hot and burn you.

360
LS600hL_U(OM50E41U)
5-4. Using the interior lights
Interior lights list
Shift lever lights
Front personal lights ( P. 362)
Front interior lights ( P. 361)
Instrument panel ornament
lights
Inside door handle lights
Rear personal lights ( P. 362)Rear interior light (
P. 361)
Door courtesy lights
Seat belt buckle lights
Footwell lights
Power switch light
Clock light
Outer foot lights1
2
3
4
5
6
7
8
9
10
11
12
13

3615-4. Using the interior lights
5
Interior features
LS600hL_U(OM50E41U)
Front
“OFF”
Door position on/off
“ON”
Rear
On/off
If door position on is selected for the
front interior light, the rear interior
light is also turned on/off by the open-
ing and closing of a door.
Interior lights
1
2
3

3625-4. Using the interior lights
LS600hL_U(OM50E41U)
Front
On/off
Rear
On/off
Pe r s o n a l l i g h t s

3635-4. Using the interior lights
5
Interior features
LS600hL_U(OM50E41U)
■Illuminated entry system
The lights automatically turn on/off according to power switch mode, the presence
of the electronic key, whether the doors are locked/unlocked, and whether the doors
are opened/closed.
■To prevent the 12-volt battery from being discharged
If the following lights remain on when the power switch is turned off, the lights will go
off automatically after 20 minutes:
●Interior lights
●Door courtesy lights
●Pe r s o n a l l i g h t s
●Inside door handle lights
●Seat belt buckle lights
●Footwell lights
●Power switch light
■Customization
Settings (e.g. The time elapsed before lights turn off) can be changed.
(Customizable features P. 5 6 4 )
NOTICE
■To prevent 12-volt battery discharge
Do not leave the lights on longer than necessary when the hybrid system is off.

364
LS600hL_U(OM50E41U)
5-5. Using the storage features
5-seat models
List of storage features
Glove box (P. 366)
Auxiliary boxes ( P. 371)
Cup holders ( P. 368)
Door pockets ( P. 367)Auxiliary boxes (if equipped)
(P. 371)
Ashtrays (if equipped) (P. 3 7 9 )
Console box ( P. 369)
Coin holder ( P. 367)1
2
3
4
5
6
7

3655-5. Using the storage features
5
Interior features
LS600hL_U(OM50E41U)
4-seat models
Glove box (P. 366)
Auxiliary boxes ( P. 371)
Cup holders ( P. 368)
Door pockets ( P. 367)Auxiliary boxes (if equipped)
(P. 371)
Ashtrays (if equipped)
(P. 3 7 9 )
Console box ( P. 369)
Coin holder ( P. 367)
CAUTION
■Items that should not be left in the storage spaces
Do not leave glasses, lighters or spray cans in the storage spaces, as this may cause
the following when cabin temperature becomes high:
●Glasses may be deformed by heat or cracked if they come into contact with
other stored items.
●Lighters or spray cans may explode. If they come into contact with other stored
items, the lighter may catch fire or the spray can may release gas, causing a fire
hazard.
1
2
3
4
5
6
7

3665-5. Using the storage features
LS600hL_U(OM50E41U)
Open (push button)
Unlock with the mechanical key
Lock with the mechanical key
■Glove box light
The glove box light turns on when the tail lights are on.
■Trunk opener main switch
The trunk opener main switch is located in the glove box. ( P. 1 5 0 )
■Removing the partition
The partition inside the glove box can be removed.
Glove box
1
2
3
Lift the front side of the partition and pull it out
at an angle.
CAUTION
■Caution while driving
Keep the glove box closed. In the event of sudden braking or sudden swerving, an
accident may occur due to an occupant be ing struck by the open glove box or the
items stored inside.
