2015 LEXUS LS600H Owners Manual

3835-6. Other interior features
5
Interior features
LS600hL_U(OM50E41U)
Rear (5-seat models)*
Open the lid.
Rear (4-seat models)*
Open the auxiliary box and open
the lid.
*: If equipped
■120 VAC*
Open the lid.
*: If equipped

3845-6. Other interior features
LS600hL_U(OM50E41U)
■The power outlet can be used when
12 V
The power switch is in ACCESSORY or ON mode.
120 VAC
The power switch is in ON mode.
NOTICE
■To avoid damaging the power outlet
Close the power outlet lid when the power outlet is not in use.
Foreign objects or liquids that enter th e power outlet may cause a short circuit.
■To prevent the fuse from being blown
12 V
Do not use an accessory that uses more than 12 V 10 A.
120 VAC
Do not use a 120 VAC appliance that requires more than 100 W.
If a 120 VAC appliance that consumes more than 100 W is used, the protection
circuit will cut the power supply.
■To prevent the 12-volt battery from being discharged
Do not use the power outlet longer than necessary when the hybrid system is off.
■Appliances that may not operate properly (120 VAC)
The following 120 VAC appliances may not operate properly even if their power
consumption is under 100 W.
●Appliances with high initial peak wattage
●Measuring devices that process precise data
●Other appliances that require an extremely stable power supply

3855-6. Other interior features
5
Interior features
LS600hL_U(OM50E41U)
Automatic operation
Operates automatically according
to the outside and cabin tempera-
ture when the power switch is
turned to ON mode. Automatic
operation can be turned off using
the switch.
The indicator light comes on when the
heater is operating.
Manual operation
Turns the heated steering wheel on/
off.
The indicator light comes on when the
heater is operating.
■Operating condition
The power switch is in ON mode.
■Timer function
Manual operation: Turns off after approximately 30 minutes.
Automatic operation: Operates for a maximum of 30 minutes. (Turns off according
to outside and cabin temperature.)
■If the indicator light does not come on
If the indicator light does not come on when the switch is pressed, a malfunction may
have occurred in the system. Have the vehicle inspected by your Lexus dealer.
■Customization
The automatic turning on/off of the heated steering wheel can be customized.
(Customizable features P. 5 6 4 )
Heated steering wheel
The left and right grip portions of the steering wheel can be heated.

3865-6. Other interior features
LS600hL_U(OM50E41U)
CAUTION
■Burns
Only appropriately qualified and capable non-impaired persons should operate
the vehicle. However, care should be taken to prevent injury if anyone in the follow-
ing categories comes into contact with the steering wheel when the heated steer-
ing wheel is on:
●Babies, small children, the elderly, the sick and the disabled
●Persons with sensitive skin
●Persons who are fatigued
●Persons who have taken alcohol or drugs that induce sleep (sleeping drugs, cold
remedies, etc.)
NOTICE
■To prevent the 12-volt battery from being discharged
Turn the switch off when the hybrid system is off.

3875-6. Other interior features
5
Interior features
LS600hL_U(OM50E41U)
Press the knob to release the
lock.
Press the knob to lock it when not in
use.
AUTO setting
Turn the knob to the “AUTO”
position.
When set to “AUTO” mode, seat
heater, off, ventilation or seat cooler is
automatically selected according to
the set temperature of the air condi-
tioning system, outside temperature,
etc.
Climate control seats
The seats can be heated or cooled. When set to “AUTO” mode, the cli-
mate control seats/seat heaters are linked to the air conditioning set-
tings and automatically adjusted.
Front climate control seats
1
2

3885-6. Other interior features
LS600hL_U(OM50E41U)
Manual setting
Set the temperature by turning
the knob to the left or right.Off
Seat heater
Ventilation
Seat cooler
■AUTO setting
The switch turned on/off.
When set to “AUTO” mode, the
indicator illuminates.
When set to “AUTO” mode, seat
heater, off, ventilation or seat
cooler is automatically selected
according to the set temperature of
the air conditioning system, outside
temperature, etc.
2
1
2
3
4
Rear climate control seats
5-seat models4-seat models

3895-6. Other interior features
5
Interior features
LS600hL_U(OM50E41U)
■Manual setting
The strength of the seat heater and seat cooler can be adjusted to 3
levels each.
Seat heater
*1: When the system is off, pressing “ ” turns the seat
heater on.
Pressing “ ” increases the level and pressing “ ” lowers the level.
Seat cooler*2: When the system is off, pressing “ ” turns the seat
cooler on.
Pressing “ ” increases the level and pressing “ ” lowers the level.
*1: The indicator illuminates in amber.
*2: The indicator illuminates in blue.
OFF
Seat heater*1
Low
Mid
HiSeat cooler
*2
Low
Mid
Hi1
2
3
4
5
6

3905-6. Other interior features
LS600hL_U(OM50E41U)
■Operating condition
The power switch is in ON mode.
■Climate control seat operation
Depending on the outside temperature and the temperature of the seat surface,
there are cases when heating operation is stronger than usual.
■Operating the rear climate control seats from the front seats
 P. 3 4 3
■Disabling the switches on the rear controller
P. 3 4 5
■Replacing the air filters
Filters are installed in the climate control seats. For replacement of the filters, contact
your Lexus dealer.
■Customization
Automatic operation settings can be customized. (Customizable features P. 5 6 4 )
