2015 LEXUS LS600H Owners Manual

5037-2. Steps to take in an emergency
7
When trouble arises
LS600hL_U(OM50E41U)
Master warning light
The master warning light also comes
on or flashes in order to indicate that a
message is currently being displayed
on the multi-information display.
Multi-information display
If any of the warning messages is shown again after the following actions
have been performed, contact your Lexus dealer.
If a warning message is displayed
The multi-information display shows warnings for system malfunctions,
incorrectly performed operations, and messages that indicate a need
for maintenance. When a message is shown, perform the correction
procedure appropriate to the message.
1
2

5047-2. Steps to take in an emergency
LS600hL_U(OM50E41U)
The warning lights and warning buzzers operate as follows depending on
the content of the message. If a message indicates the need for inspection
by a dealer, have the vehicle inspected by your Lexus dealer immediately.
*: A buzzer sounds the first time a message is shown on the multi-information display.
■Warning message in radar cruise mode (if equipped)
In the following cases, the warning message may not be displayed even if vehicle-to-
vehicle distance decreases:
●When your vehicle and the vehicle ahead are traveling at the same speed or the
vehicle ahead is traveling more quickly than your vehicle
●When the vehicle ahead is traveling at a very low speed
●Immediately after cruise control speed is set
●At the instant the accelerator pedal is depressed
Messages and warnings
System warn- ing lightWa r n i n g buzzer
*Wa r n i n g
Remains onSounds
Indicates an important situation
such as the malfunction of the
system related to driving that
may result in danger
Remains on or flashesSounds
Indicates an important situation
such as the malfunction of the
system shown on the multi-infor-
mation display
FlashesSounds
Indicates a situation such as
damage to the vehicle that may
result in danger
Remains onDoes not sound
Indicates a condition such as a
malfunction of electrical compo-
nents and the need for mainte-
nance
FlashesDoes not sound
Indicates a situation such as the
incorrect performance of an
operation and how to perform
the operation correctly

5057-2. Steps to take in an emergency
7
When trouble arises
LS600hL_U(OM50E41U)
■The LKA (Lane-Keeping Assist) lane departure warning function (if equipped)
In the following cases, the warning message will not be displayed even if a lane line is
crossed.
●When the vehicle speed deviates from the operating range of the LKA system
functions
●When the lane lines cannot be recognized
●When the steering wheel is turned as far as necessary to cause the vehicle to
change lanes
■System warning lights
The master warning light does not come on or flash in the following cases. Instead, a
separate system warning light will come on or flash along with the message shown
on the multi-information display.
●Malfunction of the brake system
The brake system warning light (red indicator) comes on. ( P. 4 9 3 )
●Malfunction of the regenerative brake syst em, electronically controlled brake sys-
tem or electric parking brake
The brake system warning light (yellow indicator) comes on. ( P. 495)
●Malfunction of the ABS
The ABS warning light comes on. ( P. 4 9 4 )
●Malfunction of the charging system
The charging system warning light comes on. ( P. 4 9 4 )
●Indicates that a door or the trunk is not fully closed
The open door warnin g light comes on. (P. 4 9 6 )
●High engine coolant temperature
The needle of the engine coolant temperature gauge enters the red zone.
( P. 5 3 0 )
■If “Maintenance required ” is shown (U.S.A. only)
Perform the necessary maintenance.
Please reset the message after the maintenance is performed. ( P. 4 2 6 )
■If “Hybrid System Overheat” is shown
Coping method: P. 5 3 0
This message may be displayed when driv ing under severe operating conditions.
(For example, when driving up a long steep hill.)
■Warning buzzer
In some cases, the buzzer may not be hear d due to ambient noise or sounds from the
audio system.

5067-2. Steps to take in an emergency
LS600hL_U(OM50E41U)●
Stop the vehicle on a hard, flat surface.
●Set the parking brake.
●Shift the shift lever to P.
●Stop the hybrid system.
●Turn on the emergency flashers. (
P. 4 8 4 )
If you have a flat tire (vehicles with a spare
tire)
Your vehicle is equipped with a spar e tire. The flat tire can be replaced
with the spare tire.
For details about tires: P. 4 5 4
CAUTION
■If you have a flat tire
Do not continue driving with a flat tire.
Driving even a short distance with a flat tire can damage the tire and the wheel
beyond repair, which could result in an accident.
Before jacking up the vehicle

5077-2. Steps to take in an emergency
7
When trouble arises
LS600hL_U(OM50E41U)
Location of the spare tire, jack and tools
Parking brake release tool
Jack handle
Wheel nut wrench
JackTo o l s
Screwdriver
Spare tire
Towing eyelet1
2
3
4
5
6
7
8

5087-2. Steps to take in an emergency
LS600hL_U(OM50E41U)
CAUTION
■Using the tire jack
Observe the following precautions.
Improper use of the tire jack may cause the vehicle to suddenly fall off the jack,
leading to death or serious injury.
●Do not use the tire jack for any purpose other than replacing tires or installing and
removing tire chains.
●Only use the tire jack that comes with this vehicle for replacing a flat tire.
Do not use it on other vehicles, and do not use other tire jacks for replacing tires
on this vehicle.
●Put the jack properly in its jack point.
●Do not put any part of your body under the vehicle while it is supported by the
jack.
●Do not start the hybrid system or drive the vehicle while the vehicle is supported
by the jack.
●Do not raise the vehicle while someone is inside.
●When raising the vehicle, do not put an object on or under the jack.
●Do not raise the vehicle to a height greater than that required to replace the tire.
●Use a jack stand if it is necessary to get under the vehicle.
●Be sure to turn off the height control and stop the hybrid system.
●When lowering the vehicle, make sure that there is no-one near the vehicle. If
there are people nearby, warn them vocally before lowering.

5097-2. Steps to take in an emergency
7
When trouble arises
LS600hL_U(OM50E41U)
Lift up the luggage mat and secure it by using the hook provided.
( P. 3 74 )
Remove the tool tray.
Remove the jack after removing
the hook.
Taking out the jack and jack handle
1
2
3

5107-2. Steps to take in an emergency
LS600hL_U(OM50E41U)
Lift up the luggage mat and secure it by using the hook provided.
( P. 3 74 )
Loosen the center fastener that
secures the spare tire.
If the center fastener cannot be turned
by hand, use the wheel nut wrench
that is stored in the trunk. (To secure
the tire, tighten the center fastener by
hand. Do not use the wrench or other
tools.)
Chock the tires.
Taking out the spare tire
1
2
CAUTION
■When storing the spare tire
Be careful not to catch fingers or other body parts between the spare tire and the
body of the vehicle.
Replacing a flat tire
1
Flat tireWheel chock positions
FrontLeft-hand sideBehind the rear right-hand side tire
Right-hand sideBehind the rear left-hand side tire
RearLeft-hand sideIn front of the front right-hand side tire
Right-hand sideIn front of the fron t left-hand side tire
