2015 LEXUS LS600H tow

3
1
8 7
6
5
4
3
2
9
LS600hL_U(OM50E41U)3-5. Opening, closing the
windows and moon roof
Power windows ............................ 189
Moon roof .......................................192
4-1. Before driving Driving the vehicle ..................... 198
Cargo and luggage................... 209
Vehicle load limits ........................213
Trailer towing .................................214
Dinghy towing ...............................215
4-2. Driving procedures Power (ignition) switch ..............216
EV drive mode .............................. 221
Hybrid transmission .................. 223
Turn signal lever ...........................227
Parking brake .............................. 228
Brake Hold .....................................231
Horn ................................................ 233
4-3. Operating the lights and wipers
Headlight switch ........................ 234
Automatic High Beam............. 238
Fog light switch ........................... 243
Windshield wipers and washer ..........................................244
Headlight cleaner switch........ 248 4-4. Refueling
Opening the fuel tank cap .................................................249
4-5. Using the driving support systems
Cruise control ............................. 253
Dynamic radar cruise control with full-speed
range .............................................257
LKA (Lane-Keeping Assist) ...........273
Driving mode select switch ........................................... 283
Electronically modulated air suspension............................287
Driving assist systems .............. 289
PCS (Pre-Collision System) ......... 296
BSM (Blind Spot Monitor) .............308
• The Blind Spot Monitor function ......................................312
• The Rear Cross Traffic Alert function ..........................315
Lexus night view .......................... 318
4-6. Driving tips Hybrid vehicle driving tips ................................................. 323
Winter driving tips ..................... 325
4Driving

5
1
8 7
6
5
4
3
2
9
LS600hL_U(OM50E41U)6-1. Maintenance and care
Cleaning and protecting the vehicle exterior ................. 418
Cleaning and protecting the vehicle inte rior.................. 422
6-2. Maintenance Maintenance requirements ............................ 425
General maintenance.............. 428
Emission inspection and maintenance (I/M)
programs .................................... 432
6-3. Do-it-yourself maintenance Do-it-yourself service precautions................................ 433
Hood ............................................... 436
Positioning a floor jack..............437
Engine compartment ............... 439
12-volt battery ............................. 450
Tires.................................................. 454
Tire inflation pressure ............... 464
Wheels ............................................467
Air conditioning filter ............... 469
Electronic key battery............... 472
Checking and replacing fuses............................................... 474
Headlight aim ...............................479
Light bulbs ..................................... 481 7-1. Essential information
Emergency flashe rs .................. 484
If your vehicle has to be stopped in an
emergency ................................ 485
7-2. Steps to take in an emergency
If your vehicle needs to be towed ..................................... 486
If you think something is wrong........................................... 492
If a warning light turns on or a warning buzzer
sounds ......................................... 493
If a warning message is displayed .................................... 503
If you have a flat tire (vehicles with a
spare tire) ................................... 506
If you have a flat tire (vehicles with
run-flat tires) ...............................515
If the hybrid system will not start ......................................... 517
If the shift lever cannot be shifted from P .......................519
If the parking brake cannot be released ................ 520
If the electronic key does not operate properly ..............524
If the 12-volt battery is discharged ..................................527
If your vehicle overheats ......... 530
6Maintenance and care7When trouble arises

18Pictorial index
LS600hL_U(OM50E41U)
■Instrument panel
Power switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 216
Starting the hybrid system/changing the modes. . . . . . . . . . . . . . . . . . . . . . P. 216
Emergency stop of the hybrid system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 485
When the hybrid system will not start . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 517
Warning messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 503
Shift lever . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 223
Changing the shift position . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 223
Precautions against towing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 486
When the shift lever does not move . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 519
Meters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 99
Reading the meters/adjusting the instrument panel light . . . . . . . . . . . . . P. 99
Warning lights/indicator lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 94
When the warning lights come on . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 4931
2
3

451-1. For safe use
1
For safety and security
LS600hL_U(OM50E41U)
Your vehicle is equipped with ADVANCED AIRBAGS designed based
on the US motor vehicle safety standards (FMVSS208). The airbag sen-
sor assembly (ECU) controls airbag deployment based on information
obtained from the sensors etc. show n in the system components diagram
above. This information includes crash severity and occupant information.
As the airbags deploy, a chemical reaction in the inflators quickly fills the
airbags with non-toxic gas to help restrain the motion of the occupants.
CAUTION
■SRS airbag precautions
Observe the following precautions regarding the SRS airbags.
Failure to do so may caus e death or serious injury.
●The driver and all passengers in the vehi cle must wear their seat belts properly.
The SRS airbags are supplemental devices to be used with the seat belts.
●The SRS driver airbag deploys with considerable force, and can cause death or
serious injury especially if the driver is very close to the airbag. The National
Highway Traffic Safety Admi nistration (NHTSA) advises:
Since the risk zone for the driver’s airbag is the first 2 - 3 in. (50 - 75 mm) of
inflation, placing yourself 10 in. (250 mm) from your driver airbag provides you
with a clear margin of safety. This distance is measured from the center of the
steering wheel to your breastbone. If you sit less than 10 in. (250 mm) away now,
you can change your driving position in several ways:
• Move your seat to the rear as far as you can while still reaching the pedals comfortably.
• Slightly recline the back of the seat. Although vehicle designs vary, many drivers can achieve the 10 in. (250 mm)
distance, even with the driver seat all the way forward, simply by reclining the
back of the seat somewhat. If reclining the back of your seat makes it hard to
see the road, raise yourself by using a fi rm, non-slippery cushion, or raise the
seat if your vehicle has that feature.
• If your steering wheel is adjustable, ti lt it downward. This points the airbag
toward your chest instead of your head and neck.
The seat should be adjusted as reco mmended by NHTSA above, while still
maintaining control of the foot pedals, steering wheel, and your view of the
instrument panel controls.

471-1. For safe use
1
For safety and security
LS600hL_U(OM50E41U)
CAUTION
■SRS airbag precautions
●Do not allow a child to stand in front of the
SRS front passenger airbag unit or sit on
the knees of a front passenger.
●Do not allow the front seat occupants to
hold items on their knees.
●Do not lean against the door, the roof side
rail or the front, side and rear pillars.
●Do not allow anyone to kneel on the pas-
senger seats toward the door or put their
head or hands outside the vehicle.
●Do not attach anything to or lean anything
against areas such as the dashboard, steer-
ing wheel pad and lower portion of the
instrument panel.
These items can become projectiles when
the SRS driver, front passenger and knee
airbags deploy.
●Do not attach anything to areas such as a
door, windshield glass, side door glass, front
and rear pillar, roof side rail and assist grip.

671-1. For safe use
1
For safety and security
LS600hL_U(OM50E41U)
4-seat models
Anchor brackets (for top tether
strap)
An anchor bracket is provided for
each rear seat.
When using a child restraint system
in an outer rear seat, adjust the fol-
lowing:
●The seat cushion to the fully rear-
ward position
●The upper seatback to the rear-
most position
●The head restraint to the lowest
and rearmost position
●Relaxation seat: The seatback to
the most upright position and
ottoman (footrest) to the stowed
position
Before installing a child restrai nt system on an outer rear seat

851-2. Hybrid system
1
For safety and security
LS600hL_U(OM50E41U)
CAUTION
■Road accident cautions
Observe the following precautions to reduce the risk of death or serious injury:
●Pull your vehicle off the road, apply the parking brake, shift the shift lever to P, and
turn the hybrid system off.
●Do not touch the high voltage parts, cables and connectors.
●If electric wires are exposed inside or outside your vehicle, an electric shock may
occur. Never touch exposed electric wires.
●If a fluid leak occurs, do not touch the flui d as it may be strong alkaline electrolyte
from the hybrid battery (traction battery). If it comes into contact with your skin or
eyes, wash it off immediately with a large amount of water or, if possible, boric
acid solution. Seek imme diate medical attention.
●If a fire occurs in the hybrid vehicle, leave the vehicle as soon as possible. Never
use a fire extinguisher that is not meant for electric fires. Using even a small
amount of water may be dangerous.
●If your vehicle needs to be towed, do so with four wheels raised. If the wheels con-
nected to the electric motor (traction mo tor) are on the ground when towing, the
motor may continue to generate electricity. This may cause an electricity leakage
leading to a fire. ( P. 4 8 6 )
●Carefully inspect the ground under the vehicle. If you find that liquid has leaked
onto the ground, the fuel system may have been damaged. Leave the vehicle as
soon as possible.

1343-2. Opening, closing and locking the doors and trunk
LS600hL_U(OM50E41U)
■Conditions affecting operation
The smart access system with push-button start uses weak radio waves. In the follow-
ing situations, the communication between the electronic key and the vehicle may be
affected, preventing the smar t access system with push-button start, wireless remote
control and immobilizer system from operating properly. (Ways of coping: P. 5 2 4 )
●When the electronic ke y battery is depleted
●Near a TV tower, electric power plant, gas station, radio station, large display, air-
port or other facility that generates strong radio waves or electrical noise
●When carrying a portable radio, cellular phone, cordless phone or other wireless
communication device
●When the electronic key is in contact with, or is covered by the following metallic
objects
• Cards to which aluminum foil is attached
• Cigarette boxes that have aluminum foil inside
• Metallic wallets or bags
•Coins
• Hand warmers made of metal
• Media such as CDs and DVDs
●When multiple electronic keys are in the vicinity
●When other wireless keys (that emit radio waves) are being used nearby
●When carrying the electronic key togeth er with the following devices that emit
radio waves
• Another vehicle’s electronic key or a wireless key that emits radio waves
• Personal computers or person al digital assistants (PDAs)
• Digital audio players
• Portable game systems
●If window tint with a metallic content or metallic objects are attached to the rear
window
