2015 LEXUS LS600H climate control

TABLE OF CONTENTS4
LS600hL_U(OM50E41U)5-1. Remote Touch screen
Remote Touch/12.3-inch display.......................................... 330
5-2. Lexus Climate Concierge Lexus Climate Concierge.................................. 335
5-3. Using the air conditioning system and defogger
Front automatic air conditioning system ............... 336
Rear air conditioning system ............................................351
Rear window and outside rear view mirror
defoggers ................................... 358
Windshield wiper de-icer ......................................... 359
5-4. Using the interior lights Interior lights list ......................... 360
• Interior lights ............................ 361
• Personal lights ....................... 362
5-5. Using the storage features List of storage features ............ 364• Glove box ............................... 366
• Coin holder .............................367
• Door pockets..........................367
• Cup holders ........................... 368
• Console box .......................... 369
• Auxiliary boxes ....................... 371
Trunk features ...............................373 5-6. Other interior features
Sun visors and vanity mirrors .......................................... 376
Clock ...............................................378
Ashtrays ..........................................379
Cigarette lighters.......................380
Power outlets ............................... 382
Heated steering wheel ............385
Climate control seats ............... 387
Armrest.......................................... 392
Retractable table........................ 393
Rear sunshade ............................ 395
Rear door sunshades ............... 398
Coat hooks .................................... 401
Assist grips ................................... 402
Garage door opener ............... 403
LEXUS Enform Safety Connect....................................... 410
5Interior features

23Pictorial index
LS600hL_U(OM50E41U)Snow mode switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 225
EV drive mode switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 221
Driving mode select switch. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 283
Vehicle height adjustment switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 287
VSC (Vehicle Stability Control) OFF switch. . . . . . . . . . . . . . . . . . . . . . . . .P. 291
Remote Touch
*1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 330
Seat and interior feature switches
*3
Rear sunshade switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 395
Rear door sunshade switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 398
Front climate control seat switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 387
Rear seat return switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 164
Front passenger’s power seat switches
*2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 157
*1: Refer to “NAVIGATION AND MULTIMEDIA SYSTEM OWNER’S MANUAL”.
*2: If equipped
*3: Location of the switches varies according to the vehicle grade level.
1
2
3
4
5
6
7

30Pictorial index
LS600hL_U(OM50E41U)
■Rear interior switches
Rear air conditioning switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 351
Rear sunshade switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 395
Rear door sunshade switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 398
Rear audio switches
*3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 357
Rear climate control seat switches. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 388
Power rear seat switches
*2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 162
Front passenger's seat control switches
*1, 2. . . . . . . . . . . . . . . . . . . P. 158, 165
Pelvic support seat switches
*2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 166
*1: If equipped
*2: Location of the switches varies according to the vehicle grade level.
*3: Refer to “NAVIGATION AND MULTIMEDIA SYSTEM OWNER’S MANUAL”.
1
2
3
4
5

3264-6. Driving tips
LS600hL_U(OM50E41U)
Perform the following according to the driving conditions:
●Do not try to forcibly open a window or move a wiper that is frozen.
Pour warm water over the frozen area to melt the ice. Wipe away the
water immediately to prevent it from freezing.
●To ensure proper operation of the climate control system fan, remove
any snow that has accumulated on the air inlet vents in front of the wind-
shield.
●Check for and remove any excess ice or snow that may have accumu-
lated on the exterior lights, vehicle’s roof, chassis, around the tires or on
the brakes.
●Remove any snow or mud from the bo ttom of your shoes before getting
in the vehicle.
Accelerate the vehicle slowly, keep a safe distance between you and the
vehicle ahead, and drive at a reduced speed suitable to road conditions.
Park the vehicle and move the shift lever to P without setting the parking
brake. The parking brake may freeze up, preventing it from being
released. If necessary, block the wheels to prevent inadvertent sliding or
creeping.
Before driving the vehicle
When driving the vehicle
When parking the vehicle

329
Interior features5
LS600hL_U(OM50E41U)5-1. Remote Touch screen
Remote Touch/12.3-inch display ......................................... 330
5-2. Lexus Climate Concierge Lexus Climate Concierge ..................................335
5-3. Using the air conditioning system and defogger
Front automatic air conditioning system ...............336
Rear air conditioning system ........................................... 351
Rear window and outside rear view mirror
defoggers .................................. 358
Windshield wiper de-icer..........................................359 5-4. Using the interior lights
Interior lights list .........................360• Interior lights ............................361
• Personal lights ....................... 362
5-5. Using the storage features List of storage features ............ 364• Glove box ............................... 366
• Coin holder ............................ 367
• Door pockets ......................... 367
• Cup holders ...........................368
• Console box........................... 369
• Auxiliary boxes ....................... 371
Trunk features .............................. 373
5-6. Other interior features Sun visors and vanity mirrors .......................................... 376
Clock............................................... 378
Ashtrays ......................................... 379
Cigarette lighters ...................... 380
Power outlets ...............................382
Heated steering wheel ............385
Climate control seats ............... 387
Armrest .......................................... 392
Retractable table ........................ 393
Rear sunshade............................. 395
Rear door sunshades................398
Coat hooks .................................... 401
Assist grips.................................... 402
Garage door opener................ 403
LEXUS Enform Safety Connect ....................................... 410

335
5
Interior features
LS600hL_U(OM50E41U)
5-2. Lexus Climate Concierge
Automatic air conditioning system (P. 339, 352)
Set the air conditioning sy stem to automatic mode.
The temperature for the driver’s seat, front passenger’s seat and both rear seats
can be adjusted individually.
Climate control seats (P. 387, 388)
Select “AUTO” mode on each seat.
Seat heater, off, ventilation or seat cooler is automatically selected according to
the set temperature of the air conditio ning system, outside temperature, etc.
Heated steering wheel ( P. 385)
Turned on automatically accordin g to the outside temperature and
cabin temperature.
Operates for a maximum of 30 minutes.
Lexus Climate Concierge
The climate control seats on each seat and heated steering wheel are
automatically controlled according to the set temperature of the air
conditioning system, outside temperature, cabin temperature, etc.
Lexus Climate Concierge allows a comfortable condition to be main-
tained without adjusting each system.
1
2
3

3395-3. Using the air conditioning system and defogger
5
Interior features
LS600hL_U(OM50E41U)
Press to operate the voice com-
mand system. For details, refer to
“NAVIGATION AND MULTIME-
DIA SYSTEM OWNER’S MAN-
UAL”.
Press the “AUTO” switch or select “AUTO” on the operation screen.
The dehumidification function begins to operate. Air outlets and fan speed are
automatically adjusted according to the temperature setting and humidity.
Press to switch to automatic air intake mode.
The air conditioning system automatically switches between outside air and recir-
culated air modes.
Press or select on the operation screen to increase the
temperature and or on the operation screen to decrease
the temperature.
When “4-ZONE” is selected (the indicator will be on) or the passenger’s side
temperature control button is pressed, the temperature for the driver’s, front pas-
senger’s and rear seats ( P. 351) can be adjusted separately.
Air outlets for the driver and passen ger seats may be adjusted separately
depending on the temperature setting.
When the climate control seats are set to “AUTO” mode, the system is operated
automatically according to the set temperature, outside temperature, etc.
■Automatic mode indicator
If the fan speed setting or air flo w modes are operated, the automatic
mode indicator goes off. However, automatic mode for functions other
than that operated are maintained.
Using the voice command system
Using the automatic air conditioning system
1
2
3

3405-3. Using the air conditioning system and defogger
LS600hL_U(OM50E41U)
To adjust the fan speed, press or select on the operation
screen to increase the fan speed and or on the operation
screen to decrease the fan speed.
Press or select “OFF” on the oper ation screen to turn the fan off.
To adjust the temperature setting, press or select on the
operation screen to increase the temperature and or on
the operation screen to decrease the temperature.
The air conditioning system switches between individual and simultaneous modes
each time “4-ZONE” is selected.
When “4-ZONE” is selected (the indicator will be on) or the passenger’s side
temperature control button is pressed, the temperature for the driver’s, front pas-
senger’s and rear seats ( P. 351) can be adjusted separately.
When the climate control seats are set to “AUTO” mode, the system is operated
automatically according to the set temperature, outside temperature, etc.
To change the air outlets, press or select an air outlet
switch.
Left-hand front seat
Right-hand front seat
Different air outlets for the driver
and front passenger seats can be
chosen.
Adjusting the settings manually
1
2
3
1
2
