2015 LEXUS LS600H traction control

12
LS600hL_U(OM50E41U)The SRS airbag and seat belt pretensioner devices in your Lexus contain explosive
chemicals. If the vehicle is scrapped with
the airbags and seat belt pretensioners left
as they are, this may cause an accident such as fire. Be sure to have the systems of
the SRS airbag and seat belt pretensioner removed and disposed of by a qualified
service shop or by your Lexus deal er before you scrap your vehicle.
Special handling may apply, See www.dt sc.ca.gov/hazardouswaste/perchlorate.
Your vehicle has components that may contain perchlorate. These components may
include airbag, seat belt pretensioners, and wireless remote control batteries.
Scrapping of your Lexus
Perchlorate Material
CAUTION
■General precautions while driving
Driving under the influence: Never drive your vehicle when under the influence of
alcohol or drugs that have impaired your ability to operate your vehicle. Alcohol
and certain drugs delay reaction time, impa ir judgment and reduce coordination,
which could lead to an accident that could result in death or serious injury.
Defensive driving: Always drive defensively. Anticipate mistakes that other drivers
or pedestrians might make and be ready to avoid accidents.
Driver distraction: Always give your full attention to driving. Anything that distracts
the driver, such as adjusting controls, ta lking on a cellular phone or reading can
result in a collision with resulting death or serious injury to you, your occupants or
others.
■General precaution regarding children’s safety
Never leave children unattended in the vehicle, and never allow children to have or
use the key.
Children may be able to start the vehicle or shift the vehicle into neutral. There is
also a danger that children may injure th emselves by playing with the windows, the
moon roof, or other features of the vehicle. In addition, heat build-up or extremely
cold temperatures inside the vehicle can be fatal to children.

811-2. Hybrid system
1
For safety and security
LS600hL_U(OM50E41U)
Hybrid system precautions
Take care when handling the hybrid system, as it contains a high voltage
system (about 650 V at maximum) as well as parts that become
extremely hot when the hy brid system is operating. Obey the caution
labels attached to the vehicle.
Caution label
Power control unit
Electric motor (traction motor)
Hybrid battery (traction bat-
tery) DC/DC converter
Service plug
High voltage cables (orange)
Air conditioning compressor1
2
3
4
5
6
7
8

2264-2. Driving procedures
LS600hL_U(OM50E41U)
■S mode
●When the shift range is 6 or lower, holding the shift lever toward “+” sets the shift
range to 8.
●When the shift lever is moved toward “-”, the shift range is downshifted to a range
that enables engine braking force that is suitable to driving conditions.
■Downshifting restrictions warning buzzer (in the S mode)
To help ensure safety and driving perfor mance, downshifting operation may some-
times be restricted. In some circumstances, downshifting may not be possible even
when the shift lever is operated. (A buzzer will sound twice.)
■When driving with cruise control or dyna mic radar cruise control with full speed
range activated
Even when performing the following actions with the intent of enabling engine brak-
ing, engine braking will not activate beca use cruise control or dynamic radar cruise
control with full speed range will not be canceled.
●While driving in S mode, downshifting to 7, 6, 5 or 4. (  P. 253, 257)
●When switching the driving mode to sp ort mode while driving in D position.
(  P. 2 8 3 )
■Snow mode automatic deactivation
Snow mode is automatically deactivated if th e power switch is turned off after driving
in snow mode.
■If the shift lever cannot be shifted from P
 P. 5 1 9
CAUTION
■When driving on slippery road surfaces
Be careful of downshifting and sudden acceleration, as this could result in the vehi-
cle skidding to the side or spinning.
NOTICE
■Hybrid battery (traction battery) charge
If the shift lever is in N, the hybrid ba ttery (traction battery) will not be charged
even when the engine is running. Therefore, if the vehicle is left with the shift lever
in N for a long period of time, the hybrid battery (traction battery) will discharge,
and this may result in the vehicle not being able to start.

2894-5. Using the driving support systems
4
Driving
LS600hL_U(OM50E41U)
◆ABS (Anti-lock Brake System)
Helps to prevent wheel lock when the brakes are applied suddenly, or if
the brakes are applied while dri ving on a slippery road surface
◆Brake assist
Generates an increased level of br aking force after the brake pedal is
depressed when the system detects a panic stop situation
◆VSC (Vehicle Stability Control)
Helps the driver to control skidding when swerving suddenly or turning
on slippery road surfaces
◆TRAC (Traction Control)
Helps to maintain drive power and prevent the drive wheels from spin-
ning when starting the vehicle or accelerating on slippery roads
◆Hill-start assist control
Helps to prevent the vehicle from ro lling backward when starting on an
incline or slippery slope
◆VGRS (Variable Gear Ratio Steering)
Adjusts the wheel turning angle in accordance with the vehicle speed
and steering wheel movement
Driving assist systems
To help enhance driving safety an d performance, the following systems
operate automatically in response to various driving situations. Be
aware, however, that these systems are supplementary and should not
be relied upon too heavily when operating the vehicle.

5578-1. Specifications
8
Vehicle specifications
LS600hL_U(OM50E41U)
This information has been prepared in accordance with regulations issued
by the National Highway Traffic Safety Administration of the U.S. Depart-
ment of Transportation.
It provides the purchasers and/or prospective purchasers of Lexus vehi-
cles with information on uniform tire quality grading.
Your Lexus dealer will help answer any questions you may have as you read this
information.
■DOT quality grades
All passenger vehicle tires must conform to Federal Safety Require-
ments in addition to these grades. Quality grades can be found where
applicable on the tire sidewall between tread shoulder and maximum
section width.
For example: Treadwear 200 Traction AA Temperature A
■Treadwear
The treadwear grade is a comparative rating based on the wear rate of
the tire when tested under controlle d conditions on a specified govern-
ment test course.
For example, a tire graded 150 would wear one and a half (1 - 1 /2) times as well
on the government course as a tire graded 100.
The relative performance of tires depends upon the actual conditions of their
use. Performance may differ significantly from the norm due to variations in
driving habits, service practices and differences in road characteristics and cli-
mate.
■Traction AA, A, B, C
The traction grades, from highest to lowest, are AA, A, B and C, and
they represent the tire’s ability to stop on wet pavement as measured
under controlled conditions on sp ecified government test surfaces of
asphalt and concrete.
A tire marked C may have poor traction performance.
Warning: The traction grade assigned to this tire is based on braking (straight
ahead) traction tests and does not include cornering (turning) traction.
Uniform Tire Quality Grading

599Alphabetical index
LS600hL_U(OM50E41U)
Approach warning............................... 264
Armrest .................................................... 392
Ashtrays.................................................... 379
Assist grips .............................................. 402
Audio/visual system
*
Automatic headlight leveling system .................................................... 236
Automatic High Beam ....................... 238
Automatic light control system....... 234
Auxiliary boxes ........................................ 371 Back-up lights
Replacing light bulbs .........................481
Battery (12-volt battery) .................... 450 If the 12-volt battery is discharged......................................... 527
Preparing and checking before winter.................................................... 325
Warning light ....................................... 494
Battery (traction battery) ....................... 81
Blind Spot Monitor (BSM) ............... 308
Brake Brake Hold ............................................. 231
Fluid .......................................................... 448
Parking brake ...................................... 228
Regenerative braking ......................... 78
Warning light ...........................493, 495
Brake assist ............................................. 289
Brake Hold................................................ 231
Break-in tips ............................................. 199
Brightness control Instrument panel light control ........ 101
BSM (Blind Spot Monitor) ............... 308
B
*: Refer to the “NAVIGATION AND MULTIMEDIA SYSTEM OWNER’S MANUAL”.

602Alphabetical index
LS600hL_U(OM50E41U)
Driver’s seat position memory .......... 172
Driving........................................................ 198Break-in tips .......................................... 199
Correct driving posture .................... 34
Driving mode select switch ......... 283
Hybrid vehicle driving tips............. 323
Procedures ............................................ 198
Winter drive tips .................................325
Dynamic radar cruise control with full-speed range ....................... 257 Function .................................................. 257
Eco drive mode ..................................... 283
EDR (Event data recorder) .................... 11
Electric motor (traction motor) ..........76
Electric Power Steering (EPS) ....... 290 Function ................................................. 290
Warning light .......................................494
Electronic key ......................................... 120 If the electronic key does not operate properly.............................524
Replacing the battery ....................... 472
Electronically modulated air suspension............................................ 287
Emergency flashers ............................. 484 Emergency, in case of
If the 12-volt battery is discharged......................................... 527
If the electronic key does not operate properly ........ 524
If the hybrid system will not start ......................................... 517
If the parking brake cannot be released .......................520
If the shift lever cannot be shifted from P ..............519
If the warning buzzer sounds ...... 493
If the warning light turns on .......... 493
If the warning message is displayed ........................................503
If you have a flat tire ...............506, 515
If you think something is wrong .............................................. 492
If your vehicle becomes stuck......................................................535
If your vehicle has to be stopped in an emergency..........485
If your vehicle needs to be towed .......................................486
If your vehicle overheats ................530
E

605Alphabetical index
LS600hL_U(OM50E41U)
HooksCargo hooks ........................................ 373
Coat hooks ............................................ 401
Retaining hooks (floor mat) ............. 32
Shopping bag hooks........................ 373
Horn ........................................................... 233
Hybrid battery (traction battery) ........81
Hybrid battery (traction battery) air vents .................................................... 82
Hybrid system ............................................76 Emergency shut off system.............. 82
Energy monitor/consumption screen ........................ 112
EV drive mode...................................... 221
High voltage components ................ 81
Hybrid System Indicator ................. 103
Hybrid system precautions............... 81
Hybrid vehicle driving tips............. 323
If the hybrid system will not start......................................... 517
Overheating ........................................ 530
Power (ignition) switch .................... 216
Starting the hybrid system .............. 216
Vehicle proximity notification system ..................................................... 77
Hybrid System Indicator..................... 103
Hybrid transmission ............................ 223 If the shift lever cannot be shifted from P ............. 519
S mode .................................................... 224 I/M test ......................................................432
Identification........................................... 539
Engine .....................................................539
Vehicle ....................................................539
Ignition switch (power switch) .......... 216
Illuminated entry system ................... 363
Immobilizer system ................................ 88
Indicators ..................................................... 97
Initialization Maintenance ........................................ 426
Moon roof ...............................................194
Power windows................................... 190
Tire pressure warning system ...............................455
Initiators (tire pressure warning system) .................................462
Inside door handle lights ................... 360
Inside rear view mirror.........................183
Instrument panel light control ............ 101
Instrument panel ornament lights ....................................................... 360
Interior lights ............................................ 361 Front interior light ................................361
Rear interior light .................................361
Interior lights list.................................... 360
Intuitive parking assist
*
I
*: Refer to the “NAVIGATION AND MULTIMEDIA SYSTEM OWNER’S MANUAL”.
