2015 LEXUS LS600H differential

2084-1. Before driving
LS600hL_U(OM50E41U)
NOTICE
■When encountering flooded roads
Do not drive on a road that has flooded after heavy rain etc. Doing so may cause
the following serious damage to the vehicle:
●Engine stalling
●Short in electrical components
●Engine damage caused by water immersion
In the event that you drive on a flooded road and the vehicle is flooded, be sure to
have your Lexus dealer check the following:
●Brake function
●Changes in quantity and quality of oil and fluid used for the engine, transmission,
transfer, differential, etc.
●Lubricant condition for the propeller shaft, bearings and suspension joints (where
possible), and the function of all joints, bearings, etc.

5448-1. Specifications
LS600hL_U(OM50E41U)
*: The fluid capacity is the quantity of reference.If replacement is necessary, contact your Lexus dealer.
*: Your Lexus vehicle is filled with Toyota genuine gear oil at the factory. Use Lexus
approved Toyota genuine gear oil or an equivalent of matching quality to satisfy
the above specification. Please contact your Lexus dealer for further details.
*: Your Lexus vehicle is filled with “Toyota Genuine Differential Gear Oil” at the fac-
tory. Use Lexus approved “Toyota Genuine Differential Gear Oil” or an equiva-
lent of matching quality to satisfy th e above specification. Please contact your
Lexus dealer for further details.
Hybrid transmission
Fluid capacity*5.8 qt. (5.5 L, 4.8 Imp. qt.)
Fluid typeTo y o t a G e n u i n e AT F W S
NOTICE
■Hybrid transmission fluid type
Using transmission fluid other than “Toyota Genuine ATF WS” may cause deterio-
ration in shift quality, and ultimately damage the transmission of your vehicle.
Tr a n s f e r
Oil capacity0.74 qt. (0.7 L, 0.62 Imp. qt.)
Oil type and viscosity*Toyota Genuine Transfer gear oil LL 80 or equivalent
Front differential
Oil capacity0.79 qt. (0.75 L, 0.66 Imp. qt.)
Oil type and viscosity*Toyota Genuine Differential gear oil LT
75W-85 GL-5 or equivalent

5458-1. Specifications
8
Vehicle specifications
LS600hL_U(OM50E41U)
*: Your Lexus vehicle is filled with “Toyota Genuine Differential Gear Oil” at the fac-
tory. Use Lexus approved “Toyota Genuine Differential Gear Oil” or an equiva-
lent of matching quality to satisfy th e above specification. Please contact your
Lexus dealer for further details.
*: Minimum pedal clearance when depressed with a force of 112 lbf (500 N, 51 kgf)
while the hybrid system is operating.
When performing the brake pedal inspection, also be sure to check that the
brake system warning light is not illumina ted when the hybrid system is operating
(If the brake system warning light is illuminated, refer to P. 493).
Rear differential
Oil capacity1.42 qt. (1.35 L, 1.19 Imp. qt.)
Oil type and viscosity*Toyota Genuine Differential gear oil LX
75W-85 GL-5 or equivalent
Brakes
Pe d a l c l e a r a n c e*5.8 in. (147 mm) Min.
Pedal free play0.04 - 0.08 in. (1.0 - 2.0 mm)
Brake pad wear limit0.04 in. (1.0 mm)
Parking brake lining wear limit0.04 in. (1.0 mm)
Fluid typeSAE J1703 or FMVSS No.116 DOT 3
Steering
Free playLess than 1.2 in. (30 mm)

601Alphabetical index
LS600hL_U(OM50E41U)
Console box ........................................... 369
Consumption screen ............................. 115
Coolant..................................................... 445Capacity .................................................543
Checking................................................445
Preparing and checking before winter ....................................................325
Cooling system ..................................... 445 Engine overheating.......................... 530
Hybrid system overheating ......... 530
Cruise control Cruise control......................................253
Dynamic radar cruise control with full-speed range .................... 257
Cup holders ............................................ 368
Curtain shield airbags ........................... 43
Customizable features ....................... 564
Daytime running light system .......... 236
Defogger Front windshield .................................. 341
Outside rear view mirrors ............ 358
Rear window ....................................... 358
Differential Front differential ..................................544
Rear differential .................................. 545
Dimensions .............................................538
Dinghy towing..........................................215 Display
Dynamic radar cruise control with full-speed range ................... 257
LKA (Lane-Keeping Assist)..........277
Multi-information display................ 105
Remote Touch screen ....................330
Trip information ................................... 106
Warning message.............................503
Do-it-yourself maintenance............. 433
Door courtesy lights ........................... 360
Door lock Doors.........................................................145
Smart access system with push-button start .............................. 125
Wireless remote control....................141
Door pockets ..........................................367
Doors .......................................................... 145 Automatic door locking and unlocking system .................... 147
Door glasses ......................................... 189
Door lock.................................................145
Open door warning buzzer ......... 130
Open door warning light .............. 496
Outside rear view mirrors ............. 185
Rear door child-protector ..............146
D

608Alphabetical index
LS600hL_U(OM50E41U)
Odometer .................................................. 99
OilEngine oil................................................. 541
Front differential oil............................544
Rear differential oil ............................ 545
Opener Fuel filler door ....................................... 251
Hood ........................................................436
Trunk ......................................................... 149
Outer foot lights Location ................................................. 360
Replacing light bulbs ......................... 481
Outside rear view mirrors ................. 185 Adjusting and folding........................ 185
BSM (Blind Spot Monitor)........... 308
Linked mirror function when reversing ................................. 187
Mirror position memory ................... 172
Outside rear view mirror defoggers ........................... 358
Outside temperature display ............. 99
Overheating ...........................................530
Parking brake......................................... 228 If the parking brake cannot be released ....................... 520
Operation ..............................................228
Parking brake engaged warning buzzer .............................. 230 Parking lights ..........................................234
Light switch........................................... 234
Replacing light bulbs .........................481
Welcome light illumination control .......................... 126
PCS (Pre-Collision System).............296 Function .................................................. 296
Pre-collision braking off switch............................................. 298
Warning light ....................................... 495
Pelvic support seat with seat vibrator.................................................... 166
Personal lights ........................................362 Front personal light........................... 362
Rear personal light ............................ 362
Power control unit .................................... 81
Power control unit coolant................446 Capacity................................................. 543
Checking ............................................... 446
Preparing and checking before winter.................................................... 325
Power easy access system ................. 159
Power outlets ......................................... 382
Power steering (Electric Power Steering system)................................ 290 Warning light ....................................... 494
Power switch............................................ 216
Power trunk opener and closer ....... 149
Power windows.......................................189 Door lock linked window operation ............................ 191
Jam protection function................... 190
Operation............................................... 189
Window lock switch ......................... 189
O
P
