2015 LEXUS LS600H windshield wipers

3
1
8 7
6
5
4
3
2
9
LS600hL_U(OM50E41U)3-5. Opening, closing the
windows and moon roof
Power windows ............................ 189
Moon roof .......................................192
4-1. Before driving Driving the vehicle ..................... 198
Cargo and luggage................... 209
Vehicle load limits ........................213
Trailer towing .................................214
Dinghy towing ...............................215
4-2. Driving procedures Power (ignition) switch ..............216
EV drive mode .............................. 221
Hybrid transmission .................. 223
Turn signal lever ...........................227
Parking brake .............................. 228
Brake Hold .....................................231
Horn ................................................ 233
4-3. Operating the lights and wipers
Headlight switch ........................ 234
Automatic High Beam............. 238
Fog light switch ........................... 243
Windshield wipers and washer ..........................................244
Headlight cleaner switch........ 248 4-4. Refueling
Opening the fuel tank cap .................................................249
4-5. Using the driving support systems
Cruise control ............................. 253
Dynamic radar cruise control with full-speed
range .............................................257
LKA (Lane-Keeping Assist) ...........273
Driving mode select switch ........................................... 283
Electronically modulated air suspension............................287
Driving assist systems .............. 289
PCS (Pre-Collision System) ......... 296
BSM (Blind Spot Monitor) .............308
• The Blind Spot Monitor function ......................................312
• The Rear Cross Traffic Alert function ..........................315
Lexus night view .......................... 318
4-6. Driving tips Hybrid vehicle driving tips ................................................. 323
Winter driving tips ..................... 325
4Driving

17Pictorial index
LS600hL_U(OM50E41U)Windshield wipers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 244
Precautions against winter season . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 325
To prevent freezing (windshield wiper de-icer)
* . . . . . . . . . . . . . . . . . . . . P. 359
Precautions against car wash . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 420
Fuel filler door . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 2 4 9
Refueling method. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 249
Fuel type/fuel tank capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 540
Tires . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 454
Tire size/inflation pressure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 546
Winter tires/tire chain . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 325
Checking/rotation/tire pressure warning system. . . . . . . . . . . . . . . . . . . . P. 454
Coping with flat tires. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 506, 515
Hood . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 436
Opening . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 436
Engine compartment cover. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 440
Engine oil . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .P. 541
Coping with overheat. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 530
Warning messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 503
Headlights/parking lights/daytime running ligh ts . . . . . . . . . . . . . . . . . . P. 234
Fog lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 243
Turn signal lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 227
Tail lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 234
Stop lights
Hill-start assist control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 289
License plate lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 234
Back-up lights
Shifting the shift lever to R . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 223
Side marker lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P. 234
4
5
6
7
Light bulbs of the ex terior lights for driving
(Replacing method: P. 481)
*: If equipped
8
9
10
11
12
13
14
15

197
Driving4
LS600hL_U(OM50E41U)4-1. Before driving
Driving the vehicle ......................198
Cargo and luggage .................. 209
Vehicle load limits ....................... 213
Trailer towing ................................. 214
Dinghy towing............................... 215
4-2. Driving procedures Power (ignition) switch.............. 216
EV drive mode ............................. 221
Hybrid transmission ..................223
Turn signal lever .......................... 227
Parking brake ...............................228
Brake Hold ..................................... 231
Horn.................................................233
4-3. Operating the lights and wipers
Headlight switch .........................234
Automatic High Beam ............ 238
Fog light switch............................ 243
Windshield wipers and washer.......................................... 244
Headlight cleaner switch ........248 4-4. Refueling
Opening the fuel tank cap....................................... 249
4-5. Using the driving support systems
Cruise control ............................. 253
Dynamic radar cruise control with full-speed
range ............................................ 257
LKA (Lane-Keeping Assist) ...........273
Driving mode select switch ........................................... 283
Electronically modulated air suspension ........................... 287
Driving assist systems............... 289
PCS (Pre-Collision System).......... 296
BSM (Blind Spot Moni tor)............. 308
• The Blind Spot Monitor function ..................................... 312
• The Rear Cross Traffic Alert function.......................... 315
Lexus night view .......................... 318
4-6. Driving tips Hybrid vehicle driving tips ................................................. 323
Winter driving tips ..................... 325

2414-3. Operating the lights and wipers
4
Driving
LS600hL_U(OM50E41U)
●In the situations below, the system may not be able to correctly detect the sur-
rounding brightness levels, and may flash or expose oncoming or preceding vehi-
cles to the high beam or may continue using the low beam. Therefore, in these
situations you should consider turning th e high beams on or off manually rather
than relying on the Automatic High Beam system.
• In bad weather (rain, snow , fog, sandstorms etc.)
• The windshield is obscured by fog, mist, ice, dirt etc.
• The windshield is cracked or damaged.
• The inside rear view mirror or camera sensor is deformed or dirty.
• The camera sensor temperature is extremely high.
• Surrounding brightness levels are equal to those of headlights, tail lights or fog lights.
• Vehicles ahead have headlights that are either switched off, dirty, are changing color, or have are not aimed properly.
• When driving through an area of interm ittently changing brightness and dark-
ness.
• When frequently and repeatedly driving ascending/descending roads, or roads with rough, bumpy or uneven surfaces (such as stone-paved roads, gravel tracks
etc.).
• When frequently and repeatedly taking curves or driving on a winding road.
• There is a highly reflective object ahead of the vehicle, such as a sign or a mirror.
• The back of a vehicle ahead is highly reflective, such as a container on a truck.
• The vehicle’s headlights are damaged or dirty.
• The vehicle is listing or tilting, due to a flat tire, a trailer being towed etc.
■Temporary lowering sensor sensitivity
The sensitivity of the sensor can be temporarily lowered.
To lower the sensitivity, push and hold the “AUTO” button on the inside rear view mir-
ror for 15 to 20 seconds, and release. The indicator light on the inside rear view mir-
ror will flash to indicate that the sensitivity has been lowered.
When the power switch is turned off, the sensitivity will be returned to its normal
level.
CAUTION
■Limitations of the Automatic High Beam
Do not rely on the Automatic High Beam. Always drive safely, taking care to
observe your surroundings and turn the high beam on or off manually if necessary.

2424-3. Operating the lights and wipers
LS600hL_U(OM50E41U)
NOTICE
■Notes when using the Automatic High Beam system
●Do not touch the camera sensor.
●Do not subject the inside rear view mirror or the camera sensor to a strong
impact.
●Do not disassemble the camera sensor.
●Do not spill liquid onto the inside rear view mirror or the camera sensor.
●Do not apply window tinting or stickers to the camera sensor or the area of wind-
shield near the camera sensor.
●Do not place items on the dashboard. There is a possibility that the camera sensor
will mistake items reflected in the windsh ield for streetlights, the headlights of
other vehicles, etc.
●Do not install a parking tag or any other accessories near or around the inside
rear view mirror and the camera sensor.
●Do not overload the vehicle.
●Do not modify the vehicle.
●If the windshield needs to be replaced, contact your Lexus dealer.
Observe the following to ensure that the
Automatic High Beam functions correctly.

2444-3. Operating the lights and wipers
LS600hL_U(OM50E41U)
Operate the lever as follows to operate the wipers. (U.S.A.) or (Canada)
Temporary operation
Rain-sensing wiper opera-
tion
The wipers will operate automatically
when the sensor detects falling rain.
The system automatically adjusts
wiper timing in accordance with rain
volume and vehicle speed.
(U.S.A.) or (Canada)
Low speed wiper operation
(U.S.A.) or (Canada)
High speed wiper operation
Windshield wipers and washer
Operating the wiper lever
1
2
3
4

2454-3. Operating the lights and wipers
4
Driving
LS600hL_U(OM50E41U)
When “AUTO” mode is selected,
the sensor sensitivity can be
adjusted by turning the switch ring.Increases the sensitivity
Decreases the sensitivity
Washer/wiper dual operation
Wipers will automatically operate a
couple of times after the washer
squirts.
■The windshield wiper and washer can be operated when
The power switch is in ON mode.
■Dripping prevention wiper sweep
After washing and the wiper has operated several times, the wipers operate one
more time after a short delay to prevent dripping.
However, the last sweep will not happen if the vehicle is traveling above 106 mph
(170 km/h).
■Effects of vehicle speed on wiper operation
Even when the wipers are not in “AUTO” mode, vehicle speed affects the time until
the drip prevention wiper sweep occurs.
With low speed windshield wiper operation selected, wiper operation will be
switched from low speed to intermittent wi per operation only when the vehicle is sta-
tionary.
(However, when the sensor sensitivity is adjusted to the highest level, the mode can-
not be switched.)
65
6
7

2464-3. Operating the lights and wipers
LS600hL_U(OM50E41U)
■Raindrop sensor
●If the wiper is turned to “AUTO” mode while the power switch is in ON mode, the
wipers will operate once to show that “AUTO” mode is activated.
●If the temperature of the raindrop sensor is 194°F (90°C) or higher, or 5°F (-15°C)
or lower, automatic operation may not occur. In this case, operate the wipers in any
mode other than “AUTO” mode.
■If no windshield washer fluid sprays
Check that the washer nozzles are not blocked if there is washer fluid in the wind-
shield washer fluid reservoir.
■Outside rear view mirror defogger activation linked to windshield wiper operation
The outside rear view mirror defoggers automatically turn on when you operate the
windshield wipers.
The outside rear view mirror defoggers automatically turn off approximately 15 min-
utes after the wipers stop.
For details about the outside rear view mirror defoggers: P. 3 5 8
●The raindrop sensor judges the amount of
raindrops.
An optical sensor is adopted. It may not
operate properly when sunlight from the
rising or setting of the sun intermittently
strikes the windshield, or if bugs etc. are
present on the windshield.
CAUTION
■Caution regarding the use of windshield wipers in “AUTO” mode
The windshield wipers may operate unexpect edly if the sensor is touched or the
windshield is subject to vibration in “AUTO” mode. Take care that your fingers or
anything else do not become ca ught in the windshield wipers.
■Caution regarding the use of washer fluid
When it is cold, do not use the washer fluid until the windshield becomes warm.
The fluid may freeze on the windshield and cause low visibility. This may lead to an
accident, resulting in death or serious injury.
