2524-4. Refueling
LS600hL_U(OM50E41U)
■When the fuel filler door cannot be opened by pressing the inside switch
●Using the lever to open the fuel filler door may not allow for an adequate reduction
in fuel tank pressure before refueling. To prevent fuel from spilling out, turn the cap
slowly when removing it.
During refueling, fuel may spill out from the filler opening due to air being dis-
charged from inside the fuel tank. Therefore, fill the fuel tank carefully and slowly.
After refueling, turn the fuel tank
cap until you hear a click. Once the
cap is released, it will turn slightly in
the opposite direction.
●If the fuel filler door opener switch cannot
be operated, contact your Lexus dealer to
service the vehicle. In case where refueling
is urgently necessary, the fuel filler door can
be opened using the lever in the trunk.
Closing the fuel tank cap
CAUTION
■When replacing the fuel tank cap
Do not use anything but a genuine Lexus fu el tank cap designed for your vehicle.
Doing so may cause a fire or other incide nt which may result in death or serious
injury.

608Alphabetical index
LS600hL_U(OM50E41U)
Odometer .................................................. 99
OilEngine oil................................................. 541
Front differential oil............................544
Rear differential oil ............................ 545
Opener Fuel filler door ....................................... 251
Hood ........................................................436
Trunk ......................................................... 149
Outer foot lights Location ................................................. 360
Replacing light bulbs ......................... 481
Outside rear view mirrors ................. 185 Adjusting and folding........................ 185
BSM (Blind Spot Monitor)........... 308
Linked mirror function when reversing ................................. 187
Mirror position memory ................... 172
Outside rear view mirror defoggers ........................... 358
Outside temperature display ............. 99
Overheating ...........................................530
Parking brake......................................... 228 If the parking brake cannot be released ....................... 520
Operation ..............................................228
Parking brake engaged warning buzzer .............................. 230 Parking lights ..........................................234
Light switch........................................... 234
Replacing light bulbs .........................481
Welcome light illumination control .......................... 126
PCS (Pre-Collision System).............296 Function .................................................. 296
Pre-collision braking off switch............................................. 298
Warning light ....................................... 495
Pelvic support seat with seat vibrator.................................................... 166
Personal lights ........................................362 Front personal light........................... 362
Rear personal light ............................ 362
Power control unit .................................... 81
Power control unit coolant................446 Capacity................................................. 543
Checking ............................................... 446
Preparing and checking before winter.................................................... 325
Power easy access system ................. 159
Power outlets ......................................... 382
Power steering (Electric Power Steering system)................................ 290 Warning light ....................................... 494
Power switch............................................ 216
Power trunk opener and closer ....... 149
Power windows.......................................189 Door lock linked window operation ............................ 191
Jam protection function................... 190
Operation............................................... 189
Window lock switch ......................... 189
O
P

616
LS600hL_U(OM50E41U)
GAS STATION INFORMATION
Auxiliary catch leverTrunk openerFuel filler door
P. 436 P. 149 P. 251
Hood lock release leverFuel filler door openerTire inflation pressure
P. 436 P. 251 P. 546
Fuel tank capacity
(Reference) 22.2 gal. (84 L, 18.4 Imp. gal.)
Fuel type
Premium unleaded gasoline only P. 249, 540
Cold tire inflation
pressure P. 5 4 6
Engine oil capacity
(Drain and refill —
reference)qt. (L, Imp. qt.)
With filter 9.5 (9.0, 7.9)
Without filter 8.9 (8.4, 7.4)
Engine oil type “Toyota Genuine Motor Oil” or equivalent
Oil grade: ILSAC GF-5 multigrade engine oil
Recommended viscosity: SAE 0W-20
P. 5 4 1
