2015 LEXUS LS600H start stop button

1373-2. Opening, closing and locking the doors and trunk
3
Operation of each component
LS600hL_U(OM50E41U)
■Electronic key battery depletion
●The standard battery life is 1 to 2 years. (The card key battery life is about a year and
a half.)
●If the battery is low, an alarm will sound in the cabin when the hybrid system is
started or stopped. ( P. 1 3 0 )
●The battery becomes depleted even if the electronic key is not used because the
key always receives radio waves. If the smart access system with push-button start
or the wireless remote control does not operate, or the detection area becomes
smaller, the battery may be depleted. Replace the battery when necessary.
(  P. 4 7 2 )
●To avoid serious deterioration, do not leave the electronic key within 3 ft. (1 m) of
the following electrical appliances that produce a magnetic field:
•TVs
•Personal computers
• Cellular phones, cordless phones and battery chargers
• Recharging cellular phones or cordless phones
•Table lamps
• Induction cookers
■When the electronic key battery is fully depleted
 P. 4 7 2
■Customization
Settings (e. g. smart access system with push-button start) can be changed.
(Customizable features P. 5 6 4 )

1653-3. Adjusting the seats
3
Operation of each component
LS600hL_U(OM50E41U)
Relaxation mode can be entered by operating a switch. The front passen-
ger seat will move forward, and then the seatback of the relaxation seat
will recline and the ottoma n will simultaneously rise.
Pressing the switch will cause a
beep to sound an d operation will
start.
Enters relaxation mode
Returns to the neutral position
To stop the operation part-way
through, press either side of the
switch again, or press any other seat
adjustment button.
Relaxation mode operation (relaxation seat)
1
2

1763-3. Adjusting the seats
LS600hL_U(OM50E41U)
■Cancelation procedure
Using the wireless remote control
Turn the power switch off and close the driver’s door.
While pressing the “SET” switch, press on the wireless remote
control until the buzzer sounds.
Using the door lock switch
Carry only the key you want to canc el and then close the driver's door.
If 2 or more keys are in the vehi cle, the driving position cannot be can-
celed properly.
Turn the power switch off and close the driver’s door.
While pressing the “SET” switch, press the lock or unlock side on the
door lock switch until the buzzer sounds.
■Recalling the driving position using the memory recall function
●Different driving positions can be registered for each electronic key. Therefore, the
driving position that is recalled may be different depending on the key being car-
ried.
●If a door other than the driver's door is unlocked with the smart access system with
push-button start, the driving position cann ot be recalled. In this case, press the
driving position switch which has been set.
■ Seat operation automatic st op function (4-seat models)
If a front seat is likely to come into contact with the retractable table or the ottoman
during seat operation or activation of the power easy access system, a buzzer will
sound and seat slide operation will be stopped partway.
(A warning message will be shown on the multi-information display.)
CAUTION
■Seat adjustment caution
Take care during seat adjustment so that the seat does not strike the rear passen-
ger or squeeze your body against the steering wheel.
1
2
1
2

5728-2. Customization
LS600hL_U(OM50E41U)
*1:If equipped
*2: The default setting varies according to countries.
*3: U.S.A. only
*4: Refer to the “NAVIGATION AND MULTIMEDIA SYSTEM OWNER’S MAN-UAL”.
■Vehicle customization
●When the smart access system with push-button start is off, the entry unlock func-
tion cannot be customized.
●When the doors remain closed after un locking the doors and the timer activated
automatic door lock function activates, signals will be generated in accordance
with the operation buzzer volume and operational signal (Emergency flashers)
function settings.
■When customizing using the Remote Touch
Stop the vehicle in a safe place, apply the parking brake, and shift the shift lever to P.
Also, to prevent 12-volt battery discharge, leave the hybrid system operating while
customizing the features.
Illumination
(  P. 3 6 0 )
Operation of the outer foot
lights when you approach
the vehicle with the elec-
tronic key on your person
OnOff——O
Operation of the outer foot
lights when the doors are
unlocked with the power
door lock switch
OnOff——O
Seat belt
reminder
(
P. 4 9 6 )
Vehicle speed linked seat
belt reminder buzzerOnOff——O
ItemFunctionDefault
settingCustom-
ized setting123

611Alphabetical index
LS600hL_U(OM50E41U)
Shift lever ................................................. 223Hybrid transmission.......................... 223
If the shift lever cannot be shifted from P ............. 519
Shift lever light ....................................... 360
Shift lock system..................................... 519
Shopping bag hooks ........................... 373
Side airbags ............................................... 43
Side marker lights................................. 234 Light switch ........................................... 234
Replacing light bulbs ......................... 481
Welcome light illumination control ................................................... 126
Side mirrors ............................................. 185 Adjusting and folding........................ 185
BSM (Blind spot monitor) ............ 308
Linked mirror function when reversing ................................. 187
Mirror position memory ................... 172
Side turn signal lights ...........................227 Replacing light bulbs ......................... 481
Turn signal lever ................................. 227
Smart access system with push-button start .......................125 Antenna location ................................. 128
Entry functions ...................................... 125
Starting the hybrid system .............. 216
Snow mode ............................................. 225
Snow tires ................................................ 328 Spare tire ................................................. 506
Inflation pressure................................ 546
Storage location ................................. 507
Spark plug ............................................... 543
Specifications......................................... 538
Speedometer .............................................99
Sport mode ............................................. 283
Steering lock ............................................ 218 Column lock release .........................218
Steering wheel ........................................ 182 Adjustment..............................................182
Heated steering wheel ...................385
Power easy access system .............159
Steering wheel position memory .............................. 172
Stop lights Replacing light bulbs .........................481
Storage feature ..................................... 364
Stuck If the vehicle becomes stuck........535
Sun shade Rear ..........................................................395
Rear door ..............................................398
Roof ............................................................193
Sun visors..................................................376
