2014 TOYOTA SIENNA Owners Manual

5
When trouble arises
745
5-2. Steps to take in an emergency
SIENNA_OM_OM45483U_(U)
Warning lightWarning light/Details
(U.S.A.)
(Canada) “ABS” warning light
Indicates a malfunction in:
• The ABS; or
• The brake assist system
Electric power steering system warning light (warning
buzzer) Indicates a malfunction in the EPS (Electric Power Steer-
ing) system
(Flashes) Pre-collision system warn
ing light (if equipped)
Indicates a malfunction in the pre-collision system
The warning light will operate as follows, even when the
system is not malfunctioning:
• The light will flash quickly when the system is operating. (P. 340)
• The light will turn on when the pre-collision braking is dis- abled. ( P. 341)
• The light will turn on when the system cannot temporarily be used.
Slip indicator light Indicates a malfunction in:
• Enhanced VSC
•TRAC
• Hill-start assist control system
The indicator will blink when the system listed above is
operational. ( P. 332, 337)
BSM warning light (if equipped) Indicates a malfunction in the Blind Spot Monitor.

746 5-2. Steps to take in an emergency
SIENNA_OM_OM45483U_(U)
Warning lightWarning light/Details
(Flashes) Automatic High Beam indi
cator light (if equipped)
Indicates a malfunction in the Automatic High Beam sys-
tem ( P. 277)
(Flashes) Cruise control indicator
light (if equipped)
Indicates a malfunction in the cruise control system
( P. 297, 302)
(Flashes) Radar cruise control indicator light (if equipped)
Indicates a malfunction in the Dynamic radar cruise control
system ( P. 302)

5
When trouble arises
747
5-2. Steps to take in an emergency
SIENNA_OM_OM45483U_(U)
Follow the correction procedures.
After taking the specified steps to correct the suspected problem,
check that the warning light turns off.
Warning lightWarning light/DetailsCorrection procedure
Open door warning light
(warning buzzer)
*1
Indicates that a door is not
fully closed. Check that all the doors are
closed.
Low fuel level warning
light Indicates remaining fuel is
approximately 3.0 gal.
(11.4 L, 2.5 Imp.gal.) or
less Refuel the vehicle.
Driver’s seat belt
reminder light
(warning buzzer)
*2
Warns the driver to fasten
his/her seat belt. Fasten the seat belt.
(on the center panel) Front passenger’s seat
belt reminder light
(warning buzzer)
*2
Warns the front passen-
ger to fasten his or her
seat belt.
Fasten the seat belt.
Master warning light A buzzer sounds and the
warning light comes on
and flashes to indicate that
the master warning system
has detected a malfunc-
tion. P. 758

748 5-2. Steps to take in an emergency
SIENNA_OM_OM45483U_(U)
Warning lightWarning light/DetailsCorrection procedure
Tire pressure warning
light
When the light comes on:
Low tire inflation pressure
such as
• Natural causes (P. 752)
• Flat tire ( P. 759, 761) Adjust the tire inflation
pressure to the specified
level.
The light will turn off after
a few minutes. In case
the light does not turn off
even if the tire inflation
pressure is adjusted,
have the system checked
by your Toyota dealer.
When the light comes on
after blinking for 1 minute:
Malfunction in the tire
pressure warning system
(  P. 754) Have the system checked
by your Toyota dealer.
Low windshield washer
fluid warning light
Low level of washer fluid Fill the tank.

5
When trouble arises
749
5-2. Steps to take in an emergency
SIENNA_OM_OM45483U_(U)
Warning lightWarning light/DetailsCorrection procedure
(U.S.A.) Maintenance required
reminder light
Indicates that mainte-
nance is requires accord-
ing to the driven distance
on the maintenance
schedule.
*3
Illuminates for about 3 sec-
onds and then flashes for
about 15 seconds approxi-
mately 4500 miles
(7200 km) after the mainte-
nance data has been reset. If necessary, perform main-
tenance.
Comes on and remains on if
the distance driven exceeds
5000 miles (8000 km) after
the maintenance data has
been reset. (The indicator
will not work property unless
the maintenance data has
been reset.) Perform the necessary
maintenance.
Please reset the mainte-
nance is performed.
(

P. 6 5 8)
Third seat warning light
(if equipped) Indicates that the third
seat operation is not yet
complete. Complete the third seat
operation.

750 5-2. Steps to take in an emergency
SIENNA_OM_OM45483U_(U)
*1:Open door warning buzzer:A buzzer will sound if the vehicle reaches a speed of 3 mph (5 km/h) with any
door open.
*2:Driver’s and front passenger’s seat belt warning buzzers:The driver’s and front passenger’s seat belt warning buzzers sound to alert
the driver and front passenger that his or her seat belt is not fastened. The
buzzer sounds intermittently for 10 seconds after the vehicle has reached a
speed of 12 mph (20 km/h). Then, if the seat belt is still unfastened, the
buzzer will sound at a different tone for 20 more seconds.
*3:Refer to the separate “Scheduled Maintenance Guide” or “Owner’s ManualSupplement” for the maintenance interval applicable to your vehicle.
Warning lightWarning light/DetailsCorrection procedure
(AWD models) Active Torque Control
4WD system warning light
When the light blinks: The
system has been over-
loaded and front-wheel
drive has been automati-
cally engaged. Drop your speed or stop the
vehicle until the light stops
blinking. (Do not stop the
engine.)
When the light comes on:
Malfunction in the Active
Torque Control 4WD sys-
tem. Have the system checked
by your Toyota dealer.

5
When trouble arises
751
5-2. Steps to take in an emergency
SIENNA_OM_OM45483U_(U)
■
SRS warning light
This warning light system monitors the airbag sensor assembly, front impact
sensors, side impact sensors (front door), side impact sensors (rear),
driver’s seat position sensor, driver’s seat belt buckle switch, front passen-
ger occupant classification system (ECU and sensors), “AIR BAG ON” indi-
cator light, “AIR BAG OFF” indicator light, front passenger’s seat belt buckle
switch, seat belt pretensioner assemblies, inflators, interconnecting wiring
and power sources. ( P. 170)
■ Front passenger detection sensor and passenger seat belt reminder
● If luggage is placed on the front passenger seat, the front passenger
detection sensor may cause the warning light to flash even if a passen-
ger is not sitting in the seat.
● If a cushion is placed on the seat, the sensor may not detect a passen-
ger, and the warning light may not operate properly.
■ Electric power steering system warning light (warning buzzer)
When the battery charge becomes insufficient or the voltage temporarily
drops, the electric power steering system warning light may come on and the
warning buzzer may sound.

752 5-2. Steps to take in an emergency
SIENNA_OM_OM45483U_(U)
■If the malfunction indicator lamp comes on while driving
First check the following:
● Is the fuel tank empty?
If it is, fill the fuel tank immediately.
● Is the fuel tank cap loose?
If it is, tighten it securely.
The malfunction indicator lamp will go off after taking several driving trips.
If the malfunction indicator lamp does not go off even after several trips, con-
tact your Toyota dealer as soon as possible.
■
When the tire pressure warning light comes on
Check the tire inflation pressure and adjust to the appropriate level.
Pushing the tire pressure warning reset switch will not turn off the tire
pressure warning light.
■The tire pressure warning light may come on due to natural causes
The tire pressure warning light may come on due to natural causes such
as natural air leaks and tire inflat ion pressure changes caused by tem-
perature. In this case, adjusting the tire inflation pressure will turn off the
warning light (after a few minutes).
■When a tire is replaced with a spare tire (vehicles with compact
spare tire)
The compact spare tire is not equipped with a tire pressure warning
valve and transmitter. If a tire goes flat, the tire pressure warning light will
not turn off even though the flat tire has been replaced with the spare
tire. Replace the spare tire with the re paired tire and adjust the tire infla-
tion pressure. The tire pressure wa rning light will go off after a few min-
utes.
