Page 465 of 724
465
3-5. Using the interior lights
3
Interior features
LC200_OM_OM60L09U_(U)
■
Illuminated entry system
The lights automatically turn on/off according to “ENGINE START STOP”
switch mode, the presence of the electronic key, whether the doors are
locked/unlocked, and whether the doors are open/closed.
■ To prevent battery discharge
If the interior lights remain on when the “ENGINE START STOP” switch is
turned off, the lights will go off automatically after 20 minutes.
■ Customization
Settings (e.g. Time period before the interior lights turn off) can be changed.
(Customizable features
P. 694)
Page 466 of 724
466
LC200_OM_OM60L09U_(U)
3-6. Using the storage features
List of storage features
CAUTION
■Items that should not be left in the storage spaces
Do not leave glasses, lighters or spray cans in the storage spaces, as this
may cause the following when cabin temperature becomes high:
● Glasses may be deformed by heat or cracked if they come into contact
with other stored items.
● Lighters or spray cans may explode. If they come into contact with other
stored items, the lighter may catch fire or the spray can may release gas,
causing a fire hazard.
Card holders
Overhead console
Glove box
Bottle holdersDoor pockets
Auxiliary boxes
Console box
Cool box
Cup holders
Page 467 of 724
467
3-6. Using the
storage features
3
Interior features
LC200_OM_OM60L09U_(U)
Glove box
Open (push button)
Lock with the mechanical key
Unlock with the mechanical
key
■Glove box light
The glove box light turns on when the tail lights are on.
■ Removing the separate tray
CAUTION
■While driving
Keep the glove box closed.
Injuries may result in the event of sudden braking, sudden swerving or an
accident.
Pull out the separate tray.
Glove box
Page 468 of 724
468 3-6. Using the storage features
LC200_OM_OM60L09U_(U)
Console boxYour vehicle is equipped with either a lower console box or cool box.
For vehicles with the cool box, refer to page 475.
Upper console box Press the tab to open.
Lower console box (if equipped) Lift the lever to open.
Remove the tray.
ITY34C005
ITY34C006
STEP1
ITY34C033
STEP2
Console box
Page 469 of 724
469
3-6. Using the
storage features
3
Interior features
LC200_OM_OM60L09U_(U)
Overhead console
Press the button.
The overhead console is useful
for temporarily storing small
items.
CAUTION
■While driving
Keep the console box closed.
Injuries may result in the event of sudden braking, sudden swerving or an
accident.
CAUTION
■Items unsuitable for storing
Do not store items heavier than 0.4 lb. (0.2 kg).
Doing so may cause the overhead console to open and the items inside may
fall out, resulting in an accident.
■ While driving
Do not leave the overhead console open.
Items may fall out and cause injury.
Console box and overhead console
Page 470 of 724
470 3-6. Using the storage features
LC200_OM_OM60L09U_(U)
Cup holdersFront (type A) Press down and release the lid.
You can adjust or remove the
separator inside.
Front (if equipped with type B)Open the lower console box lid.
Rear Pull the armrest down. ( P. 491)
Press the button.
ITY34C011
STEP1
ITY34C015
STEP2
Cup holders
Page 471 of 724
471
3-6. Using the
storage features
3
Interior features
LC200_OM_OM60L09U_(U)
■Removing the holder (front cup holders type A)
CAUTION
■Items unsuitable for the cup holder
Do not place anything other than cups or aluminum cans in the cup holders.
Other items may be thrown out of the holders in the event of an accident or
sudden braking and cause injury. If possible, cover hot drinks to prevent
burns.
■ When not in use
Keep the cup holders closed.
Injuries may result in the event of sudden braking, sudden swerving or an
accident.
NOTICE
■To prevent damage to the cup holders (vehicles with a rear cup holder)
Stow the cup holders before stowing the rear armrest.
Pull up the holder.
Cup holders
Page 472 of 724
472 3-6. Using the storage features
LC200_OM_OM60L09U_(U)
Bottle holdersFront seats
Second seats
Third seats
ITY34C016
ITY34C024
Bottle holders
