P1556, P1557 BATTERY TEMPERATURE SENSOR
EC-441
< DTC/CIRCUIT DIAGNOSIS > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
*1: Except for California
*2: For California
4. Also check harness for short to ground.
Is the inspection result normal?
YES >> Perform the trouble diagnosis for power supply circuit.
NO >> Repair or replace error-detected parts.
3.CHECK BATTERY TEMPERATURE SENSOR GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect ECM harness connector.
3. Check the continuity between battery current sensor harness connector and ECM harness connector.
*1: Except for California
*2: For California
4. Also check harness for short to power.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace error-detected parts.
4.CHECK BATTERY TEMPERATURE SENSOR
Check the battery temperature sensor. Refer to EC-441, "Component Inspection"
.
Is the inspection result normal?
YES >> Check intermittent incident. Refer to GI-43, "Intermittent Incident".
NO >> Replace battery negative cable assembly.
Component InspectionINFOID:0000000009462374
1.CHECK BATTERY TEMPERATURE SENSOR
1. Turn ignition switch OFF.
2. Disconnect battery current sensor.
3. Check the resistance between battery current sensor connector terminals.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Replace battery negative cable assembly.
+ −
Continuity
Battery current sensor ECM
Connector Terminal Connector Terminal
F5 2 F13
*1
F90*261 Existed
+
−
Continuity
Battery current sensor ECM
Connector Terminal Connector Terminal
F5 3 F13
*1
F90*262 Existed
Battery current sensor
Resistance
+ −
Te r m i n a l
2 3 Continuity with the resistance value 100 Ω or more
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

EC-452
< DTC/CIRCUIT DIAGNOSIS >[QR25DE]
P1574 ASCD VEHICL
E SPEED SENSOR
P1574 ASCD VEHICLE SPEED SENSOR
DescriptionINFOID:0000000009462383
The ECM receives two vehicle speed sensor signals via CAN communication line. One is sent from combina-
tion meter, and the other is from TCM (Transmission control module). The ECM uses these signals for ASCD
control. Refer to EC-63, "AUTOMATIC SPEED CONTROL DE VICE (ASCD) : System Description"
for ASCD
functions.
DTC LogicINFOID:0000000009462384
DTC DETECTION LOGIC
NOTE:
• If DTC P1574 is displayed with DTC U1001, first pe rform the trouble diagnosis for DTC U1001. Refer
to EC-208, "DTC Logic"
.
• If DTC P1574 is displayed with DTC P0500, first pe rform the trouble diagnosis for DTC P0500. Refer
to EC-380, "DTC Logic"
•If DTC P1574 is displayed with DTC P0603, P0604, P0605, P0606, P0607, P060A, and P060B, first per-
form the trouble diagnosis fo r DTC P0603, P0604, P0605, P0606, P0607, P060A, and P060B. Refer to
EC-404, "DTC Logic"
.
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
If DTC Confirmation Procedure has been previously conducted, always perform the following procedure
before conducting the next test.
1. Turn ignition switch OFF and wait at least 10 seconds.
2. Turn ignition switch ON.
3. Turn ignition switch OFF and wait at least 10 seconds.
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE
1. Start engine.
2. Drive the vehicle at more than 40 km/h (25 MPH). CAUTION:
Always drive vehicle at a safe speed.
NOTE:
This procedure may be conducted with the drive wheel s lifted in the shop or by driving the vehicle.
If a road test is expected to be easier , it is unnecessary to lift the vehicle.
3. Check DTC.
Is DTC detected?
YES >> Proceed to EC-452, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000009462385
1.CHECK DTC WITH TCM
Check DTC with TCM. Refer to TM-43, "CONSULT Function"
.
Is DTC detected?
NO >> GO TO 2.
DTC No. CONSULT screen terms
(Trouble diagnosis content) DTC detecting condition Possible cause
P1574 ASCD VHL SPD SEN
(ASCD VHL SPD SEN) ECM detects a difference between two
vehicle speed signals is out of the speci-
fied range. • Harness or connectors
(CAN communication line is open or shorted.)
• ABS actuator and electric unit (control unit)
•TCM
•ECM
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

P1574 ASCD VEHICLE SPEED SENSOREC-453
< DTC/CIRCUIT DIAGNOSIS > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
YES >> Perform trouble shooting relevant to DTC indicated.
2.CHECK DTC WITH “ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT)”
Check DTC with ABS actuator and elec tric unit (control unit). Refer to BRC-33, "CONSULT Function (ABS)"
.
Is DTC detected?
NO >> INSPECTION END
YES >> Perform trouble shooting relevant to DTC indicated.
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

EC-454
< DTC/CIRCUIT DIAGNOSIS >[QR25DE]
P1715 INPUT SPEED SENSOR
P1715 INPUT SPEED SENSOR
DescriptionINFOID:0000000009462386
ECM receives input speed sensor signal from TCM thr
ough CAN communication line. ECM uses this signal for
engine control.
DTC LogicINFOID:0000000009462387
DTC DETECTION LOGIC
NOTE:
• If DTC P1715 is displayed with DTC UXXXX, first perform the tr ouble diagnosis for DTC UXXXX.
• If DTC P1715 is displayed with DTC P0335, first pe rform the trouble diagnosis for DTC P0335. Refer
to EC-326, "DTC Logic"
.
• If DTC P1715 is displayed with DTC P0340, first pe rform the trouble diagnosis for DTC P0340. Refer
to EC-329, "DTC Logic"
.
• If DTC P1715 is displayed with DTC P0603, P0604, P0605, P0606, P0607, P060A, and P060B, first per-
form the trouble diagnosis fo r DTC P0603, P0604, P0605, P0606, P0607, P060A, and P060B. Refer to
EC-404, "DTC Logic"
.
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
If DTC Confirmation Procedure has been previously conducted, always perform the following before conduct-
ing the next test.
1. Turn ignition switch OFF and wait at least 10 seconds.
2. Turn ignition switch ON.
3. Turn ignition switch OFF and wait at least 10 seconds.
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE
1. Start engine and drive the vehicle at more t han 50 km/h (31 MPH) for at least 5 seconds.
CAUTION:
Always drive vehicle at a safe speed.
2. Check 1st trip DTC.
Is 1st trip DTC detected?
YES >> Proceed to EC-454, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000009462388
1.CHECK DTC WITH TCM
Check DTC with TCM. Refer to TM-43, "CONSULT Function"
.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Perform trouble shooting relevant to DTC indicated.
2.REPLACE TCM
DTC No. CONSULT screen terms
(Trouble diagnosis content) DTC detecting condition Possible cause
P1715 IN PULY SPEED
(IN PULY SPEED) Input speed sensor signal is different from
the theoretical value calculated by ECM
from output speed sensor signal and en-
gine rpm signal. • Harness or connectors
(The CAN communication line is open or
shorted)
• Harness or connectors
(Input speed sensor circuit is open or
shorted)
•TCM
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM

P1715 INPUT SPEED SENSOREC-455
< DTC/CIRCUIT DIAGNOSIS > [QR25DE]
C
D E
F
G H
I
J
K L
M A
EC
NP
O
Replace TCM. Refer to
TM-183, "Removal and Installation".
>> INSPECTION END
Revision: November 20132014 Altima NAMRevision: November 20132014 Altima NAM
