2012 Peugeot 508 RXH Owner's Manual - RHD (UK, Australia)

9
223
Checks
6-speed electronic gearbox
The gearbox does not require any maintenance (no oil change).
Refer to the servicing booklet for
details of the checking interval for
this component.

Brake wear depends on the styleof driving, par ticularly in the case of vehicles used in town, over shor t
distances. It may be necessary to
have the condition of the brakes checked, even
between vehicle services.
Unless there is a leak in the circuit, a drop in
th
e brake fluid level indicates that the brakepads are worn.
Brake pads
Par ticle emission filter (Diesel)
The star t of saturation of the par ticle
filter is indicated by the temporaryillumination of this warning lamp
accompanied by a message in the
multi-function screen.
As soon as the traffic conditions permit,regenerate the filter by driving at a speed of at least 40 mph (60 km/h) untilthe warning lamp goes off. If the warning lamp stays on, this indicates a low additive level.
On a new vehicle, the first par ticle filter regeneration operations may be accompanied by a "burning" smell, which is perfectly normal.Following prolonged operation of the vehicle at very low speed or at idle,you may, in exceptional circumstances,notice the emission of water vapour at the exhaust on acceleration. This doesnot affect the behaviour of the vehicle or the environment.

The 100% electric mode is not available
during regeneration of the par ticle emissions filter.

224
Checks
disc wear, contact a PEUGEOT
dealer or a qualified workshop.
Brake disc wear














Electric parking brake

This system does not require anyroutine servicing. However, in the event of a problem, have the system checked by a PEUGEOT dealer or
a qualified workshop.
Only use products recommended by PEUGEOT or products of equivalentquality and specification. In order to optimise the operationof units as impor tant as the braking system, PEUGEOT selects and offersvery specific products. To a v o i d d a m aging the electrical units,the use of a high pressure washer in the engine compar tment is strictly prohibited .


For more information, refer to the "Electric
parking brake - Operating faults" section.

10
225
Technical data











Electric motor and battery


Range varies according to the ambient climatic conditions, the driving style and conditions, the use of vehicle systems and ageing of the battery.
Electric motor-

Te c h n o l ogy

Synchronous with permanent magnets.
Max. power: EU standard
(kW) 27
Max. power speed
(rpm)

2 500

Max. torque: EU standard (Nm)

200

Max. torque speed (rpm) 1 250

Ef ficienc
y (%)80 to 90

Hi
gh voltage batteryNi-MH(Nickel Metal Hydride)
Volt a
ge (V~)

200

Energy capacity (kWh / Ah)
1.1 / 5.5

Ran
ge (miles (km)) 1. 2 (2) (approximately)

226
Technical data
Diesel engine2.0 litre HDi 163 hp
Gearbox

Electronic gearbox(6-speed)
Model code
8URHC8/P

Cubic capacity (cc)

1 997
Bore x stroke
(mm)
85 x 88

Max power: EU standard
(kW) 120

Max power engine speed (rpm) 3 850
Max torque: EU standard
(Nm) 300

Max torque engine speed (rpm)
1 750

F
uel Diesel

Catalytic conver ter yes
Particle emission filter yes
Oil capacity (in litres)

Engine (with filter replacement) 5














Engine and gearbox

10
227
Technical data























Weights and towed loads (in kg)



The GTW and towed load values indicated are valid up to a maximum altitude of 1000 metres; the towed load mentioned must be reduced by 10 % for each additional 1000 metres of altitude.
The speed of a towing vehicle must not exceed 60 mph (10 0 km/h) (comply with the legislation in force in your country).
High ambient temperatures may result in a reduction in the performance of the vehicle to protect the engine; if the ambient temperature is above 37 °C,
limit the towed load.

*
The kerb wei
ght is equal to the unladen weight + driver (75 kg).

**

The weight of the braked trailer can be increased, within the GTW limit, if the GV W of the towing vehicle is reduced by an equal amount; warning,
towing using a lightly loaded towing vehicle may have an adverse effect on its road holding.
Diesel engine2.0 litre HDi163 hp
Gearbox
Electronic gearbox(6-speed)
Model code

8URHC8/P


-
Unladen weight 1 770



- Kerb wei
ght *1 845



- Gross vehicle wei
ght (GV W)
2 325



-
Gross train weight (GTW)
on a 12% gradient 3 125


- Braked trailer
(within GTW limit) on a 10% or 12% gradient800



- Braked trailer **
(with load transfer withthe GTW limit)

1 100



- Unbraked trailer

750



- Recommended nose weight
75

228
Technical data





Dimensions (in mm)
conditions.
This value will vary with vehicle load, the nature of the ground surface and the surroundings.
If the driver considers that the vehicle can traverse an obstacle, they assume entire responsibility for this.

10
229
Technical data























Identifi cation markings
Various visible markings for the identification and tracing of your vehicle.
A.Vehicle Identification Number (VIN) under the bonnet.
This number is engraved on the bodyworknear the damper suppor t.


The tyre pressures must be checked when the tyres are cold, at least oncea month.


Low tyre pressures increase fuelconsumption.

B.Vehicle identification Number (VIN) on
the windscreen lower crossmember. This number is indicated on a self-adhesive label which is visible through the
windscreen.
C.Manufacturer's label.The VIN is indicated on a self-destroying
label affixed to the door aper ture, on the driver's side.
D.Tyre/paint label.This label is fitted to the middle pillar, on
the driver's side. It bears the
following information:


- the tyre inflation pressures with and without
load,

- the tyre sizes,

- the brands o
f tyre recommended by themanufacturer,

- the inflation pressure of the spare wheel,

- the paint colour code.

The use of snow chains is onlyauthorised on the front wheels.
The selector must be in 4WD mode.

230Technical data
